- Page 1 PLD193T OWNER'S MANUAL Mobile Video System Anti Theft Flip Down Detachable Panel AM/FM Digital Pll Tuning Radio Car DVD/VCD/CD/MP3 Player/TV Tuner Auxiliary Input Function Parental Control Remote Control www.pyleaudio.com...
-
Page 2: Table Of Contents
CONTENTS Safety Information... Disc Notes ... Installation ... Electric Connection ... Remote Control ... Basic Operation ... MP3/WMA/JPEG Disc Play ... AUX Operation ... On-Screen Display Function ... Multi-Audio Language Function ... Multi-Subtitle Language Function ... Multi-Angle Function ... Title Menu Function ... Operation ... -
Page 3: Safety Information
SAFETY INFORMATION CAUTION: THIS DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE . HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE DVD PLAYER CORRECTLY AS INSTRUCTED. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT... -
Page 4: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc V I D E O (Single-sided disc only) Video CD 12 cm disc 12 cm disc 12 cm disc CD-RW Discs which cannot be played with this player DVD-ROM DVD-R/DVD-RAM CD-G Handling and Cleaning... -
Page 5: Installation
INSTALLATION NOTES: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. Use only the parts included with the unit to ensure proper installation. - Page 6 INSTALLATION HEX NUT SPRING WASHER PLAIN WASHER TAPPING SCREW KEY PLATE 1.WHILE INSTALLING THE FRONT PANEL, PLEASE MOUNT THE LEFT SIDE FIRST, AND MAKE THE DIRECTION HOLE ON THE FRONT PANEL AIM AT THE LEFT GUIDE ON THE UNIT 2.THAN PUSH THE RIGHT SIDE TO 3.PUSH IT TO INSTALL THE FRONT PANEL COMPLETELY .
- Page 7 INSTALLATION CAUTION: DO NOT INSTALL THE DETACHABLE PANEL BEFORE CONNECTING THE WIRE. 1. The unit is designed for negative terminal of the battery which is connected to the vehicle metal. Please confirm it before installation. 2. If the car interior is extremely hot, as after being parked in the sun, do not use the player until the car has been driven for a while to cool off the interior.
-
Page 8: Electric Connection
ELECTRIC CONNECTION WIRING CONNECTION TV ANT IN ANTENNA CONNECTOR IGNITION SWITCH(B+) CHOKE MEMORY YELLOW BACK-UP(B+) BLACK GROUND(B-) FUSE AUTO BLUE ANTENNA FRONT Lch SPK. REAR Lch SPK. MAIN UNIT REAR RCA OUTPUT CABLE (optional) FRONT RCA OUTPUT CABLE (FOR RCA LINE OUT VERSION ONLY) GREY WHITE WHITE/BLACK... -
Page 9: Remote Control
REMOTE CONTROL Press it to change the display to clock display. 1. CLK Press it button on the select TV ,DISC,RADIO AUX IN mode. 2. MODE Press it to stop playback. 3. STOP Display the SETUP menu. 4. SETUP In radio mode,press it to select STEREO or MONO (IN disc mode, 5. -
Page 10: Preparing The Remote Control
REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1.First push to inside as the direction indicated by the arrow (See Remove the battery holder as the direction indicated by the arrow (See 2.Replace the battery Set a new battery property with (+)side up as illustrated (See 3.Insert the battery holder. -
Page 11: Basic Operation
BASIC OPERATION 1.OPEN BUTTON Press it to flip down the front panel then you can insert the cd disc into the cd compartment. and you can find the EJ button , press it to eject the disc . 2-3.VOL+/VOL- & SEL BUTTON Press it repeatedly to change audio mode through volume, bass, treble, balance, and fader modes. - Page 12 BASIC OPERATION 4.BAND BUTTON In RADIO mode, press the BAND button on the front panel or on the remote control to select your desired radio band and word which band is selected will be displayed on LCD. Press it to change the bands as below : For 3 Bands (Europe) 5.EQ BUTTON Press it to turn to equalization function and to select desired audio mode.
