FEB-9457
Intel 945GME with Atom N270
User's Manual
Rev.02, Nov. 2009

Advertisement

Table of Contents
loading

Related Manuals for Intel 945GME

Summary of Contents for Intel 945GME

  • Page 1 FEB-9457 Intel 945GME with Atom N270 User’s Manual Rev.02, Nov. 2009...

  • Page 2: Packing List

    Statement All rights reserved. No part of this publication may be reproduced in any form or by any means, without prior written permission of the publisher. All trademarks are the properties of the respective owners. All product specifications are subject to change without prior notice. Packing List None FEB-9457 User’s Manual...

  • Page 3: Table Of Contents

    2.14 Save & Exit Setup ......................39 2.15 Exit Without Saving ......................40 Chapter 3 Drivers Installation ..................41 3.1 Intel Chipset Device Software ..................41 3.2 Intel Graphic Media Accelerator Driver ...............44 3.3 LAN Driver ........................47 3.4 Audio Driver ........................49 Appendix-A Watchdog .......................50 Appendix-B GPIO ........................50...

  • Page 4: Chapter 1 Product Information

    Chapter 1 Product Information This chapter introduces the product features, jumper and connector information. 1.1 Block Diagram IMVP6 Intel Atom N270 CK410 FSB 533MHz DDR2 533 MHz DDR2(SO-DIMM) x2 LVDS (18 bit) Intel 945GME SDVO_B LVDS_CH7308 (24 bit) SDVO_C DVI_(CH7307)
  • Page 5 IO_Docking (+12V, VGA, Line-Out, COM5, COM6) AUDIO (Line_out) DC-Jack (+12V) COM5 COM6 FEB-9457 User’s Manual...

  • Page 6: Features

    1.2 Features Processor Intel Atom N270 1.6GHz (2.5W) on board System 533 MHz Processor / Chipset Chipset Intel 945GME + ICH7M BIOS AWARD 16Mb SPI Technology Dual DDR2 533 MHz SDRAM Memory Max. Capacity Up to 4GB Socket 2 x SO-DIMM DDR2...
  • Page 7 2 (RS-232, supply 5V / 12V) 1 (RJ-45) Rear I/O USB2.0 Cash Drawer RJ11, DIO: 3bit GPIO (1 In, 2 Out) Audio 3 (Mic.-In, Line-in, Line-out) Power Type DC +12V Input Interval Programmable 1~255 sec./min. Watchdog Timer Output System reset Operating -5°C ~ 60°C (23°F ~ 140°F) Temp.

  • Page 8: Pcb Layout

    1.3 PCB Layout SATA_PWR2 PS_ON JCMOS CPUFAN SATA1 DDR1 DDR2 JVLVDS1 DEBUG_PORT JCOM2 Top Side JCOM5 JCOM4 JCOM6 JCOM4_SEL JCOM1 COM1 COM2 COM4 USB2 USB1 LAN1 CASH_DRAWER USB4 USB3 INV KB_MS COM3 LVDS1 LVDS2 AUDIO_AMP SATA_PWR1 SATA2 Bottom Side IO_DOCKING_F VGA1 (Bottom View) FEB-9457 User’s Manual...
  • Page 9 IO Board Top Side IO_DOCKING_M LINE-OUT +12V-OUT VGA2 COM6 COM5 FEB-9457 User’s Manual...

  • Page 10: Jumper Setting

    1.4 Jumper Setting JCMOS：CMOS Clear Pin No. Function Normal Operation (Default) Clear CMOS Contents Jumper Setting 3 2 1 3 2 1 3 2 1 3 2 1 JCOM1/ JCOM2/ JCOM4/ JCOM5/ JCOM6：COM1/ COM2/ COM4/ COM5 / COM6 (5V/12V/RI) Select Pin No.
  • Page 11 JVLVDS1：LCD Power (+3.3V / +5V) Select Pin No. Function LCD Power: +3.3V (Default) LCD Power: +5V Jumper Setting 3 2 1 3 2 1 3 2 1 3 2 1 FEB-9457 User’s Manual...

