Intel H2000 Technical Product Specification

Server chassis
Hide thumbs Also See for H2000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Intel
Server Chassis H2000 Family
®
Technical Product Specification
Intel order number: G59059-006
Revision 1.5
April, 2015
Enterprise Platforms and Services Division

Advertisement

Table of Contents
loading

Related Manuals for Intel H2000

Summary of Contents for Intel H2000

  • Page 1 Intel Server Chassis H2000 Family ® Technical Product Specification Intel order number: G59059-006 Revision 1.5 April, 2015 Enterprise Platforms and Services Division...

  • Page 2: Revision History

    ® Revision History Intel Server Chassis H2000 Family TPS Revision History Date Revision Number Modifications February, 2012 Initial release. July, 2012 Updated safety notice for rail kit. August, 2012 Updated power redundancy mode.  Updated link to Rail Specification. November, 2012 ...
  • Page 3 Current characterized errata are available on request. Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order. Copies of documents which have an order number and are referenced in this document, or ®...

  • Page 4: Table Of Contents

    ® Table of Contents Intel Server Chassis H2000 Family TPS Table of Contents 1. Introduction ........................1 Chapter Outline ...................... 1 Server Board Use Disclaimer ................. 2 2. Product Overview ....................... 3 Chassis Views ......................4 Chassis Dimensions ....................5 System Level Environmental Limits ................
  • Page 5 ® Intel Server Chassis H2000 Family TPS Table of Contents 3.2.16 Voltage Interruptions .................... 20 3.2.17 AC Line Isolation ....................20 3.2.18 AC Power Inlet ..................... 21 DC Ouput Specification ..................21 3.3.1 Output Power/Currents ..................21 3.3.2 Standby Output ....................22 3.3.3...
  • Page 6 ® Table of Contents Intel Server Chassis H2000 Family TPS 5.3.1 Backplane Feature set: ..................38 5.3.2 Backplane Block Diagram ..................38 5.3.3 3.5" Hot Swap Backplane Connector scheme ............39 5.3.4 2.5" Hot Swap Backplane Connector scheme ............40 5.3.5...
  • Page 7 ® Intel Server Chassis H2000 Family TPS List of Figures List of Figures Figure 1. Chassis Overview (H2312xx SKU) ................4 Figure 2. Power Supply Scheme (Rear View) ................4 Figure 3. Dummy Tray Cover ...................... 4 Figure 4. Major Chassis Parts ..................... 7 ®...
  • Page 8 ® List of Tables Intel Server Chassis H2000 Family TPS List of Tables Table 1. Chassis Feature Set ...................... 3 Table 2. Chassis SKU Matrix ...................... 3 Table 3. Chassis Dimension (SKU: H2312xxJR/KR) ..............5 Table 4. Chassis Dimension (SKU: H2216xxJR/KR) ..............5 Table 5.
  • Page 9 ® Intel Server Chassis H2000 Family TPS List of Tables Table 35. Hard Drive Carrier Status LED Functions ..............42 Table 36. Hard Drive Carrier Activity LED Functions ..............42 Table 37. Backplane Input Power Connector Pin-out ..............43 Table 38. 2-Blade Compute Node Power Connector Pin-out............. 43 Table 39.
  • Page 10 ® List of Tables Intel Server Chassis H2000 Family TPS <This page is intentionally left blank.> Revision 1.5 Intel order number: G59059-006...

  • Page 11: Introduction

    Reference Documents section at the end of this document. ® The Intel Server Chassis H2000 may contain design defects or errors known as errata which ® may cause the product to deviate from published specifications. Refer to the Intel Server Board ®...

  • Page 12: Server Board Use Disclaimer

    ® components. It is the responsibility of the system integrator who chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of air flow required for their specific application and environmental conditions.

  • Page 13: Product Overview

    This will not provide Power Supply Redundancy and causes the system to log multiple errors. ® ® The Intel Server Chassis H2000 family supports node trays which are built with Intel Server Board S2600JF, S2600WP, or S2400LP. ® The Intel Server Chassis H2000 family also supports different node quantity in the same chassis.

  • Page 14: Chassis Views

    ® Product Overview Intel Server Chassis H2000 Family TPS Chassis Views Figure 1. Chassis Overview (H2312xx SKU) Figure 2. Power Supply Scheme (Rear View) Figure 3. Dummy Tray Cover Revision 1.5 Intel order number: G59059-006...