- Page 13 BASIC OPERATION 1). You can use the and then press the ENTER button to confirm . In Track Digest OR Disc/Track Interval MODE. You can use the ENTER to confirm . You can also select the items using the corresponding number buttons, and then press the ENTER to confirm .
- Page 14 BASIC OPERATION 15.PWR BUTTON Press it to turn on the unit. Press it again to turn off. BUTTON Pressing during playback will stop play temporary. Return to normal playback, press once again. BUTTONS A.When long Pressing the speed of rapid forward/reverse changes according to the disc as follow. DVD/VCD/CD/MP3: B.Shortly press the one track.(Note: In DVD mode, press continually the...
-
Page 15: Mp3/Wma/Jpeg Disc Play
BASIC OPERATION MP3/WMA/JPEG DISC PLAY 1.When inserting an MP3/WMA/JPEG disc Ex: When Mp3 file is detected. 00:56 04:07 Repeat one 003/112 woman 1 new ton ..In stop mode , use then press ENTER button to confirm. Pressing REPEAT button repeatedly can select two kinds of repeat play mode. 2. -
Page 16: On-Screen Display Function
BASIC OPERATION ON-SCREEN DISPLAY FUNCTION Press the button during playback to display the contents of the current disc on the screen. Example : 1. DVD: A.Press for the first time: TITLE ELAPSED TT 01/01 CH 01/38 Title Number, Total Title Number, Chapter Number, Total Chapter Number of this Title of the disc currently being played will be shown on the screen,... -
Page 17: Multi-Audio Language Function
BASIC OPERATION Multi-audio Language Function For DVD: Press AUDIO during playback. Each time the button is pressed, number of the audio soundtrack language changes on sequential order. NOTES: - The language number is different according to the disc. - Some disc only contain one language soundtrack - When no different language soundtrack are recorded... -
Page 18: Setup
SETUP GENERAL SETUP --- GENERAL PAGE --- -----General setup page---- TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Last Memory Go To General Setup Page 1. Press SETUP button on the remote control . 2.The SETUP menu is displayed. 3.Select the preferred item by using the buttons 4.Press ENTER button. - Page 19 SETUP -----General setup page---- TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Last Memory Set Angle Mark ANGLE MARK DISPLAY SETUP If it is set to ON, when the multi-angle DVD disc is playing, mark) will appears on the screen; if is set to OFF, the mark will not appear.
-
Page 20: Speaker Setup
SETUP -----General setup page---- TV Display Angle Mark OSDLang Spdif Output Captions Screen Saver Last Memory Screen Saver 6.SCR SAVER SETUP Select the SCR SAVER output ON/OFF. -----General setup page---- TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Last Memory Set Last Memory State 7.LAST MEMORY SETUP... -
Page 21: Preferences Setup
SETUP PREFERENCES SETUP --- PREFERENCES PAGE --- -----Preference Page---- TV Type Audio Subtitle Disc Menu Parental Password Default Set TV standard 1.TV TYPE SETUP This player can play discs recorded in either PAL or NTSC format.Select NTSC format, when you connected to NTSC TV.Select PAL format, when you connected to PAL TV.Select AUTO format, the player TV output format... -
Page 22: Defaults Table
SETUP -----Preference Page---- TV Type Audio Subtitle Disc Menu Parental Password Default Set Parental Control 5.PARENTAL Select suitable parental guidance by the cursor buttons and conformed by pressing ENTER button. -----Preference Page---- TV Type Audio Subtitle Disc Menu Parental Password Default Change Password 6.PASSWORD... -
Page 23: Specifications
SPECIFICATION GENERAL Supply Voltage Current Consumption SIGNAL SYSTEM DISCS PLAYED AUDIO SIGNAL OUTPUT CHARACTERISTICS RADIO FM TUNER SECTION Tuning Range IF Range Usable sensitivity(30dB) AM TUNER SECTION Frequency Range IF Range Usable sensitivity(30dB) TV TUNER TV System TV Sensitivity NOTE: Specifications and design are subject to modification, without notice, due to improvements in technology. -
Page 24: Trouble Shooting
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. SYMPTOM The car ignition switch is NO POWER not on The fuse is blown Presence of disc inside the player.
