Copyright Notice
This document is copyrighted, 1997. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
Acknowledgements
AMD is a trademark of Advanced Micro Devices, Inc.
Award is a trademark of Award Software International, Inc.
C&T is a trademark of Chips and Technologies, Inc.
Cyrix is a trademark of Cyrix Corporation.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows
®
is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
SiS is a trademark of Silicon Integration Systems Corporation
SMC is a trademark of Standard Microsystems Corporation.
UMC is a trademark of United Microelectronics Corporation.
VIA is a trademark of VIA Technology, Inc.
All other product names or trademarks are properties of their
respective owners.
Part No. 2006586200 1st Edition
Printed in Taiwan
May 1997

Advertisement

Table of Contents
loading

Related Manuals for AMD PCM-5862

Summary of Contents for AMD PCM-5862

  • Page 1 Acknowledgements AMD is a trademark of Advanced Micro Devices, Inc. Award is a trademark of Award Software International, Inc. C&T is a trademark of Chips and Technologies, Inc.
  • Page 2 Packing list Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PCM-5862 All-in-One Single Board Computer • 1 utility disk with system BIOS, VGA BIOS, and utility programs • 1 Ethernet driver disk •...

  • Page 3: Table Of Contents

    Contents Chapter 1 General Information ........1 Introduction................. 2 Highly integrated multi-media SBC........2 Features ................3 Specifications............... 3 Board layout and dimensions..........5 Chapter 2 Installation ..........7 Jumpers ................8 Connectors................9 Locating jumpers ..............9 Locating connectors ............10 Setting jumpers ..............
  • Page 4 Fan power supply connector (CN6) ........21 IR connector (CN12) (U23 Super I/O chipset ITE 8661 only) ..............22 Audio interfaces (CN8, CN13) .......... 22 Audio connector (CN13) ............. 22 CD audio input connector (CN8) ......... 22 Audio power source setting (J16)......... 23 COM-port connector (CN16) ..........
  • Page 5 System test and initialization ..........42 System configuration verification ........42 AWARD BIOS setup............43 Entering setup ..............43 Standard CMOS setup............44 BIOS features setup............. 45 CHIPSET features setup............46 Power management setup ............ 47 PnP/PCI configuration............48 Integrated peripherals ............49 Load BIOS defaults.............
  • Page 6 Keyboard and mouse connector (CN15) ......85 COM port connector (CN16)..........86 IDE hard drive connector (CN17)........87 Floppy drive connector (CN18) ........... 88 Parallel port connector (CN19) ..........89 Appendix D Optional Extras.......... 91 PCM-10586-2 cable kit for PCM-5862........ 92...

  • Page 7: Chapter 1 General Information

    General Information This chapter gives background information on the PCM-5862. Sections include: • Introduction • Features • Specifications • Board layout and dimensions...

  • Page 8: Introduction

    EMI. Highly integrated multi-media SBC The PCM-5862 is a highly integrated multi-media SBC that combines audio, video, and network functions on a single computer board the size of a 5.25“ floppy drive. It provides 16-bit full-duplex, integrated 3D audio and up to Hi-color display capability at 1024 x 768 resolution (with 2MB display memory).

  • Page 9: Features

    Features • Accepts Intel MMX Pentium, AMD K5, and Cyrix 6x86 processors up to 200MHz • 32-bit PCI-bus SVGA/LCD controller supports LCD & CRT display • 10Base-T Ethernet interface, Novell NE-2000 compatible • 16-bit audio interface, Sound Blaster Pro compatible •...
  • Page 10 PCI Bus Ethernet Interface: • Chipset: REALTEK RTL8029 PCI local bus Ethernet controller • Ethernet Interface: Novell NE2000 compatible 10BaseT interface. Includes software drivers & boot ROM Mechanical and environmental • Max. power requirements: 7A @ 5V (4.75V to 5.25V) PCM-5862 User‘s Manual...

  • Page 11: Board Layout And Dimensions

    • Size: 203 mm (L) x 146 mm (W) (8“ x 5.75”) • Weight: 0.32 kg (0.7 lbs.) Board layout and dimensions 135.89 146.05 40.64 5.08 119.38 193.04 5.08 198.12 203.20 Dimensions in mm PCM-5862 dimensions Chapter 1 General Information...
  • Page 12 PCM-5862 User‘s Manual...

