Audio Adjustments

Using balance adjustment

You can select a fader/balance setting that provides an ideal listening environment in
all occupied seats.
1. Press AUDIO to select FAD.
Press AUDIO until FAD appears in the display.
• If the balance setting has been previously adjusted, BAL will be displayed.
2. Press 8 or 2 to adjust front/rear speaker balance.
Each press of 8 or 2 moves the front/rear speaker balance towards the front or the
rear.
FAD :F15 – FAD :R15 is displayed as the front/rear speaker balance moves from front
to rear.
• FAD : 0 is the proper setting when only two speakers are used.
• When the rear output setting is R-SP :S/W, you cannot adjust front/rear speaker
balance. Refer to "Setting the rear output and subwoofer controller" on page 29.
3. Press 4 or 6 to adjust left/right speaker balance.
When you press 4 or 6, BAL : 0 is displayed. Each press of 4 or 6 moves the left/
right speaker balance towards the left or the right.
BAL : L15 – BAL : R15 is displayed as the left/right speaker balance moves from left
to right.

Using the equalizer

The equalizer lets you adjust the equalization to match car interior acoustic
characteristics as desired.

Recalling equalizer curves

There are six stored equalizer curves which you can easily recall at any time. Here is
a list of the equalizer curves:
Display Equalizer curve
SUPER BASS Super bass
POWERFUL Powerful
NATURAL Natural
VOCAL Vocal
CUSTOM Custom
EQ FLAT Flat
• CUSTOM is an adjusted equalizer curve that you create. If you make adjustments
to an equalizer curve, the equalizer curve setting will be memorized in CUSTOM.
• When EQ FLAT is selected no supplement or correction is made to the sound. This
is useful to check the effect of the equalizer curves by switching alternatively
between EQ FLAT and a set equalizer curve.
* Press EQ to select the equalizer.
Press EQ repeatedly to switch between the following equalizers:
SUPER BASS – POWERFUL – NATURAL – VOCAL – CUSTOM – EQ FLAT

Adjusting equalizer curves

You can adjust the currently selected equalizer curve setting as desired. Adjusted
equalizer curve settings are memorized in CUSTOM.
1. Press AUDIO to select EQ.
Press AUDIO until EQ appears in the display.
2. Press 4 or 6 to select the equalizer band to adjust.
Each press of 4 or 6 selects equalizer bands in the following order:
EQ-L (low) – EQ-M (mid) – EQ-H (high)
3. Press 8 or 2 to adjust the level of the equalizer band.
Each press of 8 or 2 increases or decreases the level of the equalization band.
+6 – –6 is displayed as the level is increased or decreased.
• You can then select another band and adjust the level.
Note
• If you make adjustments, CUSTOM curve is updated.
