  • Page 1 2 0 1 5 A l p i n e ® R a d i o O W N E R ’ S S U P P L E M E N T...

  • Page 2: Safety Guidelines 3

    TABLE OF CONTENTS SECTION PAGE SAFETY GUIDELINES ............3 GETTING STARTED .

  • Page 4: Safety Guidelines

    SAFETY GUIDELINES CONTENTS WARNING ......4...
  • Page 5 4 SAFETY GUIDELINES WARNING WARNING This symbol means important instructions. Failure to WARNING! heed them can result in serious injury or death. DO NOT OPERATE ANY FUNCTION THAT TAKES Driving while distracted can result in loss of YOUR ATTENTION AWAY FROM SAFELY DRIVING vehicle control, accident and injury.
  • Page 6 SAFETY GUIDELINES 5 accident. LISTENING AT LOUD VOLUME LEVELS IN A DO NOT BLOCK VENTS OR RADIATOR PANELS. CAR MAY ALSO CAUSE HEARING DAMAGE. Doing so may cause heat to build up inside and may DO NOT DISASSEMBLE OR ALTER. result in fire.
  • Page 7 6 SAFETY GUIDELINES HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Moisture Condensation Failure to do so may cause personal injury or damage to You may notice the CD playback sound wavering due to the product. Return it to your authorized Alpine dealer condensation.
  • Page 8 SAFETY GUIDELINES 7 Never Attempt the Following Inserting Discs Do not grip or pull out the disc while it is being pulled Your player accepts only one disc at a time for playback. back into the player by the automatic reloading mecha- Do not attempt to load more than one disc.
  • Page 9 8 SAFETY GUIDELINES the inside of the center hole and outside edge of the disc. Irregular Shaped Discs If you feel any small bumps or irregularities, this could Be sure to use round discs only for this unit and never inhibit proper loading of the disc.
  • Page 10 SAFETY GUIDELINES 9 Installation Location Correct Handling Ensure this unit will not be installed in a location Do not drop the disc while handling. Hold the disc so subjected to: you will not leave fingerprints on the surface. Do not affix tape, paper, or gummed labels to the disc.
  • Page 11 10 SAFETY GUIDELINES Disc Cleaning Disc Accessories Fingerprints, dust, or soil on the surface of the disc could There are various accessories available on the market for cause the CD player to skip. For routine cleaning, wipe protecting the disc surface and improving sound quality. the playing surface with a clean, soft cloth from the center However, most of them will influence the thickness and/or of the disc to the outer edge.
  • Page 12 SAFETY GUIDELINES 11 • Finalize the CD-R/CD-RW if necessary, and attempt On handling Compact Discs (CD/CD-R/CD-RW) playback again. • Do not touch the surface. About media that can be played • Do not expose the disc to direct sunlight. Use only compact discs with the label side showing the •...
  • Page 13 12 SAFETY GUIDELINES • ROM data other than audio files contained in a disc If you use unspecified compact discs, correct perfor- mance cannot be guaranteed. will not produce sound when played back. You can play CD-Rs (CD-Recordables)/CD-RWs (CD- Protecting the USB connector ReWritables) which have been recorded only on audio •...
  • Page 14 SAFETY GUIDELINES 13 • Artist/song name, etc., can be displayed. Certain, • Fix the Flash Memory in a location where driver special characters may not be correctly displayed. operation will not be hindered. • Flash Memory may not function correctly at high or On Handling Flash Memory low temperature.
  • Page 15 14 SAFETY GUIDELINES • Flash Memory may take time to start playback. If there • Windows Media and the Windows logo are trade- is a particular file other than audio in the Flash marks, registered trademarks Microsoft Memory, it may take considerable time before the file Corporation in the United States and/or other coun- is played back or searched.
  • Page 16 SAFETY GUIDELINES 15 • The BLUETOOTH® word mark and logos are regis- • HD Radio Technology manufactured under license tered trademarks owned by the Bluetooth SIG, Inc. and from iBiquity Digital Corporation. U.S. and Foreign any use of such marks by Alpine Electronics, Inc. is Patents.

  • Page 18: Table Of Contents

    GETTING STARTED CONTENTS ▫ Adjusting Volume ..... .22 GETTING STARTED..... .18 ▫...

  • Page 19: Getting Started

    18 GETTING STARTED GETTING STARTED WARNING! Driving while distracted can result in loss of vehicle control, accident and injury. It is strongly recommended that you use extreme caution when using any device or feature that may take your focus off the road or your hands off the steering wheel.

  • Page 20: Turning Power On And Off

    GETTING STARTED 19 Turning Power On and Off Source Selection Press to turn on the unit. Press /SOURCE to change the source. HD Radio → SiriusXM*1 → Disc → USB/iPod*2 → NOTE: BLUETOOTH Audio*3 → PANDORA*4 → Auxiliary*5 → • The unit can be turned on by pressing any other button HD Radio except *1 Displayed only when a SiriusXM Tuner is connected.

  • Page 21: Detaching And Attaching The Front Panel

    20 GETTING STARTED Detaching And Attaching The Front Panel 3. Grasp the front panel firmly, slide to the left (1), and then pull to remove (2). Detaching 1. Turn off the unit power. 2. Press (OPEN) to open the front panel To close the front panel, press the left side until it locks.
  • Page 22 GETTING STARTED 21 • To protect the front panel, place it in the supplied carrying case. • When detaching the front panel, do not apply exces- sive force as it may result in a malfunction. • Do not leave the front panel open, or drive the car with the panel open as it may result in an accident or malfunction.

  • Page 23: Initial System Start-Up

    22 GETTING STARTED Initial System Start-Up Be sure to press the RESET switch when using the unit for the first time, after changing the car battery, etc. 1. Turn off the unit power. 2. Press (OPEN) to open the front panel, and then remove it.

  • Page 24: Lowering Volume Quickly

    GETTING STARTED 23 Lowering Volume Quickly 5. Press /ENTER. Activating the Audio Mute function will instantly lower 6. Repeat steps 4 and 5 above to set month, date, hour the volume level by 20 dB. and minute. 1. Press MUTE to activate the MUTE mode. 7.

  • Page 25: Controllable With Remote Control

    24 GETTING STARTED Controllable With Remote Control Connectable to Remote Control Interface Box This unit can be controlled with an optional Alpine With an optional Alpine Steering Wheel Remote Control remote control. For details, consult your Alpine dealer. Interface Box, this unit is controllable from the vehicles Point the optional remote control transmitter at the steering wheel controls.
  • Page 26 HD RADIO CONTENTS ▫ Frequency Search Function....30 HD RADIO ......26 ▫...

  • Page 27: Hd Radio

    26 HD RADIO HD RADIO WARNING! Driving while distracted can result in loss of vehicle control, accident and injury. It is strongly recommended that you use extreme caution when using any device or feature that may take your focus off the road or your hands off the steering wheel.

  • Page 28: Listening To Radio

    HD RADIO 27 This unit is able to receive signals based on the terrestrial 2. Press BAND repeatedly until the desired radio band is digital radio broadcasting standard. displayed. FM1 → FM2 → AM → FM1 When current AM/FM broadcasters are transmitting digital audio and data services, HD Radio signals are 3.

  • Page 29: Presetting Stations Manually

    28 HD RADIO Manual mode: Presetting Stations Manually The frequency is manually tuned in steps (Manual tun- 1. Select the radio band and tune in a desired radio ing). station you wish to store in the preset memory. 4. Press to tune in the desired station.

