If #2744 is driven, then one #0223 100 Mbps Token-Ring Specify is required
for each #2744 driven.
If #5700/#5701 is driven, then one #0226 1 Gbps Ethernet Specify is required
for each #5700/#5701 driven.
Up to three IOA LAN features can be supported by the #4710/#4810, depending
on the system unit or tower position into which the #4710/#4810 is placed.
Native AS/400 functions are
The #4710, #4810, or #9710 does not support external host LAN.
The #4710/#9710 is supported in the system unit of Models 820, 825, 830, 840,
870, and 890. It is also supported in the following expansion towers when
attached to these models and the Model 520, 550, 570, and 595 : #0578, #0588,
#0595, #5074, #5075, #5078, #5079, #5088, #5094, #5095, and #5294, #8079,
#8094, #9079, and #9094.
The #4810 is supported in the system unit of Models 270, 800, and 810. It is also
supported in the #5075 #0578/#5078, #0588/#5088, and #0595/#5095 when
these towers are attached to a Model 270, 800, or 810. For Models 800 and 810,
if the #4810 is placed in a #5094 or #5294, the customer installation instructions
indicate that a CE must be called for card installation.
The #9710 is supported in the system unit of Models 825, 870, and 890. It is also
supported in the following expansion towers when attached to these Models:
#0578, #0588, #0595, #5074, #5075, #5078, #5079, #5088, #5094, #5095, and
#5294.
The #4710, #4810, or #9710 does not require a #2843, #2844, #9943 or #9844,
but placement is limited to specific slots within the various system units and
expansion towers. The #4710, #4810, or #9710 requires two PCI card slots and
does not hang over a third slot.
The #4710, #4810, or #9710 ships with a standard keyboard or mouse splitter
cable and can sup port either standard or USB 1.1 keyboard, mouse, or both.
Windows 2000 Server and Windows 2003 Server operating systems are
supported. The following conditions apply:
#0325 (IPCS Extension Cable for Windows) is the default but may be
removed.
A minimum of 1 GB server memory is required.
#1700 (IPCS Keyboard or Mouse for Windows) is the default in countries
(regions) that offer it.
A display must be connected to the Integrated Server to support Windows.