  • Page 13: Chapter 2 Installation

    Installation This chapter tells how to set up the PCM-5862 hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedure.

  • Page 14: Jumpers

    Jumpers The PCM-5862 has a number of jumpers that allow you to configure your system to suit your applications. The table below lists the function of each of the board's jumpers. Jumpers Label Function System/PCI clock setting System/PCI clock setting...

  • Page 15: Connectors

    Connectors On-board connectors link the PCM-5862 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the board's connectors. Connectors Label Function CRT display connector Flat panel display connector...

  • Page 16: Locating Jumpers

    Locating jumpers PCM-5862 User‘s Manual...

  • Page 17: Locating Connectors

    Locating connectors Chapter 2 Installation 11...

  • Page 18: Setting Jumpers

    If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. Generally, you simply need a standard cable to make most connections. PCM-5862 User‘s Manual...

  • Page 19: Cpu Installing And Upgrading

    Install a CPU in the ZIF socket PCM-5862 provides a Zero Insertion Force (ZIF) socket for easy CPU installation. 1. Make sure the ZIF socket lever is in the upright position. To raise the lever, pull it out to the side a little and raise it as far as it will go.

  • Page 20: System Clock Setting (J1, J2, And J4)

    CPU clock ratio setting jumper. Refer to the CPU Speed Reference Table (below) for instructions on adjusting the internal clocks according to the base CPU speed. CPU Speed Reference Table CPU Speed (MHz) *133 Clock setting Frequency ratio * default setting PCM-5862 User‘s Manual...

  • Page 21: Cpu Voltage Setting (J3)

    System/PCI clock setting System 50MHz 50MHz 60MHz *66MHz 75MHz 25MHz 33.3MHz 30MHz *33.3MHz 32MHz CPU frequency ratio P55C enabled/disabled P55C enabled *P55C disabled * default setting CPU voltage setting (J3) J3 must be set to match the CPU type. The chart below shows the proper jumper settings for their respective V .

  • Page 22: M1 Cache Linear Mode Setting (J5)

    2.5V 2.8V *3.3V * default setting M1 cache linear mode setting (J5) PCM-5862 supports Cyrix M1 CPU with its linear access mode on L2 cache. This mode is set through J5. M1 cache linear mode enabled/disabled *Enabled Disabled * default setting...

  • Page 23: Buzzer Enabled/Disabled (J7)

    Disabled * default setting Installing DRAM (SIMMs) The PCM-5862 CPU card provides two 72-pin SIMM (Single In- line Memory Module) sockets and supports either Fast Page Mode (FPM) or Extended Data Output (EDO) DRAM with a speed of 70 ns or faster. You can install from 8 MB to 128 MB of RAM.

  • Page 24: Ide Hard Drive Connector (Cn17)

    IDE hard drive connector (CN17) You can attach one or two Enhanced Integrated Device Electronics hard disk drives to the PCM-5862's internal controller. The PCM- 5862's IDE controller uses a PCI local-bus interface. This advanced IDE controller supports faster data transfer and allows the IDE hard drive to exceed 528 MB.

  • Page 25: Floppy Drive Connector (Cn18)

    Floppy drive connector (CN18) You can attach up to two floppy drives to the PCM-5862's on- board controller. You can use any combination of 5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB, and 2.88 MB) drives.

  • Page 26: Parallel Port Connector (Cn19)

    You can select ECP/EPP DMA channel via BIOS setup. Keyboard and PS/2 mouse connector (CN15) The PCM-5862 board provides a keyboard connector that supports both a keyboard and a PS/2 style mouse. In most cases, especially in embedded applications, a keyboard is not used. The standard PC/AT BIOS will report an error or fail during power-on self-test (POST) after a reset if the keyboard is not present.

  • Page 27: Power Connectors (Cn6, Cn10, Cn14)

    Speaker The PCM-5862 can drive an 8 Ω speaker at 0.5 watts. Ensure that alternatives to this specification do not overload the card. LED interface The front panel LED indicator for hard disk access is an active low signal (24 mA sink rate).