  • Page 30: Presetting Stations Automatically

    HD RADIO 29 Presetting Stations Automatically Tuning To Preset Stations 1. Press BAND repeatedly until the desired radio band is 1. Press BAND repeatedly until the desired band is displayed. displayed. 2. Press and hold TUNE/A.ME for at least 2 seconds. 2.

  • Page 31: Frequency Search Function

    30 HD RADIO Frequency Search Function NOTE: • Press You can search for a radio station by its frequency. in the search mode to cancel. Or, the search mode will be canceled if no operation is performed 1. Press /ENTER in Radio mode to activate the for 60 seconds.
  • Page 32 HD RADIO 31 Receiving the Multicast Station Program Service. Program Service example: Multicast Radio Program No. Program Service Station 88.1 MHz Main Program Service 88.1 MHz Sub-program Service 88.1 MHz Sub-program Service 88.1 MHz 88.1 MHz 88.1 MHz 88.1 MHz 1 —...

  • Page 33: Multicast Station Search

    32 HD RADIO Multicast Station Search NOTE: • Press If a frequency has a Multicast station broadcast, the VIEW at step 4. You can change the display Multicast indicator lights up. Use the Multicast search between station name, song name, artist name and mode to select a desired program from the Multicast program type.
  • Page 34 HD RADIO 33 • When an iPod that doesn’t support the tagging func- If no iPod/iPhone is connected, “Tag Count X” is displayed (X is the total amount of the tag information tion is connected, “Non-Tagging iPod” may be stored in this unit). displayed.

  • Page 35: About The Feature Logos

    34 HD RADIO About The Feature Logos HSD2/HD3 ) • Adjacent to traditional main stations are extra local FM Digital Sound ) channels. These HD2/HD3 Channels provide new, • Digital, CD-quality sound. HD Radio Technology en- original music as well as deep cuts into traditional ables local radio stations to broadcast a clean digital genre.
  • Page 36 CD/MP3/WMA/AAC CONTENTS ▫ Folder/File Name Search (Concerning CD/MP3/WMA/AAC ....36 MP3/WMA/AAC) .....40 ▫...

  • Page 37: Cd/Mp3/Wma/Aac

    36 CD/MP3/WMA/AAC CD/MP3/WMA/AAC WARNING! Driving while distracted can result in loss of vehicle control, accident and injury. It is strongly recommended that you use extreme caution when using any device or feature that may take your focus off the road or your hands off the steering wheel.

  • Page 38: Playback

    CD/MP3/WMA/AAC 37 Playback NOTE: • When a disc is already inserted, press /SOURCE 1. Press (OPEN). to switch to the Disc mode. The front panel will open. 4. While playing back MP3/WMA/AAC, press Rewind 2. Insert a disc with the label side facing up. Forward to select the desired folder.

  • Page 39: Repeat Play

    38 CD/MP3/WMA/AAC NOTE: Repeat Play • Do not remove a CD during its eject cycle. Do not load 1. Press more than one disc at a time. A malfunction may result The song is played back repeatedly. from doing either. RPT*1 →...

  • Page 40: Random Play)

    CD/MP3/WMA/AAC 39 M.I.X. (Random Play) 1. Press /ENTER during play. This will set the search mode. 1. Press The songs are played back in random sequence. 2. Turn the Rotary encoder to select the desired track, and then press /ENTER. *1 →...

  • Page 41: Folder/File Name Search (Concerning Mp3/Wma/Aac)

    40 CD/MP3/WMA/AAC • Press Folder/File Name Search (Concerning in the search mode to return to the previous MP3/WMA/AAC) mode. • To search for files in the Folder Name Search mode, Folder and file names may be searched and displayed during playback. press /ENTER.

  • Page 42: Search Position Memory

    CD/MP3/WMA/AAC 41 • When File Name Search is made during M.I.X. play, File Name Search Mode the M.I.X. play mode will be canceled. 1. During MP3/WMA/AAC playback, press • If any one of the preset buttons (1 through 6) is pressed /ENTER to activate the search mode.

  • Page 43: About Mp3/Wma/Aac

    42 CD/MP3/WMA/AAC About MP3/WMA/AAC maintaining near CD quality. The MP3 format realizes such high compression ratios by eliminating the CAUTION! sounds that are either inaudible to the human ear or masked by other sounds. Except for private use, duplicating audio data What is WMA? (including MP3/ WMA/AAC data) or distributing, transferring, or copying it, whether for free or for...
  • Page 44 CD/MP3/WMA/AAC 43 MP3/WMA/AAC files that are playable on this device have the file extensions “mp3”/“wma”/“m4a”. Files Sampling rates: 48 kHz, 44.1 kHz, 32 kHz with no extension cannot be played back (WMA ver. 7 , Bit rates: 32 - 192 kbps 8 and 9 are supported).
  • Page 45 44 CD/MP3/WMA/AAC ID3 tags/WMA tags Playing back MP3/WMA/AAC This device supports ID3 tag v1 and v2, and WMA/ MP3/WMA/AAC files are prepared, then written to a AAC tag. If tag data is in an MP3/WMA/AAC file, CD-R, CD-RW using CD-R writing software or stored this device can display the title (track title), artist name, to a Flash Memory.
  • Page 46 CD/MP3/WMA/AAC 45 Corresponding File Systems Formats supported This device supports discs formatted with ISO9660 This device supports CD-ROM XA, Mixed Mode CD, Level 1 or Level 2. Under the ISO9660 standard, there Enhanced CD (CD-Extra) and Multi-Session. are some restrictions to remember. The maximum This device cannot correctly play back discs recorded nested folder depth is 8 (including the root directory).
  • Page 47 46 CD/MP3/WMA/AAC * The folder No./ folder Name will not be displayed if no file is contained in the folder.
  • Page 48 CD/MP3/WMA/AAC 47 Terminology Encoding Bit rate Converting music CDs, WAVE (AIFF) files, and other sound files into the specified audio compression format. This is the “sound” compression rate specified for encod- ing. The higher the bit rate, the higher the sound quality, but also the larger the files.
  • Page 50 SOUND SETTING CONTENTS ▫ About “Text” ......76 SOUND SETTING ..... . .50 ▫...

  • Page 51: Sound Setting

    50 SOUND SETTING SOUND SETTING Adjusting Subwoofer Level/Bass Level/Treble Level/Balance (Between Left And Right)/Fader (Between Front And Rear)/Defeat 1. Press AUDIO repeatedly to choose the desired mode. Each press changes the mode as follows: SubW LEVEL*1 → BASS*2 → TREBLE*2 → BALANCE →...

