AD2
AD2 Handheld Transmitter
1. Navigate to the Utilities and select Battery.
2. Use the ▼▲ buttons to select the installed battery type:
⁃
Alkaline = Alkaline
⁃
NiMH = Nickel Metal Hydride
⁃
Lithium = Lithium Primary
3. Press enter to save.
Updating Firmware
Firmware is embedded software in each component that controls functional-
ity. Periodically, new versions of firmware are developed to incorporate addi-
tional features and enhancements. To take advantage of design improve-
ments, new versions of the firmware can be uploaded and installed using
the Shure Update Utility. The Shure Update Utility is available for download
from http://www.shure.com/.
Firmware Versioning
When performing an update, download firmware to the receiver first, and
then update transmitters to the same firmware version to ensure consistent
operation.
Shure SB900A Rechargeable Battery
Shure SB900A lithium-ion batteries offer a rechargeable option for powering
the transmitters. Batteries quickly charge to 50% capacity in one hour and
reach full charge within three hours.
Single chargers and multiple bay chargers are available to recharge the
Shure batteries.
Caution: Only charge Shure rechargeable batteries with a Shure battery
charger.
Shure SB900A Runtime
2 mW
Up to 9 hours
Up to 9 hours
Checking Battery Info
When using an SB900A rechargeable battery, the receiver and transmitter
home screens display the number of hours and minutes remaining.
Detailed information for the battery is displayed Battery menu of the transmit-
ter: Utilities>Battery
•
Battery: The chemistry type of for the installed battery (Shure, Alkaline,
Lithium, NiMH)
•
Bars: Indicates the number of bars displayed
•
Time: Battery runtime
•
Charge: Percentage of charge capacity
•
Health: Percentage of current battery health
•
Cycle: Record of the number of charging cycles for the installed battery
•
Temp: Battery temperature in Fahrenheit and Celsius
4/10
Battery
Battery: Alkaline
10 mW
35 mW
Up to 5 hours
Battery
Battery: NiMH
Battery: Lithium
The firmware numbering for Shure devices uses the following format: MA-
JOR.MINOR.PATCH (e.g., 1.2.14). At a minimum, all devices on the network
(including transmitters), must have the same MAJOR and MINOR firmware
version numbers (e.g., 1.2.x).
Updating the Transmitter
1. To upload the firmware to the transmitter, go to Device Configuration>Tx
Firmware Update on the receiver.
2. Place the transmitter on its side and align the IR ports.
3. Press ENTER on the receiver to begin the download to the transmitter.
IR ports must be aligned for the entire download, which can take 50
seconds or longer.
Important Tips for Care and Storage of Shure
Rechargeable Batteries
Proper care and storage of Shure batteries results in reliable performance
and ensures a long lifetime.
•
Always store batteries and transmitters at room temperature
•
Ideally, batteries should be charged to approximately 40% of capacity
for long-term storage
•
Periodically clean the battery contacts with alcohol to maintain ideal
contact
•
During storage, check batteries every 6 months and recharge to 40% of
capacity as needed
For additional rechargeable battery information, visit www.shure.com.
AA Batteries and Transmitter Runtime
Transmitters are compatible with the following AA battery types:
•
Alkaline
•
Nickel Metal Hydride (NiMH)
•
Lithium Primary
Battery
Battery Info
Time: 8:15
Health: 98%
Charge: 97%
Shure Incorporated
2017/08/03