  • Page 28: Ir Connector (Cn12) (U23 Super I/O Chipset Ite 8661 Only)

    CD audio input connector (CN8) All CD-ROM drives can provide analog audio signal output when used as a music CD player. The CN8 on PCM-5862 is a connector to input CD audio signal into the audio controller. The audio cable of your CD-ROM drive will be used to connect to CN8.

  • Page 29: Audio Power Source Setting (J16)

    Audio power source setting (J16) The PCM-5862 is designed to work with a single +5V power supply. The audio interface can also function normally under single +5V power supply, but most audio controllers require an independent power source generated from a +12V power. The independent power source avoids the noise from the other digital circuits.

  • Page 30: Com-Port Connector (Cn16)

    COM-port connector (CN16) The PCM-5862 provides four serial ports (COM1, 3, 4: RS-232; COM2: RS-232/422/485) in one COM port connector. The COM port connector is a 40-pin, dual-in-line, male header and provides connections for serial devices (a mouse, etc.) or a communication network.

  • Page 31: Com3/Com4 Irq Release (J8, J9)

    The IRQ and the address range for COM1, 2, 3, 4 are fixed. However, if you wish to disable the port or change these parameters later you can do this in the system BIOS setup. The table below shows the settings for the PCM-5862's serial ports. PCM-5862 serial port default settings Port...

  • Page 32: Com3/Com4 Ri Pin Setting (J11, J12)

    The COM3 and COM4 can supply +5V or +12V power to the serial devices via RI pin of the COM port connector. The outputs of COM3, COM4 RI pins are selected by setting J11, J12. COM3 RI pin setting +12V COM4 RI pin setting +12V * default setting PCM-5862 User‘s Manual...

  • Page 33: Vga Interface Connections

    Ensure that both CN10 and CN14 are connected for ±12 V power supply. The PCM-5862 provides a bias control signal on CN2 that can be used to control the LCD bias voltage. It is recommended that the LCD bias voltage not be applied to the panel until the logic supply voltage (+5V or +3.3V) and panel video signals are stable.

  • Page 34: Lcd Power Setting (J10)

    LCD power setting (J10) The PCM-5862's PCI SVGA interface supports 5V and 3.3V LCD displays. By changing the setting of J10, you can select the panel video signal level to be 5V or 3.3V. LCD power setting *5 V 3.3 V...

  • Page 35: Ethernet Configuration

    (See Chapter 3 for detailed information.) 10BASE-T connector (CN11) 10BASE-T connects to the PCM-5862 via an adapter cable to a 10-pin polarized header (CN11). For 10BASE-T RJ-45 operation, an adapter cable converting CN11 into a standard RJ-45 jack is required.

  • Page 36: Watchdog Timer Configuration

    IRQ15 * default setting USB connectors (CN4, CN5) (option) The PCM-5862 board provides two USB (Universal Serial Bus) interfaces which gives complete plug and play, hot attach/detach for up to 127 external devices. The USB interfaces comply with USB specification rev. 1.0 and are fuse protected.

  • Page 37: Chapter 3 Software Configuration

    Software Configuration This chapter details the software configuration information. It shows you how to configure the card to match your application requirements. AWARD System BIOS is covered in Chapter 4. Sections include: • Introduction • Utility disk • VGA display software configuration •...

  • Page 38: Introduction

    Introduction The PCM-5862 system BIOS and custom drivers are located in a 128 Kbyte, 32-pin (JEDEC spec.) Flash ROM device, designated U19. A single Flash chip holds the system BIOS, VGA BIOS, and network Boot ROM image. The display can be configured via software.
  • Page 39 5862_CRT.BIN Supports CRT only 5862_TFT.BIN Supports 640X480 color TFT (Toshiba LTM10C042) 5862_STN.BIN supports 640X480 color STN DD 8/16-bit displays (Sharp LM64C142) 5862_MON.BIN Supports 640X480 dual scan monochrome displays (Sharp LM64P83/64P89) 5862_EL.BIN Supports 640X480 EL displays (PLANAR EL640X480-A series) CBROM.EXE This program allows you to combine your own VGA BIOS with system BIOS(5862_SYS.BIN) Chapter 3 Software Configuration...

