Summary of Contents for ESI ES1247B16A
- Page 1 ES1247B16A 16 Amp 1 Channel Multi Purpose Programmer User Instructions...
- Page 2 Thank you for choosing ESi Controls. All our products are tested in the UK so we are confident this product will reach you in perfect condition and give you many years of service. However, for additional peace of mind, we recommend you register your product online at www.esicontrols.co.uk/warranty for your...
-
Page 3: Table Of Contents
Contents Introduction to the 1 Channel Programmer Quick Operating Guide Programming the Unit The Factory-set Programme Setting the Programmer Option (5/2, 7 Day, 24hr) 12 Setting the Central Heating/Hot Water Programme Setting the Operation (ON/OFF/AUTO/ALL DAY) Operating the Unit Temporary Overrides The Advance Function The +HR Boost Function Holiday Mode... -
Page 5: Introduction To The 1 Channel Programmer
Introduction to the 1 Channel Programmer As with all ESI’s range of programmers, the ES124716A 16 Amp 1 Channel Time switch, is featured packed, offering flexibility and reliability making it ideal for use with immersion heaters and electric boilers. It has been designed with the homeowner and simplicity in... - Page 6 affect your set programme temporarily. All buttons which can permanently change your programme are located behind the flip over facia. Although the ES124716A comes factory set as a standard 1 channel programmer, there also are a number of Installer set options and if one of these options has been chosen during installation then the programmer becomes a multifunctional Power Saver.
- Page 7 Program 3: Program 3 allows the installer to set the On and Off times and all other functions including the boost, will be disabled. N.B: If the reset is pushed at any time, the programmer will default to Program 1, which is boost only. If this happens, then the installer code will be needed to unlock the other features.
-
Page 8: Quick Operating Guide
Quick operating guide Home (takes you back to home screen) Next (moves you to the next option within a function) Advance to the next programmed ON/OFF (ADV) Add up to 3 hours of extra Central Heating/Hot Water (+HR) Set Time and Date Set Programmer Option (24hr, 5/2, 7 Day) &... - Page 9 Day of the week Time Display AM/PM Date Display Displays which ON/OFF period (1/2/3) is being set when programming Central Heating/Hot Water Displays whether setting the ON time or OFF time when programming Central Heating/Hot Water (ON/OFF) Advanced temporary override is active (ADV) Operating Mode (ON/OFF/AUTO/ALL DAY) Flame symbol shows that system is calling for heat + 1hr / 2hr / 3hr temporary override is active...
-
Page 11: Programming The Unit
Programming the unit (Only when in program 0) The Factory Pre-Set Programme This Channel Programmer has been designed to be simple to use, requiring minimal user intervention with a pre- programmed heating profile. The pre-set heating times and temperatures will suit most people (see table below). -
Page 12: Setting The Programmer Option (5/2, 7 Day, 24Hr)
Setting the Programmer Option (5/2, 7 day, 24hr) 1. Switch the slider to HEATING. Press either the +/– button to move between 7 day, 5/2 day or 24hr operation. 5/2 Day operation is shown by MO, TU, WE, TH, FR flashing (5 Day) and then SA, SU flashing (2 Day) 7 Day operation is shown by just one day flashing at a time... -
Page 13: Setting The Operation (On/Off/Auto/All Day)
Setting the Operation 1. Switch the slider to PROG. Press either the +/– button to move between ON/OFF/AUTO/ALL DAY. ON: Central Heating/Hot Water is ON continuously AUTO: Central Heating/Hot Water will be switched ON and OFF in accordance with set programmes ALL DAY: Central Heating/Hot Water will switch ON at the first ON and switch OFF at last OFF OFF: Central Heating/Hot Water will be permanently OFF... -
Page 14: Operating The Unit
Operating the unit Temporary Manual Overrides The Advance Function The ADVANCE function allows the user to move to the next ON/OFF programme for a “one off” event, without having to change the programme or use the ON or OFF buttons. N.B: The ADVANCE function is only available when the programme is in AUTO or ALL DAY operating modes and the slider must be switched to RUN. -
Page 15: The +Hr Boost Function
To +HR Boost Central Heating/Hot Water 1. Press the +HR button. 2. One press of the button will give one extra hour of Central Heating/Hot Water; two presses of the button will give two extra hours; three presses of the button will give the maximum three extra hours. -
Page 16: Basic Settings
Basic settings Setting the Time and Date The time and date are factory set and changes between summer and winter time are handled automatically by the unit. 1. Switch the slider to TIME/DATE. 2. The hour symbols will flash, use the +/- buttons to adjust. 3. -
Page 17: Resetting The Unit
Press + or – to turn backlight ON or OFF. Press the Next button or wait for 15 seconds to automatically confirm and return to Run Mode. N.B: Do not use Advance or +HR Boost Button to activate the backlight as it may engage the Advance or +HR facility Home button. - Page 19 We are continuously developing our products to bring you the very latest in energy saving technology and simplicity. However, should you have any questions setting up your controls please email us at sales@esicontrols.co.uk or for technical queries call us on our dedicated technical helpline 07539 117468. WARNING: Interference with sealed parts renders the guarantee void.
- Page 20 Version 6.10.2 © ESi Controls Limited 2017...
