Fail-safe digital modules
Hide thumbs Also See for SIMOCODE pro:
Table of Contents

Advertisement

LED
Status
Flickering yellow
5
Off
Yellow
Flashing yellow
Flickering yellow
6
Off
Yellow
Flashing yellow
Flickering yellow
7
Off
Yellow
Flashing yellow
Flickering yellow
8
OFF
Yellow
Flashing yellow
Flickering yellow
DIP switch
Setting of the safety functions
SET/RESET button
Inputs with safety
2 sensor inputs 24 V DC (Y12, Y22)
relay function
1 start signal input 24 V DC (Y33)
1 cascading input 24 V DC (1)
1 feedback circuit input 24 V DC (Y34)
Cable length
1500 m
between sensor and
start signal inputs
(single)
Input characteristic
Type 2 according to EN 61131-2
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
Meaning
Configuration error
Sensor circuit, automatic start
Sensor circuit, monitored start
Configuration mode, waiting for confirmation
Configuration error
Cascading input 1, automatic start
Cascading input 1, monitored start
Configuration mode, waiting for confirmation
Configuration error
With start-up testing
Without start-up testing
Configuration mode, waiting for confirmation
Configuration error
Automatic starting after power failure
No automatic starting after power failure
Configuration mode, waiting for confirmation
Configuration error
Application of parameters set via DIP switch
Resetting of faults (also possible via "TEST/RESET" on basic unit)
Supply via terminal T1 and T2 with cross-circuit detection or external supply (static +24 V DC)
without cross-circuit detection
Functions parameterizable via DIP switch
For monitored reconnection of the relay enabling circuits after a safety-related disconnection
Supply via terminal T1 with/without T3 (static +24 V DC) without cross-circuit detection
For use in connection with a higher-level safety relay
Supply via terminal T3 (static +24 V DC)
For contactor monitoring of the motor and incoming supply contactors via series-connected
auxiliary switch normally-closed contacts
Supply via terminal T2 with/without T3 (static +24 V DC) without cross-circuit detection
10.2 Technical data of the DM-F Local fail-safe digital module
Technical data
97
