Troubleshooting

Updating the Vector Software Using the Edge 520,
820, 1000, or 1030
Before you can update the software, you must pair your Edge
device to your Vector system.
NOTE: The left pedal receives the software update. The left
pedal sends the update to the right pedal.
1
Send your ride data to your Garmin Connect account.
Garmin Connect automatically looks for software updates
and sends them to your Edge device.
2
Bring your Edge device within range (3 m) of the sensor.
3
Rotate the crank arm a few times.
The Edge device prompts you to install any pending software
updates.
4 Follow the on-screen instructions.
Resetting the Vector Pedals
If the device stops responding, you may need to reset it by
disconnecting and reconnecting the battery cover. This does not
erase any of your data.
1 Use a 4 mm hex key to remove the battery cover
2
Replace the cover.
NOTE: Do not damage or lose the O-ring gasket.
3
Use a 4 mm hex key to tighten the battery cover.
The pedal LED flashes red once.
Performing a Static Torque Test
The static torque test is intended for advanced cyclists and
installation experts. This test is not required under normal
circumstances to achieve good results with the Vector system.
This test is available for compatible Edge devices.
Garmin recommends performing the static torque test a
minimum of three times and averaging the reported torque
values.
1
Go to www.support.garmin.com.
2
Enter your product name.
3
Enter "torque test" to view the FAQ topic.
Following repeated static torque tests, if the reported torque
value is consistently different than the expected value, you can
enter a scale factor for one or both pedals. The scale factor is
stored in the pedal and adjusts the power value that is
calculated on the pedal. The scale factor is sent to the Edge
device and stored on Edge device.
