VLAN Overview

Configuring VLAN

VLAN C
ONFIGURATION
VLAN Overview
■
Configuring GARP/GVRP
■
A virtual local area network (VLAN) groups the devices of a LAN logically, but not
physically, into segments to implement the virtual workgroups.
Using VLAN technology, network managers can logically divide the physical LAN
into different broadcast domains. Every VLAN contains a group of workstations
with the same demands. The workstations of a VLAN do not have to belong to the
same physical LAN segment.
With VLAN technology, the broadcast and unicast traffic within a VLAN will not be
forwarded to other VLANs, so VLAN configurations are very helpful in controlling
network traffic, saving device investment, simplifying network management and
improving security.
To configure a VLAN:
Create or Delete a VLAN
■
Add Ethernet Ports to a VLAN
■
Specify the Broadcast Suppression Ratio for VLAN
■
Set or Delete VLAN Description Character String
■
Specify or Remove VLAN Interfaces
■
Assign or Delete the IP Address and Mask of a VLAN Interface
■
Shut down or Enable the VLAN Interface
■
Create or Delete a VLAN
You can use the following command to create or delete a VLAN.
Perform the following configurations in system view.
Table 1 Create or Delete a VLAN
Operation
Create a VLAN and enter the
VLAN view
Delete the specified VLAN
If the VLAN to be created exists already, enter the VLAN view directly. Otherwise,
create the VLAN first, and then enter the VLAN view.
Command
vlan vlan_id
undo vlan vlan_id
