Placing the terminal adapter
The terminal adapter may be installed almost anywhere. However, install it where vibration
is minimal and locate it away from heat sources.
Placing the ISDN handset as a standard telephone
The ISDN handsets may be installed as standard telephones. The units may be installed
anywhere onboard the vessel.
Four separate ISDN ports are available on the communication unit as RJ45 jacks or screw
terminal blocks.
Placing the telefax (option)
A digital telefax (Group 4) can be connected to one of the ISDN outlets, or to an ISDN bus
for transfer at 64 kbps rate.
An analog telefax (Group 3) should be connected to the Terminal Adapter
Placing the PC (user supply)
A PC w/ISDN card can be connected to one of the ISDN outlets, or to an ISDN bus for 64
kbps rate data communication for installation up to 100 m away from the communication
unit.
With the PC connected to the USB/RS-232/RS-422 port it can also be used for control and
configuration of the Communication Unit.
This requires that the vtLite Marine program accessible on the FELCOM CD is installed.
Connection to the USB/RS-232/RS-422 port also allows 64 kbps data transmission. See the
PC's user's manual.
Cable lengths:
• ISDN port:
See "ISDN telephones/equipment" on page 27.
• USB port:
3 m
• RS-232 ports: 3 m
• RS-422 port: 100 m
12
