- Page 1 LX1200TI Touch Monitor USER’S GUIDE www.planar.com...
- Page 2 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced, translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, with- out prior written permission.
-
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions ...5 In a Vehicle ...5 Cleaning the Monitor ...5 Introduction About the Product ...6 Front View ...6 Bottom View ...8 Features ...9 Package Overview ... 10 Installation Before Installing ... 11 Step 1 - Mounting the Monitor ... 12 Step 2 - IRtouch Install ...13 Step 3 - Connecting the Monitor ... - Page 4 Video Specifi cations ... 23 Electrical Specifi cations ... 23 Electromagnetic Compatibility (EMC) ... 24 Immunity Characteristics ... 24 Safety ... 24 Environmental Specifi cations ... 25 Connectors ... 25 Addendum A ... 27 Support and Service ... 29 LX1200TI User’s Guide (020-0512-01A)
-
Page 5: Usage Notice
Usage Notice WARNING – To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. WARNING – Please do not open or disassemble the product as this may cause electric shock. Doing so will void the warranty. ATTENTION –... -
Page 6: Introduction
Introduction About Planar’s LX1200TI Touch Monitor The LX1200TI, is a high-performance, rugged touch monitor intended for demanding environments, such as those inside motor vehicles. The monitor features a 12.1-inch diagonal liquid crystal display, with XGA resolution, bright enough to be read in full sunlight. The monitor also includes stereo speakers and a sturdy magnesium enclosure that can withstand shock and vibration. - Page 7 Front View (Descriptions): 1. 12.1-inch diagonal XGA screen size. 2. Programmable SoftKeys 3. Volume control 4. “All in one” power button - controls power to the remote computer 5. USB port (Type A, accessible from the front) for connecting a peripheral device (a second connection is on the back) 6.
-
Page 8: Bottom View
Bottom View: Bottom View (Descriptions): 1. Brightness control dial 2. USB port (Type A, accessible from the front) for connecting a peripheral device 3. Volume control dial 4. Speaker (on each side) 5. USB port (Type A, accessible from the front) for connecting a peripheral device 6. -
Page 9: Features
Features • The brightness control allows you to easily adjust the display to match the ambient light, from full sunlight to night, even while wearing gloves. Its convenient dial design also enables you to quickly adjust the brightness. • The monitor’s transfl ective display uses refl ected light from the environment - even direct sunlight - to provide a bright image that can be easily viewed under any lighting conditions. -
Page 10: Package Overview
Package Overview The following items are shipped with the display. If any of these items are not in the shipping container, please contact Planar. LX1200 Touch Monitor Power Input Cable Quick Start Guide SoftKey Software and Touchscreen Driver Installation CD Note: Mounting hardware (4 M4 x .7mm Screws), power supply and... -
Page 11: Installation
Installation Before Installing Keep the following in mind while installing the monitor. • The monitor should be visible to the driver only if it is used for navigation, system control or vehicle information. If the monitor will be used for other purposes, it should be installed in such a way that it will only operate while the vehicle is not moving (such as when the parking brake is in use). -
Page 12: Step 1 - Mounting The Monitor
2. Attach the monitor to the fi xture using the attachments on the back of the monitor, shown in the following diagram. Note: Use only a Planar-approved mounting bracket for in-vehicle use. Mounting bracket and hardware are not included with the monitor, and must be obtained separately. -
Page 13: Step 2 - Irtouch Install
Step 2 - IRtouch Install Do not plug in the touchscreen yet! Install the driver fi rst. 1. Run IRtouch driver setup from the LX1200TI CD 2. Accept user agreement 3. Install in default location LX1200TI User’s Guide (020-0512-01A) - Page 14 5. Click continue, you can trust Planar and IRtouch 6. Click on Finish Attach the Planar monitor to the system or install the computer to a docking station. After the USB cable from the Planar LX1200TI is attached to the computer it will recognize the touchscreen for the fi rst time.
