- Page 1 PLDVD140 OWNER’S MANUAL Mobile Video System • Digital Audio Out-Coaxial • Multi-subtitle Languages Function • Multi-audio Languages Function • Multi-angle Function • Parental Control • Remote Control...
-
Page 2: Use This Product Safely
FEATURES Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD) This player can play discs recorded in either PAL or NTSC format. • A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders. -
Page 3: Table Of Contents
CONTENTS Safety Information ...4 Disc Notes ...5 The Player ...6 Front View ...6 Back View ...7 Installation ...8 Electric Connection ...11 Remote Control...12 Location and Function of Keys...13 Preparing the Remote Control ...14 Loading/Ejecting a disc...14 Loading a Disc ...14 Ejecting a Disc ...14 Operation ...15 Basic Play ...15... -
Page 4: Safety Information
SAFETY INFORMATION CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE MOBILE DVD PLAYER CORRECTLY AS INSTRUCTED. -
Page 5: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc (Single-sided disc only) Video CD 12 cm disc 12 cm disc 12 cm disc Discs which cannot be played with this player • DVD-ROM • DVD-R/DVD-RAM • CDV • CD-G Handling and Cleaning •... -
Page 6: The Player
THE PLAYER FRONT VIEW POWER ( Eject ( SETUP AUDIO SOURCE Disc Slot PLAY/PAUSE( II ) STOP ( ) PREVIOUS ( 10. NEXT ( 11. VOLUME 12. VOLUME 14. ENTER 15. Indicator Light for DVD 16. Indicator Light for AV INPUT 1 17. -
Page 7: Back View
THE PLAYER BACK VIEW 23. VIDEO 2 INPUT 24. AUDIO 2 L INPUT 25. AUDIO 2 R INPUT 26. REMOTE Socket 27. DIGITAL AUDIO 28. VEDIO 1 OUTPUT 29. VEDIO 2 OUTPUT 30. 14IN SOCKET 31. SUB. WOOFER OUTPUT... -
Page 8: Installation
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. - Page 9 INSTALLATION Sleeve L Key Outer Trim Ring Front Panel R Key 6. Mount the sleeve by inserting the sleeve into the opening of the dashboard and bend open the tabs located around the sleeve with a screwdriver. Not all tabs will be able to make contact, so examine which ones will be most effective.
- Page 10 INSTALLATION DIN REAR-MOUNT (Method B) If your vehicle is a Nissan, Toyota or Suzuki, follow these mounting instructions. Use the screw holes marked T (Toyota), N (Nissan) or S (Suzuki) located on both sides of the unit to fasten the unit to the factory radio mounting brackets supplied with your vehicle.
-
Page 11: Electric Connection
ELECTRIC CONNECTION YELLOW WHITE... -
Page 12: Remote Control
REMOTE CONTROL... -
Page 13: Location And Function Of Keys
REMOTE CONTROL POWER Press POWER to turn the unit ON or OFF. EJECT Press to eject the disc. MUTE Press to mute the sound. SUBTITLE Changing of the SUBTITLE language on multi-subtitle language DVD disc. ANGLE Changing of the view angle on multi-angle DVD disc. DISPLAY Display statistical disc information during playback. -
Page 14: Preparing The Remote Control
REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1. Open the battery compartment cover. 2. Insert the new batteries. Make sure that the positive and negative terminals of the batteries are oriented indicated. 3. Close the cover Battery: Two AAA size battery. Using the Remote Control Face the remote control towards the player front face IR mark (remote control... -
Page 15: Operation
BASIC OPERATION Stopping Play - Brief press the (Stop) button to stop the unit playback, when press the (Play) button it can continuous normal playback. - Press (Stop) button twice, it will stop the playback and go back to initial Track/Chapter. -
Page 16: Basic Operation
