Dashboard Fuse Box - Alfa Romeo 4C Owner's Manual

174 IN CASE OF EMERGENCY
Cavity
F83 40 Amp Orange
F84
F86
F88

Dashboard Fuse Box

The dashboard fuse box is part of the Body Control
Module (BCM) and is located on the passenger side
Vehicle Fuse Num-
Cavity
ber
3 F53
4 F38
5 F36
6 F43
7 F48
9 F50
10 F51
11 F37
Maxi Fuse
–
–
–
Mini Fuse
7.5 Amp Brown
15 Amp Blue
10 Amp Red
20 Amp Yellow
20 Amp Yellow
7.5 Amp Brown
7.5 Amp Brown
7.5 Amp Brown
Mini Fuse
– Alfa Twin Clutch Transmission Pump
5 Amp Tan After Run Pump
15 Amp Blue Rear Power Outlet 12V
7.5 Amp Brown Heated Mirrors
under the forward passenger floor. Remove the six
screws and the forward floor pan to access the BCM.
Instrument Panel Node
Central Door Locking
Diagnostic Socket, Vehicle Radio, TPMS, Alarm
Bi-Directional Washer
Passenger Power Window
Airbag
Headlamp Washer Relay, A/C Compressor Relay,
High Beam Relay, Parking ECU, Vehicle Radio,
Stop Lamp Switch
Stop Light Switch, Instrument Panel Node
Description
Description
