Icom IC-F5012 Service Manual page 27

[FRONT UNIT]
REF PARTS
NO. NO.
R133 7030008400 S.RES ERJ2GEJ 182 X (1.8K)
R134 7030008400 S.RES ERJ2GEJ 182 X (1.8K)
R135 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R136 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R137 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R138 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R139 7030005120 S.RES ERJ2GEJ 102 X (1K)
R140 7030005050 S.RES ERJ2GEJ 103 X (10K)
C2 4030017420 S.CER C1005 CH 1H 470J-T
C3 4030017420 S.CER C1005 CH 1H 470J-T
C4 4030017420 S.CER C1005 CH 1H 470J-T
C5 4030017420 S.CER C1005 CH 1H 470J-T
C8 4030017460 S.CER C1005 JB 1H 102K-T
C10 4030017460 S.CER C1005 JB 1H 102K-T
C12 4030017460 S.CER C1005 JB 1H 102K-T
C14 4030017460 S.CER C1005 JB 1H 102K-T
C15 4030016960 S.CER C1005 JB 1E 183K-T
C16 4030016930 S.CER C1005 JB 1A 104K-T
C17 4030017750 S.CER C1005 JB 1H 122K-T
C19 4030016930 S.CER C1005 JB 1A 104K-T
C20 4030017460 S.CER C1005 JB 1H 102K-T
C21 4030017460 S.CER C1005 JB 1H 102K-T
C22 4030020020 S.CER C1005 CH 1H 391J-T
C23 4030016790 S.CER C1005 JB 1E 103K-T
C24 4030017420 S.CER C1005 CH 1H 470J-T
C25 4030016790 S.CER C1005 JB 1E 103K-T
C26 4030016930 S.CER C1005 JB 1A 104K-T
C27 4030020010 S.CER C1005 CH 1H 271J-T
C28 4030016930 S.CER C1005 JB 1A 104K-T
C30 4030019560 S.CER GRM21BB31C106KE15L
C31 4030016930 S.CER C1005 JB 1A 104K-T
C34 4030017420 S.CER C1005 CH 1H 470J-T
C36 4030016930 S.CER C1005 JB 1A 104K-T
C38 4030017420 S.CER C1005 CH 1H 470J-T
C41 4030017460 S.CER C1005 JB 1H 102K-T
C50 4030017420 S.CER C1005 CH 1H 470J-T
C54 4030017420 S.CER C1005 CH 1H 470J-T
C69 4030017420 S.CER C1005 CH 1H 470J-T
C74 4030017420 S.CER C1005 CH 1H 470J-T
C76 4030016930 S.CER C1005 JB 1A 104K-T
C77 4030016950 S.CER C1005 JB 1A 473K-T
C78 4030017460 S.CER C1005 JB 1H 102K-T
C82 4030017420 S.CER C1005 CH 1H 470J-T
C84 4030017420 S.CER C1005 CH 1H 470J-T
C85 4030017420 S.CER C1005 CH 1H 470J-T
C87 4030016930 S.CER C1005 JB 1A 104K-T
C93 4030017460 S.CER C1005 JB 1H 102K-T
C101 4030016930 S.CER C1005 JB 1A 104K-T
C102 4030016930 S.CER C1005 JB 1A 104K-T
C103 4030016930 S.CER C1005 JB 1A 104K-T
C104 4030017400 S.CER C1005 CH 1H 220J-T
C105 4030017600 S.CER C1005 CH 1H 080C-T
C106 4030017640 S.CER C1005 CH 1H 150J-T
C107 4030017030 S.CER C1005 JB 1A 273K-T
C111 4030016930 S.CER C1005 JB 1A 104K-T
C112 4550006780 S.TAN TEESVB2 0J 476M8R
C113 4030018910 S.CER C1608 JB 0J 475K-T
C114 4030017420 S.CER C1005 CH 1H 470J-T
C116 4030016930 S.CER C1005 JB 1A 104K-T
C117 4030016930 S.CER C1005 JB 1A 104K-T
C118 4030016930 S.CER C1005 JB 1A 104K-T
C119 4030016930 S.CER C1005 JB 1A 104K-T
C120 4030016930 S.CER C1005 JB 1A 104K-T
C123 4030017460 S.CER C1005 JB 1H 102K-T
C124 4030016930 S.CER C1005 JB 1A 104K-T
C125 4030016930 S.CER C1005 JB 1A 104K-T
C126 4030017460 S.CER C1005 JB 1H 102K-T
C128 4030016930 S.CER C1005 JB 1A 104K-T
C129 4030017460 S.CER C1005 JB 1H 102K-T
C130 4030017460 S.CER C1005 JB 1H 102K-T
C131 4030018860 S.CER C1005 JB 0J 105K-T
C139 4030017420 S.CER C1005 CH 1H 470J-T
J1 6450002210 CON 3017-8821 <KIN>
J2 6510027960 S.CON 04-6294-040-000-800
J3 6510022022 S.CON 14FLT-SM2-TB(LF)(SN)(M)
DS1 5040003510 S.LED LNJ426W83RA
DS2 5040003510 S.LED LNJ426W83RA
DS3 5040003510 S.LED LNJ426W83RA
DS4 5040003510 S.LED LNJ426W83RA
DS5 5040003510 S.LED LNJ426W83RA
DS6 5040003510 S.LED LNJ426W83RA
DS7 5040003510 S.LED LNJ426W83RA
DS8 5040003510 S.LED LNJ426W83RA
DS9 5040003510 S.LED LNJ426W83RA
DS10 5040002670 S.LED CL-165HR/YG
SP1 2510001221 SPE C052SB500-14 <OSC>
W1 8900010503 CAB OPC-1046B-1(P0.5N40L55)
<TJM>
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
B
B
B
B
B
T
T
T
T
T
T
T
T
T
T
S.=Surface mount
H/V
40.5/20.7
57.6/21.4
27.4/28.4
47.2/28.3
47.2/27.4
78.5/24.2
54.7/9.2
63.1/15.8
84.4/5.1
34.6/10.2
45.3/10.8
57.0/4.2
13.8/17.2
7.7/9.2
5.2/9.2
32.9/26.6
32.9/25.7
32.9/23.9
31.2/26.6
36.3/23.9
34.6/17.6
32.9/18.5
30.0/16.0
32.9/22.1
28.2/16.0
25.5/28.4
23.6/26.6
25.5/26.6
29.1/16.0
29.9/12.6
36.3/11.1
80.7/10.8
38.7/27.2
78.9/10.8
23.6/28.4
61.9/9.3
62.8/9.3
67.4/1.8
61.7/1.8
29.1/26.6
73.0/12.4
8.9/17.4
36.3/23.0
25.5/27.5
32.9/17.6
34.6/15.6
61.9/12.6
56.0/15.3
53.8/18.8
54.7/18.8
52.1/15.3
53.4/14.9
53.4/14.0
43.8/29.3
43.8/28.4
53.4/21.7
63.9/12.2
62.8/12.6
65.7/12.6
66.6/12.6
69.3/12.6
67.5/12.6
68.4/12.6
80.0/14.7
73.9/30.1
83.5/6.8
30.4/14.0
14.3/19.2
14.3/17.5
84.8/8.1
36.3/21.2
5.6/17.4
71.0/5.7
84.4/28.6
37.5/6.8
67.9/6.8
75.5/27.2
60.3/27.2
45.1/27.2
29.9/27.2
60.3/21.2
45.1/21.2
29.9/21.2
79.8/21.2
7 - 6