  • Page 15: Chassis Dimensions

    ® Intel Server Chassis H2000 Family TPS Product Overview Chassis Dimensions Table 3. Chassis Dimension (SKU: H2312xxJR/KR) Height 87.9 mm 3.46" Width 438 mm 17.24" Depth 771 mm 30.35" Table 4. Chassis Dimension (SKU: H2216xxJR/KR) Height 87.9 mm 3.46" Width 438 mm 17.24"...

  • Page 16: Chassis Parts

    Intel Corporation cannot be held responsible, if components fail or the server board does not operate correctly when used outside any of its published operating or non-operating limits.

  • Page 17: Hard Drive And Peripheral Bays

    ® Intel Server Chassis H2000 Family TPS Product Overview Front Control Panel HDD bays Upper and Lower Power Distribution Boards Common Redundant Power Supply Hot Swap Back Plane Note: Not shown - Rack slide rail, and top cover. Figure 4. Major Chassis Parts...

  • Page 18: Front Bezel Support

    Front Bezel Support ® Intel Server Chassis H2000 family provides front panel bezel. The bezel provides protection to system HDD bays with a lock to chassis. The front view of the bezel is as below. Figure 7. Chassis Bezel Front View Rack and Cabinet Mounting Options The chassis was designed to support 19 inches wide by up to 30 inches deep server cabinets.
  • Page 19 ® Intel Server Chassis H2000 Family TPS Product Overview mechanical assist to install and align server into the rack rails is recommended. Advisory Note: The AXXELVRAIL value rack mount rail kit is not designed to support shipment of the server system while installed in a rack.

  • Page 20: Power Sub-System

    PMBus* features included in this specification are requirements for AC silver rated box power ® supply for use in server systems based on Intel Server Chassis H2000 Family. This specification is based on the PMBus* Specifications part I and II, revision 1.1.

  • Page 21: Ac Power Supply Unit General Data

    ® Intel Server Chassis H2000 Family TPS Power Sub-System 3.1.2 AC Power Supply Unit General Data Below is general specification data for AC Power Supply Unit. Table 6. Specification Data for AC Power Supply Unit Wattage 1200W/1600W (Energy Smart) Voltage 90 –...

  • Page 22: Handle Retention

    ® Power Sub-System Intel Server Chassis H2000 Family TPS PSU Output Connector +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V PMBus SDA* A0* (SMBus address) PMBus SCL* A1* (SMBus address)

  • Page 23: Power Cage With Power Distribution Board

    ® Intel Server Chassis H2000 Family TPS Power Sub-System Table 9. Power Supply Status LED Power Supply Condition LED State Output ON and OK Solid GREEN No AC power to all power supplies AC present/Only 12VSB on (PS off) or PS in Cold...

  • Page 24: Power Cage Output Pin Assignment

    ® Power Sub-System Intel Server Chassis H2000 Family TPS Power Distribution Board 1 Power Distribution Board 2 Power Supply Unit #2(upper) and #1(lower) Figure 9. Power Cage Overview 3.1.9 Power Cage Output Pin Assignment The power cage provides +12V and +12V output to the system.

  • Page 25: Figure 10. Power Distribution Board

    ® Intel Server Chassis H2000 Family TPS Power Sub-System Main Power Output Connector P1 Power Supply Unit Connector Control Signal Connector Main Power Output Connector P2 Figure 10. Power distribution board Table 10. Pin assignment of power ouput connector Description...

  • Page 26: Ac Input Specification

    ® Power Sub-System Intel Server Chassis H2000 Family TPS Table 11. Pin assignment of control signal connector Description Description PMBus SDA A0 (SMBus Address) PMBus SCL A1 (SMBus Address) PSON# 12V Load Share Bus SMBAlert# Cold Redundancy Bus Return Sense...

  • Page 27: Efficiency

    ® Intel Server Chassis H2000 Family TPS Power Sub-System ® The power supply must meet the power factor requirements stated in the Energy Star Program Requirements for Computer Servers. These requirements are stated below. Table 13. Typical power factor 10% load...

  • Page 28: Ac Line Dropout/Holdup

    Power Sub-System Intel Server Chassis H2000 Family TPS The power supply must meet the inrush requirements for any rated AC voltage, during turn on at any phase of AC voltage, during a single cycle AC dropout condition as well as upon recovery after AC dropout of any duration, and over the specified temperature range (T 3.2.6...

  • Page 29: Electrostatic Discharge Susceptibility

    ® Intel Server Chassis H2000 Family TPS Power Sub-System a cage with an external EMI filter, which meets the criteria, defined in the SSI document EPS Power Supply Specification. For further information on customer standards please request a copy of the customer Environmental Standards Handbook.

