Pyle PLD35MU Instruction Manual
  1. Manuals
  2. Brands
  3. Pyle Manuals
  4. Car Receiver
  5. PLD35MU
  6. Instruction manual
Pyle PLD35MU Instruction Manual

Pyle PLD35MU Instruction Manual

Disc/usb/card/radio 4 in 1 car audio system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
PDF created with FinePrint pdfFactory trial version
http://www.pdffactory.com

Instruction Manual

1
2
3
INT
RPT
BND
_
UP
CLK
SEL
EQ
DN
+
APS
MU
5
6
MODE
4
RDM
-10
+10
PWR
P/N
EQ
BAND
MU
MODE
MENU
0K
SEL
+
SETUP
Fully Compatible to These
1
2
3
4
-10
+10
Formats of Files: DVD,VCD,
5
6
7
8
9
0/10
10+
CLK
SLOW_FWD
ST
JPEG,MP4,MP3,WMA,CD.
LOC
SEARCH
APS
ZOOM
INT
RPT
RDM
AUDIO
TITLE/PBC
SUBTITLE
A-B
PROG
OSD
LOUD
STEP
DISC/USB/CARD/RADIO
4 IN 1 CAR AUDIO SYSTEM
www.pyleaudio.com
Remark: Any information subject to change without further notice
PLD35MU
ANG
DVD/VCD/CD/MP3/USB/MMC
USB
3.8 " TFT
AUX
REL

Advertisement

Table of Contents
loading

Related Manuals for Pyle PLD35MU

Summary of Contents for Pyle PLD35MU

  • Page 1: Instruction Manual

    PDF created with FinePrint pdfFactory trial version MODE SLOW_FWD ZOOM PROG Remark: Any information subject to change without further notice http://www.pdffactory.com PLD35MU Instruction Manual DVD/VCD/CD/MP3/USB/MMC 3.8 " TFT BAND MODE MENU SETUP Fully Compatible to These Formats of Files: DVD,VCD, 0/10 JPEG,MP4,MP3,WMA,CD.
  • Page 2 PRECAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightening flash with arrowhead symbol, within an equilateral triangle, i s intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 3: Table Of Contents

    7. Specification General Specification Power Supply Requirement...DC 12V Maximum Power Output...4 x 80W(measured at DC 14.4 V) Dimensions(w x h x d)...178 x 50 x 167mm DVD Deck Specification Format...DVD/VCD/JPEG/MP4/MP3/WMA/CD Video System...PAL/PAL-M/PAL-N/NTSC/AUTO Audio System...24 bit/96KHz Loading System..Auto Loading Mounting Angle...0 to +/-30 Video Specification...

  • Page 4: Before Operation

    1. Before Operation 1.1 Glossary PBC (playback control) It is a kind of signal(menu) recorded in the disc with SVCD or VCD2.0 format used for the playback control. For the discs contained PBC, It can playback interactive software with the menu displayed on monitor screen. If the disc contain still images, it can playback high definition of still image.

  • Page 5: Maintenance And Cleaning Of Discs

    5.21 The Region Code Q: Not begin to playback but to display REGION ERROR after inserting disc into disc compartment. Why ? A: Because the DVD player and disc has respective region code. If the region codes of them are not match with each other, the DVD player can not play the disc. Appendix: The region code of DVD: The Motion Picture Association of America (MPAA) divided the world into 6 regions, and named every region a code, namely region code.

  • Page 6: The Remote Control Description

    1.5 The Remote Control Description BAND MODE MENU SETUP 0/10 SLOW_FWD SEARCH ZOOM AUDIO TITLE/PBC SUBTITLE PROG LOUD STEP 16. SEARCH BUTTON 17. RDM BUTTON 18. RPT BUTTON 19. SUBTITLE BUTTON 20. TITLE/PBC BUTTON 21. ANGLE/ST BUTTON 22. ZOOM BUTTON 23.

  • Page 7: Description Of The Face Of The Front Panel

    It is for adjusting the hue of the video output. SATURATION It is for adjusting the saturation of the video output. SHARPNESS It is for adjusting the sharpness of the video output. .19.5 SPEAKER SETUP SPEAKER SETUP DOWNMIX EXIT SETUP DOWNMIX It is for selecting your desired sound effect when there is not central speaker and sub-woofer.

  • Page 8: Description Of The Rear Cabinet

    1.9 Description of the Rear Cabinet Reversal line Orange Parking Line Brown YELLOW GRAY VIDEO OUT GRAY YELLOW Note: 1. after connecting the Parking Line, the video on the small monitor of the front panel will be display only after braking the car. 2.

  • Page 9: Unit Installation

    For the DVD System Menu, there are 6 setup pages in all. They display as follows: 5 .19.1 SYSTEM SETUP SYSTEM SETUP TV SYSTEM TV TYPE PASSWORD RATING DEFAULT EXIT SETUP TV SYSTEM This product supports output of various TV system, including PAL, PAL-M, PAL-N, NTSC and AUTO.

  • Page 10: Common Operation

    2. Common Operation 1. To turn on/off the unit Under power off mode, press the POWER button to turn on the unit. Under power on mode, long press the POWER button on the front panel or briefly press the POWER button on the remote control to turn off the unit. 2.

  • Page 11: Radio Operation

    .14 Program Playback It allows you to enter the order in which you want some chapters/tracks in DVD/VCD/MP3/WMA/CD disc to play. 1 During playback, press the PROG button to enter a program interface as follows: for DVD discs for VCD/MP3/WMA/CD discs PROG PROG 1__:__ 5__:__ 9 __:__13 __:__...

  • Page 12: Basic Disc, Usb Or Mmc/Sd Operation

    4. Basic Disc, USB or MMC/SD Operation 4.1 Begin playback 1. Press the POWER button briefly to turn on the DVD player. After turning on the DVD player, please turn on the monitor, and ensure that the video output of the monitor is the video input from the DVD player connected with the monitor.

  • Page 13: Pause Playback

    5.5 Playback in Scan Mode 1. In the state of VCD(PBC OFF)/CD disc playing, press the INT button to play the previous 10 seconds part of each track on the disc. Press the INT button again to resume normal playback. 2.

  • Page 14: Terminate The Playback

    In VCD mode 1. When starting to turn on the PBC function, it will play from the beginning of the disc till it display the PBC menu on monitor screen if the disc include the PBC menu. 2. Press the number buttons to select your desired track to play. In MP3/WMA mode 1.

This manual is also suitable for:

Plus pld35mu

Table of Contents