BASIC OPERATION A-B repeat allows a passage to be repeated continuously. Press A-B button at the start of the required passage, then press A-B button again at the end of the passage. To revert to normal playing, press A-B button again. Each time the button pressed, the screen will display as follows: A TO B SET A... -
Page 17: On-Screen Display Function
BASIC OPERATION On-Screen Display Function Press the DISPLAY button during playback to display the contents of the current disc on the screen. Example: DVD: (1) Press DISPLAY for the first time: TITLE 01/03 CHAPTER 002/025 00:02:25 Title Number, Total Title Number, Chapter Number, Total Chapter Number of this Title of the disc currently being played will be shown on the screen, along with... -
Page 18: Multi-Audio Language Function
BASIC OPERATION (4) Press DISPLAY for the fourth time: TOTAL REMAIN 00:40:35 TOTAL TRACK : 14 TRACK : - 01 (5) Press DISPLAY for the fifth time: The message on the screen will be cleared. MP3 (When set to NO MENU in SMART NAV item): (1) Press DISPLAY for the first time: CHAPTER ELASPED 00:00:25... -
Page 19: Mp3 Disc Play
BASIC OPERATION MP3 Disc Play MP3 disc is playing as the format of FOLDER. For example: SMART NAVI ROOT ROOT MP3 MUSIC MP3 HEAR YOUR PLAY MODE DISC to select the item or folder, then press ENTER button. Pressing REPEAT button repeatedly can select three kinds of repeat play mode. -
Page 20: General Setup
GENERAL SETUP --- GENERAL PAGE --- TV DISPLAY NORMAL/PS PIC MODE NORMAL/LB ANGLE MARK WIDE OSD LANG CAPTIONS SCR SAVER MAIN PAGE TV Screen Video Material Normal Pan Scan 16:9 TV display setup This is to select the appropriate TV aspect (4:3 or 16:9) according to the connected TV set. -
Page 21: Speaker Setup
SETUP --- GENERAL PAGE --- TV DISPLAY PIC MODE ANGLE MARK OSD LANG ENGLISH CAPTIONS SCR SAVER MAIN PAGE OSD LANG type setup Select the preferred OSD language by using the buttons. --- GENERAL PAGE --- TV DISPLAY PIC MODE ANGLE MARK OSD LANG CAPTIONS... - Page 22 SETUP --- SPEAKER SETUP PAGE --- DOWNMIX CENTER REAR SUBWOOFER CNTR DELAY REAR DELAY TEST TONE MAIN PAGE CENTER This is to activate the center speaker audio output ON or OFF. When set it to OFF, the CNTR DELAY item turns grey and can’t be used.
-
Page 23: Audio Setup
SETUP --- SPEAKER SETUP PAGE --- DOWNMIX CENTER REAR SUBWOOFER CNTR DELAY REAR DELAY TEST TONE MAIN PAGE REAR DELAY Select REAR DELAY and adjust the delay time for rear speaker audio output from 0 to 15MS. --- SPEAKER SETUP PAGE --- DOWNMIX CENTER REAR... -
Page 24: Preferences Setup
SETUP --- AUDIO SETUP --- AUDIO OUT OP MODE DYNAMIC LPCM OUTPUT MAIN PAGE Dynamic Range Control Select DYNAMIC and adjust the dynamic range of a Dobly Digital encoded program. There are 8 steps between full compression and off compression. --- AUDIO SETUP --- AUDIO OUT OP MODE... - Page 25 SETUP --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE ENGLISH DISC MENU FRENCH PARENTAL SPANISH PASSWORD CHINESE DEFAULTS JAPANESE SMART NAV MAIN PAGE SUBTITLE language setup Select the preferred SUBTITLE language by using the cursor buttons. --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE...
-
Page 26: Defaults Table
SETUP --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS RESET SMART NAV MAIN PAGE DEFAULTS Select reset to become factory initial setting. --- PREFERENCES PAGE --- TV TYPE AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS NO MENU SMART NAV WITH MENU... -
Page 27: Specifications
SPECIFICATIONS Supply Voltage Current Consumption Signal System Discs Played Audio Output Level Audio Signal Output Characteristics Note: Specifications and design are subject to modification, without notice, due to improvements in technology. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. - Page 28 www.pyleaudio.com 88-V2012-04...
