Quadra-Fire QVI-30FB-S Owner's Manual page 2

Read this manual before installing or operating this appliance.
Congratulations on selecting a Quadra-Fire gas appliance
—an elegant and clean alternative to wood burning
appliances. The Quadra-Fire gas appliance you have
selected is designed to provide the utmost in safety,
reliability, and effi ciency.
As the owner of a new appliance, you'll want to read and
carefully follow all of the instructions contained in this
Owner's Manual. Pay special attention to all Cautions and
Warnings.
Homeowner Reference Information
Model Name: ___________________________________________ Date purchased/installed: __________________
Serial Number: __________________________________________ Location on appliance: ____________________
Dealership purchased from: _______________________________ Dealer Phone: __________________________
Notes: _______________________________________________________________________________________
_____________________________________________________________________________________________
Listing Label Information/Location
Type of Gas
Gas and Electric
Information
2
Please retain this owner's manual for future reference.
Congratulations
The model information regarding your specifi c appliance can be found on
the rating plate usually located in the control area of the appliance.
