IPv6 multicast VLAN configuration task list

Tasks at a glance
(Required.) Perform one of the following tasks:
•

Configuring a sub-VLAN-based IPv6 multicast VLAN

•
Configuring a port-based IPv6 multicast VLAN
Configuring user port attributes
Assigning user ports to an IPv6 multicast VLAN
(Optional.)
If you have configured both a sub-VLAN-based IPv6 multicast VLAN and a port-based IPv6 multicast
VLAN on a device, the port-based IPv6 multicast VLAN configuration takes effect.
Configuring a sub-VLAN-based IPv6 multicast
VLAN
You must first configure a VLAN as an IPv6 multicast VLAN, and then assign the VLANs that contain
multicast receivers to the IPv6 multicast VLAN as sub-VLANs.

Configuration prerequisites

Before you configure a sub-VLAN-based IPv6 multicast VLAN, complete the following tasks:
Create VLANs as required.
•
• Enable MLD snooping for the VLAN to be configured as the IPv6 multicast VLAN, and for the
VLANs to be configured as sub-VLANs.

Configuration guidelines

When you configure a sub-VLAN-based IPv6 multicast VLAN, follow these guidelines:
The VLAN to be configured as the IPv6 multicast VLAN must exist.
•
A VLAN to be configured as a sub-VLAN must exist and must not be an IPv6 multicast VLAN or a
•
sub-VLAN of any other IPv6 multicast VLANs.
The total number of IPv6 multicast VLANs on a device must not exceed the upper limit.
•

Configuration procedure

To configure a sub-VLAN-based IPv6 multicast VLAN:
Step
1. Enter system view.
Setting the maximum number of IPv6 multicast VLAN forwarding entries
Command
system-view
95
Remarks
N/A