  • Page 52: Audio Setup

    SOUND SETTING 51 NOTE: Subwoofer Level 0 ~ 15 • By setting DEFEAT ON, previously adjusted level Bass Level −7 ~ 7 settings of BASS and TREBLE will return to the Treble Level −7 ~ 7 factory defaults. Balance −15 (L) ~ 15 (R) Audio Setup Fader −15 (R) ~ 15 (F)
  • Page 53 52 SOUND SETTING 2. Turn the Rotary Encoder to select Audio, and then *4 Any changes made to either Factory’s EQ or Para- press /ENTER. metric EQ are reflected in the others’ settings. Audio*1 ↔ General ↔ Display ↔ Tuner ↔ Siri- *5 In step 3, nine sound adjustment items can be usXM*2 ↔...
  • Page 54 SOUND SETTING 53 Equalizer Presets (Factory’s EQ) Adjusting The Parametric Equalizer Curve (Parametric EQ) 10 typical equalizer settings are preset at the factory for a variety of musical source material. User settings are You can modify the Equalizer settings to create a re- created in the Parametric EQ mode.
  • Page 55 54 SOUND SETTING Adjusting The Frequency (Freq.) Setting The Bandwidth (Q) Adjustable frequency bands: 20 Hz to 20 kHz Setting contents: 3.0 (Initial setting) / 4.0 / 5.0 Band 1 20 Hz ~ 100 Hz (63 Hz) NOTE: Band 2 63 Hz ~ 315 Hz (125 Hz) •...
  • Page 56 SOUND SETTING 55 • The Parametric EQ is used to create the Factory’s EQ Adjusting The Level settings. Setting contents: Setting The Source Volume Level -7 to +7 (Initial setting: 0) The output level of each source is individually adjustable. NOTE: For example, if the Tuner level sounds lower than Disc, •...
  • Page 57 56 SOUND SETTING • Setting item: Subwoofer Phase Turning Subwoofer ON/OFF When the subwoofer is on, you can adjust the subwoofer Setting contents: output level (refer to “Adjusting Subwoofer Level/Bass 0° (Initial setting) / 180° Level/Treble Level/Balance (Between Left and Right)/ Setting The Subwoofer System Fader (Between Front and Rear)/Defeat”...
  • Page 58 SOUND SETTING 57 Setting The Media Xpander Mode (MX Setup) Customizing The Media Xpander Setting MX (Media Xpander) makes vocals or instruments sound If Customize is selected in step 2, you can modify the distinct regardless of the music source. The CD and iPod, Media Xpander to suit your personal preference.
  • Page 59 58 SOUND SETTING Setting contents: 2. Turn the Rotary Encoder to adjust the distance of the selected speaker, and then press /ENTER. cm (Initial setting) / inch 0.0 cm to 336.6 cm (3.4 cm/step) cm: Time correction value is in centimeters. 0.0 inch to 132.7 inch (1.3 inch/step) inch: Time correction value is in inches.
  • Page 60 SOUND SETTING 59 Adjusting SPATIAL Adjusting The Crossover Settings (X-Over) This function allows you to change the sound field easily. Before performing the following procedures, refer to There are three modes to choose from. For details, refer to “About the Crossover” on page 68. the table below.
  • Page 61 60 SOUND SETTING Selecting The Cut-Off Frequency (Freq.) 1. The Parametric EQ/T.Correction/X-OVER settings can be stored in any one of the preset buttons (1 Setting contents: through 6). After completing any adjustment for Para- 20 / 25 / 31.5 / 40 / 50 / 63 / 80 (Initial setting) / metric EQ/ T.Correction/X-OVER (e.g.

  • Page 62: About Time Correction

    SOUND SETTING 61 • While perform this operation, all adjusted contents of adjusted contents Parametric Parametric EQ/ T.Correction and X-Over will be T.Correction/X-Over stored into the preset button will stored in the preset buttons. be demonstrated. • The stored contents are not deleted even when reset- 2.
  • Page 63 62 SOUND SETTING Listening Position example as follows in this section: Example 1: Front Left Seat Adjust the time correction level of the front left speaker to a high value and the rear right to zero or a low value. 1 —...
  • Page 64 SOUND SETTING 63 Conditions: Example 2: All Seats Farthest Speaker - listening position : 2.25 m (88-9/16 ) Adjust the time correction level of each speaker to almost the same level. Front left speaker - listening position : 0.5 m (19-11/16 ) 1.
  • Page 65 64 SOUND SETTING Time Correction Value List Delay Time Distance Distance Number Difference (cm) (inch) Delay Time Distance Distance (ms) Number Difference (cm) (inch) 37.4 14.7 (ms) 40.8 16.1 44.2 17.4 47.6 18.8 51.0 20.1 10.2 54.4 21.4 13.6 57.8 22.8 17.0 61.2...
  • Page 66 SOUND SETTING 65 Delay Time Distance Distance Delay Time Distance Distance Number Difference (cm) (inch) Number Difference (cm) (inch) (ms) (ms) 81.6 32.2 125.8 49.6 85.0 33.5 129.2 50.9 88.4 34.8 132.6 52.3 91.8 36.2 136.0 53.6 95.2 37.5 139.4 54.9 98.6 38.9...
  • Page 67 66 SOUND SETTING Delay Time Distance Distance Delay Time Distance Distance Number Difference (cm) (inch) Number Difference (cm) (inch) (ms) (ms) 170.0 67.0 214.2 84.4 173.4 68.3 217.6 85.8 176.8 69.7 221.0 87.1 180.2 71.0 224.4 88.4 183.6 72.4 227.8 89.8 187.0 73.7...
  • Page 68 SOUND SETTING 67 Delay Time Distance Distance Delay Time Distance Distance Number Difference (cm) (inch) Number Difference (cm) (inch) (ms) (ms) 258.4 101.8 302.6 119.3 261.8 103.2 306.0 120.6 265.2 104.5 309.4 121.9 268.6 105.9 312.8 123.3 272.0 107.2 316.2 124.6 275.4 108.5...

  • Page 69: About The Crossover

    68 SOUND SETTING About The Crossover Cut-off Slope Level frequency (1/3 Crossover (X-Over): octave steps) This unit is equipped with an active crossover. The crossover limits the frequencies delivered to the outputs. — 20 Hz — Flat, 0 to Each channel is controlled independently. Thus, each 6, 12, range - 200...
  • Page 70 SOUND SETTING 69 1 — Low Range 1 — Level Adjusting (0 to −12 4 — Slope Adjusting 2 — High Range 5 — LPF Cut-Off Frequency 2 — Output Frequency Range 6 — HPF Cut-Off Frequency 3 — Slope Flat 7 —...
  • Page 71 70 SOUND SETTING • You cannot adjust the crossover frequency higher than NOTE: the HPF or lower than the LPF. • HPF (high pass filter): Cuts the lower frequencies and • Adjustment should be made according to the recom- allows the higher frequencies to pass. mended crossover frequency of the connected speak- •...

  • Page 72: Other Functions

    SOUND SETTING 71 OTHER FUNCTIONS Displaying The Text Text information, such as the disc name and the track name, will be displayed if playing a CD text compatible disc. It is also possible to display the folder name, the file name and the tag, etc.
  • Page 73 72 SOUND SETTING The display in HD Radio mode: The display in CD mode:...
  • Page 74 SOUND SETTING 73 The display in MP3/WMA/AAC mode: The display in BLUETOOTH Audio mode: *1 When an HD Radio signal is received, text information such as Radio Station, Artist, etc., is displayed. If there is no text information, nothing will be displayed. *2 Displayed during playback of a disc with CD Text.

  • Page 75: About The Indication Display

    74 SOUND SETTING *3 The root folder of disc/Flash Memory is displayed as About The Indication Display “\ROOT”. If there is no text information, nothing will be When displaying Text, the following indicators are lit displayed. according to the mode. *4 If an MP3/WMA/AAC file contains ID3 tag/WMA tag information, the ID3 tag/WMA tag information is displayed (e.g., song name, artist name, and album...
  • Page 76 SOUND SETTING 75 Indicator/ HD Radio Mode CD Mode MP3/WMA/AAC iPod/iPhone/ BLUETOOTH Mode Mode Audio Mode — — Folder Name being — displayed Artist Name — Artist Name being Artist Name being being displayed displayed displayed — — Album Name be- Album Name being ing displayed displayed...

