IMPORTANT
READ THIS INSTRUCTION MANUAL
CAREFULLY
before attempting to operate the
transceiver.
SAVE THIS INSTRUCTION MANUAL.
manual contains important safety and operating in-
structions for the IC-M802.
PRECAUTIONS
R WARNING HIGH VOLTAGE! NEVER
tach an antenna or internal antenna connector during
transmission. This may result in an electrical shock or
burn.
R WARNING! NEVER
an AC outlet directly. This may pose a fire hazard or
result in an electric shock.
R WARNING! NEVER
(main unit) overhead. The weight of the transceiver is
approximately 8 kg, but its apparent weight will in-
crease several fold due to wave shocks or vibration.
The transceiver must be mounted on a flat hard sur-
face only.
R NEVER
connect a power source of more than
16 V DC, such as a 24 V battery. This connection
could cause a fire or ruin the transceiver.
R NEVER
place the transceiver where normal oper-
ation of the ship or vehicle may be hindered or where it
could cause bodily injury.
R NEVER
let metal, wire or other objects touch any
internal part or connectors on the rear panel of the
transceiver. This may result in an electric shock.
R NEVER
expose the transceiver to rain, snow or
any liquids.
i
This
at-
connect the transceiver to
mount the transceiver

EXPLICIT DEFINITIONS

WORD
Personal injury, fire hazard or electric
R R WARNING
shock may occur.
CAUTION Equipment damage may occur.
If disregarded, inconvenience only. No
risk or personal injury, fire or electric
NOTE
shock.
DO NOT use chemical agents such as benzine or al-
cohol when cleaning, as they can damage the trans-
ceiver surface.
During maritime mobile operation, KEEP the trans-
ceiver and microphone as far away as possible (at
least 1 m; 3 ft) from the magnetic navigation compass
to prevent erroneous indications.
Use Icom microphones and/or headset only (supplied
or optional). Other manufacturer's microphones and/or
headset have different pin assignments, and connec-
tion to the IC-M802 may damage the transceiver.
AVOID using or placing the transceiver in areas with
temperatures below –20°C (–4°F) or above +60°C
(+140°F).
AVOID placing the transceiver in excessively dusty en-
vironments or in direct sunlight.
AVOID placing the transceiver against walls or putting
anything on top of the transceiver. This will obstruct
heat dissipation.
Place unit in a secure place to avoid inadvertent use
by children.
BE CAREFUL! The heatsink will become hot when op-
erating the transceiver continuously for long periods.
Icom, Icom Inc. and the
Icom Incorporated (Japan) in the United States, the United
Kingdom, Germany, France, Spain, Russia and/or other
countries.
DEFINITION
are registered trademarks of
