Lenovo Flex System x280 X6, x480 X6, and
x880 X6 Compute Node
Installation and Service Guide
Machine Types: 7196, 4258

Advertisement

Table of Contents
loading

Related Manuals for Lenovo Flex System x480 X6 Compute Node

Summary of Contents for Lenovo Flex System x480 X6 Compute Node

  • Page 1 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide Machine Types: 7196, 4258...
  • Page 2 Before using this information and the product it supports, read the general information in Appendix B “Notices” on page 1045, the Warranty Information document, and the Safety Information and the Environmental Notices and User Guide documents on the Lenovo Documentation CD. Sixth Edition (March 2017) ©...

  • Page 3: Table Of Contents

    Brocade documentation ... . Installing the operating system without using The Lenovo Documentation CD ..ServerGuide ....
  • Page 4 Avis de conformité à la réglementation Installing an I/O expansion adapter ..1011 d'Industrie Canada ..1048 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 5 Index....1053 Korea Communications Commission (KCC) statement ....1050 © Copyright Lenovo 2014, and 2017, 2017...
  • Page 6 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 7: Safety

    Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. Antes de instalar este produto, leia as Informações sobre Segurança. © Copyright Lenovo 2014, and 2017, 2017...

  • Page 8: Safety Statements

    Be sure to read all caution and danger statements in this documentation before you perform the procedures. Read any additional safety information that comes with your system or optional device before you install the device. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 9 Do not: • Throw or immerse into water • Heat to more than 100°C (212°F) • Repair or disassemble Dispose of the battery as required by local ordinances or regulations. © Copyright Lenovo 2014, and 2017, 2017...
  • Page 10 Hazardous energy is present when the blade is connected to the power source. Always replace the blade cover before installing the blade. UL regulatory information This device is for use only with Listed chassis. viii Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 11: Chapter 1. Introduction

    Chapter 1. Introduction The Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Types 7196 and 4258 is a high-availability, scalable compute node that is optimized to support the next-generation microprocessor technology and is ideally suited for medium and large businesses.

  • Page 12: Related Documentation

    The model number and serial number are on the ID label on the bezel on the front of the compute node, and on a label on the bottom of the compute node that is visible when the compute node is not in the Lenovo Flex System chassis.

  • Page 13: Brocade Documentation

    Safety Information document. • Lenovo Warranty Information This printed document contains the warranty terms and a pointer to the Lenovo Statement of Limited Warranty. • Environmental Notices and User Guide This document is in PDF.

  • Page 14: The Lenovo Documentation Cd

    The Lenovo Documentation CD contains documentation for the compute node in Portable Document Format (PDF). It includes a documentation browser to help you find information quickly. You can run the Lenovo Documentation CD on any computer that meets the hardware and software requirements.

  • Page 15: Notices And Statements In This Document

    2. The operating system in the compute node must provide USB support for the compute node to recognize and use USB media drives and devices. The following is a summary of the features and specifications of the Lenovo Flex System x280 X6, x480 X6, and x880 X6 compute node.
  • Page 16 (CMM, Lenovo XClarity Administrator, or Flex System Manager management node) determines the security mode in which the compute node operates. Environment: The Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node complies with ASHRAE class A3 specifications. •...
  • Page 17 – Maximum rate of temperature change: 5°C/hr (41°F/hr ) • Power off – Temperature: 5°C to 45°C (41°F - 113°F) – Relative humidity: 8% - 85% – Maximum dew point: 27°C (80.6°F) • Storage (non-operating): – Temperature: 1°C to 60°C (33.8°F - 140°F) –...

  • Page 18: What Your Compute Node Offers

    Optionally, the IMM2 also provides a virtual presence capability for remote systems management. The IMM2 provides remote systems management through industry-standard interfaces: – Common Information Model (CIM) Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 19 Lenovo Flex System chassis. This policy is enforced when the initial power is applied to the Lenovo Flex System chassis or when a compute node is inserted into the Lenovo Flex System chassis.
  • Page 20 – The Lenovo XClarity Administrator is a virtual appliance that you can use to manage a Flex System chassis in a secure environment. The Lenovo XClarity Administrator provides a central interface to perform the following functions for all managed endpoints: –...

  • Page 21: Lenovo Xclarity Administrator

    Fsetup.html. – Free 90-day trial Lenovo XClarity Administrator offers a free, 90-day trial license that enables you to use all available features (including operating-system deployment, firmware maintenance, and configuration management) for a limited time. After 90 days, you can continue to use Lenovo XClarity Administrator to manage and monitor your hardware for free;...
  • Page 22 Lenovo XClarity Administrator provides a centralized view of all events and alerts that are generated from the managed endpoints. When a CMM or IMM detects an issue, an alert or event is passed to the Lenovo XClarity Administrator and is displayed in the events or alerts log. A summary of all alerts and events is visible from the Dashboard and the Status bar.

  • Page 23: Reliability, Availability, And Serviceability Features

    Lenovo XClarity Administrator is available stand-alone or as a bundled offering that is known asLenovo XClarity Pro. Lenovo XClarity Pro is composed of the base Administrator product plus two Lenovo XClarity Integrator modules that provide integration into Microsoft Systems Center or VMware vCenter. Together, these tools provide discovery, monitoring, configuration, and management functions to reduce the cost and complexity of routine system administration for System x, NeXtScale, and Flex System endpoints.

  • Page 24: Power, Controls, And Indicators

    When this green LED is lit, it indicates that the hard disk drive is powered on. When flashing, this LED indicates that the drive is in use. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 25 To view the IMM2 event log see “IMM event log” on page 66. The check log LED can be turned off through the CMM led command, the CMM web interface, Lenovo XClarity Administrator (if available), or Flex System Manager management software (if available).
  • Page 26 The system administrator can remotely light this blue LED to aid in visually locating the compute node. When this LED is lit, the identify LED on the Lenovo Flex System chassis is also lit. The identify LED can be lit and turned off through the CMM led command, the CMM web interface, Lenovo XClarity Administrator (if available), or Flex System Manager management software (if available).

  • Page 27: Console Breakout Cable

    – Power permissions have not been assigned to the compute node through the Chassis Management Module. – The Lenovo Flex System chassis does not have enough power to turn on the compute node. – The IMM2 in the compute node is not communicating with the Chassis Management Module.

  • Page 28: Turning On The Compute Node

    • If a power failure occurs, the Lenovo Flex System chassis and the compute node can be configured through the CMM power command and the CMM web interface to start automatically when power is restored.

  • Page 29: Turning Off The Compute Node

    Use this information for details about turning off the compute node. When you turn off the compute node, it is still connected to power through the Lenovo Flex System chassis. The compute node can respond to requests from the IMM2, such as a remote request to turn on the compute node.

  • Page 30: System-Board Layouts

    2 Ligthpath diagnostic Internal panel DIMMs DIMMs DIMMs DIMMs expansion USBs System-board jumpers Use this information to locate the system-board jumpers. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 31: System-Board Leds

    The following illustration shows the locations of the jumpers on the system board. security IMM TPM Power permision The following table describes the function of each jumper on the system board. Jumper number Description IMM TPM (JP2461) Two-pin jumper. The default is no jumper. Place a jumper on pins 1 and 2 to indicate a physical presence to the IMM2 TPM chip.

  • Page 32: System-Board Switches

    System-board switches Use this information to locate the system-board switches. The following illustration shows the location of the switch blocks on the system board. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 33 On Off On Off SW8111 SW8110 switch switch The following table describes the functions of the switches. Switch number Description Switch setting Definition Password override The default position is off. SW8110-1 Changing this switch to the on position overrides the power-on password.

  • Page 34: Working With Scalable Partitions

    SW8111-8 MUX (U9811) TX/RX SIO RTS/CTS Working with scalable partitions This topic provides information about connecting multiple compute nodes together to create scalable partitions. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 35: Flexnode Partitioning

    A multi-node complex supports the following implementation modes: • Single partition: The configuration functions as a single compute node that contains up to eight microprocessors and 192 DIMMs. When the configuration is implemented as a single-hardware partition, the lowest node bay ID in the chassis is the primary node. The single partition uses the operating system of the primary compute node.
  • Page 36 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 37: Chapter 2. Configuring

    The firmware on the secondary compute nodes is automatically updated. 2. If you update firmware in a scalable partition using Lenovo ToolsCenter Bootable Media Creator, you only have to upgrade each primary node. The firmware on the secondary compute nodes is automatically updated.
  • Page 38 Creator, you can create a single bootable image on supported media (such as CD, DVD, ISO image, USB flash drive, or set of PXE files) that bundles multiple Lenovo Flex System tools and updates from UpdateXpress System Packs, which contain Windows and Linux firmware updates.

  • Page 39: Recovering A Uefi Image

    7. Update the UEFI code (see “Updating firmware and device drivers” on page 27). 8. Turn off the compute node and remove it from the Lenovo Flex System chassis (see “Turning off the compute node” on page 19 and “Removing a compute node from a chassis” on page 975).

  • Page 40: Configuring The Compute Node

    “System-board switches” on page 22). 11. Replace the cover and reinstall the compute node in the Lenovo Flex System chassis (see “Installing the compute node cover” on page 988 and “Installing a compute node in a chassis” on page 976).

  • Page 41: Using The Setup Utility

    You can access the Setup utility remotely through the CMM web interface. From the CMM web interface, select Launch Compute Node Console. For more information, see the "Flex System Chassis Management Module: User's Guide" at http://pic.dhe.ibm.com/infocenter/flexsys/information/topic/com.lenovo.acc.cmm.doc/ cmm_user_ guide.html. All fields and options are described in the CMM web interface online help.
  • Page 42 Select this choice to view the system-management network interface port, IMM2 MAC address, current IMM2 IP address, and host name; define the static IMM2 IP address, subnet mask, and gateway address; Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 43 specify whether to use the static IP address or have DHCP assign the IMM2 IP address; save the network changes; and reset the IMM2. • Reset IMM to Defaults Select this choice to restore the IMM2 to the manufacturing default settings. The IMM2 controller restarts after you restore the settings.
  • Page 44 – Input minutes for assertion: select this option to input a number from 0~100 which stands for the number of minutes Remote Physical Presence is asserted. Physical Presence Policy has to be enabled before this option is available. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 45 – Refresh assert status: select this option to view the current status of asserting. – Rollback Configuration Select this choice to allow (enable)/forbid(disable) rolling back to an older version of UEFI. Default is Enable. – Secure Boot Configuration Select this choice to choose from the following Secure Boot options. –...
  • Page 46 • Load Default Settings Select this choice to cancel the changes that you have made in the settings and restore the manufacturing settings. • Exit Setup Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 47: Nx Boot Failure

    Select this choice to exit from the Setup utility. If you have not saved the changes that you have made in the settings, you are asked whether you want to save the changes or exit without saving them. Nx boot failure Configuration changes, such as added devices or adapter firmware updates, and firmware or application code problems can cause a compute node to fail the power-on self-test (POST).

  • Page 48: Using The Boot Selection Menu Program

    • Although the command syntax is shown in mixed case, the commands are not case sensitive. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 49 Locally: Keyboard Controller Style (KCS) This access method uses the IPMI/KCS interface. The IPMI driver must be installed; with some operating systems, the IPMI driver is installed by default. The ASU provides the corresponding mapping layer. To update the UUID, in the ASU command-line interface, enter the following command: asu set SYSTEM_PROD_DATA.SysInfoUUID uuid where uuid is the user-assigned hexadecimal value, up to 16 bytes, that identifies the compute node.
  • Page 50 To update the DMI/SMBIOS data, complete the following steps: Step 1. In the ASU command-line interface, enter the following command: asu set SYSTEM_PROD_DATA.SysInfoProdName xxxxyyy –host ipaddress [–user userid][–password password] where: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 51: Configuring A Raid Array

    You can use two hard disk drives in the compute node to implement and manage RAID level-0 (striping) or RAID level-1 (mirror) arrays in operating systems that are listed on the ServerProven list at http://www.lenovo.com/ serverproven/. For the compute node, you must configure the RAID by using the LSI Configuration Utility program.