  • Page 77: About "Text

    76 SOUND SETTING About “Text” NOTE: • The option menu varies depending on the source. Text compatible CDs contain text information such as the disc name and track name. Such text information is 2. Turn the Rotary encoder to select the desired setting referred to as “text”.
  • Page 78 SOUND SETTING 77 DISC mode: BT Audio mode: CD Setup*6 ↔ VOL LV ADJ*2 ↔ MX Setup*3 ↔ CD BT Setup*11 ↔ VOL LV ADJ*2 ↔ MX Setup*3 ↔ BT Setup Setup USB mode: Phone mode (Non-calling mode): USB Setup*7 ↔ VOL LV ADJ*2 ↔ MX Setup*3 ↔ USB Phone Setup*12 ↔...
  • Page 79 78 SOUND SETTING *3 Refer to “Setting the Media Xpander mode (MX *10 AUX Name can be selected in this mode. For Setup)” on page 57. details, refer to “Setting the AUX NAME mode” on page 88. *4 Refer to “Storing the desired Artist and Song Alerts” on page 174.

  • Page 80: Applying Tuneit

    SOUND SETTING 79 *15 While calling, the call sound can be switched Applying TuneIt between the unit and Smartphone by using this setting. This unit’s sound tuning is programmable from a con- This operation can also be done by pressing BAND. nected Smartphone.

  • Page 81: Adjusting The Sound Via Smartphone

    80 SOUND SETTING Before these operations, set Alpine APP to USB or BT NOTE: depending on the connected Smartphone. For details, • Volume and sound parameter preset function cannot refer to “Setting the communication mode with a Smart- be adjusted via Smartphone. phone (Alpine APP)”...

  • Page 82: Facebook Notification Function

    SOUND SETTING 81 Facebook Notification Function 2. Turn the Rotary encoder to select the desired mode, and then press /ENTER . Some functions may be available in a future version of Like*1 ↔ Replay ↔ Next ↔ Previous ↔ TTS Vol- TuneIt.

  • Page 83: Displaying Notification List (Ready On Future Update)

    82 SOUND SETTING Displaying Notification List (Ready On Future Previous: To select the previous Notification. Update) TTS Volume: To adjust the playback volume of You can view the received Notification from Facebook in TTS (Text To Speech). the connected Smartphone via this unit. NOTE: 1.
  • Page 84 SETUP CONTENTS ▫ Tuner Setting ......95 SETUP .......84 ▫...

  • Page 85: Setup

    84 SETUP SETUP Setting You can flexibly customize the unit to suit your own preferences and usage. From the SETUP menu, General Setting, Display Setting, etc. can be modified. Use steps 1 to 5 to select one of the SETUP modes to modify.
  • Page 86 SETUP 85 General: *2 Refer to “SiriusXM Setting” Clock Mode ↔ Clock Adjust*4 ↔ Calendar ↔ AUX IN *3 Refer to “BLUETOOTH SETUP” ↔ AUX Name*5 ↔ Play Mode ↔ Beep ↔ Demo ↔ *4 Refer to “Setting the Time and Calendar” Clock Mode *5 Displayed only when AUX IN is ON.

  • Page 87: General Setting

    86 SETUP General Setting 4. Turn the Rotary encoder to select either 00:00 (24-hour) or AM (Before noon) 12:00 (12-hour) (Initial setting), General is selected on the setup main menu in step 2. and press /ENTER. Setting The Clock Display (Clock Mode) 5.
  • Page 88 SETUP 87 Setting The AUX SETUP mode You can input the audio of an external device, (such as a Shows the month Portable audio player) to the AUX connector of this unit. • Setting item: AUX IN Shows the day Setting contents: ex.
  • Page 89 88 SETUP 2. Turn the Rotary encoder to select General, and press 1. Press and hold AUDIO/SETUP for at least 2 seconds /ENTER. to activate the SETUP mode. 3. Turn the Rotary encoder to select AUX IN, and press 2. Turn the Rotary encoder to select General, and press /ENTER.
  • Page 90 SETUP 89 select playback of a single session only, containing the NOTE: CD data. When a disc contains both CD and MP3/ • Perform this setting before inserting a disc. If a disc has WMA/AAC data, playback starts from the CD data already been inserted, remove it first.
  • Page 91 90 SETUP Sound (Beep) Guide Function 4. Turn the Rotary encoder to select either OFF or Level 1~7, and press /ENTER. This function will give audible feedback with varying tones depending upon the button pressed. 5. Press and hold AUDIO/SETUP for at least two 2 seconds to return to normal mode.

  • Page 92: Display Setting

    SETUP 91 2. Turn the Rotary encoder to select General, and press TYPE1: /ENTER. The color of all buttons is blue. 3. Turn the Rotary encoder to select Demo, and press TYPE2: /ENTER. The color of all buttons is green. 4.
  • Page 93 92 SETUP 4. Turn the Rotary encoder to select either TYPE1, 2. Turn the Rotary encoder to select Display, and press TYPE2, TYPE3 or TYPE4 (Initial setting), and press /ENTER. /ENTER. 3. Turn the Rotary encoder to select Dimmer, and press 5.
  • Page 94 SETUP 93 1. Press and hold AUDIO/SETUP for at least 2 seconds TYPE 1: to activate the SETUP mode. The characters scroll from right to left, one character at 2. Turn the Rotary encoder to select Display, and press a time, until the entire title has scrolled. /ENTER.
  • Page 95 94 SETUP 5. Press and hold AUDIO/SETUP for at least 2 seconds Auto: to return to normal mode. CD text information, folder and file names, HD Radio Scroll Setting (Text Scroll) and SiriusXM text are scrolled continuously. In addi- tion, all tag information is automatically rotated in the This CD player can scroll the disc and track names display continuously, without pressing the VIEW...

  • Page 96: Tuner Setting

    SETUP 95 NOTE: 2. Turn the Rotary encoder to select Display, and press /ENTER. • In parts of the display, scrolling may not occur, or scroll content may differ. 3. Turn the Rotary encoder to select Opening MSG, and press /ENTER.
  • Page 97 96 SETUP 1. Press and hold AUDIO/SETUP for at least 2 seconds Setting The Digital Seek to activate the SETUP mode. Digital Seek can be set to ON/OFF. 2. Turn the Rotary encoder to select Tuner Setting, and • Setting item: Seek Type press /ENTER.
  • Page 98 SETUP 97 2. Turn the Rotary encoder to select Tuner Setting, and Hybrid: press /ENTER. Receive both digital and analog radio stations. If the 3. Turn the Rotary encoder to select Seek Type, and press digital signal is weak, this unit will switch to receive /ENTER.
  • Page 99 98 SETUP 2. Turn the Rotary encoder to select Tuner Setting, and Analog: press /ENTER. While receiving a live broadcast, this unit will only 3. Turn the Rotary encoder to select Listen Mode, and receive the analog radio signal even when the digital press /ENTER.
  • Page 100 SETUP 99 3. Turn the Rotary encoder to select Live Mode, and Normal: press /ENTER. Standard setting 4. Turn the Rotary encoder to select either Analog (Initial Stable: setting), Digital Listen Mode, press /ENTER. Control noise 5. Press and hold AUDIO/SETUP for at least 2 seconds 1.

