High speed Screen Printer SP28P
Operating Instructions
KXF-1F4C
Model No.
Installation Manual
Thank you for purchasing SP28P, the high speed screen printer.
Before placing the machine in service, be sure to read the instruction manual for
proper usage.
After that, store it carefully and it if necessary.
1F4C-E-IMAB-0007
Advertisement
Table of Contents
Related Manuals for Panasonic SP28P
Summary of Contents for Panasonic SP28P
-
Page 1: Operating Instructions
KXF-1F4C Model No. Installation Manual Thank you for purchasing SP28P, the high speed screen printer. Before placing the machine in service, be sure to read the instruction manual for proper usage. After that, store it carefully and it if necessary. - Page 3 This machine shall be operated by professional, specially trained operators. It shall not be operated by non-professional, not specially trained operators. Regarding the training course, please contact Panasonic Factory Solutions Co., Ltd. or PFSE.” WARNING DO NOT ALLOW ANY PERSON WHO HAS NOT RECEIVED SPECIAL TRAINING TO OPERATE THE MACHINE.
-
Page 4: Specifications
SPECIFICATIONS : . x c i l c i l . y l c i l c t i t i s e l l t l u x i f ± ± 1 ° t i s y t i y t i y t i y t i... -
Page 5: Maintenance Manual
ORGANIZATION OF MANUALS 4 manuals are attached to this machine. They are classified into 4 types. Use each manual according to the working purpose and person in charge. The production data of the line including this machine are programmed on PT. Refer to the instruction manuals accompanied with PT. - Page 6 = MEMO = 1F4C-E-IMA00-B01-00 Page 4...
- Page 7 Installation Manua Installation Manua O N S C A U T I Y P R E S A F E T L A T I O N I N S T A L 1F4C-E-IMA00-A02-03 Page 5...
-
Page 8: Table Of Contents
SAFETY PRECAUTIONS ..............INSTALLATION Chapter Preparations for Installation ................ 1-2 1-1-1 Selection of Location ................... 1-2 1-1-2 Power Source and Air Source ................1-3 1-1-3 Foundation ......................1-5 1-1-4 Transfer ....................... 1-5 1-1-5 Arrangement Diagram ..................1-5 1-1-6 Setting the Line Connection Cable and the Relay Board ........1-6 Installing Procedure .................. - Page 9 SAFETY PRECAUTIONS Be sure to observe The precautions that must be observed in order to prevent injury to the user or another person, or damage to property, are as follows. The degrees of danger or injury resulting from incorrect usage owing to the failure to read an indication, are described as follows.
-
Page 10: Safety Precautions
SAFETY PRECAUTIONS Be sure to observe WARNING DO NOT DAMAGE POWER AND PERIODICALLY REMOVE DUST OTHER CORDS OR PLUGS. FROM POWER PLUG. Never damage, remake, bring close to heating appliances, bend forcibly, twist, pull, put heavy objects on, and bundle up. Damaged cord and plug may cause electric shock, Dust on the plug may result in fire caused by short circuit or fire. - Page 11 SERIAL PLATE The serial plate attached to this machine indicates the model name and produc- tion number. SP28P-DHU SP28P-DHU KXF-1F4C 1D4C-809E Actual numbers are shown on the plate instead of ∗ Temperature Control Unit MPA-15AU (Option) MPA-15AU KXF-11TC 1E4C-003E Actual numbers are shown on the plate instead of ∗.
- Page 12 = MEMO = Page 10 1F4C-E-IMA00-A03-01...
- Page 13 Chapter INSTALLATION For the installation This manual for the installation of this equipment. The installation should be conducted with the procedure of this manual. Machine setting for displacement of line should be conducted in the reverse order of “1-2.” Preparations for Installation The condition of installation and the setting procedure are described.