  • Page 40: Vga Display Software Configuration

    Configure the VGA display as follows: 1. Apply power to the PCM-5862 with a color TFT display attached. This is the default setting for the PCM-5862. Ensure that the AWDFLASH.EXE and *.BIN files are located in the working drive.

  • Page 41: Connections For Four Standard Lcds

    This configuration will remain the same until you run the AWDFLASH.EXE program and change the settings. Connections for four standard LCDs Connections to Sharp LM64183P, LM64P89 (640 x 480 DSTN MONO LCD) LM64183/64P89 PCM-5862 CN2 Pin name Pin name CN1-1 CN1-2 CN1-3...

  • Page 42: Connections To Planar El (640 X 480 Ad4 El)

    Pin name — — — — — — — — VCLK ASHFCLK /BLANK — — — — — — SELFTST COLMAP ENABLE — — RESERVED — — /LOWPOW — — 31,32 — — RESERVED — — — — PCM-5862 User‘s Manual...

  • Page 43: Connections To Toshiba Ltm10C042 (640 X 480 Tft Color Lcd)

    Connections to Toshiba LTM10C042 (640 x 480 TFT Color LCD) LTM10C042 PCM-5862 CN2 Pin name Pin name SHFCLK ENAB Chapter 3 Software Configuration...

  • Page 44: Connections To Sharp Lm64C142 (640 X 480 Dstn Color Lcd)

    Pin name CN1-1 CN1-2 CN1-3 SHFCLK CN1-4 DISP +5 V CN1-5 +5 V CN1-6 CN1-7 +27 V* CN1-8 CN1-9 CN1-10 CN1-11 CN1-12 CN1-13 CN1-14 CN1-15 CN2-1 CN2-2 CN2-3 CN2-4 CN2-5 CN2-6 CN2-7 CN2-8 CN2-9 CN2-10 *external power PCM-5862 User‘s Manual...

  • Page 45: Ethernet Software Configuration

    To configure the medium type, to view the current configuration, or to run diagnostics, do the following: 1. Power the PCM-5862 on. Ensure that the RSET8029.EXE file is located in the working drive. 2. At the prompt type RSET8029.EXE and press <Enter>. The Ethernet configuration program will then be displayed.
  • Page 46 PCM-5862 User‘s Manual...

  • Page 47: Chapter 4 Award Bios Setup

    Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 48: System Test And Initialization

    3. The CMOS memory has lost power and the configuration information has been erased. The PCM-5862’s CMOS memory has an integral lithium battery backup. The battery backup should last ten years in normal service, but when it finally runs down, you will need to replace the complete unit.

  • Page 49: Award Bios Setup

    AWARD BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. Entering setup Power on the computer and press <Del>...

  • Page 50: Standard Cmos Setup

    Once a field is highlighted, on-line help information is displayed in the left bottom of the Menu screen. AUTO AUTO 1.44MB None All, but keyboard CMOS setup screen PCM-5862 User‘s Manual...

  • Page 51: Bios Features Setup

    BIOS features setup By choosing the BIOS FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-5862. BIOS features setup Chapter 4 Award BIOS Setup...

  • Page 52: Chipset Features Setup

    CHIPSET features setup By choosing the CHIPSET FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-5862. CHIPSET features setup PCM-5862 User‘s Manual...

  • Page 53: Power Management Setup

    Power management setup By choosing the POWER MANAGEMENT SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-5862. Power management setup Chapter 4 Award BIOS Setup...

  • Page 54: Pnp/Pci Configuration

    PnP/PCI Configuration By choosing the PnP/PCI CONFIGURATION option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-5862. PnP/PCI Configuration PCM-5862 User‘s Manual...

  • Page 55: Integrated Peripherals

    Integrated Peripherals By choosing the INTEGRATED PERIPHERALS option from the INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-5862. Integrated Peripherals Chapter 4 Award BIOS Setup...