  • Page 52: Features On Demand

    1. If the compute node is configured in the Setup utility to boot in legacy mode, you must leave UEFI option ROM initialization enabled for devices for which Features on Demand feature keys are installed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 53: Setting Up The Lan-On-Motherboard (Lom) Feature

    This topic provides information about setting up the LAN-on-motherboard (LOM) feature. Some models of the Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node have one Ethernet LAN-on-motherboard (LOM) controller integrated on the system board. The LOM provides the following features: •...
  • Page 54 For more information about using the LOM feature, go to http://www.emulex.com/support.html. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 55: Chapter 3. Installing The Operating System

    Flex System Manager management software that is managing the compute node. 2. Connect to the Flex System Manager management software (if installed) that is managing the Lenovo Flex System chassis in which the compute node is installed.

  • Page 56: Using The Serverguide Setup And Installation Cd

    In addition to the ServerGuide Setup and Installation CD, you must have your operating-system CD to install the operating system. ServerGuide features This information provides an overview of the ServerGuide features. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 57: Typical Operating-System Installation

    The ServerGuide Scripting Toolkit is a collection of system-configuration tools and installation scripts that you can use to deploy software to your Lenovo Flex System compute node in a repeatable, predictable manner. When the ServerGuide Scripting Toolkit is used with Lenovo ServerGuide, it provides a total solution for deploying Lenovo Flex System compute nodes in an unattended mode.
  • Page 58 For more information about using the Lenovo ServerGuide Scripting Toolkit, see https://support.lenovo.com/us/en/ documents/LNVO-CENTER. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 59: Chapter 4. Accessing The Imm2

    The network access tag is attached to the front of the compute node. The front of the network access tag lists the first four IMM MAC addresses in the lower-right corner, as shown in the following illustration. © Copyright Lenovo 2014, and 2017, 2017...

  • Page 60: Logging On To The Web Interface

    • If the CMM and compute nodes are set to use DHCP, and the CMM loses connectivity to the network, the CMM attempts to acquire a new IP address when network connectivity is restored. The compute nodes Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 61: Imm2 Action Descriptions

    Log out of the IMM web interface. Beneath the title bar are tabs that allow you to access various IMM2 functions, as listed in Table 2 “IMM2 actions” on page 51. For more information about the IMM2 actions, see http://publib.boulder.ibm.com/infocenter/ systemx/documentation/topic/ com.lenovo.sysx.imm2.doc/ printable_doc.html. Table 2. IMM2 actions Selection...
  • Page 62 Use the Scalable Complex page to view, create, and manage scalable complexes. A scalable complex allows compute nodes to be grouped into a single partition or multiple partitions. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 63 Table 2. IMM2 actions (continued) Selection Description IMM Management IMM Properties The IMM Properties page provides access to various properties, status, and settings for your IMM2: • The Firmware tab provides a link to the Server Firmware section of Server Management. •...

  • Page 64: Accessing The Imm2 Using The Lan Over Usb Interface

    • Take down the interface (run ifdown under Linux). • Remove the device driver (run rmmod under Linux). • Disable the LAN over USB interface from the CMM web interface. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 65: Configuring The Lan Over Usb Interface

    When you install a Windows operating system, there will be an unknown RNDIS device in the Device Manager. Lenovo provides a Windows INF file that identifies this device. The signed version of the INF file is included in all of the Windows versions of the IMM2, UEFI, and DSA update packages. Complete the following steps to install ibm_rndis_server_os.inf.
  • Page 66 USB network interface is shown as a network device in the operating system. To discover the name that the operating system has assigned to the IMM2 USB network interface, type dmesg | grep -i cdc ether Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 67: Chapter 5. Parts Listing, Types 7196 And 4258

    The following illustration shows the QR code for the Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node. Note: The illustrations in this document might differ slightly from your hardware.
  • Page 68 • Structural parts: Purchase and replacement of structural parts (components such as the top cover) is your responsibility. If Lenovo acquires or installs a structural part at your request, you will be charged for the installation.
  • Page 69 Tier 1 CRU FRU part Index Description part number number Flex System FC3052 2-Port 8 Gb FC Adapter 95Y2378 69Y1945 Flex System FC5172 2-Port 16 Gb FC Adapter Flex System CN4022 2-Port 10 Gb Converged Network Adapter 88Y5922 00JY803 Flex System CN4052 2-Port 10 Gb Converged Network Adapter Flex System EN6132 2-Port 40 Gb Ethernet Adapter 90Y3485 00Y3309...
  • Page 70 85x, A5x, B5x, C5x and Type 4258, models 35X, 55X) Flex System console breakout cable 81Y5287 Light path LED card 81Y5290 RFID label tag assembly - EMEA 00E6323 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 71 Tier 1 CRU FRU part Index Description part number number RFID label tag assembly - US 74Y8800 Thermal grease kit 41Y9292 Adapter connector retention kit 00AG916 Base assembly (includes chassis and system board) with LOM (Type 7196, 00MY642 models 15x, 25x, 35x, 45x, 55x, 65x, 75x, 85x, A5x, B5x, C5x and Type 4258, models 35X, 55X) Base assembly (includes chassis and system board) without LOM (Type 00MY643...
  • Page 72 If you need help with your order, call the toll-free number that is listed on the retail parts page, or contact your local Lenovo representative for assistance. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 73: Chapter 6. Troubleshooting

    Service bulletins Lenovo continually updates the support website with tips and techniques that you can use to solve problems that you might have with the Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Types 7196 and 4258.
  • Page 74 LEDs to isolate the failing component. 2. To view the light path diagnostics LEDs, select one of the following procedures: • You can view the LEDs through the CMM led command, the CMM web interface, Lenovo XClarity Administrator, or Flex System Manager management software.

  • Page 75: Light Path Diagnostics Leds

    The following illustration shows the locations of the light path diagnostics LEDs on the system board. Light path diagnostics LEDs Use this information to diagnose possible errors that are indicated by the light path diagnostics LEDs. The following table describes the LEDs on the light path diagnostics panel and the light path diagnostics LEDs on the system board.

  • Page 76: Imm Event Log

    You can also view the Chassis Management Module event log through the Event Log link by using the CMM displaylog command or the CMM web interface. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 77 Linux operating system come with a current version of IPMItool. For information about IPMItool, complete the following steps. Note: Changes are made periodically to the Lenovo website. The actual procedure might vary slightly from what is described in this document.

  • Page 78: Lenovo Dynamic System Analysis Preboot Diagnostic Program

    DSA Preboot performs the following tasks: • Collects system information into a compressed XML file that you can send to Lenovo Support • Provides a bootable image that you can use to run extended hardware tests independent of the operating system or applications •...