- Page 15 7. Continue 8. Click Finish 9. Click the IRtouch icon located on your desktop to calibrate the touch monitor. 10. Click Calibrate LX1200TI User’s Guide (020-0512-01A)
- Page 16 11. Set Modes When used in rugged environments with software written for touchscreens, you may fi nd it easier to use the ‘click on release’ radio button. 12. Beep You can set the computer to beep on touch activation if needed. LX1200TI User’s Guide (020-0512-01A)
-
Page 17: Step 3 - Connecting The Monitor
Step 3 - Connecting the Monitor Once the LX1200TI is mounted in place, connect it to the computer (or other video source) and the 12 VDC power supply as follows. Note: This procedure refers to connections to and from the computer. However, depending on your particular hardware confi guration, these connections may be to a dock or other device rather than directly to the computer. - Page 18 Note: If needed, connect an audio cable to the audio port on the monitor, and to the headphone or audio line output connector on the computer. If an external keyboard or other USB device will be used with the monitor, plug it into either of the monitor’s Type A USB connectors. Two USB devices can be connected to the monitor.
-
Page 19: User Controls Front Panel Controls
User Controls Front Panel Controls Softkeys Volume Control CONTROL Volume Control Dial Power Button Power Indicator LED Brightness Control Dial Display On/Off Button Autosync Remote PC Shutdown/ Start Button Softkey Button Power Button Brightness/Backlight Control FUNCTION Increases and decreases the volume of the display Turns the connected computer on and off - see page 20 for details. -
Page 20: Turning The Monitor On And Off
Turning the Monitor On and Off The monitor’s power button controls power to the computer. The monitor itself turns its display on and off according to whether it is receiving a video signal. • To turn on the computer, press the remote PC shutdown/start button on the front of the monitor. -
Page 21: Cleaning The Monitor
Cleaning the Monitor Clean the monitor’s touchscreen periodically to keep the display image bright and sharp, and to keep the touchscreen functions working properly. • Always turn off the monitor before cleaning. • Clean the touchscreen only with a dry soft cloth. If this does not clean the screen adequately, use water or mild glass or window cleaner (that does not contain ammonia) applied to the cloth and not to the display. -
Page 22: Appendix
Appendix Troubleshooting the Monitor If you are experiencing trouble with the LX1200TI monitor, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen • Make sure the brightness is not turned all the way down. •... -
Page 23: Specifi Cations
Specifi cations Dimensions • Size: 313mm (12.3”) • Screen Size: 12.1-inch Diagonal • Weight: 5 kg maximum Video Specifi cations • Input: Standard VGA (15-pin Analog) • Resolution: XGA (1024 x 768), supports SVGA (800 x 600) and VGA (640 x 480) •... -
Page 24: Electromagnetic Compatibility (Emc)
Electromagnetic Compatibility (EMC) • ESD, 6 kV contact and 8 kV air discharge • Emissions • 47 CFR. Part 15, Subpart B, Class B - Conducted and Radiated Tests • CE EMC Directive 89/336/EEC • EN55022:1998+A1:2000+A2:2003; Class B Conducted & Radiated Test •... -
Page 25: Environmental Specifi Cations
Environmental Specifi cations Temperature • Operating: -20° to 60° C • Operating Survival: -25° to 65° C • Storage: -20° to +70° C Humidity • Operating: 5 to 90% RH, 40° C, non-condensing • Non-operating: 5 to 93% RH, non-condensing Altitude •... - Page 26 • J5: DC Power Input • Chassis-mounted, two-pin connector (Molex Mini Fit Jr., Header 5569 Molex part number 39-30-0020) • The table below lists the connector’s pin assignments, and the fi gure below shows the physical layout as seen by the interface cable from the DC power source.
-
Page 27: Addendum A
BUTTON INITIAL KEY MAPPING The Planar softkey software will allow the user to remap those keys to any other single keys, combination of keys, or launch a program from the buttons on the front of the LX1200TI monitor. Softkey Install Guide 1. - Page 28 Windows notifi cation area, and on the start menu. The software will install with a default confi guration. 4. There is a screen keyboard that can be activated by right clicking on the Planar Logo in the Windows information tray. LX1200TI User’s Guide (020-0512-01A)
-
Page 29: Support And Service