  • Page 30: Power Recovery

    ® Power Sub-System Intel Server Chassis H2000 Family TPS voltage dropping below nominal voltage conditions. “Surge” will be defined to refer to conditions when the AC line voltage rises above nominal voltage. The power supply shall meet the requirements under the following AC line sag and surge conditions.

  • Page 31: Ac Power Inlet

    ® Intel Server Chassis H2000 Family TPS Power Sub-System used. In addition the insulation system must comply with reinforced insulation per safety standard IEC 950. Separation between the primary and secondary circuits, and primary to ground circuits, must comply with the IEC 950 spacing requirements.

  • Page 32: Standby Output

    ® Power Sub-System Intel Server Chassis H2000 Family TPS must provide 4.0A with two power supplies in parallel. The power supply fan is allowed to run in standby mode for loads > 1.5A. Peak combined power for all outputs shall not exceed 1600W (for 1200W PSU) and 2100W (for 1600W PSU) Length of time peak power can be supported is based on thermal sensor and assertion of the SMBAlert# signal.

  • Page 33: Capacitive Loading

    ® Intel Server Chassis H2000 Family TPS Power Sub-System Note: For dynamic condition +12V min loading is 1A. 3.3.5 Capacitive Loading The power supply must be stable and meet all requirements, with the following capacitive loading conditions. Table 22. Capacitive Loading Conditions...

  • Page 34: Closed Loop Stability

    ® Power Sub-System Intel Server Chassis H2000 Family TPS 3.3.8 Closed Loop Stability The power supply shall be unconditionally stable under all line/load/transient load conditions including capacitive load ranges specified in section 3.3.5. A minimum of: 45 degrees phase margin and -10dB-gain margin is required. The power supply manufacturer shall provide proof of the unit’s closed-loop stability with local sensing through the submission of Bode plots.

  • Page 35: Forced Load Sharing

    ® Intel Server Chassis H2000 Family TPS Power Sub-System latching mechanism to prevent insertion and extraction of the power supply when the AC power cord is inserted into the power supply. 3.3.14 Forced Load Sharing The +12V output will have active load sharing. The output will share within 10% at full load. The failure of a power supply should not affect the load sharing or output voltages of the other supplies still operating.

  • Page 36: Power Supply Cold Redundancy Support

    ® Power Sub-System Intel Server Chassis H2000 Family TPS Item Description Min. Max. Units Delay from PWOK de-asserted to output voltages dropping out pwok_off of regulation limits. Duration of PWOK being in the de-asserted state during an pwok_low off/on cycle using AC or the PSON signal.

  • Page 37: 1200W Crps Cold Redundancy

    ® Intel Server Chassis H2000 Family TPS Power Sub-System Standby state. Each power supply has an additional signal that is dedicated to supporting Cold Redundancy; CR_BUS. This signal is a common bus between all power supplies in the system. CR_BUS is asserted when there is a fault in any power supply OR the power supplies output voltage falls below the Vfault threshold.

  • Page 38: 1600W Crps Cold Redundancy

    ® Power Sub-System Intel Server Chassis H2000 Family TPS 3.4.2 1600W CRPS Cold Redundancy If the output power is less than 640W (40%). the Cold redundant function will be enable. Thus you will see one PSU working normal. The second PSU will be CR mode. The Power Supply LED is green blinking.

  • Page 39: Smbalert# Signal

    ® Intel Server Chassis H2000 Family TPS Power Sub-System delay time shall inhibited as long as any power supply output is in current limit. Table 28. PWOK Signal Characteristics Signal Type PWOK = High Power OK PWOK = Low Power Not OK Logic level low voltage, Isink=400uA 0.4V...

  • Page 40: Protection Circuits

    ® Power Sub-System Intel Server Chassis H2000 Family TPS Sink current, Alert# = low 4 mA 50 µA Sink current, Alert# = high 100 µs Alert# rise and fall time Protection circuits Protection circuits inside the power supply shall cause only the power supply’s main outputs to shut down.

  • Page 41: Pmbus

    ® Intel Server Chassis H2000 Family TPS Power Sub-System cooling or excessive ambient temperature. In an OTP condition the PSU will shut down. When the power supply temperature drops to within specified limits, the power supply shall restore power automatically, while the 12VSB remains always on. The OTP circuit must have built in margin such that the power supply will not oscillate on and off due to temperature recovering condition.

  • Page 42: Accuracy

    ® Power Sub-System Intel Server Chassis H2000 Family TPS For redundant systems there are two signals to set the address location of the power supply once it is installed in the system; Address0 and Address1. For non-redundant systems the power supply device address locations should align with the Address0/Address1 location of 0/0.