  • Page 79: Dsa Diagnostic Test Results

    • In the DSA GUI, select DSA Error Log from the System Information page. You can send the DSA error log file to Lenovo Support to aid in diagnosing the compute node problems, or you can use the DSA CLI copy command to copy the log to an external USB device.
  • Page 80 7. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website – Latest level of DSA Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 81 – Latest level of BMC/IMM • 089-802-000 : CPU Stress Test Aborted CPU Stress Test Aborted. System resource unavailability error. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Turn off and restart the system. 2.
  • Page 82 6. If the system has stopped responding, turn off and restart the system and then run the test again. 7. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 83 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM DSA memory stress test results The following messages can result when you run the memory stress test. Test results for the DSA memory stress test The following messages can result when you run the DSA memory stress test. •...
  • Page 84 Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 202-901-000 : MemStr Test Failed Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 85 Test Failed. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1. Execute the standard DSA memory diagnostics to validate all memory. 2. Make sure that the DSA Diagnostic code is at the latest level. 3. Turn off the system and disconnect it from power. 4.
  • Page 86 Latest level of BMC/IMM • 201-000-001 : Standalone Memory Test Passed Quick/Full Memory Test CPU 1 Passed. Recoverable Severity Event Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 87 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-000-002 : Standalone Memory Test Passed Quick/Full Memory Test CPU 2 Passed. Recoverable Severity Event Serviceable Automatically notify support Related links – IBM Support website –...
  • Page 88 Latest level of DSA – Latest level of BMC/IMM • 201-811-001 : Standalone Memory Test Aborted Unable to Locate SMBIOS key "_SM_". Recoverable Severity Warning Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 89 Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 90 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-812-001 : Standalone Memory Test Aborted Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 91 Memory test is not supported for this system. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3.
  • Page 92 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 93 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-813-001 : Standalone Memory Test Aborted Chipset Error: Can not turn OFF ECC error reporting in CPU. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 94 Latest level of BMC/IMM • 201-814-000 : Standalone Memory Test Aborted Chipset Error: Can not disable Scubbing feature for CPU. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 95 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 96 Latest level of DSA – Latest level of BMC/IMM • 201-815-000 : Standalone Memory Test Aborted Program Error with Quick Memory Menu Option Selection. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 97 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 98 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 99 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-816-000 : Standalone Memory Test Aborted Program Error with Full Memory Menu Option Selection. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 100 Latest level of BMC/IMM • 201-816-003 : Standalone Memory Test Aborted Program Error with Full Memory Menu Option Selection. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 101 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 102 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-818-003 : Standalone Memory Test Aborted Unable to Locate SMBIOS key "_SM_". Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 103 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 104 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 105 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-819-003 : Standalone Memory Test Aborted The start-end address ranges in the restricted area of the memory. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 106 Latest level of BMC/IMM • 201-820-002 : Standalone Memory Test Aborted Memory Upper limit is less than 16 Mbytes. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 107 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 108 Latest level of DSA – Latest level of BMC/IMM • 201-821-002 : Standalone Memory Test Aborted Variable range MTRR registers are larger than fixed range MTRR registers. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 109 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 110 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 111 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-822-002 : Standalone Memory Test Aborted Invalid MTRR service request. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2.
  • Page 112 Node Interleave feature must be OFF. Go to Setup and disable Node Interleave option and then re-run the test. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 113 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 114 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-826-001 : Standalone Memory Test Aborted Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 115 BIOS: Memory Controller has been disabled. Go to Setup and Enable Memory Controller. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2.
  • Page 116 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 117 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-827-001 : Standalone Memory Test Aborted BIOS: ECC function has been disabled by BIOS. Go to Setup and enable ECC generation. Recoverable Severity Warning Serviceable Automatically notify support...
  • Page 118 201-844-000 : Standalone Memory Test Aborted Chipset Error: Problem in masking MSR machine check control MASK registers. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 119 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 120 Latest level of DSA – Latest level of BMC/IMM • 201-845-000 : Standalone Memory Test Aborted Chipset Error: Problem clearing MSR machine check control registers. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 121 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 122 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 123 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-859-000 : Standalone Memory Test Aborted INVALID XSECSRAT type. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2.
  • Page 124 Latest level of DSA – Latest level of BMC/IMM • 201-859-003 : Standalone Memory Test Aborted INVALID XSECSRAT type. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 125 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 126 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-860-003 : Standalone Memory Test Aborted No OEM0 type 1 found. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 127 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 128 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 129 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-861-003 : Standalone Memory Test Aborted No SRAT type 1 found. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2.
  • Page 130 Latest level of DSA – Latest level of BMC/IMM • 201-862-002 : Standalone Memory Test Aborted No OEM1 structure found. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 131 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 132 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-863-002 : Standalone Memory Test Aborted No IBMERROR key in OEM1 structure. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 133 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 134 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 135 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-864-002 : Standalone Memory Test Aborted No GAS located in OEM1. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2.
  • Page 136 Latest level of BMC/IMM • 201-865-001 : Standalone Memory Test Aborted No XSECSRAT key in OEM0 structure. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 137 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 138 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-866-001 : Standalone Memory Test Aborted EFI-SAL Invalid parameter from GetMemoryMap function. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 139 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 140 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 141 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-867-001 : Standalone Memory Test Aborted EFI/SAL: Buffer not allocated. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2.
  • Page 142 Latest level of BMC/IMM • 201-868-000 : Standalone Memory Test Aborted EFI/SAL: Buffer allocated in GetMemoryMap too small. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 143 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 144 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-869-000 : Standalone Memory Test Aborted EFI/SAL Invalid parameter from GetMemoryMap function. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 145 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 146 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 147 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-870-000 : Standalone Memory Test Aborted CPU Doamin in ACPI not valid. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 148 Latest level of BMC/IMM • 201-870-003 : Standalone Memory Test Aborted CPU Doamin in ACPI not valid. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 149 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 150 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-871-003 : Standalone Memory Test Aborted Data Mis-compare encountered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 151 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 152 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 153 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-877-003 : Standalone Memory Test Aborted BIOS: Sparing in Extended PCI reg. must be OFF. Go to setup and disable sparing. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps:...
  • Page 154 201-878-002 : Standalone Memory Test Aborted Sparing feature must be turned OFF. Go to setup and turn the sparing feature OFF. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 155 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 156 Latest level of BMC/IMM • 201-885-002 : Standalone Memory Test Aborted Processor does not support MTRR register manipulation. Can not write to memory without cache. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 157 Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 158 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 159 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-886-002 : Standalone Memory Test Aborted Memory Upper limit is less than 16 Mbytes. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 160 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-899-002 : Standalone Memory Test Aborted Memory Diagnostics Test Aborted by user. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 161 Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-899-003 : Standalone Memory Test Aborted Memory Diagnostics Test Aborted by user. Recoverable Severity Warning Serviceable Automatically notify support Related links –...
  • Page 162 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 201-901-002 : Standalone Memory Test Failed Memory Diagnostics Test Failed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 163 Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power.
  • Page 164 215-801-000 : Optical Drive Test Aborted Optical Drive Test Aborted. Unable to communicate with driver. Recoverable Severity Warning Serviceable Automatically notify support User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 165 Complete the following steps: 1. Make sure that the DSA Diagnostic code is at the latest level. 2. Run the test again. 3. Check the drive cabling for loose or broken connections at both ends or damage to the cable. Replace the cable if damage is present.
  • Page 166 5. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 167 – Latest level of DSA – Latest level of BMC/IMM • 215-901-000 : Optical Drive Test Aborted Optical Drive Test Aborted. Drive media is not detected. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Insert a new CD or DVD into the drive and wait for 15 seconds for the media to be recognized. Rerun the test.
  • Page 168 Latest level of DSA – Latest level of BMC/IMM DSA tape drive test results The following messages can result when you run the tape drive test. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 169 Test results for the DSA tape drive test The following messages can result when you run the DSA tape drive test. • 264-000-000 : Tape Test Passed Tape Test Passed. Recoverable Severity Event Serviceable Automatically notify support Related links – IBM Support website –...
  • Page 170 1. Clean the tape drive using the appropriate cleaning media and install new media. 2. Run the test again. 3. Make sure that the drive firmware is at the latest level. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 171 4. Rerun the test after upgrading to the latest firmware level. 5. If the failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website – Latest level of DSA –...
  • Page 172 8. Run the test again. 9. If the failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 173 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 264-907-000 : Tape Test Failed An error was found in the block address somewhere. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 174 2. Rerun the test. 3. Verify that Hard drive supports self test and self test logging. 4. If the problem remains, contact your technical-support representative. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 175 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 217-900-000 : HDD Test Failed HDD Test Failed. The hard drive self-test detected a failure. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 176 3. Verify whether the firmware is at the latest level. 4. Rerun the test. 5. If the problem remains, contact your IBM technical-support representative. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 177 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM DSA Nvidia GPU test results The following messages can result when you run the Nvidia GPU test. Test results for the DSA Nvidia GPU test The following messages can result when you run the DSA Nvidia GPU test.
  • Page 178 Latest level of DSA – Latest level of BMC/IMM • 409-006-000 : Nvidia::DiagnosticServiceProvider::Binomial Test Passed Nvidia GPU Binomial test passed. Recoverable Severity Event Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 179 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 409-800-000 : NVIDIA User Diagnostic Test Aborted NVIDIA User Diagnostic test was canceled. Recoverable Severity Event Serviceable Automatically notify support Related links – IBM Support website –...
  • Page 180 Nvidia GPU Binomial test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 181 • 409-900-000 : NVIDIA User Diagnostic Test Failed NVIDIA User Diagnostic Test Failed. Recoverable Severity Event Serviceable Automatically notify support User Response Complete the following steps: 1. Verify that the GPU is seated in the PCIe slot correctly by reseating the GPU. Then power cycle the system.
  • Page 182 Latest level of DSA – Latest level of BMC/IMM • 409-905-000 : Nvidia::DiagnosticServiceProvider::Matrix Test Failed Nvidia GPU Matrix Test Failed. Recoverable Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 183 Automatically notify support User Response Complete the following steps: 1. Verify that the GPU is seated in the PCIe slot correctly by reseating the GPU. Then power cycle the system. 2. Verify that the power connectors to the GPU are connected firmly. Then power cycle the system. 3.
  • Page 184 2. Make sure that DSA and BMC/IMM are at the latest level. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 166-802-001 : IMM I2C Test Aborted Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 185 Test cannot be completed for unknown reason. Recoverable Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2.
  • Page 186 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 166-806-001 : IMM I2C Test Aborted Timeout while processing command. Recoverable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 187 Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2.
  • Page 188 Latest level of DSA – Latest level of BMC/IMM • 166-810-001 : IMM I2C Test Aborted Request data length invalid. Recoverable Severity Warning Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 189 Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Related links –...
  • Page 190 Recoverable Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 191 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Related links – IBM Support website – Latest level of DSA –...
  • Page 192 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 193 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 166-819-001 : IMM I2C Test Aborted Command response could not be provided. SDR Repository in?update mode. Recoverable Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1.
  • Page 194 2. Make sure that DSA and BMC/IMM are at the latest level. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 195 • 166-823-001 : IMM I2C Test Aborted Cannot execute command. Insufficient privilege level. Recoverable Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2.
  • Page 196 4. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website – Latest level of DSA Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 197 – Latest level of BMC/IMM • 166-903-001 : IMM I2C Test Failed IMM Indicates failure in 9545A bus (BUS 2). Recoverable Severity Error Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1.
  • Page 198 The following messages can result when you run the DSA checkpoint panel test. • 180-000-000 : Check-point Panel Test Passed Check-point Panel Test Passed. Recoverable Severity Event Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 199 Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 180-801-000 : Check-point Panel Test Aborted Check-point Panel Test Aborted. BMC is unable to verify that the operator information panel cable is connected.
  • Page 200 – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 405-001-000 : BRCM:TestMIIRegisters Test Passed The test passed. Recoverable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 201 Severity Event Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 405-002-000 : BRCM:TestEEPROM Test Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links –...
  • Page 202 Latest level of DSA – Latest level of BMC/IMM • 405-006-000 : BRCM:TestLoopbackPhysical Test Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 203 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 405-007-000 : BRCM:TestLEDs Test Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA –...
  • Page 204 The internal memory test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 205 • 405-804-000 : BRCM:TestInterrupt Test Aborted The interrupt test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 405-805-000 : BRCM:TestLoopbackMAC Test Aborted Loopback testing at the MAC layer was canceled.
  • Page 206 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 207 • 405-901-000 : BRCM:TestMIIRegisters Test Failed A failure was detected while testing internal PHY registers. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1. Check component firmware level and upgrade if necessary. The installed firmware level can be found in the DSA Diagnostic Event Log within the Firmware/VPD section for this component.
  • Page 208 1. Check component firmware level and upgrade if necessary. The installed firmware level can be found in the DSA Diagnostic Event Log within the Firmware/VPD section for this component. 2. Rerun the test. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 209 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 405-905-000 : BRCM:TestLoopbackMAC Test Failed BRCM:TestLoopbackMAC Test Failed.
  • Page 210 Test results for the DSA Brocade test The following messages can result when you run the DSA Brocade test. • 218-000-000 : Brocade:MemoryTest Passed The test passed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 211 Recoverable Severity Event Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 218-001-000 : Brocade:ExternalLoopbackTest Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links –...
  • Page 212 IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 218-005-000 : Brocade:SerdesEthLoopbackTest Passed The test passed. Recoverable Severity Event Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 213 Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 218-006-000 : Brocade:InternalLoopbackTest Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links – IBM Support website –...
  • Page 214 218-803-000 : Brocade:PCILoopbackTest Aborted The test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 215 – Latest level of BMC/IMM • 218-804-000 : Brocade:ExternalEthLoopbackTest Aborted The test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 218-805-000 : Brocade:SerdesEthLoopbackTest Aborted The test was canceled.
  • Page 216 218-901-000 : Brocade:ExternalLoopbackTest Failed A failure was detected during the Loopback test. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 217 1. Check cable connections. 2. Rerun the test. 3. Verify whether the firmware is at proper level. 4. Rerun the test. 5. If the problem remains, contact your IBM technical-support representative. Related links – IBM Support website – Latest level of DSA –...
  • Page 218 Latest level of DSA – Latest level of BMC/IMM • 218-905-000 : Brocade:SerdesEthLoopbackTest Failed A failure was detected during the Loopback test. Recoverable Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 219 Serviceable Automatically notify support User Response Complete the following steps: 1. Rerun the test. 2. Verify whether the firmware is at proper level. 3. Rerun the test. 4. If the problem remains, contact your IBM technical-support representative. Related links – IBM Support website –...
  • Page 220 Latest level of DSA – Latest level of BMC/IMM • 516-002-000 : ELXUCNA: ELXUCNA: NIC LED(Beacon)Test Passed The test passed. Recoverable Severity Event Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 221 Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 516-800-000 : ELXUCNA: NIC MAC LoopBackTest Aborted Loopback testing at the MAC layer was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links –...
  • Page 222 Latest level of BMC/IMM • 516-901-000 : ELXUCNA: NIC PHY LoopBackTest Failed A failure was detected during the loopback test at the physical layer. Recoverable Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 223 Serviceable Automatically notify support User Response Complete the following steps: 1. Check component firmware level and upgrade if necessary. The installed firmware level can be found in the DSA Diagnostic Event Log within the Firmware/VPD section for this component. 2. Rerun the test. 3.
  • Page 224 – Latest level of DSA – Latest level of BMC/IMM • 408-800-000 : MLNX:MLNX_DiagnosticTestEthernetPort Test Aborted Port Test was canceled. Recoverable Severity Warning Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 225 Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 408-801-000 : MLNX:MLNX_DiagnosticTestIBPort Test Aborted Port Test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website –...
  • Page 226 The following messages can result when you run the DSA EXA port ping test. • 401-000-000 : EXA Port Ping Test Passed EXA Port Ping Test Passed. Recoverable Severity Event Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 227 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 401-801-000 : EXA Port Ping Test Aborted EXA Port Ping Test Aborted. Unable to get device base address. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 228 Test results for the DSA Intel network test The following messages can result when you run the DSA Intel network test. • 406-000-000 : IANet:Registers Test Passed The test passed. Recoverable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 229 Severity Event Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 406-001-000 : IANet:EEPROM Test Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links –...
  • Page 230 Latest level of DSA – Latest level of BMC/IMM • 406-800-000 : IANet:Registers Test Aborted Registers test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 231 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 406-801-000 : IANet:EEPROM Test Aborted EEPROM test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – IBM Support website – Latest level of DSA –...
  • Page 232 1. Check component firmware level and upgrade if necessary. The installed firmware level can be found in the DSA Diagnostic Event Log within the Firmware/VPD section for this component. 2. Rerun the test. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 233 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 406-901-000 : IANet:EEPROM Test Failed A failure was detected during the EEPROM test.
  • Page 234 Latest level of DSA – Latest level of BMC/IMM • 406-904-000 : IANet:Loopback Test Failed A failure was detected during the Loopback test. Recoverable Severity Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 235: Event Messages