-
Page 14: Preparations For Installation
Preparations for Installation 1-1-1 Selection of Location 1. The machine should be placed on horizontal place. 2. The conditions are as follows. (Under no moisture condensation) : 10 °C to 35 °C • Temperature • Temperature difference : Less than 1 °C per minute •... -
Page 15: Power Source And Air Source
Preparations for Installation 1-1-2 Power Source and Air Source WARNING POWER AND AIR SOURCES SHOULD BE CONNECTED AT THE LAST OF INSTALLING OPERATION. If they are connected earlier, you may get an electric shock or injured. M 92E A) Power source 1. - Page 16 Preparations for Installation C) Air source 1. Supply the compressive air to the A part shown on the figure. 2. After it, set the air pressure to 0.5 MPa by the regulator. 3. Supply the air cleaned by the air dryer. •...
-
Page 17: Foundation
Preparations for Installation 1-1-3 Foundation As the foundation for installation, flat concrete floor is required. Confirm that the endurance of the base is enough. • Endurance of base : more than 4900 N/m 1-1-4 Transfer A) Use the forklift for loading or unloading the machine to the truck. -
Page 18: Setting The Line Connection Cable And The Relay Board
Preparations for Installation 1-1-6 Setting the Line Connection Cable and the Relay Board A) Line connection cable The line signal cables are required for the machine of line specifications. Connect the line cable. (Refer to the page 1-7.) B) Setting the relay board 1) Single CN00 1-2 short (Line air pressure) 2) Line connection... - Page 19 Preparations for Installation Construction of hardware Arrangement and names of connector pins CN00 CN01 Line air pressure Line air pressure Line output 1 + 12 V F-OK contact point Line output Production-end Production-end Line start Line start R-READY F-OK Signal interface Common Vss=12 V or 24 V +12 V...
- Page 20 Preparations for Installation 1F4C-811E 1F4C-E-IMA01-A01-01 Page 1-8...
- Page 21 Preparations for Installation C) Instructions for connecting PT Ethernet cables SP28 is not equipped with HUB. Following the steps below, connect PT Ethernet cables. 1) Stand-alone . Connect the cable indicating CROSS, to CN1 of CPU board: SCMYEX. . Connect a PT Ethernet cable to CNRI located at the right end of the machine.
-
Page 22: Installing Procedure
Installing Procedure NOTICE Machine installation should be conducted by experts. The outline of its procedure is described here. As for replacing the machine, inform our service department. 1) Transfering conditions of machine The board lifter, recognition unit and the squeegee head are fixed so that they do not move during the transfer with fixing metal fittings. - Page 23 Installing Procedure 2) Placing the machine Place the machine along the reference line. Adjust the machine position for the smooth and the height of transfer to the reference machine.) 3) Surrounding equipment Install the warning indicator, blower, and atmosphere temperature controller according to section 1-3.
- Page 24 Installing Procedure 5) Removing the fixing metal fittings After leveling, remove the fixing metal fittings on the board lifter, recognition unit and squeegee head. ∗ Be careful of interference between the connecting rod and the lift unit. WARNING POWER AND AIR SOURCES SHOULD BE CONNECTED AT THE LAST OF INSTALLING OPERATION.
-
Page 25: Installing Procedure Of Surrounding Equipment
Installing Procedure of Surrounding Equipment WARNING BEFORE INSTALLATION OF ATTACHED EQUIPMENT, MAKE SURE THAT POWER AND AIR SOURCES ARE NOT CONNECTED WITH THE BODY OF MACHINE. If they are connected, you may get an electric shock or injured. M 93E 1-3-1 Installing the Warning Indicator 1) Install the warning indicator to the main body of the machine. -
Page 26: Installing The Blower
Installing Procedure of Surrounding Equipment 1-3-2 Installing the blower 1) Connect the terminal to the connector terminal block (TB4) for power box 1. ∗ Be careful not to mistake the terminal number for connecting the terminal. Terminal block (TB4) Red (L1) Green (E) 1F4C-AA00 White (L2) -
