STEP 4 Manually Configure Your Static IP
The Linksys adaptor you have received for your Broadband Phone Service is fully configured,
and within minutes you can begin to make your calls. Members using Static IP on their home
network may wish to configure the adaptor with Static IP. If you have otained a Static IP with
your internet service provider (ISP) and wish to configure your adaptor with your Static IP
settings, please follow the instructions below:
1. You will first have to obtain the following information: IP Address, Default Gateway
and Subnet Mask. If you are using a router, please contact the router manufacturer
for instructions for retrieving this information from the router directly. If you have
obtained a Static IP from your internet service provider (ISP) and wish to configure
your adaptor with your Static IP settings, please obtain the information directly from
your ISP.
2. Pick up the telephone receiver of the phone connected to the adaptor and dial * * *
*. You will hear a voice prompt say "Linksys configuration menu."
3. Press the keys 101# on your analog phone to access the static IP configuration
menu.
4. Press 0 # to disable DHCP, then press 1to save the setting.
5. Press # to access the IP address Menu.
6. Enter your IP address followed by # (i.e., "1 2 3 * 4 5 * 6 7 * 8 9 #" to represent
the IP 123.45.67.89). Press 1 to save the setting.
7. Press 3 # to access the Default Gateway Menu.
8. Enter your Default Gateway (i.e. "1 2 3 * 4 5 * 6 7 * 8 9 #" to represent the
gateway 123.45.67.89. Press to save the setting.
9. Press 2 # to access the subnet mask menu.
10. Enter your Subnet Mask (i.e. "1 2 3 * 4 5 * 6 7 * 8 9 #" to represent the subnet
mask 123.45.67.89. Press to save the setting.
You have now completed the static IP configuration.
To verify that the configuration is correct, please pick up the telephone receiver on the phone
connected to the ATA, and dial * * * * to enter the Linksys configuration menu. Dial 110 # to
hear the adaptor read back the IP address that you have configured. If the IP read aloud is
not the same as the one that you have just entered in, please repeat steps 1 through 10
above once again to ensure that you have entered the correct settings.
