Instruction Manual Supplement
D103988X012
Configuring the FIELDVUE
Throttling Control Using ValveLink
WARNING
This instruction manual supplement is not intended to be used as a stand-alone document. It must be used in conjunction
with the following documents:
• Safety manual for DVC6200 SIS Digital Valve Controller (D103601X012), sections pertaining to the Position Monitor
• Fisher FIELDVUE DVC6200 SIS Instruction Manual (D103557X012)
Failure to use this instruction manual supplement in conjunction with the above referenced manuals could result in
personal injury or property damage. If you have any questions regarding these instructions or need assistance in obtaining
either of these documents, contact your
This instruction manual supplement is intended to assist in the use of the DVC6200 SIS as a SIL capable position
monitor AND as a non-SIL capable throttling digital valve controller.
WARNING
The DVC6200 SIS failure rates for the digital valve controller safety function, as listed in the FMEDA and SIL certificate, are
not valid in this configuration (with 420 mA operation).
www.Fisher.com
™
Emerson sales office
or Local Business Partner.
DVC6200 SIS for
™
Software
DVC6200 SIS
October 2017