  • Page 43: Power Management Policy

    ® Intel Server Chassis H2000 Family TPS Power Sub-System Accuracy, +/-W PMBus Input power monitoring accuracy Accuracy, +/-% 6.0% 5.0% 4.0% 3.0% 2.0% 1.0% 0.0% Input power, W Figure 14. PMBus Monitoring Accuracy Power Management Policy ® When working with Intel Server Board S2600JF, the BMC on each node will monitor its fans and temperature for critical failures.
  • Page 44 ® Power Sub-System Intel Server Chassis H2000 Family TPS Redundant Mode work normally. With BIOS setting “server management - shutdown policy” set to “disable” all nodes in the system may be throttled to maintain power. This may cause lower performance.

  • Page 45: Cooling Sub-System

    Intel® Server Chassis H2000 Family TPS Cooling Sub-System Cooling Sub-System The chassis cooling system contains the fan cooling sub-system of each node tray and common fan cooling in the power supply units. Both node fans and PSU fans work together as thermal solution to the chassis.

  • Page 46: Hard Disk Drive Support

    Below are hard disk drive distribution schemes on different SKUs of H2000 chassis family. Figure 15. HDD Scheme for H2312xx Figure 16. HDD Scheme for H2216xx Note: Replace the faulty drive only with one from the same manufacturer with the same model and capacity.

  • Page 47: Hard Drive Carrier

    ® Intel Server Chassis H2000 Family TPS Hard Disk Drive Support Hard Drive Carrier There are two types of HDD carriers for two chassis SKUs respectively: Figure 17. 3.5" HDD Assembly Overview Figure 18. 2.5" HDD Assembly Overview Hot-swap drive carriers make insertion and extraction of the drive from the system very simple.

  • Page 48: Backplane Feature Set

    ® Hard Disk Drive Support Intel Server Chassis H2000 Family TPS Each compute node in the system has dedicated Hot Swap Controller (HSC) to manage three or four HDDs. There are totally four sets of independent Programmable System On Chip (PSOC) on the backplane, to function as HSC respectively to four compute nodes.

  • Page 49: 3.5" Hot Swap Backplane Connector Scheme

    ® Intel Server Chassis H2000 Family TPS Hard Disk Drive Support Figure 19. Passive Backplane Block Diagram (for one node) 5.3.3 3.5" Hot Swap Backplane Connector scheme The following diagrams show the layout of major components and connectors for 3.5" Hot Swap backplane.

  • Page 50: 2.5" Hot Swap Backplane Connector Scheme

    ® Hard Disk Drive Support Intel Server Chassis H2000 Family TPS 20-pin Front Panel cable connector for Node 2, 4 2Blade Compute Node Power connector for Node 4 2x40 pin Bridge Board connector for Node 4 2x9 pin Power supply input connector...

  • Page 51: Figure 22. 2.5" Backplane Component And Connectors (Front View)

    ® Intel Server Chassis H2000 Family TPS Hard Disk Drive Support SATA/SAS connectors for Node 1 SATA/SAS connectors for Node 2 SATA/SAS connectors for Node 3 SATA/SAS connectors for Node 4 Figure 22. 2.5" Backplane Component and Connectors (Front View)

  • Page 52: Backplane Led Support

    ® Hard Disk Drive Support Intel Server Chassis H2000 Family TPS 5.3.5 Backplane LED Support The backplanes support both HDD online and activity/fault LEDs for each of the hard drive connectors. A light duct in HDD tray is used to conduct LED light to front panel. The following lists LED functionality.

  • Page 53: Backplane Connector Definition

    ® Intel Server Chassis H2000 Family TPS Hard Disk Drive Support 5.3.6 Backplane Connector Definition The backplanes include several different connectors. This section defines the purpose and pin out associated with each. 1. 2x9 Pin Power Input Connector The backplane is powered by +12V and +12V from PDB of CRPS.

  • Page 54: Table 39. 2X40 Pin Connector Pin-Out For Node Bridge Board

    ® Hard Disk Drive Support Intel Server Chassis H2000 Family TPS Upper Blade (Circuit 2) P12V P12V P12V P12V P12V P12V P12V P12V 3. 2x40 Pin Bridge Board Connector The Compute Node provides four SATA/SAS ports (in SCU0) to backplane, together with front panel control signals and SMBus.
  • Page 55 ® Intel Server Chassis H2000 Family TPS Hard Disk Drive Support Signal Description Signal Description SMBUS_R1 CLK FP Health LEDG_N FP PWR LED_N SMBUS_R5 DATA FP ID LED_N SMBUS_R5 CLK FP ID BTN_N FP RST BTN_N SMBUS_R7 DATA FP PWR BTN_N...