  • Page 101: Ipod&Usb Setting

    100 SETUP NOTE: searched are less than the assigned skipped-over ones, pressing and holding Rewind Forward will • Noise may be more noticeable when Hi-Fi is set, skip to the first or last folder/file. depending on the reception status. In this case, the •...
  • Page 102 SETUP 101 5. Press and hold AUDIO/SETUP for at least 2 seconds 3. Turn the Rotary encoder to select iPod List Setup, and to return to normal mode. press /ENTER. iPod/iPhone Search Mode Setting 4. Turn the Rotary encoder to select either Playlists, Artists, Artists, Albums, Audiobooks, Podcasts, The unit allows you to search for the iPod/iPhone using Genres, Composers, Songs, or Genius Mixes, and press...

  • Page 103: Application Setting (App)

    102 SETUP Application Setting (APP) Application is selected on the setup main menu in step 2. Set this when an Android Smartphone is paired with this unit via BLUETOOTH technology. At this time, Setting The Communication Mode With A you can enjoy Pandora, program the unit’s sound Smartphone (Alpine APP) tuning parameters, or communicate with SNS.
  • Page 104 SETUP 103 NOTE: 1. Press and hold AUDIO/SETUP for at least 2 seconds to activate the SETUP mode. • After the above setting, turn the ignition key off (ACC OFF) and on again (ACC ON). 2. Turn the Rotary encoder to select Application, and press /ENTER.
  • Page 106 BLUETOOTH HANDS FREE CALLING CONTENTS ▫ Hands-Free Phone Control ....125 BLUETOOTH HANDS FREE CALLING ..106 ▫ Setup Before Using ....107 ▫...

  • Page 107: Bluetooth Hands Free Calling

    106 BLUETOOTH HANDS FREE CALLING BLUETOOTH HANDS FREE CALLING WARNING! Any voice commanded system should be used only in safe driving conditions following all ap- plicable laws. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing serious injury or death.

  • Page 108: Setup Before Using

    BLUETOOTH HANDS FREE CALLING 107 Setup Before Using About BLUETOOTH BLUETOOTH is a wireless technology allowing commu- nication between a mobile device or personal computer over short distances. This enables a hands-free call or data transmission between BLUETOOTH compatible de- vices.
  • Page 109 108 BLUETOOTH HANDS FREE CALLING • Proper function of this unit with all BLUETOOTH Before Using BLUETOOTH Function compatible devices is not guaranteed. For handling of Before using the BLUETOOTH function, the following the BT compatible device, consult your ALPINE dealer settings need to be made.
  • Page 110 BLUETOOTH HANDS FREE CALLING 109 How To Connect To A Bluetooth Compatible Pairing a BLUETOOTH compatible device without Device (Pairing) SSP (Secure Simple Pairing) For details on the control from a BLUETOOTH compat- 1. Using your BLUETOOTH compatible device, select ible device, refer to the Owner’s Manual of the the “Alpine CD Receiver”...

  • Page 111: Bluetooth Setup

    110 BLUETOOTH HANDS FREE CALLING • After a successful pairing, the two devices should NOTE: reconnect automatically whenever the vehicle’s igni- • Set “Bluetooth IN” to ON, and then perform tion is turned ON. If the auto connection fails, try to BLUETOOTH SETUP operation.
  • Page 112 BLUETOOTH HANDS FREE CALLING 111 BLUETOOTH: NOTE: • Press to return to the previous mode. Bluetooth IN*1 ↔ Paired Device*2 ↔ Visible • If no operation is performed for 60 seconds, the unit Mode*1/*2 ↔ Search Device*1/*2 ↔ Call Sound*2 ↔ Caller ID*2 ↔...
  • Page 113 112 BLUETOOTH HANDS FREE CALLING OFF: 5. Press and hold AUDIO/SETUP for at least 2 seconds to return to normal mode. Hands-Free Phone function and Bluetooth Audio func- tion are not used. NOTE: • When Bluetooth IN is set to OFF, the indicators related to Hands-free phone ( battery quantity and Select when you want to pair your BLUETOOTH...
  • Page 114 BLUETOOTH HANDS FREE CALLING 113 • If a Smartphone is connected to this unit successfully, 3. Turn the Rotary encoder to select Paired Device and then press /ENTER. indicator lights up to show the battery charge of the connected Smartphone. The indicator 4.
  • Page 115 114 BLUETOOTH HANDS FREE CALLING • If all the 3 positions have been registered, you cannot 1. Press and hold AUDIO/SETUP for at least 2 seconds register the 4th device. To register another device, you to activate the SETUP mode. need to delete one of the devices from position 1 to 3 2.
  • Page 116 BLUETOOTH HANDS FREE CALLING 115 1. Press and hold AUDIO/SETUP for at least 2 seconds 6. If this unit is successfully connected to a BLUETOOTH to activate the SETUP mode. compatible device, “Connected” is displayed, and then the unit returns to normal mode. 2.
  • Page 117 116 BLUETOOTH HANDS FREE CALLING 1. Press and hold AUDIO/SETUP for at least 2 seconds Adjusting The Volume (VOL LV ADJ) to activate the SETUP mode. You can emphasize or weaken the volume level of the Phone call, the ring tone and the microphone input to fit 2.
  • Page 118 BLUETOOTH HANDS FREE CALLING 117 Sound Type Setting (Type Setup) Noise reduction: This function can reduce the road noise, but excessive enhancement may affect the sound Depending on your calling environment, choose one of quality of the call. the settings below which gives the best sound quality. Echo-cancel: This function can reduce the echo, but Setting contents: TYPE1 (Initial setting) / TYPE2 / excessive enhancement may affect the sound quality of...
  • Page 119 118 BLUETOOTH HANDS FREE CALLING 2. Turn the Rotary encoder to select “Bluetooth”, and Setting The Phone Book Update then press /ENTER. You can update the phone book automatically or manu- ally. 3. Turn the Rotary encoder to select Caller ID and then press /ENTER.
  • Page 120 BLUETOOTH HANDS FREE CALLING 119 4. Turn the Rotary encoder to select either Auto or NOTE: Manual and press /ENTER. • Updating” will be displayed during the phone book 5. Press and hold AUDIO/SETUP for at least 2 seconds update. to return to normal mode.
  • Page 121 120 BLUETOOTH HANDS FREE CALLING Setting The Phone Book Manual Update ON/OFF 5. Turn the Rotary encoder to select either NO (Initial (Manual) setting) or YES and press /ENTER. When you select YES in this step, the phone book will be 6.
  • Page 122 BLUETOOTH HANDS FREE CALLING 121 1. Press and hold AUDIO/SETUP for at least 2 seconds NOTE: to activate the SETUP mode. • “Waiting” will be displayed while the Phone book 2. Turn the Rotary encoder to select “Bluetooth”, and order is switching. You can cancel the “Waiting” screen then press /ENTER.
  • Page 123 122 BLUETOOTH HANDS FREE CALLING OFF: NOTE: • If the received call setting on the Smartphone is on, the When a call is received, it is not answered automati- cally. Press /ENTER to receive the call. call will be answered automatically even though this setting is set to OFF.
  • Page 124 BLUETOOTH HANDS FREE CALLING 123 4. Press and hold AUDIO/SETUP for at least 2 seconds F-L: to return to normal mode. The sound only be output from the front left speaker. NOTE: F-R: • Depending on the character type some phone service The sound only be output from the front right speaker.
  • Page 125 124 BLUETOOTH HANDS FREE CALLING 5. Press and hold AUDIO/SETUP for at least 2 seconds Updating The Firmware to return to normal mode. Future BLUETOOTH firmware updates may become available for phone interoperability. Displaying The Firmware Version The current firmware version will be displayed. For detailed information and operation to update your BLUETOOTH firmware, please visit Alpine home page •...