  • Page 56: Load Bios Defaults

    LOAD BIOS DEFAULTS loads the default system values directly from ROM. If the stored record created by the Setup program becomes corrupted (and therefore unusable), these defaults will load automatically when you turn the PCM-5862 on. ROM PCI/ISA BIOS (2A5IHAKA) CMOS SETUP UTILITY AWARD SOFTWARE, INC.

  • Page 57: Change Password

    Change Password To change the password, choose the PASSWORD SETTING option form the Setup main menu and press <Enter>. 1. If the CMOS is bad or this option has never been used, a default password is stored in the ROM. The screen will display the following messages: Enter Password: Press <Enter>.

  • Page 58: Auto Detect Hard Disk

    This record is required for the system to operate. Exit without saving Selecting this option and pressing <Enter> lets you exit the Setup program without recording any new values or changing old ones. PCM-5862 User‘s Manual...

  • Page 59: Chapter 5 Pci Svga Setup

    PCI SVGA Setup The PCM-5862 features an on- board PCI flat panel/VGA interface. This chapter provides instructions for installing and operating the software drivers on the included display driver diskette.

  • Page 60: Before You Begin

    The enhanced display drivers for the PCM-5862 board are located on the software installation diskette. You must install the drivers and utility software by using the supplied SETUP program for DOS...

  • Page 61: Simultaneous Display Mode

    (multisync) monitors are supported as analog monitors. Both CRT and panel displays can be used simultaneously. The PCM-5862 can be set in one of three configurations: on a CRT, on a flat panel display, or on both simultaneously. The system is initially set to simultaneous display mode.

  • Page 62: Driver Installation

    The display driver diskette contains drivers for several versions of certain applications. You must install the correct version in order for the driver to work properly so make sure you know which version of the application you have. PCM-5862 User‘s Manual...

  • Page 63: Windows Setup

    Windows setup These drivers are designed to work with Microsoft Windows 3.1. You may install these drivers through Windows or in DOS. Step 1: Install Windows as you normally would for a VGA display. Run Windows to make sure that it is working correctly. Step 2: Place the display driver diskette in drive A.

  • Page 64: Dos Setup

    Step 5: Follow the directions on the screen to complete the setup. In most cases, you may press <ENTER> to accept the suggested option. When Setup is done, it will return to DOS. Type WIN <ENTER> to start Windows with the new display driver. PCM-5862 User‘s Manual...

  • Page 65: Windows 95 Drivers Setup Procedure

    Changing Display Drivers in DOS To change display drivers from DOS, change to the Windows directory and run Setup, repeating steps 4 and 5 from the previous page. Besides the special display drivers marked by an asterisk (*), you should be able to use the following standard drivers: 640x480, 16 colors Super VGA 800x600, 16 colors...

  • Page 66: Windows Nt Drivers Setup Procedure

    2. Click on Test to test the newly selected graphics mode. A color test screen should appear, followed by the Testing Mode window. 3. Click on Yes to continue. The Display Settings Change window will appear. 4. Click on Restart Now for the new settings to take effect. PCM-5862 User‘s Manual...

  • Page 67: Os/2 Drivers Setup Procedure

    OS/2 Drivers Setup Procedure Preliminary Steps The following steps must be performed before you install the 65550/554 display driver: 1. OS/2 DOS Support must be installed. 2. If you previously installed SVGA support, you must reset the system to VGA mode. VGA is the default video mode enabled when OS/2 is installed.
  • Page 68 Make sure to remove the install diskette before restarting the system. When the system has restarted, the display driver will be initialized for 640x480x256 Color, 60Hz refresh. To switch to a different video resolution color depth, or refresh rate, follow the steps below. PCM-5862 User‘s Manual...

  • Page 69: Selecting Monitor Type

    Selecting Monitor Type Monitor type is initially set to DEFAULT. This DEFAULT setting may not allow you to select all resolution/refresh combinations that are available for your monitor. The following steps can be done to select monitor type. This section applies only after installation, or when a different monitor is used.

  • Page 70: Installation Notes

    “corrupted” display. This is normal, as the configuration process is doing Video BIOS mode sets to determine which screen resolutions BIOS supports. This configuration information is then used to provide the System-Settings Resolution and Refresh selections. PCM-5862 User‘s Manual...