  • Page 12: Connector Function List

    1.5 Connector Function List Connector Function Note +12V-OUT +12v Output IO Board AUDIO_AMP Audio Amplifier Out CASH_DRAWER CASH DRAWER with RJ-11 Connector CPUFAN CPUFAN 4-pin Connector COM1, COM2 Serial port Connector COM3 Serial port Connector with Box-header COM4 Serial port with RJ-45 Connector COM5, COM6 Serial port Connector IO Board...
  • Page 13 Connector Function Note VGA1 VGA Connector VGA2 VGA Connector IO Board FEB-9457 User’s Manual...

  • Page 14: Internal Connector Pin Define

    1.6 Internal Connector Pin Define AUDIO_AMP：Audio Amplifier Output with Pin-header (2.0 mm) Pin No. Signal Amplifier Line-Out Right Ground Ground Amplifier Line-Out Left CASH_DRAWER：CASH_DRAWER with RJ-11 Connector Pin No. Signal Pin No. Signal Ground DIO_OUT1 +12V DGP_IN0 DIO_OUT0 Ground CPUFAN：4Pin FAN Connector Pin No.
  • Page 15 DEBUG_PORT：Power On Self Test Card with Low Pin Count interface Connector with Pin-header (2.0 mm) Pin No. Signal Pin No. Signal LAD0 Reset# LAD1 LFRAME# LAD2 +3.3V LAD3 Ground LPC Clock DVI：Digital Video Interface with Box-header (2.0 mm) Pin No. Signal Pin No.
  • Page 16 KB_MS：PS2 Keyboard, Mouse Connector with Box header (2.54 mm) Pin No. Signal PS2 Power Keyboard Clock Keyboard Data Mouse Clock Mouse Data Ground LPT：Parallel Port Connector with Box-header (2.0 mm) Pin No. Signal Pin No. Signal Strobe# Auto Form Feed# Data 0 Error# Data 1...
  • Page 17 LVDS1：18 bit LVDS Panel Signal with Wafer Connector (1.0 mm) Pin No. Signal Pin No. Signal Ground Ground A_CLK+ A_CLK- A_DATA2+ A_DATA2- A_DATA1+ A_DATA1- A_DATA0+ A_DATA0- Ground Ground B_CLK+ B_CLK- B_DATA2+ B_DATA2- B_DATA1+ B_DATA1- B_DATA0+ B_DATA0- Ground Ground LVDS Power LVDS Power LVDS Power LVDS Power...
  • Page 18 MIC：Micro Phone Input Connector with Box header (2.0 mm) Pin No. Signal Micro Detect Micro Phone In-Right Micro Phone In-Left Ground SATA_PWR1, SATA_PWR2：SATA Power Connector Pin No. Signal Ground Ground SPI_PORT：Serial Peripheral Interface Connector with Pin-header (2.54 mm) Pin No. Signal Pin No.
  • Page 19 VGA1：VGA Connector with Box-header (2.0mm) Pin No. Signal Pin No. Signal DDC Data GREEN DDC Clock BLUE Ground H-SYNC Ground V-SYNC FEB-9457 User’s Manual...

  • Page 20: Chapter 2 Bios Setup

    Chapter 2 BIOS Setup This chapter introduces BIOS setup information. Power on or reboot the system board, when screen appears message as “Press DEL to enter SETUP“. Press <DEL> key to run BIOS SETUP Utility. Note: The BIOS configuration for reference only, it may subject to change without prior notice.

  • Page 21: Standard Cmos Features

    2.2 Standard CMOS Features Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Item Help Date (mm:dd:yy) Wed. 18 2009 Time (hh:mm:ss) 19 : 28 : 15 Menu Level IDE Channel 0 Master [ None ] Change the day, month, IDE Channel 0 Slave [ None ] year and century...

  • Page 22: Advanced Bios Features

    □ Halt on Select stop procedure or ignore when error detected during POST (Power On Self Test). 2.3 Advanced BIOS Features Phoenix – AwardBIOS CMOS Setup Utility Advanced BIOS Features CPU Feature Press Enter Item Help Hard Disk Boot Priority [ Press Enter ] CPU L1 &...
  • Page 23 □ Hyper-Threading Technology Select “Hyper-Threading Technology” Enabled/Disabled. □ First/Second/Third Boot Device Select boot device priority. □ Security Option Select security mode, Setup: Require password to permit BIOS setup utility. System: Require password to permit boot-up and BIOS setup utility. □ HDD S.M.A.R.T. Capability Select “HDD S.M.A.R.T.