  • Page 126: Hands-Free Phone Control

    BLUETOOTH HANDS FREE CALLING 125 • If both calling parties are using hands-free devices, or 4. Turn the Rotary encoder to select either NO (Initial setting) or YES and press /ENTER. the call is made in a noisy location, difficulty hearing the other person’s voice is normal.
  • Page 127 126 BLUETOOTH HANDS FREE CALLING • While calling, the source sound on the unit is muted. All features, functionality, and other product specifica- tions, as well as the information contained in the After calling, playback will resume. Owner’s Manual are based upon the latest available Hanging Up The Telephone information and are believed to be accurate at the time Press...
  • Page 128 BLUETOOTH HANDS FREE CALLING 127 • Voice recognition operation depends on the function of After the Voice Recognition mode is activated and “Speak” is displayed, you can make a phone call, play a the Smartphone. For details, refer to the Owner’s song, etc., via this unit by inputting voice control com- Manual of the Smartphone.
  • Page 129 128 BLUETOOTH HANDS FREE CALLING 2. Turn the Rotary encoder to select the outgoing mode. NOTE: • It may take some time for the list to be displayed, Dialed: and also directly after connection, the list may not be Dialed history brought up to date.
  • Page 130 BLUETOOTH HANDS FREE CALLING 129 name*, then turn the Rotary encoder to choose the 2. Turn the Rotary encoder to select Dialed. desired number and press /ENTER, the tele- 3. Press /ENTER phone will be called. 4. Turn the Rotary encoder to select a name or a tele- * If the name cannot be recognized, “NO Name”...
  • Page 131 130 BLUETOOTH HANDS FREE CALLING 4. Turn the Rotary encoder to select a name or a tele- 5. Press /ENTER phone number from the list. Dialing a Number In The Phone Book 5. Press /ENTER Up to 1,000 names (at most 3 telephone numbers for each name) are downloadable from a Smartphone.
  • Page 132 BLUETOOTH HANDS FREE CALLING 131 NOTE: * The telephone label of a number depends on the number information stored in Phone book of the Smart- • The order of the list display depends on the setting of phone, which includes 4-type icons-(Mobile), (Home), “PB Order”...
  • Page 133 132 BLUETOOTH HANDS FREE CALLING • Press 1. Press ABC SEARCH while in the phone book list, the in step 3 or 4 to delete the current entry and phone book alphabet search mode is activated. return to the previous step. •...
  • Page 134 BLUETOOTH HANDS FREE CALLING 133 NOTE: Select a number you want to preset from the Phone Menu list (Phone Book, Dialed Call, etc.). Press and hold any • In the call waiting mode, press Rewind For- one of the preset buttons (1 through 6) as the one that you ward to switch between the current call and the wish to store the number for at least 2 seconds.
  • Page 135 134 BLUETOOTH HANDS FREE CALLING • If you store a phone number in a preset with a NOTE: previously stored number, the current number will be • You may need to increase volume from your regular cleared and replaced by the new one. audio listening source level.

  • Page 136: Bluetooth Audio Operation

    BLUETOOTH HANDS FREE CALLING 135 Call Switching Operation * To play back audio, a Smartphone or a portable player conforming to A2DP (Advanced Audio Distribution Pro- While making a call, this function allows you to initiate file) and AVRCP (Audio/ Video Remote Control Profile) the transfer of the audio between the Smartphone and the is required.
  • Page 137 136 BLUETOOTH HANDS FREE CALLING Recalling The Bluetooth Audio Mode Pausing Press /SOURCE to select the BLUETOOTH Audio Press mode. Playback stops. Pressing again will resume play- back. Selecting The Desired Song 1. Press Selecting The Desired Group (Folder) Returns the beginning of the song being played back. Press Rewind Forward to select the desired Group (Folder).
  • Page 138 BLUETOOTH HANDS FREE CALLING 137 Searching For A Desired Song NOTE: • Search mode may differ depending on the connected Artist name, album name, etc., may be searched and displayed during playback or pause. device. • The pause mode may be canceled after the search. 1.
  • Page 140 ACCESSORIES CONTENTS ▫ Setting The iPod Control ....147 FLASH MEMORY (Optional) ....141 ▫...
  • Page 141 140 ACCESSORIES ▫ Displaying The Text ....157 ▫ QuickMix ......161 ▫...

  • Page 142: Flash Memory (Optional)

    ACCESSORIES FLASH MEMORY (Optional) Connecting The Flash Memory (Optional) If a Flash Memory device is connected to the unit, MP3/WMA/AAC files can be played back. Playback 1. Press SOURCE to select the USB mode. 2. Press to select the desired track (file). Pressing and holding will fast backward/ fast forward track continuously.

  • Page 143: Repeat Play

    142 ACCESSORIES • The playback time may not be correctly displayed Repeat Play when a VBR (Variable Bit Rate) recorded file is played 1. Press back. The song is played back repeatedly. • If there is tag information, artist name/album name/ RPT*1 →...

  • Page 144: Random Play)

    ACCESSORIES M.I.X. (Random Play) NOTE: • When a song is played back during Random (M.I.X.) 1. Press play in the USB mode, the song can be played back The songs are played back in random sequence. again randomly even if not all songs in the Flash *1 →...

  • Page 145: Select Folder

    144 ACCESSORIES • If any one of the preset buttons (1 through 6) is 3. Press /ENTER to play the selected file or enter the selected folder. pressed in the search mode, a search can be made quickly by skipping to the specified location. For Press and hold /ENTER for at least 2 seconds to details, refer to “Direct Search Function”...

  • Page 146: Search Position Memory

    ACCESSORIES NOTE: iPod/iPhone (OPTIONAL) • This function is inactive during MIX ALL playback. Search Position Memory During playback, you can quickly return to the last- selected hierarchy level in the search mode. Press The hierarchy you selected last in the search mode is displayed.

  • Page 147: Connecting An Ipod/Iphone

    146 ACCESSORIES Connecting An iPod/iPhone About iPod/iPhone models usable with this unit • Confirmed devices regarding Made for iPod. Correct An iPod/iPhone can be connected to this unit by using function of earlier versions cannot be guaranteed. the Interface cable for iPod (included with iPod/iPhone). When this unit is connected by using the cable, the iPod touch (4th generation): Ver.5.1.1 controls on the iPod are not functional.

  • Page 148: Setting The Ipod Control

    ACCESSORIES • Confirmed devices regarding Made for iPhone. Cor- Setting The iPod Control rect function of earlier versions cannot be guaranteed. When an iPod/iPhone is connected, operate it from its own controls or from the head unit. iPhone 4S: Ver.5.1.1 1.

  • Page 149: Playback

    148 ACCESSORIES NOTE: 3. To pause playback, press • During HU Mode, you can switch to iPod Mode Pressing again will resume playback. directly by pressing BAND. NOTE: • Once the control mode is changed, this will set pause • A song playing on the iPod/iPhone while it is con- status, press to continue.
  • Page 150 ACCESSORIES Each music category has its own individual hierarchy as shown below. Choose a music category from the list below to narrow searches quickly. Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4 Playlist Song — — Artist* Album* Song — Album* Song —...
  • Page 151 150 ACCESSORIES For example: *3 When an iPod/iPhone with Genius Mix list created by iTunes is connected to this unit, Genius Mix search Searching by Artist name. mode can be used to search a Genius Mix list. The following example explains how an Artist search is 3.
  • Page 152 ACCESSORIES • After selecting [All] in the search mode, press and hold • “No Genius” will be displayed if there is no genius /ENTER for at least 2 seconds to play back all mix list data in the Genius Mix search mode. songs in the iPod/iPhone or selected search mode.

