- Page 1 Service manual ACP-12CFIFM35GEI RoHS...
- Page 3 Mo d e l GTH D (0 9 )AAN K3 A1 AI ACP-12CFIFM35GEI GTH D (1 8 )AAN K3 A1 AI Fa n Mo to r Sp e e d (r/m in ) 7 9 0 /6 7 0 /5 5 0 7 9 0 /6 7 0 /5 5 0 1 0 7 0 /9 7 0 /8 7 0 (H /M/L )
- Page 4 Floor Ceiling Series Suitable for : ACP-12CFIFM35GEI Indoor Unit Swing assy Air outlet Decorative panel Air inlet Front grill Remote controller...
-
Page 5: Outline And Installation Dimension
Outline and Installation Dimension Outline and Installation Dimension of Indoor Unit Outline Dimension Installation Dimension... -
Page 6: Electric Diagram
Floor Ceiling Series Electric Diagram ACP-12CFIFM35GEI... -
Page 7: Basic Functions
Controller Function Manual and Operation Instruction Controller Function Manual 1 Temperature Parameters Indoor ambient temperature (T Evaporator tube temperature (T amb. tube 2 Basic Functions 2.1 Cooling Mode 1.Temp. can be set in the range of 16-30 2. The unit will firstly run at high fan speed for 8s and then switch to preset fan speed. 3. - Page 8 Floor Ceiling Series 3. Other Control 3.1 Buzzer When the unit is energized or receives signal from valid button or remote controller , the buzzer will give out a beep. 3.2 Auto Fan Speed of Indoor Fan Indoor fan will automatically select high,middle or low fan speed according to ambient temp.During switchover, there is 3min and 30s delay protection.
- Page 9 3.7 Communication Malfunction Communication malfunction occurs, if the unit can not receivie correct signal for 3 minutes continuously.Under AUTO HEAT or HEAT mode, the unit runs with blowing residual heat.Under other mode, indoor fan keeps its original operating state. If signal from wire controller can not be received for 1min continuously, communication malfunction with wire controller occurs.
- Page 10 Floor Ceiling Series 3.10 Turbo Function (invalid when connected with wire controller) After setting of turbo function by remotr controller, indoor fan will run at high speed forcibly and turbo setiing is send to outdoor unit at the same time. Instruction to Wire Controller (Optional) NOTE:1.
- Page 11 When the unit is running operated by wire controller The Codes of Failure Definitions are as Follows: Meaning Wire controller Fault code Compressor high pressure protection unit stop Indoor unit anti-freezing protection Low-pressure protection unit stop Air exhaust protection unit stop Over current protection unit stop Communication malfunction unit stop Unit modes conflict...
-
Page 12: Disassembly Procedures
Floor Ceiling Series 7 7 7 7 7 Disassembly Procedures Disassembly Procedures for Indoor Unit Operating Procedures / Photos 1.Disassemble Front Grill and Filter Manually pull the clasp 1 of front grill downwards to open the front grill.Loose the clasp 2 with pincers to remove the front grill. - Page 13 Operating Procedures / Photos 3.Disassemble Front Panel Fig.7-4 Unscrew the 4 screws at the front panel and 3 screws in the sponge.Lift the front panel upwards to remove it. Screws Fig.7.5 Screws Fig.7.5 Screws 4.Disassemble Rear Side Plate (air outlet) Remove the flanneletteand unscrew the 2 screws at the rear side plate to remove it.
- Page 14 Floor Ceiling Series Operating Procedures / Photos Axile Bush Fig.7-8 6.Disassemble Water Tray Sub-assy Unscrew the 4 screws fixing the right and left side of the water tray to remove it. Fig.7-9 Screw Fig.7-9 7.Disassemble Evaporator Assy Unscrew the 4 screws fixing the cover plate of evaporator.Pull out the 3 temp sensors on the pipes and then unscrew the 2 screws at the left Screws...
- Page 15 Operating Procedures / Photos Temp Sensor Fig.7-11 Temp Sensor Fig.7-12 8.Disassemble Electric Box Assy Unscrew the 2 screws fixing the electric box cover to pull out the cover upwards.Loosen the wiring terminals of fan motor and guide louver motor and then remove the ambient temp sensor bound by the tie line at the side of elelctric box.At last unscrew the 3 screws fixing the electric box to remove it.
- Page 16 Floor Ceiling Series 9.Disassemble Cross Flow Fan Loosen the clasps in and at the front and back of the propeller housing to remove it from the motor support.Unscrew the 1 screw fixing cross flow fan with a inner hexagon spanner to remove it. Fig.7-15,7-16 Propeller Housing Clasps...
- Page 17 Exploded View...
- Page 18 Floor Ceiling Series Components and Parts List of Indoor Unit 1 Part Code Description GTHD(09)AANK3A1AI ACP-12CFIFM35GEI Connecting Lever Right Swing Motor Fixer Right Fixing Plate of Evaporator Foam of Right Side Plate Right Fixing Plate Right Decoration Panel Pipe Clamp Plate...
- Page 19 Part Code Description GTHD(09)AANK3A1AI ACP-12CFIFM35GEI Front Grill Clip 2 Buttons Panel Front Panel Water Tray Panel Motor Support Left Decoration Panel Left Fixing Plate Left Side Foam Left Fixing Plate of Evaporator Motor Clamp Step Motor MP35CA Step Motor MP35CB...
- Page 20 Floor Ceiling Series Components and Parts List of Indoor Unit 2 Part Code Description GTHD(18)AANK3A1AI Rear Side Plate 01302013 Handle 26232001 Left Decoration Plate 261124151 Rear Side Plate of Air Outlet 01302015 Louver 1051953201 Right Decoration Plate 261124161 Shaft of Louver II 10512026 Louver Support 24212019...
- Page 21 Part Code Description GTHD(18)AANK3A1AI Front Grill Clip 2 26252003 Buttons Panel 201620041 Front Panel 01532001 Water Tray Panel 01272205P Motor Support 01709532 Left Decoration Panel 26112028 Left Fixing Plate 01332405 Left Side Foam 12312403 Left Fixing Plate of Evaporator 01072410 Motor Clamp 26112026 Step Motor MP35CA...
