Dual Monitor Emulation - Polycom vsx 7000 Series Beginner's Manual

Dual Monitor Emulation (VSX Only)
What is Dual Monitor Emulation?
The VSX 7000 features a unique dual monitor emulation (DME)
feature, providing dual monitor-type display on a single monitor.
With DME, users will see near & far end video simulatenously on the
same monitor. During content presentations, the content will
display on a single, large viewing area, while near & far end video
appear in smaller windows.
Turning On Dual Monitor Emulation
• Push the Home button on the remote control
• Arrow to the System button in the lower left corner of the screen, and press enter
• Select "Admin Settings"
• Select "Monitors"
• Select "TV Monitors"
• Arrow to "Dual Monitor Emulation" at the bottom of the page, and press enter to check the box
• Push the Home button on the remote control again, and proceed with your video call
• If in a call, press the blue Near button to return to your video call
Turning Off Dual Monitor Emulation
• Touching the PIP button on the remote will turn off Dual Monitor Emulation
• If you prefer, repeat the steps above to access the Dual Monitor Emulation setting
• Press enter to un-check the setting
Dual Monitor Emulation Settings & Controls
• By default, two equal-sized, side-by-side viewing areas will appear
• Press the blue PIP button once, and the far end video will appear full screen (no local view)
• Press PIP a second time, and the far end will appear in a large viewing window, while the local view
will open in a small window in the corner of the monitor
• If sending or receiving Visual Concert PC graphics, the content will appear in a large
window, while the local and far video view will appear in two smaller windows.
SERMC Contact: Tad Hunt (402) 219-7378 thunt@stez.org SKC Contact: (800) 882-7779 contact.us@skccom.com
14
