Preparing the Appliance
Selection of the nozzles
You need to use the matching nozzles to
ensure that your pressure washer works
properly.
Note:
Delivery rate (l/min): See operating in-
structions or type plate of your pressure
washer.
Pressure washer with delivery rate of
less than 5.8 l/min (350 l/h)
e.g.: K 2 – K 3
Use green nozzles.

Note:To ensure a trouble free opera-
tion of your pressure washer, you
must replace the two violet nozzles
with the green nozzles.
Pressure washer with delivery rate
from 5.8 l/min (351 l/h) to 7.5 l/min
(450 l/h)
e.g.: K 3 – K 5
Use violet nozzles.

Note: The violet nozzles are
premounted.
Replacement of nozzles
Illustration
a Remove the clip.
b Pull out the violet nozzle.
c Insert the green nozzle.
d Re-insert the clip.
Application
Note: Always use Kärcher water filter
(order no. 4.730-059.0) during suction
operations of the pressure washer.
Cleaning horizontal surfaces
Note: Outdoor surfaces should be
swept before the T-Racer is used to
avoid damaging the nozzles.
Connect the T-Racer and both wands
with the trigger gun.
Illustration
Connect lower wand (green) with T-

Racer.
1 Press the bayonet connection into
the bayonet catch, then turn by 90°
until it locks into place.
2 Tighten the union nut.
Connect upper wand (yellow) with

lower wand (green).
1 Press the bayonet connection into
the bayonet catch, then turn by 90°
until it locks into place.
2 Tighten the union nut.
Connect trigger gun with upper wand

(yellow).
1 Press the bayonet connection into
the bayonet catch, then turn by 90°
until it locks into place.
2 Tighten the union nut.
Illustration
CAUTION
Do not run over freestanding corners.
Adjust the twist grip "Power" in accor-
dance with the cleaning surface.
Do not reach under the edge of the T-
Racer while the device is in operation.
EN 5