    IMM messages When a hardware event is detected by the IMM2 on a Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Types 7196 and 4258, the IMM2 logs that event in the system-event log in the compute node.
  • Page 236 Perform the steps listed in this section in the order shown until the problem is solved. After you perform all of the actions that are described in this field, if you cannot solve the problem, contact Lenovo Support. Note: This list includes error codes and messages that might not apply to this machine type and model.
  • Page 237 Serviceable Automatically notify support Alert Category System - IMM Network event SNMP Trap ID CIM Information Prefix: IMM ID: 0001 User Response Information only; no action is required. • 40000002-00000000 : Certificate Authority [arg1] has detected a [arg2] Certificate Error. A problem has occurred with the SSL Server, SSL Client, or SSL Trusted CA certificate that has been imported into the IMM.
  • Page 238 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0005 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 239 • 40000006-00000000 : Ethernet locally administered MAC address modified from [arg1] to [arg2] by user [arg3]. The specified user has changed the Ethernet locally administered MAC address of the Integrated Management Module external network interface to the specified value. Severity Info Serviceable Automatically notify support...
  • Page 240 The specified user has changed the subnet mask of the Integrated Management Module external network interface to the specified value. Severity Info Serviceable Automatically notify support Alert Category none Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 241 SNMP Trap ID CIM Information Prefix: IMM ID: 0010 User Response Information only; no action is required. • 4000000b-00000000 : IP address of default gateway modified from [arg1] to [arg2] by user [arg3]. The specified user has changed the gateway address of the Integrated Management Module external network interface to the specified value.
  • Page 242 • 4000000f-00000000 : Attempting to [arg1] server [arg2] by user [arg3]. The specified user has initiated a power function on the system using the Management Controller. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 243 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0015 User Response Information only; no action is required. • 40000010-00000000 : Security: Userid: [arg1] had [arg2] login failures from WEB client at IP address [arg3]. A user has exceeded the maximum allowed number of unsuccessful login attempts from a web browser and has been prevented from logging in for the lockout period.
  • Page 244 A user has attempted to log in from a Telnet session by using an invalid login ID or password. Severity Info Serviceable Automatically notify support Alert Category System - Remote Login SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 245 CIM Information Prefix: IMM ID: 0019 User Response Make sure that the correct login ID and password are being used. • 40000014-00000000 : The [arg1] on system [arg2] cleared by user [arg3]. The specified user has deleted system log events or audit log events. Severity Info Serviceable...
  • Page 246 Information only; no action is required. • 40000018-00000000 : LAN: Ethernet[[arg1]] interface is no longer active. The IMM Ethernet interface has been disabled. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 247 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0024 User Response Information only; no action is required. • 40000019-00000000 : LAN: Ethernet[[arg1]] interface is now active. The IMM Ethernet interface has been enabled. Severity Info Serviceable Automatically notify support...
  • Page 248 If there was no operating-system error, complete the following steps until the problem is solved: 1. Reconfigure the watchdog timer to a higher value. 2. Make sure that the IMM Ethernet-over-USB interface is enabled. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 249 3. Reinstall the RNDIS or cdc_ether device driver for the operating system. 4. Disable the watchdog. If there was an operating-system error, check the integrity of the installed operating system. Related links – “Installing the LAN over USB Linux device driver” on page 56 –...
  • Page 250 • 40000020-00000000 : Management Controller [arg1] Reset was caused by restoring default values. The default configuration has been restored to the Integrated Management Module. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 251 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0032 User Response Information only; no action is required. • 40000021-00000000 : Management Controller [arg1] clock has been set from NTP server [arg2]. The IMM clock has been set to the date and time that are provided by the Network Time Protocol server.
  • Page 252 The specified firmware has not been updated. Severity Info Serviceable Automatically notify support Alert Category System - other SNMP Trap ID CIM Information Prefix: IMM ID: 0036 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 253 User Response Information only; no action is required. • 40000025-00000000 : The [arg1] on system [arg2] is 75% full. The IMM event log is 75% full. When the event log is completely full, the new entries will overwrite the oldest entries. To avoid losing older log entries, save the log as a text file and clear the log. Severity Info Serviceable...
  • Page 254 Automatically notify support Alert Category System - other SNMP Trap ID CIM Information Prefix: IMM ID: 0040 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 255 • 40000029-00000000 : Security: Userid: [arg1] had [arg2] login failures from an SSH client at IP address [arg3]. A user has exceeded the maximum allowed number of unsuccessful login attempts from SSH and has been prevented from logging in for the lockout period. Severity Info Serviceable...
  • Page 256 Information only; no action is required. • 4000002d-00000000 : DDNS setting changed to [arg1] by user [arg2]. DDNS setting changed by user. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 257 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0045 User Response Information only; no action is required. • 4000002e-00000000 : DDNS registration successful. The domain name is [arg1]. The DDNS registration was successful. Severity Info Serviceable Automatically notify support...
  • Page 258 Information only; no action is required. • 40000032-00000000 : IPv6 DHCP enabled by user [arg1]. The specified user has enabled DHCPv6 on the Integrated Management Module. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 259 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0050 User Response Information only; no action is required. • 40000033-00000000 : IPv6 stateless auto-configuration enabled by user [arg1]. IPv6 stateless address auto-configuration has been enabled on the Integrated Management Module by the specified user.
  • Page 260 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0054 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 261 • 40000037-00000000 : ENET[[arg1]] IPv6-LinkLocal:HstName=[arg2], IP@=[arg3], Pref=[arg4] . The IPv6 link-local address is active. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0055 User Response Information only; no action is required. •...
  • Page 262 The DHCPv6 server has failed to assign an IP address to a management controller. Severity Warning Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 263 Prefix: IMM ID: 0059 User Response Complete the following steps until the problem is solved: 1. Make sure that the IMM network cable is connected. 2. Make sure that there is a DHCPv6 server on the network that can assign an IP address to the IMM.
  • Page 264 The specified user has changed the HTTP port number. New HTTP (web) connections must use the new port number. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0063 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 265 Information only; no action is required. • 40000040-00000000 : Web-HTTPS port number changed from [arg1] to [arg2] by user [arg3]. The specified user has changed the HTTPS port number. New HTTPS (secure web) connections must use the new port number. Severity Info Serviceable...
  • Page 266 The specified user has changed the Simple Network Management Protocol (SNMP) traps port number. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 267 CIM Information Prefix: IMM ID: 0068 User Response Information only; no action is required. • 40000045-00000000 : Syslog port number changed from [arg1] to [arg2] by user [arg3]. A user has modified the Syslog receiver port number. Severity Info Serviceable Automatically notify support Alert Category none...
  • Page 268 40000049-00000000 : SNMP [arg1] enabled by user [arg2] . The specified user has enabled the SNMPv1 or SNMPv3 agent. Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 269 none SNMP Trap ID CIM Information Prefix: IMM ID: 0073 User Response Information only; no action is required. • 4000004a-00000000 : SNMP [arg1] disabled by user [arg2] . The specified user has disabled the SNMPv1 or SNMPv3 agent. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 270 Information only; no action is required. • 4000004e-00000000 : Serial Redirection set by user [arg1]: Mode=[arg2], BaudRate=[arg3], StopBits=[arg4], Parity=[arg5], SessionTerminateSequence=[arg6]. A user configured the Serial Port mode. Severity Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 271 Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0078 User Response Information only; no action is required. • 4000004f-00000000 : Date and Time set by user [arg1]: Date=[arg2], Time-[arg3], DST Auto-adjust=[arg4], Timezone=[arg5]. The specified user has changed the date and time in the Integrated Management Module.
  • Page 272 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0082 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 273 • 40000053-00000000 : Server [arg1] scheduled for every [arg2] at [arg3] by user [arg4]. A user configured a recurring Server Power Action. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0083 User Response Information only;...
  • Page 274 40000057-00000000 : Telnet [arg1] by user [arg2]. The specified user has enabled or disabled Telnet. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 275 Prefix: IMM ID: 0087 User Response Information only; no action is required. • 40000058-00000000 : DNS servers set by user [arg1]: UseAdditionalServers=[arg2], PreferredDNStype=[arg3], IPv4Server1=[arg4], IPv4Server2=[arg5], IPv4Server3=[arg6], IPv6Server1=[arg7], IPv6Server2=[arg8], IPv6Server3=[arg9]. The specified user has configured the DNS servers. Severity Info Serviceable Automatically notify support Alert Category none...
  • Page 276 • 4000005c-00000000 : Secure CIM/XML(HTTPS) [arg1] by user [arg2]. The secure CIM-XML port has been enabled or disabled. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 277 Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0092 User Response Information only; no action is required. • 4000005d-00000000 : Secure LDAP [arg1] by user [arg2]. A user enables or disables Secure LDAP services. Severity Info Serviceable Automatically notify support Alert Category none...
  • Page 278 • 40000061-00000000 : License key for [arg1] removed by user [arg2]. The specified user has removed an Integrated Management Module license. Access to the specified feature is no longer allowed. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 279 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0097 User Response Information only; no action is required. • 40000062-00000000 : Global Login General Settings set by user [arg1]: AuthenticationMethod=[arg2], LockoutPeriod=[arg3], SessionTimeout=[arg4]. A user changes the Global Login General Settings. Severity Info Serviceable...
  • Page 280 A user account has been removed. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0101 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 281 Information only; no action is required. • 40000066-00000000 : User [arg1] password modified. The password for the specified user account has been changed. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0102 User Response Information only;...
  • Page 282 4000006a-00000000 : SSH Client key added for user [arg1]. User locally defined an SSH Client key. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 283 CIM Information Prefix: IMM ID: 0106 User Response Information only; no action is required. • 4000006b-00000000 : SSH Client key imported for user [arg1] from [arg2]. User imported an SSH Client key. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information...
  • Page 284 • 4000006f-00000000 : Alert Recipient Number [arg1] updated: Name=[arg2], DeliveryMethod=[arg3], Address=[arg4], IncludeLog=[arg5], Enabled=[arg6], EnabledAlerts=[arg7], AllowedFilters=[arg8]. The specified user has changed or reset the remote alert recipient configuration. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 285 Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0111 User Response Information only; no action is required. • 40000070-00000000 : SNMP Traps enabled by user [arg1]: EnabledAlerts=[arg2], AllowedFilters=[arg3] . The specified user has enabled Simple Network Management Protocol (SNMP) traps. Severity Info Serviceable...
  • Page 286 • 40000074-00000000 : The soft minimum power cap value changed from [arg1] watts to [arg2] watts. The soft minimum power cap value has been changed. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 287 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0116 User Response Information only; no action is required. • 40000075-00000000 : The measured power value exceeded the power cap value. The measured power value has exceeded the power cap value. Severity Warning Serviceable...
  • Page 288 The power capping control has been disabled. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0120 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 289 User Response Information only; no action is required. • 40000079-00000000 : Static Power Savings mode has been turned on by user [arg1]. Static Power Savings mode turned on by user. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0121 User Response...
  • Page 290 • 4000007d-00000000 : Power cap and external throttling occurred. Power cap and external throttling has occurred. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 291 CIM Information Prefix: IMM ID: 0125 User Response Information only; no action is required. • 4000007e-00000000 : External throttling occurred . External throttling has occurred. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0126 User Response Information only;...
  • Page 292 • 40000082-00000000 : The measured power value has returned below the power cap value. The measured power value has returned below the power cap value. Severity Info Serviceable Automatically notify support Alert Category Warning - Power Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 293 SNMP Trap ID CIM Information Prefix: IMM ID: 0130 User Response Information only; no action is required. • 40000083-00000000 : The new minimum power cap value has returned below the power cap value. The new minimum power cap value has returned below the power cap value. Severity Info Serviceable...
  • Page 294 Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0134 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 295 • 40000087-00000000 : Manual Call Home by user [arg1]: [arg2]. The specified user has submitted a service request. Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0135 User Response IBM Support will address the problem. •...
  • Page 296 2. After 45 seconds, reconnect the server to the power source and turn on the server. 3. Retry the operation • 4000008b-00000000 : One or more of the Storage Management IP addresses has changed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 297 One or more of the Storage Management IP addresses has changed. Severity Info Serviceable Automatically notify support Alert Category System - IMM Network event SNMP Trap ID CIM Information Prefix: IMM ID: 0139 User Response Information only; no action is required. •...
  • Page 298 • 4000008f-00000000 : The bare metal connection process has been started. Bare Metal Connection process has been started Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 299 CIM Information Prefix: IMM ID: 0143 User Response Information only; no action is required. • 40000090-00000000 : The bare metal update application reports a status of [arg1]. Bare Metal Update Application Status Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information...
  • Page 300 TKLM client. User generated a new encryption key pair and installed a self-signed certificate for the TKLM client. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 301 Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0148 User Response Information only; no action is required. • 40000095-00000000 : User [arg1] has generated a new encryption key and certificate signing request for the TKLM client. User generated a new encryption key and certificate signing request for the TKLM client. Severity Info Serviceable...
  • Page 302 40000099-00000000 : Security: Userid: [arg1] had [arg2] login failures from IPMI client at IP address [arg3]. A user was not able to log in to a Management Controller from IPMI Severity Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 303 Info Serviceable Automatically notify support Alert Category System - Remote Login SNMP Trap ID CIM Information Prefix: IMM ID: 0153 User Response Information only; no action is required. • 4000009a-00000000 : Security: Userid: [arg1] had [arg2] login failures from SNMP client at IP address [arg3].
  • Page 304 Automatically notify support Alert Category System - Remote Login SNMP Trap ID CIM Information Prefix: IMM ID: 0157 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 305 • 4000009e-00000000 : Login ID: [arg1] from [arg2] at IP address [arg3] has been logged off. A user has been logged off of a Management Controller. Severity Info Serviceable Automatically notify support Alert Category System - Remote Login SNMP Trap ID CIM Information Prefix: IMM ID: 0158 User Response...
  • Page 306 User has mounted/unmounted file from URL or server. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0162 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 307 User Response Information only; no action is required. • 400000a3-00000000 : User [arg1] has set the SMTP Server reverse-path to [arg2]. User set SMTP Server reverse-path address. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0163 User Response...
  • Page 308 • 400000a7-00000000 : The server is restarted by chassis control command. Server is restarted by chassis control command. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 309 CIM Information Prefix: IMM ID: 0167 User Response Information only; no action is required. • 400000a8-00000000 : The server was reset via pushbutton. Server was reset via pushbutton. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0168 User Response...
  • Page 310 Server was automatically powered on because the power restore policy is set to always restore. Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 311 System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0172 User Response Information only; no action is required. • 400000ad-00000000 : The server was automatically powered on because the power restore policy is set to restore previous power state.. Server was automatically powered on because the power restore policy is set to restore previous power state.
  • Page 312 • 400000b1-00000000 : The server was powered up via Real Time Clock (scheduled power on). Server was powered up via Real Time Clock (scheduled power on). Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 313 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0177 User Response Information only; no action is required. • 400000b2-00000000 : The server was powered off for an unknown reason. Server was powered off for an unknown reason. Severity Info Serviceable...