  • Page 71: Chapter 6 Audio Setup

    Audio Setup The PCM-5862 is equipped with an audio interface that records and playback CD-quality audio. This chapter provides instructions for installing the software drivers on the included audio driver diskettes.

  • Page 72: Introduction

    The audio interface can record, compress, and play back voice, sound, and music with built-in mixer control. The PCM-5862 on board audio interface also supports the Plug and Play (PnP) standard and provides PnP configuration for the audio, FM, and MPU-104 logical devices. It is compatible with Sound Blaster™;...
  • Page 73 the setting of audio volumes. The VOLUME CONTROL utility located in the UTILITY subdirectory of audio driver diskette is used to control the volume setting in DOS. To control the volume setting, simply type the ESSVOL at the DOS prompt with appropriate parameters. The syntex of ESSVOL is shown as follows.

  • Page 74: Driver Installation

    To facilitate the installation of the audio drivers, you should read the instructions in this chapter carefully before you attempt installation. The audio drivers for the PCM-5862 board are located on the audio driver diskettes. You must install the drivers by using the supplied SETUP program.

  • Page 75: Windows 95 Drivers

    Windows 95 Drivers 1. Boot your system and place the audio driver diskette in drive 2. Select Add New Hardware from Windows‘s Control Panel. 3. Click Next to bring up the Windows search for new hardware setup screen. 4. Select No and click Next button. 4.
  • Page 76 PCM-5862 User‘s Manual...

  • Page 77: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The PCM-5862 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial standalone, or unmanned, environments.

  • Page 78: Programming The Watchdog Timer

    GOSUB 2000 REM Your application task #2 OUT &H443, data REM Reset the timer X=INP (&H043) REM Disable the watchdog timer 1000 Subroutine #1, you application task 1070 RETURN 2000 Subroutine #2, you application task 2090 RETURN PCM-5862 User‘s Manual...

  • Page 79: Appendix B Installing Pc/104 Modules

    Installing PC/104 Modules This appendix gives instructions for installing PC/104 modules.

  • Page 80: Installing Pc/104 Modules

    48-Channel DIO Module • PCM-3680 Dual Port CAN Module Installing these modules on the PCM-5862 is quick and simple. The following steps show how to mount the PC/104 modules: 1. Remove the PCM-5862 from your system paying particular attention to the safety instructions already mentioned above.

  • Page 81: Appendix C Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • CRT display connector • Flat panel display connector • PC/104 connectors • USB connectors • Fan power connector • Front panel connector • CD audio connector •...

  • Page 82: Crt Display Connector (Cn1)

    CRT display connector (CN1) 15 13 11 9 7 5 3 16 14 12 10 8 6 4 PCM-5862 CRT display connector Signal Signal SIGNAL GND H-SYNC GREEN CHASSIS GND SIGNAL GND V-SYNC BLUE CHASSIS GND CHASSIS GND PCM-5862 User‘s Manual...

  • Page 83: Flat Panel Display Connector (Cn2)

    Flat panel display connector (CN2) …… 42 44 …… 41 43 PCM-5862 Flat panel display connector Function Function +12 V +12 V 5V/3.3V 5V/3.3V ENAVEE* SHFCLK ENABKL* ASHFCLK ENAVDD* 5V/3.3V * Low active Appendix C Pin Assignments...

  • Page 84: Pc/104 Connectors (Cn3, Cn9)

    PC/104 connectors (CN3, CN9) …… 31 32 Row A Row B …… 31 32 …… 19 20 Row C Row D …… 19 20 PCM-5862 PC/104 connectors Signal (CN3) Signal (CN9) Number RowA RowB RowA RowB IOCHCHK* RESET SBHE* MEMCS16* LA23...
  • Page 85 PCM-5862 PC/104 connectors (cont.) Signal (CN3) Signal (CN9) Number RowA RowB RowA RowB SA13 DRQ1 SD14 MASTER* SA12 REFRESH* SD15 SA11 SYSCLK (KEY) SA10 IRQ7 — — IRQ6 — — IRQ5 — — IRQ4 — — IRQ3 — — DACK2* —...

