- Page 1 D2016 PORTABLE 10" LCD MONITOR AND DVD PLAYER...
- Page 2 Notice: 1.This Product incorporates copyright protection technology that is pro- tected by method claims of certain U.S. Patents and other intellectual property rights owned by Macrovision Corporation and other rights own- ers. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited view- ing uses only unless otherwise authorized by Macrovision Corporation.
-
Page 3: Table Of Contents
Content A. Introduction ... 4 B. Cautions and Warnings ... 4 C. Contents ... 6 D. Powering and installation ... 6 E. Controls, Indicators, and Connectors ... 7 F. Loading and Playing a Disc ... 8 G. Basic Operation... 9 H. -
Page 4: Introduction
A. Introduction Thank you for choosing the D2016 portable DVD player. The main features include a 10" Wide Screen (16:9 Aspect Ratio) Liquid Crys- tal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in vehicles, hotels, offices or your home. - Page 5 operation, never cover or block the slots and openings with a cloth or other material. Keep the unit away from an open flame such as fire, candle etc. It is hazardous to replace the battery incorrectly. Replace the battery only with the same or equivalent type, in order to protect the environment, please dispose the battery properly.
-
Page 6: Contents
2. Powering the system in a car Plug one end of the DC Power adapter into the DC input jack on the unit, then plug the other end into the vehicle power outlet. Note: Unplug the D2016 when not in use. DC 9V A / V... -
Page 7: Controls, Indicators, And Connectors
E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 2) 1) Battery Release Button 2) DC 9-12V Input Jack 3) AV Jack 4) AV In/Out Switch 5) USB Port 6) Game Port 7) Power On/Off Switch 8) SD Card Slot 9) Power Indicator 10) Remote Control Sensor * Connecting to headphone jack number 1 will disable the... -
Page 8: Loading And Playing A Disc
2. Remote Control (Refer to figure 3) 1) Setup Button 2) Up Button 3) Skip- Button 4) Enter Button 5) Reverse/Left Keypad 6) DOWN Button 7) Numeric Button 8) Display Button 9) Zoom Button 10) SD/USB/DVD Button 11) Skip+ Button 12) A-B Repeat Button 13) Forward/Right Keypad 14) 1/All Repeat Button... -
Page 9: Basic Operation
G. Basic Operation POWER OPEN PLAY /PAUSE STOP NEXT PREVIOUS FORWARD REVERSE LEFT/RIGHT/UP/DOWN ENTER NUMBERS MENU REPEAT DISPLAY SUBTITLE AUDIO ZOOM SETUP Turn the unit on/off Remove/load the disc Start Play/Execute item or setting Still Picture (1 time) Stop at the present playing point / (2 times) Stop playing Go to the next chapter, track or scene during play back... -
Page 10: Menu
H. Menu A DVD is divided into sections called titles and chapters. When you play a DVD’s root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu. -
Page 11: Audio Language
2. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are mul- tiple languages press ‘SUBTITLE’ again to select another subtitle lan- guage. -
Page 12: Normal Playback
4. ZOOM During playback press ‘ZOOM’ mutiple times to enlarge the picture by 2X, 3X or 4X or reduce the picture by 1/2,1/3,1/4. 5. A-B REPEAT a. During playback press the ‘A-B’ button once to set the Starting Point A. b. -
Page 13: Playing Audio Cds
6. REPEAT a. During playback press ‘REPEAT’ repeatedly to cycle through the repeat modes. Chapter: Repeat the current chapter Title: Repeat the current title All: Repeat all chapters and titles Repeat Off: Resume normal playback J. Playing Audio CDs When playing an audio CD press the DISPLAY button constantly on the remote to view time information. -
Page 14: Playing Mp3 Discs
Total Elapsed: The current track playing and the total time that the Total Remain: Display Off: USING THE1/ALL REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: • Track- repeats the track that is playing. •... - Page 15 4. Use the (PREVIOUS) button to move to the beginning of the previous song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: • Repeat One (repeat playback of a song) •...
-
Page 16: Playing Jpeg File
L. Playing JPEG file 1) Load the JPEG Disc into tray. 2) Select JPEG file by pressing “UP/DOWN” button. 3) You can preview the JPEG file by pressing “Play” or “ENTER”. 4) Pressing the “Left Key“ will rotate the picture counterclockwise. Pressing the “Right Key“... -
Page 17: Connecting To A Tv Or Another Monitor
M. Connecting to other Electronical Equipment 1. Connecting to a TV or another monitor ( Refer to Figure 4) a. Position the AV In/Out Switch to “Out” Position. b. Connect one end of the audio/video adapter cable’s black 1/8” plug into the unit’s AV jack. - Page 18 4. SD Card and Thumb Drive/Digital Cameras With no disc in the unit, insert either an SD card, Thumb Drive, or digital camera with JPEG or MP3 files into the appropriate input. The D2016 will automatically select the input in use.
-
Page 19: Setup
N. Setup 1. General Setup Page 1)With no disc inside the player, press ‘SETUP’ to display the Main screen of the Setup Menu on the screen and “General Setup Page” appears. At the same time, “ Setup Menu. 2)Press the ENTER button, “TV Display” is highlighted. 3) Press the page. - Page 20 2.Video Quality Setup 1)In Setup menu, Press the Setup” and is highlighted. Press ENTER to enter the video quality setup page. 2)Press the ENTER button, “Brightness” is highlighted. 3)Press the quality setup page. 4) Press to enter the sub menu. 5) Press the and press ENTER to confirm your selection.
- Page 21 4) Press to enter the sub menu. 5) Press the button to select the desired option and press ENTER to confirm your selection. 6) Repeat steps 3-5 for other menus. Note: Press to return the previous menu. a) Audio b) Subtitle c) Disc Menu Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages.
-
Page 22: Specifications
O. Specifications Compatible DISC: DVD/CD/MP3 Signal system: NTSC Panel size: 10 inch Frequency response: 20 Hz to 20 kHz Video output: 1 Vp-p/75 Ohm, unbalanced Audio output: 1.4V Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm Power source: DC 9-12V Power consumption: 12 W... - Page 23 battery in optimum condition. Under no circumstances short the bat- tery terminals, store the battery in a metal container, or leave the bat- tery in a humid or damp environment. Ideally, store the battery in an airtight container with desiccant or other dehumidifying agent. Each full recharge takes approximately five-hours and one full charge can provide power to the player for at least 2 hours.
- Page 24 Installing the Battery Pack: 1. First, make sure the player is in “Power Off” mode and that the AC power supply has been disconnected. 2. Flip down the monitor. 3. Push the battery towards the rear of the player until it locks into position.
-
Page 25: Troubleshooting
Q. Troubleshooting PROBLEM No sound or distorted sound Can’t advance through a movie The icon ( appears on screen • The disc might be damaged. Try another Picture is distorted • It is normal for some distortion to appear • Some discs have sections that prohibit rapid No forward or reverse scan •... - Page 26 Troubleshooting (Cont) PROBLEM IR sensor inoperative Disc won’t play Play starts, but then stops immediately SOLUTION • Verify that the batteries in the remote are fresh. • Verify that the remote sensor eye is not obstructed. • Verify that the infrared transmitter is affixed over the sensor eye of the component to be controlled.
-
Page 27: Day Limited Warranty
90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from... - Page 28 © 2006 Audiovox Electronics Corporation 128-7687...