  • Page 153: Direct Search Function

    152 ACCESSORIES quickly by skipping to the specified location. For Song search example: details, refer to “Direct Search Function” on page 152. If there are 100 songs in your iPod/iPhone, they are • During search mode, a search can be made quickly by divided into 6 groups using percentages (shown below).

  • Page 154: Change Playlist/Artist/Album/Genre

    ACCESSORIES All 100 songs (100%) Preset but- tons Songs 1st song 17th song 33rd song 50th song 67th song 83rd song NOTE: Change Playlist/Artist/Album/Genre/ Composer/Episode • This function is also applicable to CD/MP3/WMA/ Playlist/Artist/Album/Genre/Composer/Episode can AAC search. be easily changed. For example, if you listen to a song •...

  • Page 155: Alphabet Search Function

    154 ACCESSORIES NOTE: 2. Turn the Rotary Encoder to select a desired letter (e.g. M), and then press /ENTER. • If the song search mode was used to select a song, this The titles beginning with “M” are listed. function is inactive. •...

  • Page 156: Search Position Memory

    ACCESSORIES Search Position Memory Shuffle Songs: During iPod/iPhone playback, you can quickly return to Song shuffle randomly plays back songs within a selected the last-selected hierarchy level in the search mode. category (playlist, album, etc.). The songs within the category are played just once until all songs have been Press played.

  • Page 157: Repeat Play

    156 ACCESSORIES Shuffle All: Repeat Play Shuffle All plays all songs in the iPod/iPhone randomly. Only Repeat One is available for the iPod/iPhone. Any one song does not play back again until all songs Repeat One: have been played back. A single song is repeatedly played back.

  • Page 158: Displaying The Text

    ACCESSORIES Displaying The Text You can display the tag information of a song in the iPod/iPhone. Press VIEW. Each press changes the display. NOTE: • When the Text Scroll is set to Manual (refer to “Scroll Setting (Text Scroll)” on page 94), press and hold VIEW for at least 2 seconds, the current text will be scrolled one time.

  • Page 159: Pandora® Internet Radio (If Equipped)

    158 ACCESSORIES *3 When the Text Scroll (refer to “Scroll Setting (Text PANDORA® INTERNET RADIO (IF EQUIPPED) Scroll)” on page 94. ) is set to “Auto,” the display cannot be switched by pressing VIEW. The display contents switch alternately. NOTE: •...

  • Page 160: Listening To Pandora

    ACCESSORIES • Before this operation, set ALPINE APP to USB or BT Pandora® internet radio is your own FREE personalized radio now available to stream music on your Smartphone depending on the connected Smartphone. For details, (which runs Android OS or iOS). refer to “Application Setting (APP)”...

  • Page 161: Thumbs" Feedback

    160 ACCESSORIES • The unit remembers the source just before turning off : The icon is displayed. Pandora® will ban that the power. If Pandora® is the last SOURCE to be song from your station, and the current song is played, it will appear as the SOURCE the next time the skipped.

  • Page 162: Quickmix

    ACCESSORIES 3. Turn the Rotary encoder to select the desired station, NOTE: and then press /ENTER. • If any one of the preset buttons (1 through 6) is pressed Pandora® will play that station. in the search mode, a search can be made quickly by skipping the specified number of channels.

  • Page 163: Bookmarking A Desired Song Or Artist

    162 ACCESSORIES NOTE: NOTE: • The songs from the created stations are played back in • Your bookmarks can be viewed on your “Profile” page random sequence. at www.pandora.com. • Select another station during search mode to cancel • In some situations, bookmarks may not be available. QuickMix.

  • Page 164: Search Position Memory

    ACCESSORIES NOTE: Changing The Display Press VIEW. • Your New Station can be viewed on your “Profile” page at www.pandora.com. • In some situations, creating a new station function may not be available. • If this operation fails, N/A will be displayed. •...
  • Page 165 164 ACCESSORIES About The Indication Display When displaying Text, the following indicators are illu- minated according to the mode. Indicator/Mode Pandora Mode Station Name being displayed Artist Name being displayed Album Name being displayed Song Name being displayed...
  • Page 166 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) CONTENTS ▫ Tuning Channels Using Presets ... .174 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) ......166 ▫...

  • Page 167: Siriusxm Satellite Radio Operation (Optional)

    166 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) SiriusXM SATELLITE RADIO OPERATION When a SiriusXM Tuner is connected to this unit, the (OPTIONAL) following operations may be performed. SiriusXM Tuner operation: Receiving Channels With The SiriusXM Tuner About SiriusXM Satellite Radio WARNING! Everything worth listening to is on SiriusXM.

  • Page 168: Siriusxm Setting

    SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 167 1. Press /Source to activate the Satellite Radio 2. Turn the Rotary encoder to select “SiriusXM”, and (SiriusXM) mode. then press /Enter. The SiriusXM setup mode is activated. 2. Press to select the desired channel. Holding down will rapidly browse through 3.

  • Page 169: Managing Artist And Song Alerts

    168 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) Managing Artist And Song Alerts 2. Turn the Rotary encoder and select a stored Artist or Song and press / ENTER. The following operations can be performed to change the Alert settings. The Artist and Song Alerts feature allows 3.

  • Page 170: Setting The Favorite Sports Team Alerts

    SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 169 If OFF is set, the alert for all stored Artists/Songs is Setting The Favorite Sports Team Alerts disabled. This menu option allows you to select your favorite teams, organized by leagues, so that you will be alerted later when All Source Alert your favorite teams are playing on other channels.

  • Page 171: Setting The Parental Control

    170 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 4. Turn the Rotary encoder to select the desired league Setting The Parental Control and press /ENTER. You can lock out channels with passcode protection. Channels that are locked cannot be accessed without 5. Turn the Rotary encoder to select a team you want to entering the pass code.
  • Page 172 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 171 The pass code is entered one digit at a time with the Locked Channels: Rotary encoder. For example, by turning clockwise 2 After selecting this item, turn the Rotary encoder to select steps, the number 1 is selected. a channel from channel list, press / ENTER to select After entering the digit, it is displayed as...

  • Page 173: Confirming The Strength Of The Siriusxm Signal

    172 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) A confirm screen will be displayed and the new passcode Confirming The Strength Of The SiriusXM Signal must be entered again for confirmation. When the pass- You can check the signal strength through this setting code is changed successfully, the unit will display Code item.

  • Page 174: Checking The Siriusxm Radio Id Number

    SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 173 Checking The SiriusXM Radio ID Number Storing Channel Presets To subscribe to the SiriusXM Satellite Radio service, it is 1. Press BAND to select the desired band you want to necessary to locate and identify the Radio ID of your store the preset in.

  • Page 175: Tuning Channels Using Presets

    174 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) NOTE: Storing The Desired Artist And Song Alerts • A total of 18 channels can be stored in the preset While listening to SiriusXM Satellite Radio, you can be alerted when your favorite songs or artists are playing on memory, 6 Channels for each band (SiriusXM1, Siri- other channels.
  • Page 176 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 175 NOTE: NOTE: • If both the artist name and song title are not available • If you try to store when the memory is full, “Memory to save, Artist/Song will be displayed. Full” is displayed followed by “Replace/Cancel”. If you want to replace an existing alert item, select 4.

