Mounting the communication unit
Fix the unit to the chosen location with six self-tapping screws.
Connecting the antenna cable to the communication unit
1. Strip the antenna coaxial cable, leaving sufficient slack for connection to the CU.
2. Attach the N-plug to the cable in accordance with the instructions (see the next several
pages).
SIM CARD
SIM CARD INSIDE
WHEN CHANGING MODEM UNIT
REMOVE COVER
AND TAKE OUT SIM CARD
Dia 6.5
11-32 VDC / 110W
NOT IN USE
(50
TERM)
23
ON/OFF
RF
N-P-8DFB
N-P-12DSFA
From antenna unit
