Model No. PFEL57916.1
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to www.proformservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.proformservice.com.
Or call 1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form PFEL57916.1

Summary of Contents for Pro-Form PFEL57916.1

  • Page 1 Model No. PFEL57916.1 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 18. The elliptical does not have a freewheel; the 20. Over exercising may result in serious injury pedals will continue to move until the fly- or death. If you feel faint, if you become short wheel stops. Reduce your pedaling speed in of breath, or if you experience pain while a controlled way.
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM reading this manual, please see the front cover of this ® ENDURANCE 720 E elliptical. The ENDURANCE 720 E manual. To help us assist you, note the product model elliptical provides an impressive selection of features number and serial number before contacting us.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 8: Assembly

    ASSEMBLY • To hire an authorized service technician to • In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tools: one Phillips screwdriver • Assembly requires two persons. two adjustable wrenches • Place all parts in a cleared area and remove the packing materials.
  • Page 9 3. Press the Cover Mounts (106) on the underside of the Rear Stabilizer Cover (15) into the Rear Stabilizer (2). 4. With the help of a second person, place some of the packing materials (not shown) under the front of the Frame (1). Have the second per- son hold the Frame to prevent it from tipping while you complete this step.

  • Page 10: Wire (110

    5. Tip: Avoid pinching the Main Wire (110). Avoid damaging the indicated plastic tabs Avoid pinching (A). Have a second person hold the Upright (4) the Main Wire on the Frame (1). (110) and avoid damaging the Attach the Upright (4) with four M10 x 25mm tabs (A) Screws (99) and four M10 Split Washers (105);...
  • Page 11 7. Using a plastic bag to keep your fingers clean, apply some of the included grease to the Pivot Axle (35). Insert the Pivot Axle (35) through the Upright (4) and center it. Tip: It may be helpful to use a rubber mallet.

  • Page 12: Wire (110

    9. Untie and discard the wire tie on the Main Wire (110). While a second person holds the Console (7) near the Upright (4), connect the wires on the Console to the Main Wire (110) and to the Sensor Wires (63). Insert the excess wire into the Upright (4).
  • Page 13 11. Orient the Right Pedal Arm (58) as shown, and then apply grease to the axle. Attach the Right Pedal Arm (58) to the Right Roller Arm (59) with an M8 x 20mm Screw (126) and a Retainer (55); make sure that the flat side (D) of the Retainer is facing the Right Roller Arm.
  • Page 14 13. Orient the Rear Upright Cover (81) as shown and attach it to the Upright (4) with four M4 x 16mm Screws (101); start all the Screws, and then tighten them. Next, orient the Front Upright Cover (117) as shown and press it onto the Rear Upright Cover (81).
  • Page 15 15. Identify the Right Leg Inner Cover (83), orient it as shown, and attach it to the Right Upper Body Leg (60) with an M4 x 16mm Screw (101) and an M5 Washer (94). Next, identify the Right Leg Outer Cover (69), orient it as shown, and press it onto the Right Leg Inner Cover (83).
  • Page 16 17. Orient the Rear Console Cover (80) as shown, and attach it to the Upright (4) with two M4 x 16mm Screws (101). Next, orient the Front Console Cover (79) as shown, and attach it to the Rear Console Cover (80) with two M4 x 16mm Screws (101).

  • Page 17: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should mal- be used to function or break down, grounding provides a path of connect the Adapter least resistance for electric current to reduce the risk power cord...
  • Page 18 HOW TO MOVE THE ELLIPTICAL HOW TO LEVEL THE ELLIPTICAL Due to the size and weight of the elliptical, moving If the elliptical rocks slightly on your floor during use, it requires two persons. Stand in front of the elliptical, turn one or both of the leveling feet beneath the rear of hold the upright, and place one foot against one of the the frame or turn the leveling foot under the center of...
  • Page 19 HOW TO EXERCISE ON THE ELLIPTICAL To dismount the elliptical, wait until the pedals come to a complete stop. Note: The elliptical does not have To mount the elliptical, hold the handlebars or the a free wheel; the pedals will continue to move until the flywheel stops.
  • Page 20 CONSOLE DIAGRAM FEATURES OF THE CONSOLE resistance of the pedals as it guides you through an effective workout. The advanced console offers an array of features designed to make your workouts more effective and You can even connect your personal audio player to enjoyable.
  • Page 21 HOW TO TURN ON THE POWER Note: After you press a button, it will take a moment for the pedals to reach the selected IMPORTANT: If the elliptical has been exposed to resistance level. cold temperatures, allow it to warm to room tem- perature before you turn on the power.
  • Page 22 Pulse Average (BPM AVG)—This display will Press the Home button to exit the workout and show your average heart rate in beats per minute return to the main menu. If necessary, press the (bpm) when you use the handgrip heart rate moni- Home button again.
  • Page 23 6. Turn on the fan if desired. 7. When you are finished exercising, unplug the power cord. The fan has several speed settings, including an auto If the pedals do not move for several seconds, a mode. While the auto mode tone will sound, the console will pause, and the is selected, the speed of the time will flash in the display.
  • Page 24 HOW TO USE AN ONBOARD WORKOUT in the display for a few seconds to alert you. The resistance of the pedals and/or the incline level of 1. Begin pedaling or press any button on the the ramp will then change. console to turn on the console.
  • Page 25 HOW TO CONNECT YOUR TABLET TO THE HOW TO CONNECT YOUR HEART RATE MONITOR CONSOLE TO THE CONSOLE The console supports BLUETOOTH connections to The console is compatible with all BLUETOOTH Smart tablets via the iFit app and to compatible heart rate heart rate monitors.
  • Page 26 THE OPTIONAL CHEST HEART RATE MONITOR 3. Change settings as desired. Whether your Units—The currently selected unit of measurement goal is to will appear in the display. To change the unit of burn fat or to measurement, press the Enter button repeatedly. strengthen your To view distance in miles, select ENGLISH.

  • Page 27: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 28: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE Note: For clarity, the left shield and the left disc ring are not shown in the drawing below. Regular maintenance is important for optimal performance and to reduce wear. Inspect and properly Locate the Reed Switch (38). Turn the Pulley (19) until tighten all parts each time the elliptical is used.
  • Page 29 HOW TO ADJUST THE DRIVE BELT See EXPLODED DRAWING C on page 35. Identify the Left and Right Shields (73, 74). Remove the If the pedals slip while you are pedaling, even while M4 x 19mm Tek Screws (5), the M4 x 19mm Screws the resistance is adjusted to the highest level, the drive (127), and the M4 x 48mm Screw (107) from the Left and Right Shields;...

  • Page 30: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 31: Part List

    PART LIST Model No. PFEL57916.1 R1216A Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Pedal Handle Ramp Axle Cover Upright Pivot Spacer M4 x 19mm Tek Screw Retainer Front Stabilizer Roller Arm Bushing Console Large Arm Bearing...
  • Page 32 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Screw M10 Flange Nut M8 Locknut Bumper M6 x 8mm Screw M8 x 20mm Screw M10 x 122mm Screw M4 x 19mm Screw M10 Split Washer M10 x 3mm Washer Cover Mount Small Arm Bearing M4 x 48mm Screw...

  • Page 33: Exploded Drawing

    EXPLODED DRAWING A Model No. PFEL57916.1 R1216A...
  • Page 34 EXPLODED DRAWING B Model No. PFEL57916.1 R1216A...
  • Page 35 EXPLODED DRAWING C Model No. PFEL57916.1 R1216A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
