CAUTION:
To avoid damage to the processor, handle the processor only by the edges. Do not touch the bottom
of the processor, especially the contact area.
CAUTION:
To prevent possible server blade malfunction and damage to the equipment, multiprocessor
configurations must contain processors with the same part number.
The processor and heatsink ship as two separate units and are coupled together during installation into
the server blade.
Procedure
1. Remove the CPU airflow baffle.
2. Transfer the duplicate part/serial numbers label from the processor module to the processor heatsink.
a. Remove the duplicate tear-away label that lists the part and serial numbers from the processor
module.
b. Place the label on the top of the heatsink.
3. Install the processor over the load posts.
NOTE:
Ensure pin 1, indicated on the empty socket with an embossed triangle, matches the pin 1
marker on the processor module, the chamfered corner of its attached voltage regulator
heatsink.
44 Optional components