  • Page 314 Information only; no action is required. • 400000b6-00000000 : The server stayed powered off because the power restore policy is set to always restore.. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 315 Server stayed powered off because the power restore policy is set to always restore. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0182 User Response Information only; no action is required. •...
  • Page 316 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0186 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 317 • 400000bb-00000000 : Management Controller [arg1] reset was initiated by PRESET. Management Controller reset was initiated by PRESET. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0187 User Response Information only;...
  • Page 318 Operating System status change. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0191 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 319 User Response Information only; no action is required. • 400000c0-00000000 : Inventory data collecting and processing complete for [arg1]. Inventory data collecting and processing complete. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0192 User Response Information only;...
  • Page 320 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 321 • 80010701-3702ffff : Numeric sensor [NumericSensorElementName] going high (upper non-critical) has asserted. The inlet 2 temperature has exceeded its specified threshold. The compute node has attempted a soft shutdown. Severity Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0490...
  • Page 322 • 80010902-0701ffff : Numeric sensor [NumericSensorElementName] going high (upper critical) has asserted. A voltage has exceeded its specified threshold. Severity Error Serviceable Automatically notify support Alert Category Critical - Voltage SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 323 CIM Information Prefix: PLAT ID: 0494 User Response Use one of the following procedures: – If the specified sensor is Planar 12V or Planar 3.3V or Planar 5V, replace the system board. – If the specified sensor is Planar 12V, check the Chassis Management Module or Flex System Manager event log for power-supply-related issues, and resolve those issues.
  • Page 324 Information only; no action is required. • 8003010c-2581ffff : Sensor [SensorElementName] has asserted. IMM has reported a SMI Lane Failover. Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 325 System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0508 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Info Center for the appropriate user response.
  • Page 326 Related links – “Finding the UEFI diagnostic code” on page 919 • 8003010f-2101ffff : Sensor [SensorElementName] has asserted. IMM Firmware is Corrupted. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 327 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0508 User Response Check that the primary build level is correct and upgrade primary to latest level. • 80030112-0601ffff : Sensor [SensorElementName] has asserted. IMM has entered a system maintenance mode (SMM Mode, SMM Monitor) where the current power state is important.
  • Page 328 Info Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0518 User Response ROMB Volume : Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 329 • 80070101-030101ff : Sensor [SensorElementName] has transitioned from normal to non-critical state. The microprocessor 1 temperature has risen above its specified threshold. Severity Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 User Response Complete the following steps until the problem is solved: 1.
  • Page 330 The temperature of microprocessor 2 has exceeded its specified threshold. Severity Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 331 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 332 • 80070101-2c01ffff : Sensor [SensorElementName] has transitioned from normal to non-critical state. The temperature of the I/O expansion adapter in I/O expansion connector 1 has exceeded its specified threshold. Severity Warning Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 333 Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
  • Page 334 Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 335 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. • 80070101-2c04ffff : Sensor [SensorElementName] has transitioned from normal to non-critical state.
  • Page 336 The FlashDIMM agent has indicated that this system contains a FlashDIMM with Less than 1% write warranty remaining Severity Warning Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 337 CIM Information Prefix: PLAT ID: 0520 User Response Information only; warranty is about to expire but no action is required. • 8007010d-3030ffff : Sensor [SensorElementName] has transitioned from normal to non-critical state. This message is for the use case when an implementation has detected a Sensor transitioned to non-critical from normal.
  • Page 338 Less than optimal I/O resource configuration. Severity Warning Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 339 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 340 • 8007020c-2581ffff : Sensor [SensorElementName] has transitioned to critical from a less severe state. A Mem Lane has transitioned to critical from less severe. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 341 Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0522 User Response User is advised to not install this type of mezzanine expansion adaptor in slot 3 or slot 4. • 8007020d-2582ffff : Sensor [SensorElementName] has transitioned to critical from a less severe state.
  • Page 342 IMM has detected a "No I/O Resources" Sensor has transitioned to critical. Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 343 CIM Information Prefix: PLAT ID: 0522 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 344 The I/O expansion adapter in I/O expansion connector 3 has reported a fault. Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0522 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 345 User Response Complete the following steps: 1. Remove any recently installed components. 2. Try to power on the chassis. – If the chassis successfully powers on, complete the following steps: a. Check the ServerProven website to make sure that recently installed components are compatible with the chassis.
  • Page 346 CPU 1 QPI Link Failure detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0522 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 347 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 348 The microprocessor 1 temperature has risen above its specified threshold, causing a hard shutdown of the node. Severity Error Serviceable Automatically notify support Alert Category Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 349 Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0524 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2.
  • Page 350 The temperature of microprocessor 2 has exceeded its specified threshold, causing a hard shutdown of the compute node. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 351 SNMP Trap ID CIM Information Prefix: PLAT ID: 0524 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 352 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 353 3. Make sure that the room temperature is within operating specifications. 4. If there are no other thermal issues, replace the I/O expansion adapter. • 80070301-2c0201ff : Sensor Mezz Exp 2 temp has transitioned to non-recoverable from a less severe state. The temperature of the I/O expansion adapter in I/O expansion connector 2 has exceeded its specified threshold.
  • Page 354 The temperature of the I/O expansion adapter in I/O expansion connector 3 has exceeded its specified threshold. The compute node has attempted a soft shutdown. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 355 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0524 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
  • Page 356 Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0524 User Response Complete the following steps until the problem is solved: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 357 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3.
  • Page 358 • 80070401-2c02ffff : Sensor [SensorElementName] has transitioned to non-critical from a more severe state. The previously high temperature of the I/O expansion adapter in I/O expansion connector 2 has returned to below its specified threshold. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 359 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0526 User Response Information only; no action is required. • 80070401-2c03ffff : Sensor [SensorElementName] has transitioned to non-critical from a more severe state.
  • Page 360 The temperature of the I/O expansion adapter in I/O expansion connector 2 has exceeded its specified threshold. The compute node has attempted a soft shutdown. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 361 Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0530 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
  • Page 362 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 363 – “Finding the UEFI diagnostic code” on page 919 • 80070614-2201ffff : Sensor [SensorElementName] has transitioned to non-recoverable. Trusted Platform Module (TPM) initialization error. Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0530 User Response This is a UEFI detected event.
  • Page 364 Check the ServerProven website to make sure that recently installed components are compatible with the chassis. b. Inspect the previously installed components for physical damage. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 365 – If the chassis does not successfully power on or if this is not the first occurrence of this problem, replace the I/O expansion adapter. • 80070617-2c03ffff : Sensor [SensorElementName] has transitioned to non-recoverable. A problem was detected in the I/O expansion adapter in I/O expansion connector 3. The adapter is unable to initialize.
  • Page 366 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0537 User Response Informational message. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 367 On a LOM model compute node, if you are utilizing LOM and it is not working ensure you have the necessary fabric connector installed. – To utilize the LOM: – have the LOM model compute node – have the corresponding fabric connector installed –...
  • Page 368 On a LOM model compute node, if you are utilizing LOM and it is not working ensure you have the necessary fabric connector installed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 369 – To utilize the LOM: – have the LOM model compute node – have the corresponding fabric connector installed – Information regarding the fabric connectors: – LOM 1 utilizes the fabric connector in location 1. – LOM 2 utilizes the fabric connector in location 2. –...
  • Page 370 Information only; no action is required. • 8009010c-0701ffff : Device [LogicalDeviceElementName] has been enabled. The user has switched from Acoustic mode to Performance mode. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 371 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0538 User Response Information only; no action is required. • 80090112-2101ffff : Device [LogicalDeviceElementName] has been enabled. An IPMI or SNMP Account has been enabled. Severity Info Serviceable...
  • Page 372 Device has reached end of life and can no longer be written to. The device should be replaced. • 800b010c-2581ffff : Redundancy Lost for [RedundancySetElementName] has asserted. Redundancy has been lost. Severity Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 373 Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0802 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 374 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 375 • 806f0007-0302ffff : [ProcessorElementName] has Failed with IERR. A Processor has Failed - IERR Condition. Severity Error Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0042 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 376 • 806f000d-0402ffff : The [StorageVolumeElementName] has been added. Hard disk drive 2 has been installed. Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 377 SNMP Trap ID CIM Information Prefix: PLAT ID: 0162 User Response Information only; no action is required. • 806f000d-0403ffff : The [StorageVolumeElementName] has been added. Hard disk drive 3 has been installed. Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information...
  • Page 378 Information only; no action is required. • 806f000d-0407ffff : The [StorageVolumeElementName] has been added. Hard disk drive 7 has been installed. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 379 Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0162 User Response Information only; no action is required. • 806f000f-220100ff : The System [ComputerSystemElementName] encountered a POST Error. A Post Error has been detected. ABR Status. Firmware Error. Severity Error Serviceable...
  • Page 380 • 806f000f-220103ff : The System [ComputerSystemElementName] encountered firmware error - unrecoverable boot device failure. A System Firmware Error Unrecoverable boot device failure has occurred. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 381 Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0770 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 382 806f000f-22010bff : Firmware BIOS (ROM) corruption was detected on system [ComputerSystemElementName] during POST. Firmware BIOS (ROM) corruption was detected on the system during POST. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 383 Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0850 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 384 2. Replace the system board. • 806f001e-2201ffff : No bootable media available for system [ComputerSystemElementName]. No boot device has been detected in the system. Severity Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 385 Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0286 User Response Please install and configure a boot media, and attempt to power on and boot the server, again. • 806f0021-1201ffff : Fault in slot [PhysicalConnectorSystemElementName] on system [ComputerSystemElementName].
  • Page 386 “Finding the UEFI diagnostic code” on page 919 • 806f0021-25820902 : Fault in slot [PhysicalConnectorSystemElementName] on system [ComputerSystemElementName]. A fault in a slot has been detected. PCIe error. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 387 Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0330 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 388 806f0028-2101ffff : Sensor [SensorElementName] is unavailable or degraded on management system [ComputerSystemElementName]. TPM initialization or start up commands have failed. Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 389 Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0398 User Response 1. Reboot the system. 2. If error persists, or boot is unsuccessful, (Trained service technician only) Replace the system board.. • 806f002b-2101ffff : A hardware change occurred on system [ComputerSystemElementName]. The Scale Config sensor reports a Hardware Changed occurred.
  • Page 390 4. Make sure that the microprocessor heat sink is securely installed. 5. Make sure that the microprocessor heat sink is installed correctly and the thermal material is correctly applied. 6. Replace microprocessor 2. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 391 • 806f0107-2584ffff : An Over-Temperature Condition has been detected on [ProcessorElementName]. The temperature of the specified microprocessor has risen above its specified threshold. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0036 User Response Complete the following steps until the problem is solved: 1.
  • Page 392 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 393 – “Finding the UEFI diagnostic code” on page 919 • 806f010c-2002ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response...
  • Page 394 806f010c-2004ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 395 CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 396 • 806f010c-2007ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 397 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 398 “Finding the UEFI diagnostic code” on page 919 • 806f010c-2009ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 399 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 400 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 401 • 806f010c-200bffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event.
  • Page 402 An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 403 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 404 • 806f010c-200fffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 405 SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 406 “Finding the UEFI diagnostic code” on page 919 • 806f010c-201202ff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 407 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 408 “Finding the UEFI diagnostic code” on page 919 • 806f010c-2014ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 409 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 410 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 411 – “Finding the UEFI diagnostic code” on page 919 • 806f010c-2016ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response...
  • Page 412 806f010c-2018ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 413 CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 414 • 806f010c-201affff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 415 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 416 “Finding the UEFI diagnostic code” on page 919 • 806f010c-201cffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 417 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 418 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 419 • 806f010c-201effff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event.
  • Page 420 An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 421 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 422 806f010c-2022ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 423 SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 424 “Finding the UEFI diagnostic code” on page 919 • 806f010c-202502ff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 425 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 426 “Finding the UEFI diagnostic code” on page 919 • 806f010c-202702ff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 427 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 428 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 429 – “Finding the UEFI diagnostic code” on page 919 • 806f010c-202902ff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response...
  • Page 430 806f010c-202affff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 431 CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 432 • 806f010c-202cffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 433 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 434 “Finding the UEFI diagnostic code” on page 919 • 806f010c-202effff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 435 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 436 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 437 • 806f010c-2030ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event.
  • Page 438 1. Check the Support Portal for service bulletins and RETAIN tips related to your drive. 2. Check the Support Portal for firmware updates related to your drive. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 439 3. Replace the drive. 4. Check for any other RAID-related errors. • 806f010d-0402ffff : The [StorageVolumeElementName] has been disabled due to a detected fault. The hard disk drive controller has detected a fault in hard disk drive 2. Hard disk drive 2 is now defunct. Severity Error Serviceable...