  • Page 177: Receiving And Tuning To An Alert

    176 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) Receiving And Tuning To An Alert Search Function Whenever a stored sports team, artist, or song is playing You can search for SiriusXM programming content by on another channel, an interruption Alert appears on the Category or by Channel.
  • Page 178 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 177 NOTE: The artist names and song names that you have stored and are currently playing will be displayed in a list. • Press VIEW, the information of the broadcasting * Displayed only when the stored song or artist is channels will be displayed.

  • Page 179: Using Jump Memory And Jump Recall Function

    178 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) Searching By My Games Using Jump Memory And Jump Recall Function 1. Turn the Rotary encoder to select My Games* after 1. While in SiriusXM mode, select your favorite Siri- step 1, and then press / ENTER.

  • Page 180: Replay Function

    SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 179 • Returning to the beginning of the current song: Replay Function Press In SiriusXM mode, you can pause, rewind and replay of • Advancing to the beginning of the next song: live SiriusXM Satellite Radio. Press 1.

  • Page 181: Parental Lock Function

    180 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) • After entering the correct passcode, you can access all Parental Lock Function locked channels without entering the passcode again This function can help restrict the listening of channels to until the unit is powered off and then back on. children of appropriate age levels only.
  • Page 182 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 181 • When an iPod that doesn’t support the tagging func- If no iPod/iPhone is connected, “Tag Count X” is dis- played (X is the total amount of the tag information tion is connected, “Non-Tagging iPod” is displayed. stored in this unit).

  • Page 183: Changing The Display

    182 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) Changing The Display About The Indication Display Text information, such as the channel name, artist name/ When displaying Text, the following indicators are lit feature and song/program title, is available with each according to the mode. SiriusXM channel.
  • Page 184 SiriusXM SATELLITE RADIO OPERATION (OPTIONAL) 183 Indicator/Mode SiriusXM Mode Channel Number being displayed Channel Name being displayed Artist Name being displayed Song Title being displayed Content INFO being displayed Category Name being displayed...

  • Page 186: Additional Information

    ADDITIONAL INFORMATION CONTENTS ▫ Flash Memory Messages....190 IN CASE OF DIFFICULTY....186 ▫...

  • Page 187: In Case Of Difficulty

    186 ADDITIONAL INFORMATION • Blown fuse. IN CASE OF DIFFICULTY – Check the fuse of the unit; replace with the proper If you encounter a problem, turn the power off, then on value if necessary. again. If the unit is still not functioning normally, review the items in the following checklist.
  • Page 188 ADDITIONAL INFORMATION 187 • If the area you are in is a primary signal area, the antenna may not be grounded and connected properly. CD Player not functioning. – Check your antenna connections; make sure the • Out of operating temperature range +50°C (+120°F) for antenna is properly grounded at its mounting location.
  • Page 189 188 ADDITIONAL INFORMATION • The CD is being improperly inserted. • The pick-up lens is dirty. – Make sure the CD is being inserted following in- – Do not use a commercially available lens cleaner structions in the CD Player Operation section. disc.

  • Page 190: Mp3/Wma/Aac

    ADDITIONAL INFORMATION 189 MP3/WMA/AAC iPod MP3, WMA or AAC is not played back. iPod does not play and no sound is output. • Writing error occurred. The MP3/WMA/AAC format • The iPod has not been recognized. is not compatible. – Reset this unit and the iPod. Refer to “Initial System –...

  • Page 191: Flash Memory Messages

    190 ADDITIONAL INFORMATION Error Protect • Mechanism error. • A copy-protected WMA file was played back. – You can only play back non-copy-protected files. 1. Press the button and eject the CD. Unsupported If not ejecting, consult your Alpine dealer. •...
  • Page 192 ADDITIONAL INFORMATION 191 Error-02 No Song • Communication error or boot error, etc. • No song (file) is stored in the Flash Memory. – You can solve the problem by reconnecting the Flash – Connect the Flash Memory device after storing Memory or format the USB Memory.

  • Page 193: Ipod Messages

    192 ADDITIONAL INFORMATION iPod Messages Error-02 • The iPod/iPhone version is too low. No USB Unit – Update the iPod/iPhone version. • The iPod/iPhone is not connected. – Make sure the iPod/iPhone is correctly connected Error-03 (refer to “Connections” on page 146). Make sure the •...

  • Page 194: Siriusxm Advisory Messages

    ADDITIONAL INFORMATION 193 SiriusXM Advisory Messages No Signal • The SiriusXM satellite signal is too weak at the current The following messages may be displayed while operat- ing the unit in SiriusXM mode. location. – Move the vehicle to a location with a clear view of Check Tuner the southern sky.
  • Page 195 194 ADDITIONAL INFORMATION Channel Unavailable Channel Locked • The active channel is no longer in the SiriusXM • A locked channel is selected. channel lineup or the user has entered an invalid – Input the pass code. On how to input pass code, channel number.

  • Page 196: Pandora® Mode Messages

    ADDITIONAL INFORMATION 195 Pandora® Mode Messages No Service • You switched CDE-HD149BT to Pandora® mode by No Pandora pressing /SOURCE with a Smartphone con- • A Smartphone is not connected. nected, without launching installing – Make sure a Smartphone is correctly connected. Pandora®...
  • Page 197 196 ADDITIONAL INFORMATION Alternate Channel Selec- 80 dB Signal-to-Noise Ratio 105 dB tivity Channel Separation 85 dB (at 1 kHz) Signal-to-Noise Ratio 65 dB PICKUP Stereo Separation 35 dB Capture Ratio 2.0 dB Wave length 795 nm AM TUNER SECTION Laser power CLASS I USB SECTION...
  • Page 198 ADDITIONAL INFORMATION 197 BLUETOOTH SECTION GENERAL BLUETOOTH Specification Bluetooth V2.1 + EDR Power Requirement 14.4 V DC (11~16 V allow- able) Output Power +4 dBm Max. (Power class 2) Power Output 18 W RMS × 4* Profile HFP (Hands-Free Profile) * Primary amplifier ratings per CEA-2006 Standard HSP (Head Set Profile) •...
  • Page 199 198 ADDITIONAL INFORMATION CHASSIS SIZE NOSEPIECE SIZE Width 178 mm (7 ) Width 168 mm (6–5/8 ) Height 50 mm (2 ) Height 45 mm (1–3/4 ) Depth 161.5 mm (6–3/8 ) Depth 24 mm (1 ) NOTE: Due to continuous product improvement, speci- fications and design are subject to change without notice.

  • Page 200: About The Rules Of Bluetooth Electromagnetic Radiation Regulation

    ADDITIONAL INFORMATION 199 About The Rules Of Bluetooth Electromagnetic Radiation Regulation USA/Canada FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s).
  • Page 201 200 ADDITIONAL INFORMATION USA/Canada This equipment complies with FCC/IC radiation expo- sure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equip- ment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evalu- ation (MPE).
  • Page 202 ADDITIONAL INFORMATION 201 USA/Canada Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles les radioélectriques (RF) de la FCC lignes directrices d’exposition dans le Supplément C à OET65 et d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC.
  • Page 203 202 ADDITIONAL INFORMATION México La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o disposi- tivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluy- endo la que pueda causar su operación no deseada.
  • Page 204 FCA US LLC 15ALFA-526-AA First Edition Printed in U.S.A.

Table of Contents
