Clarion CZ109 Service Manual

(CZ109)
This product is a lead free model.
Lead free solder is used in PWB stamped LF mark.
Please keep the following conditions when you repair.
1. Use lead free solder.
* Koki's lead free solder S3X-55M 0.6mm
(CLARION Parts No.642-0231-01)
* Koki's lead free solder S3X-55M 1.0mm
(CLARION Parts No.642-0231-02)
2. Use a nitrogen solder system.
3. Do not use "General solder" and "Lead free solder"
together.

SPECIFICATIONS

FM tuner section
Frequency range:
Usable sensitivity:
50dB quieting sensitivity:
Alternate channel selectivity: 70dB
Stereo separation:
Frequency Response:
AM tuner section
Frequency range:
Usable sensitivity:
CD player section
System:
Usable discs:
Frequency response:
Dynamic range:
Harmonic distortion:
Xiamen Clarion Electrical Enterprise Co., Ltd
8/F., Xiamen Mail Processing Centre, No.275 Lujiang Road , Xiamen,China
Tel:+86-592-2389080 Fax:+86-592-2389089
Clarion Co., Ltd.
7-2, Shintoshin, Chuo-Ku, Saitama-Shi, Saitama 330-0081, Japan
87.9MHz to 107.9MHz
(PE-3159B-A)
87.0MHz to 108.0MHz
(PE-3159K-A/B)
9dBuV
15dBuV
35dB(1kHz)
30Hz to 15kHz(+3/-3dB)
530kHz to 1710kHz
(PE-3159B-A)
531kHz to 1629kHz
(PE-3159K-A/B)
25dBuV
Compact disc digital audio system
Compact disc
5Hz to 20kHz(+1/-1dB)
85dB(1kHz)
0.01%
Service Manual
CD/MP3/WMA Receiver
CZ109
Model
(PE-3159B-A for U.S.A)
CZ109A
Model
(PE-3159K-A/B for Other Countries)
MP3/WMA mode
MP3 Sampling rate:
MP3 Bit rate:
WMA Bit rate:
Logical format:
Audio section
Maximum power output:
Bass control action:
Treble control action:
Line output level:
General
Power supply voltage:
Current consumption:
Speaker impedance:
Weight:
Dimensions(mm):
COMPONENTS
PE-3159B-A/PE-3159K-A/B
1. Source unit
2. Mounting bracket
3. Mounting bracket (PE-3159K-A/B)
4. Mounting bracket (PE-3159K-A/B)
5. Escutcheon(OUT)
6. Extension lead
7. Parts bag
7-1. Removal key
7-2. Stopper(PE-3159B-A)
7-3. Screw(M5x8)(PE-3159K-A/B)
8. Remote control unit
9. Battery (PE-3159B-A)
-1-
Published by Service Dept.
298-6623-00 FEB. 2009P
Printed in P.R.C.
8kHz to 48kHz
8kbps to 320kbps / VBR
48kbps to 192kbps
ISO9660 level1, 2
JOLIET or Romeo
50Wx4
+14/-14dB(100Hz)
+14/-14dB(10kHz)
1.8V(CD 1kHz)
14.4V DC(10.8 to 15.6V allowable),
negative ground
Less than 15A
4ohm(4ohm to 8ohm allowable)
Source unit 1.14kg
Remote control unit
(PE-3159B-A)
Source unit
178(W)x50(H)x155(D)
Remote control unit
44 (W) 113 (H) 11 (D)
x x
(PE-3159B-A)
(PE-3159B-A) 300-8088-00
300-4976-00
300-7742-00
370-6451-00
854-6433-50
331-2497-00
335-4899-20
716-0496-51
(PE-3159B-A)
RCB-176-200
CZ109/CZ109A
40 g
1
1
1
1
1
1
1
2
1
1
1
1
