GENUINE REMOTE ENGINE START
USER'S INSTRUCTIONS
Parts number
Thank you for purchasing a genuine Mazda accessory.
Before use, be sure to thoroughly read these instructions.
Please read the contents of this booklet in order to properly use the Remote Engine Start.
Your safety depends on it.
After using this instruction manual, store it in a place where it can be easily located.
Note, consult your authorized Mazda dealer, or a dealer appointed store, for proper
vehicle installation of the Remote Engine Start.
If the vehicle equipped with this product, or the product itself, is sold, transferred or
loaned to another party, be sure to give this instruction manual to the new owner, so he
or she can use this product safely and correctly.
<Safe and correct use of the product>
Various warnings and cautions are displayed in this manual to assist you in the safe and
correct use of the product and as precautions against you or others being injured, or the
product being damaged.
Depending on the degree of possible injury or damage that may be incurred,
precautionary items have been divided into 'Warnings' and 'Cautions' and illustrated with
symbols to depict the nature of the precautionary content.
A WARNING indicates a situation in which serious
WARNING
injury or death could result if the warning is ignored.
A CAUTION indicates a situation in which bodily injury
CAUTION
or damage to objects, or both, could result if the
caution is ignored.
Always follow the ADVICE noted to ensure vehicle
safety and performance. Vehicle damage could result,
ADVICE
or proper performance may be compromised if the
advice is ignored.
A NOTE indicates information or a point related to
vehicle usage. Vehicle damage could result, or proper
NOTE
performance may be compromised if the note is
ignored.
C960 V7 620
No.:ZZ092-00640-00
GB
Advertisement
Table of Contents
Related Manuals for Mazda C960 V7 620
Summary of Contents for Mazda C960 V7 620
- Page 1 Your safety depends on it. After using this instruction manual, store it in a place where it can be easily located. Note, consult your authorized Mazda dealer, or a dealer appointed store, for proper vehicle installation of the Remote Engine Start.
-
Page 2: Table Of Contents
CONTENTS 1. Remote Engine Start features ................3 2. Safety precautions ....................3 3. General information ....................6 4. Operating precautions .................... 7 5. Part names ......................9 6. Basic functions for Remote Engine Start .............. 10 7. Low battery warning & replacement directions ............ 12 8. -
Page 3: Remote Engine Start Features
1. Remote Engine Start features The Remote Engine Start allows the user to start the engine of a vehicle from a remote location using a remote control. The user can turn on the air conditioner / heater beforehand so the cabin of the vehicle can be cooled or heated ahead of time. - Page 4 WARNING Do not start up the engine using the Remote Engine Start when parked on an incline. If the vehicle were to move unintentionally due to the engine vibration, jolt, etc., it could result in a serious accident. Performing safe maintenance and inspection. When performing vehicle inspection and maintenance, remove the (-) terminal on the vehicle battery.
- Page 5 WARNING Fire prevention. Do not start the engine when the vehicle is near something flammable (oil or dry grass). Otherwise, the high temperature from the exhaust fumes or exhaust pipe could cause a fire. Do not start the engine while the vehicle is wrapped with a body cover.
-
Page 7: Operating Precautions
4. Operating precautions Usage Environment ●The remote control signal (or the response signal from the controller) may not reach the controller (or the remote control) if there are strong radio waves transmitting nearby, or if there are obstacles blocking the signal. ●... - Page 8 Remote Control Handling Instructions The remote control is a sensitive electronic device similar to a cellular telephone. Please follow the handling instructions below to avoid damage to or breakdown of the remote control. Avoid storing or using the remote control in places that expose it to direct sunlight, places that have high humidity, places with extremely high temperatures (on top of the dashboard, etc.) or places with extremely low temperatures (leaving inside the vehicle while parked at ski resorts, etc.).
-
Page 10: Basic Functions For Remote Engine Start
6. Basic functions for Remote Engine Start Engine Start & Stop Function The remote control is equipped with START engine start, engine stop and automatic stop (set with timer) functions. In addition, the engine start operation will perform when conditions outlined on page 14 are Engine start →... - Page 11 Car Find Function If the car find operation is performed on the remote control, the hazard lights will flash twice and the horn will sound twice so you can confirm the vehicle’s location. This function is convenient when Car find looking for your vehicle in a large Directions for car find parking lot, etc.
-
Page 12: Low Battery Warning & Replacement Directions
7. Low battery warning & replacement directions If the battery power is depleted, the LED light (red) turns on when a switch is pressed and battery power depleted is indicated. In this case, as battery replacement will be required soon, replace the batteries with new ones according to the following procedure. -
Page 13: Basic Operations
8. Basic operations Check points when the vehicle is parked. When using the engine start function with this device, follow the instructions below when parking, in order to avoid vehicle theft or an accident from occurring. Be sure to always engage the parking brake. Put the shift lever in the “P”... -
Page 14: Engine Start Operation
8-1. Engine start operation Operation Indication Press START switch while LED light (green) is Press F switch flashing (approx. 3 seconds) LED light color: Engine start Press switches until sound is heard. Green Release F switch when beep sound is Engine not started heard Check engine start conditions... -
Page 15: Engine Stop Operation
8-2. Engine stop operation Indication Operation Press STOP switch while LED light (green) is Press F switch flashing (approx. 3 seconds) LED light color: Engine start Press switches until sound is heard. Green Engine not started Release F switch when beep sound is Radio signal from remote heard controller not received. - Page 16 ● Other Engine Stop Conditions The engine will stop if one of the following conditions is true. 1) The hood is opened. 2) The shift lever is put in a position other than the “P” position. 3) A door is opened. 4) The push start switch is pressed.
-
Page 17: Warm Up Time Check
8-3. Warm up time check This operation only applies when the engine has been started with the remote control. Operation Indication Press START switch while LED light (green) is Press F switch flashing (approx. 3 seconds) LED light color: See table below Press switches until sound is heard. -
Page 18: Warm Up Time Settings
8-4. Warm up time settings Operation Indication Press switch while Press START switch LED light (green) and STOP switch at flashes (approx. 3 same time until LED seconds) light (green) flashes 10-minute warm- LED light color 30-minute 10 minutes warm- Press the Green [Beep]... -
Page 19: Engine Start Operation With Rear Defrost Start Up
8-5. Engine start operation with rear defrost start Up When starting the engine using this operation, the rear defogger turns on automatically Operation Indication Press F switch Press START switch while LED light (green) is flashing (approx. Press F switch while LED light color 3 seconds) LED light (green) is... -
Page 20: Car Find Function
8-6. Car find function When the engine is turned off or after starting the engine using the remote controller, perform this operation to activate the hazard warning lights 2 times. Indication Operation Press F switch Press START LED light color Press F switch while switch while LED LED light (green) is... -
Page 21: Troubleshooting
Request for Dealer Performing Installation Service Be sure to explain the device operation to the customer. • Note that some contents of this instruction manual may not match the actual device due to changes in the vehicle or product specification.