  • Page 24: Advanced Chipset Features

    2.4 Advanced Chipset Features Phoenix – AwardBIOS CMOS Setup Utility Advanced Chipset Features On-Chip Frame Buffer Size Item Help DVMT Mode [ DVMT ] DVMT / FIXED Memory Size [ 128MB ] Menu Level Boot Display [ CRT + LFP1 ] Panel Number [ 1024x768-18 LVDS ] Onboard Lan...

  • Page 25: Integrated Peripherals

    □ Panel Number Select LCD panel type □ Onboard Lan Select “Onboard Lan” Enabled/Disabled 2.5 Integrated Peripherals Phoenix – AwardBIOS CMOS Setup Utility Integrated Peripherals OnChip IDE Device Press Enter Item Help Onboard Device [ Press Enter ] Super IO Device [ Press Enter ] Menu Level Onboard Lan Boot ROM...

  • Page 26: Onchip Ide Device

    □ OnChip IDE Device Set IDE and SATA device configuration Phoenix – AwardBIOS CMOS Setup Utility OnChip IDE Device IDE HDD Block Mode Enabled Item Help On-Chip Primary PCI IDE [ Enabled ] IDE Primary Master PIO [ Auto ] Menu Level IDE Primary Slave PIO [ Auto ]...
  • Page 27 □ Onboard Device Press <Enter> to select Azalia/AC97 Auto/All Disabled Phoenix – AwardBIOS CMOS Setup Utility Onboard Device Azalia/AC97 Audio Select Auto Item Help Menu Level ↑ ↓ ← → :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults FEB-9457 User’s Manual...
  • Page 28 □ Super IO Device Press <Enter> to select Serial, Parallel and “PWRON After PWR-Fail” configuration. Phoenix – AwardBIOS CMOS Setup Utility Super IO Device Onboard Serial Port 1 3F8/IRQ4 Item Help Onboard Serial Port 2 [ 2F8/IRQ3 ] UART Mode Select [ Normal ] Menu Level x RxD , TxD Active...

  • Page 29: Usb Device Setting

    □ USB Device Setting Press <Enter> to select USB device configuration. Phoenix – Award WorkstationBIOS CMOS Setup Utility USB Device Setting Item Help USB 1.0 Controller Enabled [ Enabled ] USB 2.0 Controller Menu Level [ High Speed ] USB Operation Mode [ Enabled ] USB Keyboard Function [Enable] or [Disable]...

  • Page 30: Power Management Setup

    2.6 Power Management Setup Phoenix – AwardBIOS CMOS Setup Utility Power Management Setup PCI Express PM Function Press Enter Item Help ACPI Function [ Enabled ] ACPI Suspend Type S1(POS) Menu Level Run VGABIOS if S3 Resume Auto Soft-Off by PWR-BTTN [ Instant-Off ] Power On by Ring [ Disabled ]...
  • Page 31 □ PCI Express PM Function Press <Enter> to select “Wake-up by LAN” Enabled/Disabled. Phoenix – AwardBIOS CMOS Setup Utility PCI Express PM Function Wake-up by LAN Disabled Item Help Menu Level ↑ ↓ ← → :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults...

  • Page 32: Pnp/Pci Configurations

    2.7 PnP/PCI Configurations Phoenix – AwardBIOS CMOS Setup Utility PnP / PCI Configurations Reset Configuration Data Disabled Item Help Resources Controlled By [ Auto(ESCD) ] Menu Level IRQ Resources Press Enter Default is Disabled, Select Enabled to PCI/VGA Palette Snoop [ Disabled ] reset Extended System Configuration Data...