  • Page 86: Usb Connectors (Cn4, Cn5)

    USB connectors (CN4, CN5) 4 3 2 1 PCM-5862 USB connector Signal +5 V Fan power connector (CN6) 3 2 1 PCM-5862 Fan power connector Signal +5 V +12 V PCM-5862 User‘s Manual...

  • Page 87: Front Panel Connector (Cn7)

    Front panel connector (CN7) 3 5 7 PCM-5862 Front panel connector Signal HDD LED- (HARD DISK ACTIVE) HDD LED+ (V SPEAKER+ SPEAKER- (GND) WATCHDOG OUTPUT* RESET SWITCH- (GND) RESET SWITCH+ * Low active Appendix C Pin Assignments...

  • Page 88: Cd Audio Connector (Cn8)

    CD audio connector (CN8) 4 3 2 1 PCM-5862 CD audio connector Signal CD AUDIO L CD AUDIO R Peripheral power connector (CN10) PCM-5862 Peripheral power connector Function -5 V -12 V PCM-5862 User‘s Manual...

  • Page 89: Ethernet 10Base-T Connector (Cn11)

    Ethernet 10BASE-T connector (CN11) 7 5 3 1 10 8 6 4 2 PCM-5862 Ethernet 10BASE-T connector Signal V CC CRS LED RCV+ RCV- BNC LED XMT+ XMT- IR connector (CN12) 5 4 3 PCM-5862 IR connector Signal V CC...

  • Page 90: Audio Connector (Cn13)

    SPEAKER OUT R+ SPEAKER OUT R- SPEAKER OUT L+ SPEAKER OUT L- LINE OUT R LINE OUT L LINE IN R LINE IN L MIC IN Main power connector (CN14) PCM-5862 Main power connector Signal +12 V +5 V PCM-5862 User‘s Manual...

  • Page 91: Keyboard And Mouse Connector (Cn15)

    Keyboard and PS/2 mouse connector (CN15) PCM-5862 Keyboard and mouse connector Signal MS VCC MS DATA MS CLOCK KB VCC KB DATA KB CLOCK Appendix C Pin Assignments...

  • Page 92: Com Port Connector (Cn16)

    COM port connector (CN16) 39 37 …… 40 38 …… PCM-5862 COM port connector Signal Signal RLSD1 DSR1 RTS1 CTS1 DTR1 RLSD2 DSR2 RTS2 CTS2 DTR2 RLSD3 DSR3 RTS3 CTS3 DTR3 RLSD4 DSR4 RTS4 CTS4 DTR4 PCM-5862 User‘s Manual...

  • Page 93: Ide Hard Drive Connector (Cn17)

    IDE hard drive connector (CN17) PCM-5862 IDE hard drive connector Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1...

  • Page 94: Floppy Drive Connector (Cn18)

    Floppy drive connector (CN18) PCM-5862 Floppy drive connector Signal Signal DENSITY SELECT* DRIVE TYPE INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * Low active PCM-5862 User‘s Manual...

  • Page 95: Parallel Port Connector (Cn19)

    Parallel port connector (CN19) PCM-5862 Parallel port connector Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * Low active Appendix C Pin Assignments...
  • Page 96 PCM-5862 User‘s Manual...

  • Page 97: Appendix D Optional Extras

    Optional Extras...

  • Page 98: Pcm-10586-2 Cable Kit For Pcm-5862

    PCM-10586-2 Cable kit for PCM-5862 The PCM-5862 requires several cables for normal operation. You can make them yourself or purchase an optional cable kit assembly, which includes the following: Part No. Cable Description PCM-5862 Terminating Connector Connector 1701440350 2.5“ and 1.8” IDE...
  • Page 99 Note: The cable of serial port (CN16) comes with four DSUB-9 male connectors. The pin assignments of each DSUB-9 connector are listed below for your reference: DSUB-9 Conn.(RS-232) mode RS-422 mode RS-485 module Signal Signal DATA- DATA+ Appendix D Optional Extras...

Table of Contents
