SCREEN 5
DRIVERS
FREQUENCY RESPONSE
RATED POWER
SENSITIVITY
CROSSOVER
IMPEDANCE
DISPERSION
DIMENSIONS
WEIGHT
SHIPPING DIMENSIONS
SHIPPING WEIGHT
Due to our policy of continuous improvement all specifications are subject to
change without notice.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
>
PRINT
Martin Audio – CINEMA SERIES
2 x 15" (380mm) low frequency
1 x 6.5" (165mm) mid horn
1 x 1" (25mm) HF compression driver
45Hz-20Hz ±3dB
LF: 800 AES, 3200W peak
MF(/HF): 150W AES, 600W peak
HF: 60W AES, 240W peak
LF: 100dB 1 Watt/1 metre
MF(/HF): 106dB 1 Watt/1 metre
HF: 110dB 1 Watt/1 metre
420Hz active, 2kHz active or passive
LF: 4 ohms
MF/HF: 8 ohms
HF: 8 ohms
90 degs horizontal x 50 degs vertical
LF: (W) 670mm x (H) 1010mm x (D) 470mm
(W) 26.4ins x (H) 39.8ins x (D) 18.5ins
MF/HF: (W) 720mm x (H) 885mm x (D) 610mm
(W) 28.3ins x (H) 34.8ins x (D) 24ins
LF: 61kg (134.5lbs)
MF/HF: 18kg (39.6lbs)
LF: (W) 670mm x (H) 1030mm x (D) 490mm
(W) 26.4ins x (H) 40.6ins x (D)19.3ins
MF/HF: (W) 1000mm x (H) 750mm x (D) 840mm
(W) 39.4ins x (H) 29.5ins x (D) 33ins
LF: 61kg (134.5lbs)
MF/HF: 18kg (39.7lbs)
