- Page 1 PLL Synthesizer Stereo Radio • DVD Player • Automatic Memory Storing • Fold Down Detachable Panel • Preset Equalization • Multi-subtitle Languages Function • Multi-audio Languages Function • Multi-angle Function • Parental Control • Remote Control OWNER’S MANUAL Mobile Audio/Video System PLDVD48...
- Page 2 FEATURES Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD) This player can play discs recorded in either PAL or NTSC format. • A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders.
-
Page 3: Table Of Contents
CONTENTS Safety Information ...4 Disc Notes ...5 Installation ...6 Using the Detachable Front Panel ...9 Wiring Connection ...10 Location and Function of Keys...11 The Player ...11 Remote Control...12 Remote Control...14 Preparing the Remote Control ...14 Loading/Ejecting a disc...14 Loading a disc ...14 Ejecting a disc...14 Operation ...15 Basic Operation ...15... -
Page 4: Safety Information
SAFETY INFORMATION CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE MOBILE DVD PLAYER CORRECTLY AS INSTRUCTED. -
Page 5: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc Video CD 12 cm disc 12 cm disc 12 cm disc Handling and Cleaning • Dirt, dust, scratches and warping discs will cause misoperation. • Do not place stickers or make scratches on discs. -
Page 6: Installation
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. - Page 7 INSTALLATION 6. Mount the sleeve by inserting the sleeve into the opening of the dashboard and bend open the tabs located around the sleeve with a screwdriver. Not all tabs will be able to make contact, so examine which ones will be most effective.
- Page 8 INSTALLATION DIN REAR-MOUNT (Method B) If your vehicle is a Nissan, Toyota, follow these mounting instructions. Use the screw holes marked T (Toyota), N (Nissan) located on both sides of the unit to fasten the unit to the factory radio mounting brackets supplied with your vehicle.
-
Page 9: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL To Detach the Front Panel 1. Press the OPEN button (OPEN) , then the front panel will be folded down. Open 2. Remove the front panel by pulling its middle-hand side outward. Front Panel 3. For safekeeping, store the front panel in the supplied protective case immediately after being removed. -
Page 10: Wiring Connection
WIRING CONNECTION ANTENNA CONNECTOR GREEN FRONT Lch SPEAKER REAR Lch SPEAKER MUTE WHILE TELEPHONING If your unit is connected to a mobile telephone through the telephone mute line, the car radio’s volume will be muted as soon as you “pick up” the telephone. -
Page 11: Location And Function Of Keys
LOCATION AND FUNCTION OF KEYS THE PLAYER (PWR/ILL) 4. DISP 5. IR 6. MODE/(SW) 7. OPEN 8. Vacuum Fluorescent Display 9. MUT/ENT 10. ST/LOC/TITLE 11. VOL+ 12. VOL- 13. MENU/BAND When remove the front panel: 27. Disc Slot 28. LED 8 13 14. -
Page 12: Remote Control
LOCATION AND FUNCTION OF KEYS REMOTE CONTROL... - Page 13 LOCATION AND FUNCTION OF KEYS POWER/ILL Press it to turn the unit on. When system is on, press shortly to control the brightness of VFD. Press it for several seconds to turn off the unit. 2. SMART (DISC) In DVD mode, press it shortly to enter SMART MODE function. (For details, refer to the following text).
-
Page 14: Remote Control
REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1. Open the battery compartment cover. 2. Insert the new battery. Make sure that the positive and negative terminals of the battery are oriented as indicated. 3. Close the cover. Battery: a button cell lithium battery (CR2025 3V) Using the Remote Control Point the remote control towards the... -
Page 15: Operation
OPERATION BASIC OPERATION SWITCHING ON/OFF THE UNIT AND ILLUMINATING Press PWR/ILL button on the front panel or POWER/ILL button on the remote control to turn on the unit. When system is on,press PWR/ILL or POWER/ILL button shortly to control the brightness of VFD. -
Page 16: Radio Operation
OPERATION RADIO OPERATION SWITCHING TO RADIO MODE Press MODE on the front panel or MODE on the remote control to select radio mode, the radio mode appears in the display together with the memory band and frequency. SELECTING THE FREQUENCY BAND During radio mode, shortly press MENU (BAND) button on the front panel or BND (MENU) button on the remote control to... -
Page 17: Disc (Dvd/Vcd/Cd/Mp3) Operation
OPERATION DISC (DVD/VCD/CD/MP3) OPERATION STOPPING PLAY - Briefly press the AMS/STOP button on the front panel or AMS (STOP) button on the remote control to stop the unit playback, when the pressed, normal playback will continue. - Press AMS/STOP button or AMS (STOP) button twice to stop the playback and go back to initial Track/Chapter. - Page 18 OPERATION on the remote control at the start of the required passage, then press A-B button again at the end of the passage. To revert to normal playing, press A-B button again. Each time the button is pressed, the screen will display as follows: A TO B SET A A TO B SET B TIME SEARCH (GOTO)
- Page 19 OPERATION ON-SCREEN DISPLAY FUNCTION Press the DISPLAY button during playback to display the contents of the current disc on the screen. Example: FOR DVD: (1) Press DISPLAY for the first time: TITLE 01/03 CHAPTER 002/025 00:02:25 Title Number, Total Title Number, Chapter Number, Total Chapter Number of this Title of the disc currently being played will be shown on the screen, along with...