  • Page 56: Table 40. Front Panel Connector Pin-Out

    ® Hard Disk Drive Support Intel Server Chassis H2000 Family TPS 4. 20-Pin Front Panel Connector The backplanes provide connectors for front panel control signals. Each connector integrates the control signals of two compute nodes. Table 40. Front Panel Connector Pin-out...

  • Page 57: Table 41. Power Supply Control Connector Pin-Out

    ® Intel Server Chassis H2000 Family TPS Hard Disk Drive Support Table 41. Power Supply Control Connector Pin-out Signal Description Signal Description SMBUS_R7_DATA SMBUS_R7_CLK PSON_N PMBUS_ALERT_N 12V RS_RTN PWROK 12V RS Reserved PDU1-12VSB PDU1-12VSB PDU2-12VSB PDU2-12VSB Reserved Revision 1.5 Intel order number: G59059-006...

  • Page 58: Front Panel Control And Indicators

    ® The Intel Server Chassis H2000 family Front Control Panel is integrated with rack handles at the both sides of the chassis. Each control panel contains two sets of node control buttons and status LEDs. The control panel assembly is pre-assembled and fixed with the rack handles.

  • Page 59: Control Panel Button

    ® Front Panel Control and Indicators Intel Server Chassis H2000 Family TPS Figure 25. Front Control Panel Control Panel Button The following table lists the control panel features and functions. The control panels features a system power button. Table 42. Front Control Button Function...

  • Page 60: Power/Sleep Led

    ® Intel Server Chassis H2000 Family TPS Front Panel Control and Indicators Notes: Blink rate is ~1 Hz at 50% duty cycle. It is also off when the system is powered off (S5) or in a sleep state (S1). The power LED sleep indication is maintained on standby by the chipset. If the system is powered down without going through the BIOS, the LED state in effect at the time of power off is restored when the system is powered on until the BIOS clear it.
  • Page 61 ® Front Panel Control and Indicators Intel Server Chassis H2000 Family TPS Color State Criticality Description Green Blink Degraded BIOS detected Unable to use all of the installed memory (more than one DIMM installed). In a mirrored configuration, when memory mirroring takes place and system loses memory redundancy.

  • Page 62: System Status Led - Bmc Initialization

    ® Intel Server Chassis H2000 Family TPS Front Panel Control and Indicators 6.2.3 System Status LED – BMC Initialization When power is first applied to the system and 5V-STBY is present, the BMC controller on the server board requires 15-20 seconds to initialize. During this time, the system status LED will be solid on, both amber and green.

  • Page 63: Appendix A: Integration And Usage Tips

    ® Intel Server Chassis H2000 Family TPS Appendix A: Integration and Usage Tips Appendix A: Integration and Usage Tips Before attempting to integrate and configure your system, you should reference this section, which provides a list of useful information. ...

  • Page 64: Glossary

    ® Intel Server Chassis H2000 Family TPS Glossary Glossary Term Definition ACPI Advanced Configuration and Power Interface Application Processor APIC Advanced Programmable Interrupt Control ASIC Application Specific Integrated Circuit ASMI Advanced Server Management Interface BIOS Basic Input/Output System BIST Built-In Self Test...
  • Page 65 ® Glossary Intel Server Chassis H2000 Family TPS Term Definition Internet Protocol IPMB Intelligent Platform Management Bus IPMI Intelligent Platform Management Interface Infrared In-Target Probe 1024 bytes Keyboard Controller Style Local Area Network Liquid Crystal Display Light Emitting Diode Low Pin Count...
  • Page 66 ® Intel Server Chassis H2000 Family TPS Glossary Term Definition SEEPROM Serial Electrically Erasable Programmable Read-Only Memory System Event Log Server Input/Output Server Management Interrupt (SMI is the highest priority non-maskable interrupt.) Server Management Mode Server Management Software SNMP Simple Network Management Protocol...

  • Page 67: Reference Documents

    Node Power and Thermal Management Architecture Specification v1.5, rev.0.79. 2007, Intel Corporation.  ® Intel Server System Integrated Baseboard Management Controller Core External Product Specification, 2007 Intel Corporation.  ® Intel Thurley Server Platform Services IPMI Commands Specification, 2007. Intel Revision 1.5 Intel order number: G59059-006...
  • Page 68 Server Chassis H2000 Family TPS Reference Documents Corporation.  ® Intel Server Safety and Regulatory, 2011. Intel Corporation. (Intel Order Code: G23122)  Intelligent Platform Management Bus Communications Protocol Specification, Version 1.0, 1998. Intel Corporation, Hewlett-Packard* Company, NEC* Corporation, Dell* Computer Corporation.
