Time Format: Sets the device to show time in a 12-hour or 24-
hour format.
Brightness: Sets the brightness level of the backlight.
Auto Standby: Adjusts the amount of time before the device
automatically goes into standby mode
page
1).
Reset: Allows you to reset user data and settings
Default Settings, page
5).
Device Information
Device Care
Do not store the device where prolonged exposure to extreme
temperatures can occur, because it can cause permanent
damage.
Avoid chemical cleaners, solvents, and insect repellents that can
damage plastic components and finishes.
Secure the weather cap tightly to prevent damage to the USB
port.
Cleaning the Device
Do not use a dry cloth to clean the lens. Use of a dry cloth may
damage the lens.
Avoid chemical cleaners and solvents that can damage plastic
components.
1
Wipe the outer casing and lens with a soft, non-scratch cloth
dampened with water or alcohol.
2
Wipe the outer casing dry, and allow the lens to air dry.
Long-Term Storage
When you do not plan to use the device for several months, you
should charge the battery to at least 50% before you store the
device. You should store the device in a cool, dry place with
temperatures around the typical household level. After storage,
you should fully recharge the device before using it.
Attaching the Carabiner Clip
1
Position the carabiner clip in the slots on the mounting spine
of the carry case.
2
Slide the carabiner clip up until it locks in place.
Specifications
Battery type
Rechargeable, built-in lithium-ion battery
Battery life
Up to 15 hr. typical use
Water rating
IEC 60529 IPX7
Operating
From -10º to 55ºC (from 14º to 131ºF)
temperature range
NOTE: The device protects itself from
overheating and shuts down automatically if the
internal temperature exceeds the operating
temperature threshold.
1
The device withstands incidental exposure to water of up to 1 m for up to 30 min.
For more information, go to www.garmin.com/waterrating.
4
(Standby Mode,
(Restoring All
NOTICE
NOTICE
1
Charging temperature
From 10º to 45ºC (from 50º to 113ºF)
range
Wireless frequency/
10.1 dBm @ 2.4 GHz
protocol
Viewing E-label Regulatory and Compliance
Information
The label for this device is provided electronically. The e-label
may provide regulatory information, such as identification
numbers provided by the FCC or regional compliance markings,
as well as applicable product and licensing information.
1
Select Settings.
2
Select About.
Troubleshooting
Ranging Accuracy
External factors may affect ranging accuracy, such as ambient
light, weather conditions, target reflectivity, and target size.
• The device can target longer ranges in lower light conditions,
such as on overcast days. Bright sunlight minimizes ranging
ability.
• Rain minimizes ranging ability.
• The device can target longer ranges when measuring the
distance to brightly colored, reflective, or shiny objects. Black
objects are less reflective, and can be targeted at shorter
ranges.
• Larger objects are easier to target than smaller objects. For
example, you should target the flag instead of the pin.
• The device can target longer ranges when the angle to the
target is closer to 90 degrees. A smaller angle to the target
limits ranging ability.
Acquiring Satellite Signals
The device may need a clear view of the sky to acquire satellite
signals. The time and date are set automatically based on the
GPS position.
1
Go outdoors to an open area.
The top of the device should be oriented toward the sky.
2
Wait while the device locates satellites.
It may take 30–60 seconds to locate satellite signals.
My device cannot find nearby golf courses
If a course update is interrupted or canceled before it completes,
your device may be missing course data. To repair missing
course data, you must update the courses again.
1
Download and install course updates from the Garmin
Express
™
application
(Product Updates, page
2
Safely disconnect your device
Cable, page
4).
3
Go outside, and start a test round of golf to verify the device
finds nearby courses.
Disconnecting the USB Cable
If your device is connected to your computer as a removable
drive or volume, you must safely disconnect your device from
your computer to avoid data loss. If your device is connected to
your Windows
computer as a portable device, it is not
®
necessary to safely disconnect the device.
1
Complete an action:
• For Windows computers, select the Safely Remove
Hardware icon in the system tray, and select your device.
• For Apple
®
computers, select the device, and select File >
Eject.
5).
(Disconnecting the USB