  • Page 33: Pc Health Status

    2.8 PC Health Status Phoenix – AwardBIOS CMOS Setup Utility PC Health Status Shutdown Temperature Disabled Item Help CPU Warning Temperature [ Disabled ] Current CPU Temperature 46 ℃ / 114 ℉ Menu Level CPU Fan Speed 0 RPM Vcore 1.15 V +12 (V) 11.96 V...

  • Page 34: Frequency/Voltage Control

    2.9 Frequency/Voltage Control Phoenix – AwardBIOS CMOS Setup Utility Frequency / Voltage Control Auto Detect PCI Clk Enabled Item Help Spread Spectrum [ Disabled ] Menu Level ↑ ↓ ← → :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults □...

  • Page 35: Load Fail-Safe Defaults

    2.10 Load Fail-Safe Defaults Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency / Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save &...

  • Page 36: Load Optimized Defaults

    2.11 Load Optimized Defaults Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency / Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save &...

  • Page 37: Set Supervisor Password

    2.12 Set Supervisor Password Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency / Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save &...

  • Page 38: Set User Password

    2.13 Set User Password Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency / Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save &...

  • Page 39: Save & Exit Setup

    2.14 Save & Exit Setup Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency / Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save &...

  • Page 40: Exit Without Saving

    2.15 Exit Without Saving Phoenix – AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency / Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password Quit Without Saving (Y/N)? N PnP/PCI Configurations Save &...

  • Page 41: Chapter 3 Drivers Installation

    Operate System or did not appear automatically, please select corresponding driver of utility CD to install. The Windows XP driver installation steps are as below. 3.1 Intel Chipset Device Software Step 1. Click “Next” to continue FEB-9457 User’s Manual...
  • Page 42 Step 2. Read the License Agreement and click “Yes” to continue Step 3. Click “Next” to continue FEB-9457 User’s Manual...
  • Page 43 Step 4. Click “Next” to continue Step 5. Click “Finish” to complete setup FEB-9457 User’s Manual...

  • Page 44: Intel Graphic Media Accelerator Driver

    3.2 Intel Graphic Media Accelerator Driver Step 1. Click “Next” to continue Step 2. Click “Next” to continue FEB-9457 User’s Manual...
  • Page 45 Step 3. Read the License Agreement and click “Yes” to continue Step 4. Click “Next” to continue FEB-9457 User’s Manual...
  • Page 46 Step 5. Click “Next” to continue Step 6. Click “Finish” to complete setup FEB-9457 User’s Manual...

  • Page 47: Lan Driver

    3.3 LAN Driver Step 1. Click “Next” to continue Step 2. Click “Install” to continue FEB-9457 User’s Manual...
  • Page 48 Step 3. Click “Finish” to complete setup FEB-9457 User’s Manual...

  • Page 49: Audio Driver

    3.4 Audio Driver Step 1. Click “Next” to continue Step 2. Click “Finish” to complete setup FEB-9457 User’s Manual...

  • Page 50: Appendix-A Watchdog

    Appendix-A Watchdog The system board provides Watchdog function, the Super I/O setting step as below. Step 1: CR2D, Bit0→0 (select pin77 to WDTO#) Step 2: LD8, CR30, Bit0→1 (Active WDTO#) Step 3: LD8, CRF7, Bit4→Write 0 to clear WDTO# status. Step 4: LD8, CRF5, Bit3→0: Second mode, 1: Minute mode Step 5: LD8, CRF6, Bit [7:0] →Set WDTO# Time out value.
  • Page 51 // Enter Extended Function Mode outp(0x002E, 0x87); outp(0x002E, 0x87); // Assign Pin121-128 to be GPIO port 1 outp(0x002E, 0x29); outp(0x002F, inp(0x002F) | 0x01); // Select Logic Device 7 outp(0x002E, 0x07); outp(0x002F, 0x07); // Active Logic Device 7 outp(0x002E, 0x30); outp(0x002F, 0x01); // Select Inversion Mode outp(0x002E, 0xF2);...
  • Page 52 Value of Inversion Register: Only lower nibble is available for this function. When set to a ‘1’, the incoming/outgoing port value is inverted. When set to a ‘0’, the incoming/outgoing port value is the same as in Data Register. Value of I/O Selection Register: Only lower nibble is available for this function.