  • Page 440 Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0164 User Response Complete the following steps until the problem is solved: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 441 1. Check the Support Portal for service bulletins and RETAIN tips related to your drive. 2. Check the Support Portal for firmware updates related to your drive. 3. Replace the drive. 4. Check for any other RAID-related errors. • 806f010d-0406ffff : The [StorageVolumeElementName] has been disabled due to a detected fault. The hard disk drive controller has detected a fault in hard disk drive 6.
  • Page 442 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Info Center for the appropriate user response. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 443 Related links – “Finding the UEFI diagnostic code” on page 919 • 806f010f-2201ffff : The System [ComputerSystemElementName] encountered a firmware hang. A system firmware hang has been detected. Severity Error Serviceable Automatically notify support Alert Category System - Boot failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0186...
  • Page 444 SNMP Trap ID CIM Information Prefix: PLAT ID: 0266 User Response 1. Check the SAS backplane 2 is connected completely to main system planar. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 445 2. Check that disk is completely inserted in connector. • 806f0123-2101ffff : Reboot of system [ComputerSystemElementName] initiated by [WatchdogElementName]. The IPMI watchdog timer has expired. The compute node has restarted. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0370...
  • Page 446 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 447 • 806f020d-0400ffff : Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. Failure predicted (PFA) on the hard drive. Severity Warning Serviceable Automatically notify support Alert Category System - Predicted Failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0168 User Response Replace the hard disk drive at the next maintenance period.
  • Page 448 806f020d-0404ffff : Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. Failure predicted (PFA) on the hard drive. Severity Warning Serviceable Automatically notify support Alert Category System - Predicted Failure Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 449 SNMP Trap ID CIM Information Prefix: PLAT ID: 0168 User Response Replace the hard disk drive at the next maintenance period. • 806f020d-0405ffff : Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. Failure predicted (PFA) on the hard drive. Severity Warning Serviceable Automatically notify support Alert Category...
  • Page 450 DIMM population that could be related to this problem.) 3. Check IBM support site for an applicable service bulletin or firmware update that applies to this eXFlash error. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 451 4. If problem persists and there are no other eXFLash DIMMs with the same indication, confirm that the eXFlash DIMM is under warranty before replacement. Related links – “Removing an eXFlash DIMM” on page 999 – “Installing an eXFlash DIMM” on page 1000 –...
  • Page 452 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 453 • 806f030c-2001ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event.
  • Page 454 Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 455 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 456 806f030c-200501ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 457 SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 458 “Finding the UEFI diagnostic code” on page 919 • 806f030c-200701ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 459 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 460 “Finding the UEFI diagnostic code” on page 919 • 806f030c-200901ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 461 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 462 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 463 – “Finding the UEFI diagnostic code” on page 919 • 806f030c-200bffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response...
  • Page 464 806f030c-200dffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 465 CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 466 • 806f030c-200fffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 467 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 468 “Finding the UEFI diagnostic code” on page 919 • 806f030c-2011ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 469 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 470 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 471 • 806f030c-2013ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event.
  • Page 472 Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 473 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 474 806f030c-201702ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 475 SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 476 “Finding the UEFI diagnostic code” on page 919 • 806f030c-201901ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 477 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 478 “Finding the UEFI diagnostic code” on page 919 • 806f030c-201bffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 479 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 480 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 481 – “Finding the UEFI diagnostic code” on page 919 • 806f030c-201dffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response...
  • Page 482 806f030c-201fffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 483 CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 484 • 806f030c-2022ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 485 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 486 “Finding the UEFI diagnostic code” on page 919 • 806f030c-202502ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 487 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 488 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 489 • 806f030c-202702ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event.
  • Page 490 Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 491 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 492 806f030c-202bffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 493 SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 494 “Finding the UEFI diagnostic code” on page 919 • 806f030c-202dffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 495 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 496 “Finding the UEFI diagnostic code” on page 919 • 806f030c-202fffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 497 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 498 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 499 – “Finding the UEFI diagnostic code” on page 919 • 806f030d-0400ffff : Hot Spare enabled for [ComputerSystemElementName]. A hot spare drive is available. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0170 User Response Information only;...
  • Page 500 • 806f030d-0404ffff : Hot Spare enabled for [ComputerSystemElementName]. A hot spare drive is available. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 501 CIM Information Prefix: PLAT ID: 0170 User Response Information only; no action is required. • 806f030d-0405ffff : Hot Spare enabled for [ComputerSystemElementName]. A hot spare drive is available. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0170 User Response...
  • Page 502 • 806f0323-2101ffff : Power cycle of system [ComputerSystemElementName] initiated by watchdog [WatchdogElementName]. The IPMI watchdog timer has expired. The compute node has been powered off and powered on. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 503 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0374 User Response Information only; no action is required. • 806f032b-210100ff : A firmware or software incompatibility was detected on system [ComputerSystemElementName]. A mismatch of IMM firmware between nodes has been detected. Severity Error Serviceable...
  • Page 504 Memory has been Disabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 505 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 506 “Finding the UEFI diagnostic code” on page 919 • 806f040c-2006ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 507 SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 508 – “Finding the UEFI diagnostic code” on page 919 • 806f040c-200affff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 509 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 510 Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 • 806f040c-200effff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 511 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 512 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 513 – “Finding the UEFI diagnostic code” on page 919 • 806f040c-2012ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event.
  • Page 514 806f040c-2015ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 515 CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 516 “Finding the UEFI diagnostic code” on page 919 • 806f040c-2019ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 517 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 518 Related links – “Finding the UEFI diagnostic code” on page 919 • 806f040c-201dffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 519 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 520 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 521 • 806f040c-2021ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 522 Memory has been Disabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 523 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 524 “Finding the UEFI diagnostic code” on page 919 • 806f040c-2028ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 525 SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 526 – “Finding the UEFI diagnostic code” on page 919 • 806f040c-202cffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 527 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 528 Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 • 806f040c-2030ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 529 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 530 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 531 • 806f0507-0302ffff : [ProcessorElementName] has a Configuration Mismatch. A processor configuration mismatch has occurred. Severity Error Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0062 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 532 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 533 – “Finding the UEFI diagnostic code” on page 919 • 806f050c-2002ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response...
  • Page 534 806f050c-2004ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 535 CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 536 806f050c-2008ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 537 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 538 “Finding the UEFI diagnostic code” on page 919 • 806f050c-200cffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 539 Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 540 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 541 • 806f050c-200f02ff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event.
  • Page 542 The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 543 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 544 806f050c-2013ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 545 SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 546 “Finding the UEFI diagnostic code” on page 919 • 806f050c-2016ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 547 Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 548 “Finding the UEFI diagnostic code” on page 919 • 806f050c-2019ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 549 Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 550 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 551 – “Finding the UEFI diagnostic code” on page 919 • 806f050c-201c01ff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response...
  • Page 552 806f050c-201dffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 553 CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 554 806f050c-202001ff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 555 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 556 “Finding the UEFI diagnostic code” on page 919 • 806f050c-2022ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 557 Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 558 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 559 • 806f050c-202502ff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event.
  • Page 560 The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 561 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 562 806f050c-2029ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 563 SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 564 “Finding the UEFI diagnostic code” on page 919 • 806f050c-202d02ff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Severity Warning Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 565 Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 566 “Finding the UEFI diagnostic code” on page 919 • 806f050c-203002ff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 567 Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 568 • 806f050d-0401ffff : Array [ComputerSystemElementName] is in critical condition. The RAID array is in critical condition. Immediate action is required to avoid a system outage. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 569 Severity Error Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0174 User Response Replace the hard disk drive 1 that is indicated by a lit status LED. • 806f050d-0402ffff : Array [ComputerSystemElementName] is in critical condition. The RAID array is in critical condition.
  • Page 570 SNMP Trap ID CIM Information Prefix: PLAT ID: 0174 User Response Replace the hard disk drive 5 that is indicated by a lit status LED. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 571 • 806f050d-0406ffff : Array [ComputerSystemElementName] is in critical condition. The RAID array is in critical condition. Immediate action is required to avoid a system outage. Severity Error Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0174 User Response...
  • Page 572 • 806f0607-0301ffff : An SM BIOS Uncorrectable CPU complex error for [ProcessorElementName] has asserted. An SM BIOS Uncorrectable CPU complex error has asserted. Severity Error Serviceable Automatically notify support Alert Category Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 573 Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0816 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 574 The Drive 1 is part of an RAID array that is in the failed condition. To identify drives in the failed array all member drives will report this message. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 575 Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0176 User Response – Replace the hard disk drives that are indicated by a lit status LED on the drive. – Recreate the array. –...
  • Page 576 The Drive 5 is part of an RAID array that is in the failed condition. To identify drives in the failed array all member drives will report this message. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 577 Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0176 User Response – Replace the hard disk drives that are indicated by a lit status LED on the drive. – Recreate the array. – Restore data from backup. •...
  • Page 578 806f070c-2002ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 579 SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 580 “Finding the UEFI diagnostic code” on page 919 • 806f070c-2004ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 581 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 582 “Finding the UEFI diagnostic code” on page 919 • 806f070c-2006ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 583 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 584 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 585 – “Finding the UEFI diagnostic code” on page 919 • 806f070c-2008ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response...
  • Page 586 806f070c-200a01ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 587 CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 588 • 806f070c-200c01ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 589 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 590 “Finding the UEFI diagnostic code” on page 919 • 806f070c-200effff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 591 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 592 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 593 • 806f070c-2010ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event.
  • Page 594 A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 595 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 596 806f070c-201502ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 597 SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 598 “Finding the UEFI diagnostic code” on page 919 • 806f070c-201702ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 599 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 600 “Finding the UEFI diagnostic code” on page 919 • 806f070c-201901ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 601 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 602 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 603 – “Finding the UEFI diagnostic code” on page 919 • 806f070c-201bffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response...
  • Page 604 806f070c-201d01ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 605 CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 606 • 806f070c-201f01ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 607 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 608 “Finding the UEFI diagnostic code” on page 919 • 806f070c-2021ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 609 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 610 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 611 • 806f070c-2023ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event.
  • Page 612 A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 613 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 614 806f070c-2027ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 615 SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 616 “Finding the UEFI diagnostic code” on page 919 • 806f070c-2029ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 617 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 618 “Finding the UEFI diagnostic code” on page 919 • 806f070c-202bffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 619 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 620 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 621 – “Finding the UEFI diagnostic code” on page 919 • 806f070c-202dffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response...
  • Page 622 806f070c-202f02ff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 623 CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 624 • 806f070c-2581ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory DIMM configuration error has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 625 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 626 • 806f070d-0404ffff : Rebuild in progress for Array in system [ComputerSystemElementName]. The array that contains Drive 4 is in the process of being rebuilt. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 627 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0178 User Response Information only; no action is required. • 806f070d-0405ffff : Rebuild in progress for Array in system [ComputerSystemElementName]. The array that contains Drive 5 is in the process of being rebuilt. Severity Info Serviceable...
