9.2.3.3

X2 PROFINET

Data Transmission Rate and Cables
For PROFINET, you require a data transmission rate of 100 Mbit/s (Fast Ethernet). The
interfaces are designed for full-duplex mode; in other words, the ports can both transmit and
receive. For data transfer purposes you can use electrical twisted copper cables (twisted pair,
4-wire, 100Base-T):
● The transmission characteristics of these cables must meet the requirements of CAT5.
● The maximum length of the connections between the end device and network component
Pin assignment
Table 9-16
Pin
1
2
3
4
5
6
7
8
Cable specification
Table 9-17
Characteristic
Connector type
Cable type
Max. cable length
LED displays
For diagnostic purposes, the RJ45 sockets are each equipped with a green and a yellow LED.
This allows the following information to be displayed for the respective PROFINET port:
Table 9-18
Name
Link
NCU 7x0.3 PN, NCU 7x0.3B PN
Manual, 06/2014, 6FC5397-1EP40-5BA1
or between two network components (e.g. switch ports) must not exceed 100 m.
PROFINET interfaces X2, ports 1, 2
Signal name Signal type
TX+ O
TX- O
RX+ I
N.C. -
N.C. -
RX- I
N.C. -
N.C. -
Cable specification at X2, ports 1, 2
PROFINET ports LED displays
Color
Green
Meaning
Transmit data +
Transmit data -
Receive data +
Reserved, do not use
Reserved, do not use
Receive data -
Reserved, do not use
Reserved, do not use
Version
RJ45 socket
Industrial Ethernet cable (CAT5)
100 m
Status Meaning
lit Transfer rate 100 Mbit/s
off No or faulty connection
Connectable components
9.2 PP 72/48D PN
