Battery - AT&T ADS1 Manual

Battery

To extend your battery's life, do not browsing web frequently. Also poor signal area and extreme temperature discharge
battery easily. If not necessary, it is recommended that you turn off Wi-Fi, Bluetooth, etc.
Battery installation
Please use only original batteries and accessories that came with your phone or replacements that we recommend.
1. Make sure that your device is turned off, and then remove the battery cover.
2. Align the battery's exposed gold contacts with the battery connectors
inside the battery compartment.
3. Insert the contact side of the battery first and then gently push the
battery into place.
4. Replace the battery cover by setting it to the slot of the phone and
sliding it back into its place.
Battery removal
1. Make sure that your device is turned off, and then remove the battery cover.
2. Lift the tab of the battery to remove the battery.
Charging your battery
Before you turn on and start using your device, it is recommended that you charge the battery.
1.Plug the USB cable into the AC Charger port.
2. Plug the AC Charger into a standard outlet.
3.To access the USB port located on the left side of your device,
open the flap and plug the other end of the AC Charger into the USB port.
The battery must be installed for the phone to work properly.
4. The USB icon on the USB cable should always be face-up on the same side as
the display screen when it is inserted into the your device.
See the diagram to the right for proper positioning and insertion of the
AC Charger adapter into the phone. You should never force the
AC Charger adapter into the phone.
NOTE
9
