Features
Front Panel
23
23
22
22
1
2
3
1.
Master Volume: A d j u s t t h i s k n o b t o control the level for the master volume going
to the Line Output.
1
2.
Wireless Mic Volume 1: Adjust this knob to control the level for the wireless mic receiver
1.
3.
Wireless Mic Volume 2: Adjust this knob to control the level for the wireless mic receiver
2
2.
4.
USB/SD/BT Volume: Adjust this knob to control the level for the USB, SD, and
Bluetooth sources.
5.
Mic/Line 1 Volume: Adjust this knob to control the mic/line input level.
6.
Mic/Line 2 Volume: Adjust this knob to control the mic/line input level.
7.
Random: Press this button to have USB or SD card tracks play in a random order.
8.
Repeat: Press this button to repeat a track from a USB or SD card source.
9.
Stop: Press this button to stop audio track playback from a Bluetooth, USB, or SD card
source.
10. LCD Display: This shows the battery level, charging status, Bluetooth connection, input
sources, and track playback information.
11. Back: Press this button to exit out of a folder or menu.
12. Browse: Press in this knob and scroll to select to use W. Mic 1 or W. Mic 2 (if you want
to use the beltpack transmitter and headset microphone). Also, use this knob to select a
track or folder when playing SD card or USB sources.
13. Mode: Press to cycle through USB, SD, and Bluetooth source modes.
14. Bluetooth Disconnect: Press this button to disconnect from a paired Bluetooth device.
4
AUDIO
4
7
8
5
9
6
11 12
11
3
4
8
15
15
16
16
10
10
17
17
13
13
14
14
12
1
5
6
23
23
18
18
19
19
20
20
7
9
10
21
21
