4 C 1: S
HAPTER YSTEM
Configuring the
Switch 7700
A
CCESS
Table 1 Function Features
Features
IP routing
DHCP Relay
Link aggregation
Security features
Reliability
Quality of Service (QoS)
Management
Loading and update
Maintenance
On the Switch 7700, you can set up the configuration environment through the
console port. To set up the the local configuration environment:
1 Plug the DB-9 or DB-25 female plug of the console cable into the serial port of the
PC or the terminal where the switch is to be configured.
2 Connect the RJ-45 connector of the console cable to the console port of the
switch, as shown in Figure 1.
Support
Static route
Routing Information Protocol (RIP) V1/v2
Open Shortest Path First (OSPF)
Dynamic Host Configuration Protocol (DHCP) Relay
Link aggregation
Multi-level user management and password protect
802.1X authentication
Packet filtering
Virtual Redundancy Routing Protocol (VRRP)
Traffic classification
Bandwidth control
Priority
Queues of different priority on the port
Queue scheduling: supports Strict Priority Queueing (SP)
Command line interface configuration
Configuration by the console port
Remote configuration by Telnet
Configuration through dialing the modem
SNMP
System log
Level alarms
Load and upgrade software using the XModem protocol
Load and upgrade software using the File Transfer Protocol
(FTP) and Trivial File Transfer Protocol (TFTP)
Output of the debugging information
PING and Tracert
Remote maintenance using Telnet and a modem