  • Page 628 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0450 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 629 • 806f072b-2201ffff : A successful software or firmware change was detected on system [ComputerSystemElementName]. Successful Software or Firmware Change occured for Bkup Auto Update or ROM Recovery Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0450 User Response...
  • Page 630 Information Center for the appropriate user response. Related links – “Finding the UEFI diagnostic code” on page 919 • 806f0813-2581ffff : An Uncorrectable Bus Error has occurred on bus [SensorElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 631 A catastrophic system error has occurred. The system firmware will attempt to analyze the failure to determine whether the failure was due to a hardware component or a software component. Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0240...
  • Page 632 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 633 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3.
  • Page 634 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 635 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-2005ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142...
  • Page 636 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-2008ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 637 Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 638 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-200bffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 639 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 640 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-200effff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 641 SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 642 Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 643 Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3.
  • Page 644 Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 645 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 646 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 647 • 806f090c-2018ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 648 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-201bffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 649 Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 650 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-201effff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 651 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 652 806f090c-202101ff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 653 CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 654 Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 655 Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3.
  • Page 656 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 657 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-2027ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled.
  • Page 658 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 659 • 806f090c-202affff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 660 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-202dffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 661 Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 662 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-2030ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. Severity Warning Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 663 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 664 Prefix: PLAT ID: 0038 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan- or cooling-related issues or power-related issues.. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 665 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. • 806f0a0c-2001ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 666 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 667 • 806f0a0c-2004ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps:...
  • Page 668 806f0a0c-2007ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 669 Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 670 806f0a0c-200affff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 671 Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 672 An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 673 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 674 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 675 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3.
  • Page 676 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 677 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f0a0c-2014ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable...
  • Page 678 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f0a0c-2017ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 679 An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 680 806f0a0c-201affff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 681 Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 682 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 683 SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 684 An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 685 Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3.
  • Page 686 Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 687 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 688 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 689 • 806f0a0c-2026ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps:...
  • Page 690 • 806f0a0c-2029ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 691 Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2.
  • Page 692 806f0a0c-202cffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 693 Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 694 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 695 CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 696 “Finding the UEFI diagnostic code” on page 919 • 806f0b13-0701ffff : Bus [SensorElementName] is operating in a degraded state. IMM has detected that the DMI Bus is degraded. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 697 Severity Warning Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0246 User Response Complete the following steps: 1. AC cycle the machine 2. Remove CPU 1 and inspect the CPU socket for bent pins. 3.
  • Page 698 • 81010701-3702ffff : Numeric sensor [NumericSensorElementName] going high (upper non-critical) has deasserted. The previously high inlet temperature 2 has returned to below its specified threshold. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 699 Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0491 User Response Information only; no action is required. • 81010901-3701ffff : Numeric sensor [NumericSensorElementName] going high (upper critical) has deasserted. The previously high inlet temperature 1 has returned to below its specified threshold. Severity Info Serviceable...
  • Page 700 Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0499 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 701 • 81010b01-3702ffff : Numeric sensor [NumericSensorElementName] going high (upper non-recoverable) has deasserted. The previously high inlet temperature 2 has returned to below its specified threshold. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0499 User Response Information only;...
  • Page 702 An eXFlash DIMM firmware configuration error has deasserted on eXFlash DIMM. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 703 Prefix: PLAT ID: 0509 User Response Information only; no action is required. Related links – “Removing an eXFlash DIMM” on page 999 – “Installing an eXFlash DIMM” on page 1000 • 8103010d-2b81ffff : Sensor [SensorElementName] has deasserted. An eXFlash DIMM firmware configuration error has deasserted on eXFlash DIMM. Severity Info Serviceable...
  • Page 704 Prefix: PLAT ID: 0513 User Response Information only; no action is required. • 81070101-030101ff : Sensor [SensorElementName] has deasserted the transition from normal to non-critical state. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 705 The previously high microprocessor 1 temperature has returned to below its specified threshold. Severity Info Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response Information only; no action is required. •...
  • Page 706 IMM has detected that the Drive temperature has returned to normal. Severity Info Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 707 Prefix: PLAT ID: 0521 User Response Information only; no action is required. • 81070101-2c01ffff : Sensor [SensorElementName] has deasserted the transition from normal to non-critical state. The previously high I/O Exansion card temperature has returned to below its specified threshold. Severity Info Serviceable...
  • Page 708 81070101-2d01ffff : Sensor [SensorElementName] has deasserted the transition from normal to non-critical state. IMM has detected that the PCH temperature has returned to a normal range. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 709 Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response Information only; no action is required. • 8107010d-2582ffff : Sensor [SensorElementName] has deasserted the transition from normal to non-critical state. This message is for the use case when an implementation has detected that a Sensor has deasserted a transition to non-critical from normal.
  • Page 710 Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 711 • 8107010f-2582ffff : Sensor [SensorElementName] has deasserted the transition from normal to non-critical state. The prior condition of less than optimal I/O resource configuration has been cleared. Severity Info Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response...
  • Page 712 IMM has reported a SMI Lane Failed has deasserted. Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 713 CIM Information Prefix: PLAT ID: 0523 User Response Information only; no action is required. • 8107020d-2582ffff : Sensor [SensorElementName] has transitioned to a less severe state from critical. This message is for the use case when an implementation has detected a Sensor transition to less severe from critical.
  • Page 714 81070217-2c01ffff : Sensor [SensorElementName] has transitioned to a less severe state from critical. The I/O Expansion card is no longer in a fault condition. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 715 Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0523 User Response Information only; no action is required. • 81070217-2c02ffff : Sensor [SensorElementName] has transitioned to a less severe state from critical. The I/O Expansion card is no longer in a fault condition.
  • Page 716 Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0523 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 717 • 8107021b-0301ffff : Sensor [SensorElementName] has transitioned to a less severe state from critical. IMM has detected that CPU 1 has recovered from a QPI Link Error. Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0523 User Response...
  • Page 718 The previously high microprocessor 1 temperature has returned to below its specified threshold. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 719 SNMP Trap ID CIM Information Prefix: PLAT ID: 0525 User Response Information only; no action is required. • 81070301-0302ffff : Sensor [SensorElementName] has deasserted the transition to non-recoverable from a less severe state. The previously high microprocessor 2 temperature has returned to below its specified threshold. Severity Info Serviceable...
  • Page 720 • 81070301-2c03ffff : Sensor [SensorElementName] has deasserted the transition to non-recoverable from a less severe state. The previously high I/O Expansion card temperature has returned below its specified threshold. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 721 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0525 User Response Information only; no action is required. • 81070301-2c04ffff : Sensor [SensorElementName] has deasserted the transition to non-recoverable from a less severe state. The previously high I/O Expansion card temperature has returned below its specified threshold.
  • Page 722 Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0525 User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 723 Information only; no action is required. • 8107030d-3030ffff : Sensor [SensorElementName] has deasserted the transition to non-recoverable from a less severe state. This message is for the use case when an implementation has detected that the Sensor transition to non-recoverable from less severe has deasserted. Severity Info Serviceable...
  • Page 724 81070601-2c04ffff : Sensor [SensorElementName] has deasserted the transition to non-recoverable. The previously high I/O Expansion card temperature has returned below its specified threshold. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 725 Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0531 User Response Information only; no action is required. • 8107060f-2201ffff : Sensor [SensorElementName] has deasserted the transition to non-recoverable. BOFM Config Sensor has transitioned to non-recoverable has deasserted. Severity Info Serviceable...
  • Page 726 81070617-2c04ffff : Sensor [SensorElementName] has deasserted the transition to non-recoverable. The I/O expansion adapter in I/O expansion connector 4 no longer reports a non-recoverable condition. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 727 Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0531 User Response Information only; no action is required. • 81090112-2101ffff : Device [LogicalDeviceElementName] has been disabled. An account with IPMI / SNMP access has been disabled. Severity Info Serviceable...
  • Page 728 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0811 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 729 • 816f0007-0301ffff : [ProcessorElementName] has Recovered from IERR. A processor has recovered - IERR Condition. Severity Info Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0043 User Response Information only; no action is required. •...
  • Page 730 Presence of drive 1 is no longer detected. If hard drive is absent from drive bay a filler is required. Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 731 SNMP Trap ID CIM Information Prefix: PLAT ID: 0163 User Response – If drive was intentionally removed, no action required. – Make sure that the drive properly seated. – If drive is properly seated, replace the drive. • 816f000d-0402ffff : The [StorageVolumeElementName] has been removed from unit [PhysicalPackageElementName].
  • Page 732 Presence of drive 5 is no longer detected. If hard drive is absent from drive bay a filler is required. Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0163 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 733 User Response – If drive was intentionally removed, no action required. – Make sure that the drive properly seated. – If drive is properly seated, replace the drive. • 816f000d-0406ffff : The [StorageVolumeElementName] has been removed from unit [PhysicalPackageElementName]. Presence of drive 6 is no longer detected. If hard drive is absent from drive bay a filler is required. Severity Info Serviceable...
  • Page 734 Prefix: PLAT ID: 0223 User Response Information only; no action is required. • 816f0021-1201ffff : Fault condition removed on slot [PhysicalConnectorElementName] on system [ComputerSystemElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 735 The SMP scaling connector in the system has been removed. Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0331 User Response Information only; no action is required. • 816f0021-2201ffff : Fault condition removed on slot [PhysicalConnectorElementName] on system [ComputerSystemElementName].
  • Page 736 The microprocessor 1 temperature has returned to below the critical level. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0037 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 737 User Response Information only; no action is required. • 816f0107-0302ffff : An Over-Temperature Condition has been removed on [ProcessorElementName]. The microprocessor 2 temperature has returned to below the critical level. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0037...
  • Page 738 • 816f010c-2003ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 739 Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. • 816f010c-2004ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 740 Information only; no action is required. • 816f010c-2008ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 741 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. • 816f010c-2009ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered.
  • Page 742 A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 743 User Response Information only; no action is required. • 816f010c-200dffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response...
  • Page 744 • 816f010c-2011ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 745 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. • 816f010c-2012ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable...
  • Page 746 Information only; no action is required. • 816f010c-2016ffff : Uncorrectable error recovery detected for DIMM 22 on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 747 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. • 816f010c-2017ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered.
  • Page 748 A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 749 User Response Information only; no action is required. • 816f010c-201bffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response...
  • Page 750 • 816f010c-201fffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 751 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. • 816f010c-2020ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable...
  • Page 752 Information only; no action is required. • 816f010c-2024ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 753 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. • 816f010c-2025ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered.
  • Page 754 A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 755 User Response Information only; no action is required. • 816f010c-2029ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response...
  • Page 756 • 816f010c-202dffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 757 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. • 816f010c-202effff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A memory uncorrectable error has recovered. Severity Info Serviceable...
  • Page 758 User Response Information only; no action is required. • 816f010d-0400ffff : The [StorageVolumeElementName] has been enabled. The previously disabled drive 0 has been enabled. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 759 Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0167 User Response Information only; no action is required. • 816f010d-0401ffff : The [StorageVolumeElementName] has been enabled. The previously disabled drive 1 has been enabled. Severity Info Serviceable...
  • Page 760 Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0167 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 761 • 816f010d-0405ffff : The [StorageVolumeElementName] has been enabled. The previously disabled drive 5 has been enabled. Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0167 User Response Information only;...
  • Page 762 A System Firmware hang has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0187 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 763 User Response Information only; no action is required. • 816f0207-0301ffff : [ProcessorElementName] has Recovered from FRB1/BIST condition. A processor has Recovered - FRB1/BIST condition. Severity Info Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0045 User Response Information only;...