- Page 20 OPERATION (4) Press DISPLAY for the fourth time: TOTAL REMAIN 00:40:35 TRACK: 01/14 (5) Press DISPLAY for the fifth time: The message on the screen will be cleared. FOR MP3: (1) Press DISPLAY for the first time: CHAPTER ELASPED 00:00:25 (2) Press DISPLAY for the second time:.
- Page 21 OPERATION SMART MODE FUNCTION In DVD mode, press SMART button on the DVD unit or SMART button on the remote control shortly during disc playback to activate SMART MODE function and “SMART MODE” appears on the display of the DVD unit. When press MODE button to switch to radio or AV IN mode or CDC mode, the front speakers will output the corresponding...
-
Page 22: Cdc Operation
OPERATION CDC OPERATION You can connect a CD changer to the unit with CDC operation version only. Information on handling CDs, inserting CDs and operating the CD changer can be found in the operating instructions supplied with your CD changer. SWITCHING TO CDC MODE Keep pressing MODE button on the DVD unit shortly or MODE button on the... -
Page 23: Av In Operation
OPERATION REPEATING INDIVIDUAL TRACKS OR WHOLE CDs Press RPT button on the DVD unit shortly to continuously repeat the same track. Press and hold RPT button on the DVD unit for several seconds to continuously repeat all tracks on the current disc. Press it again to stop repeat. -
Page 24: Setup
SETUP INITIAL SETUP SETUP MENU --- MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCES EXIT SETUP 1. Press SETUP on the remote control or on the DVD unit in the stop mode.(Press the stop button twice to ensure that the player is in STOP mode.) 2. - Page 25 SETUP --- GENERAL PAGE --- TV DISPLAY PIC MODE AUTO ANGLE MARK HI-RES OSD LANG N-FLICKER CAPTIONS SCR SAVER MAIN PAGE PIC mode setup Select AUTO, the player PIC mode will depend on DVD disc. Select HI-RES format for best image resolution.
-
Page 26: Speaker Setup
SETUP --- GENERAL PAGE --- TV DISPLAY PIC MODE ANGLE MARK OSD LANG CAPTIONS SCR SAVER MAIN PAGE SCR SAVER setup Select the SCR SAVER ON/OFF. SPEAKER SETUP --- SPEAKER SETUP PAGE --- DOWNMIX LT/RT STEREO MAIN PAGE This is to activate the audio output from DOLBY AC3 5.1 DOWNMIX to 2 channel mode. -
Page 27: Preferences Setup
SETUP --- AUDIO SETUP --- SPDIF OP MODE LPCM OUTPUT DYNAMIC LPCM 48K LPCM 96K MAIN PAGE LPCM OUTPUT Selecting LPCM (Line Pause Code Modulation) OUTPUT between LPCM 48K and LPCM 96K. The higher the sampling frequency is, the better the output audio quality is. It is recommended to select LPCM 96K. - Page 28 SETUP --- PREFERENCES PAGE --- TV TYPE AUDIO ENGLISH SUBTITLE FRENCH DISC MENU SPANISH PARENTAL CHINESE PASSWORD JAPANESE DEFAULTS GERMAN SMART NAV ITALIAN LOGO PORTUGUESE MAIN PAGE SUBTITLE language setup Select the preferred SUBTITLE language by using the cursor buttons. --- PREFERENCES PAGE --- TV TYPE AUDIO...
- Page 29 SETUP --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS RESET SMART NAV LOGO MAIN PAGE DEFAULTS Select reset to revert to factory initial settings. --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS NO MENU...
-
Page 30: Defaults Table
SETUP DEFAULTS TABLE General Setup TV Display PIC Mode Angle Mark OSD Language English Captions SCR Saver Speaker Setup Downmix Audio Setup SPDIF OP Mode Dynamic LPCM Output LPCM 96K Preferences TV Type Audio Subtitle DISC Menu Parental Password Smart NAV Logo Normal/LB AUTO... -
Page 31: Trouble Shooting
TROUBLE SHOOTING If it appears that your DVD unit is faulty, first consult this checklist. It may be that something simple has been overlooked. Under no circumstances should you try to repair the player yourself, as this will invalidate the warranty. Only qualified service personnel can remove the cover or service this player. -
Page 32: Specifications
Power Supply Requirements Chassis Dimensions Tone Controls - Bass (at 100 Hz) - Treble (at 10 KHz) Maximum Output Power Current Drain DVD PLAYER Signal to Noise Ratio Channel Separation Frequency Response RADIO Frequency Coverage Sensitivity (S/N = 30 dB) - Page 33 SPECIFICATIONS Supply voltage: Discs played: Note: Specifications and design are subject to modification, without notice, due to improvements in technology. CAUTION: • To avoid electric shock, this unit must not be exposed to dripping water or water splash. • Minimum distances around the apparatus for sufficient ventilation. •...
- Page 36 88-V1623-02...