  • Page 764 816f020d-0401ffff : Failure no longer Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. The predicted failure for Drive 1 no longer exists. Severity Info Serviceable Automatically notify support Alert Category System - Predicted Failure Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 765 SNMP Trap ID CIM Information Prefix: PLAT ID: 0169 User Response Information only; no action is required. • 816f020d-0402ffff : Failure no longer Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. The predicted failure for Drive 2 no longer exists. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 766 Information only; no action is required. • 816f020d-0406ffff : Failure no longer Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. The predicted failure for Drive 6 no longer exists. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 767 Serviceable Automatically notify support Alert Category System - Predicted Failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0169 User Response Information only; no action is required. • 816f020d-0407ffff : Failure no longer Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. The predicted failure for Drive 7 no longer exists. Severity Info Serviceable...
  • Page 768 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0395 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 769 • 816f030c-2001ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only;...
  • Page 770 816f030c-2005ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 771 SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2006ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 772 Information only; no action is required. • 816f030c-200affff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 773 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-200bffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable...
  • Page 774 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 775 • 816f030c-200fffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only;...
  • Page 776 816f030c-2013ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 777 SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2014ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 778 Information only; no action is required. • 816f030c-2018ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 779 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2019ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable...
  • Page 780 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 781 • 816f030c-201dffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only;...
  • Page 782 816f030c-2021ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 783 SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2022ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 784 Information only; no action is required. • 816f030c-2026ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 785 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2027ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable...
  • Page 786 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 787 • 816f030c-202bffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only;...
  • Page 788 816f030c-202fffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 789 SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2030ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 790 Information only; no action is required. • 816f030d-0402ffff : Hot spare disabled for [ComputerSystemElementName]. A hot spare drive is not available. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 791 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0171 User Response Information only; no action is required. • 816f030d-0403ffff : Hot spare disabled for [ComputerSystemElementName]. A hot spare drive is not available. Severity Info Serviceable...
  • Page 792 User Response Information only; no action is required. • 816f030d-0407ffff : Hot spare disabled for [ComputerSystemElementName]. A hot spare drive is not available. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 793 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0171 User Response Information only; no action is required. • 816f0313-1701ffff : System [ComputerSystemElementName] has recovered from an NMI. A Software NMI has recovered. Severity Info Serviceable...
  • Page 794 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 795 • 816f040c-2003ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. •...
  • Page 796 Information only; no action is required. • 816f040c-2007ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 797 SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-2008ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130...
  • Page 798 Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-200cffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 799 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-200dffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 800 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 801 • 816f040c-2011ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. •...
  • Page 802 Information only; no action is required. • 816f040c-2015ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 803 SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-2016ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130...
  • Page 804 Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-201affff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 805 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-201bffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 806 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 807 • 816f040c-201fffff : DIMM 31 Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. •...
  • Page 808 816f040c-2023ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 809 CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-2024ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response...
  • Page 810 Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-2028ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 811 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f040c-2029ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category...
  • Page 812 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 813 • 816f040c-202dffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. •...
  • Page 814 Memory has been enabled. All DIMMs. One of the DIMMs. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 815 CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. • 816f0413-2582ffff : A PCI PERR recovery has occurred on system [ComputerSystemElementName]. A PCI Parity Error (PERR) has recovered. All PCI Error. One of PCI Error. Severity Info Serviceable...
  • Page 816 816f050c-2001ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 817 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-2002ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable...
  • Page 818 Information only; no action is required. • 816f050c-2006ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 819 Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-2007ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed.
  • Page 820 The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 821 User Response Information only; no action is required. • 816f050c-200bffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response...
  • Page 822 816f050c-200fffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 823 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-2010ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable...
  • Page 824 Information only; no action is required. • 816f050c-2014ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 825 Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-2015ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed.
  • Page 826 The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 827 User Response Information only; no action is required. • 816f050c-2019ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response...
  • Page 828 816f050c-201dffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 829 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-201effff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable...
  • Page 830 Information only; no action is required. • 816f050c-2022ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 831 Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-2023ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed.
  • Page 832 The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 833 User Response Information only; no action is required. • 816f050c-2027ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response...
  • Page 834 816f050c-202bffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 835 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-202cffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Severity Info Serviceable...
  • Page 836 Information only; no action is required. • 816f050c-2030ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Removed. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 837 Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. • 816f050c-2581ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The memory logging limit has been removed.
  • Page 838 Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0175 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 839 • 816f050d-0403ffff : Critical Array [ComputerSystemElementName] has deasserted. The RAID array (Drive 3) is no longer in a critical condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0175 User Response Information only;...
  • Page 840 The RAID array (Drive 7) is no longer in a critical condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0175 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 841 User Response Information only; no action is required. • 816f0513-2582ffff : A PCI SERR on system [ComputerSystemElementName] has deasserted. A PCI System Error (SERR) has recovered. All PCI Error. One of PCI Error. Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information...
  • Page 842 • 816f060d-0400ffff : Array in system [ComputerSystemElementName] has been restored. The failed RAID array (Drive 0) has been restored. Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 843 Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0177 User Response Information only; no action is required. • 816f060d-0401ffff : Array in system [ComputerSystemElementName] has been restored. The failed RAID array (Drive 1) has been restored. Severity Info Serviceable...
  • Page 844 Information only; no action is required. • 816f060d-0405ffff : Array in system [ComputerSystemElementName] has been restored. The failed RAID array (Drive 5) has been restored. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 845 Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0177 User Response Information only; no action is required. • 816f060d-0406ffff : Array in system [ComputerSystemElementName] has been restored. The failed RAID array (Drive 6) has been restored. Severity Info Serviceable...
  • Page 846 Information only; no action is required. • 816f070c-2003ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 847 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. • 816f070c-2004ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable...
  • Page 848 A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 849 User Response Information only; no action is required. • 816f070c-2008ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response...
  • Page 850 • 816f070c-200cffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 851 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. • 816f070c-200dffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable...
  • Page 852 Information only; no action is required. • 816f070c-2011ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 853 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. • 816f070c-2012ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable...
  • Page 854 A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 855 User Response Information only; no action is required. • 816f070c-2016ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response...
  • Page 856 • 816f070c-201affff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 857 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. • 816f070c-201bffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable...
  • Page 858 Information only; no action is required. • 816f070c-201fffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 859 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. • 816f070c-2020ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable...
  • Page 860 A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 861 User Response Information only; no action is required. • 816f070c-2024ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response...
  • Page 862 • 816f070c-2028ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable Automatically notify support Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 863 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. • 816f070c-2029ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable...
  • Page 864 Information only; no action is required. • 816f070c-202dffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 865 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. • 816f070c-202effff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Severity Info Serviceable...
  • Page 866 A memory DIMM configuration error has recovered. All DIMMs. One of the DIMMs. Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 867 User Response Information only; no action is required. • 816f070d-0400ffff : Rebuild completed for Array in system [ComputerSystemElementName]. The rebuild of the RAID array (drive 0) has completed. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0179 User Response...
  • Page 868 The rebuild of the RAID array (Drive 4) has completed. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 869 CIM Information Prefix: PLAT ID: 0179 User Response Information only; no action is required. • 816f070d-0405ffff : Rebuild completed for Array in system [ComputerSystemElementName]. The rebuild of the RAID array (Drive 5) has completed. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID...
  • Page 870 Information only; no action is required. • 816f0807-0302ffff : [ProcessorElementName] has been Enabled. A processor has been enabled. Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 871 SNMP Trap ID CIM Information Prefix: PLAT ID: 0060 User Response Information only; no action is required. • 816f0807-2584ffff : [ProcessorElementName] has been Enabled. A processor has been enabled. All CPUs. One of CPUs. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID...
  • Page 872 Information only; no action is required. • 816f090c-2002ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 2 throttling has been turned off. Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 873 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2003ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 3 throttling has been turned off. Severity Info Serviceable...
  • Page 874 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 875 • 816f090c-2007ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 7 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only;...
  • Page 876 Throttled. Memory DIMM 11 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 877 CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-200cffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 12 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information...
  • Page 878 Information only; no action is required. • 816f090c-2010ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 16 throttling has been turned off. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 879 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2011ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 17 throttling has been turned off. Severity Info Serviceable...
  • Page 880 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 881 • 816f090c-2015ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 21 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only;...
  • Page 882 816f090c-2019ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 25 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 883 SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-201affff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 26 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID...
  • Page 884 Information only; no action is required. • 816f090c-201effff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 30 throttling has been turned off. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 885 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-201fffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 31 throttling has been turned off. Severity Info Serviceable...
  • Page 886 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 887 • 816f090c-2023ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 35 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only;...
  • Page 888 816f090c-2027ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 39 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 889 SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2028ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 40 throttling has been turned off. Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID...
  • Page 890 Information only; no action is required. • 816f090c-202cffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 44 throttling has been turned off. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 891 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-202dffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM 45 throttling has been turned off. Severity Info Serviceable...
  • Page 892 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 893 • 816f0a07-0301ffff : The Processor [ProcessorElementName] is no longer operating in a Degraded State. The microprocessor 1 is no longer being throttled. (or ... has been turned off.) Severity Info Serviceable Automatically notify support Alert Category Warning - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0039 User Response...
  • Page 894 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 2 is no longer in an over-temperature condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 895 SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2003ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 3 is no longer in an over-temperature condition. Severity Info Serviceable...
  • Page 896 816f0a0c-2007ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 7 is no longer in an over-temperature condition. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 897 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2008ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 8 is no longer in an over-temperature condition.
  • Page 898 Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 899 • 816f0a0c-200cffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 12 is no longer in an over-temperature condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only;...
  • Page 900 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 16 is no longer in an over-temperature condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 901 SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2011ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 17 is no longer in an over-temperature condition. Severity Info Serviceable...
  • Page 902 816f0a0c-2015ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 21 is no longer in an over-temperature condition. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 903 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2016ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 22 is no longer in an over-temperature condition.
  • Page 904 Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 905 • 816f0a0c-201affff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 26 is no longer in an over-temperature condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only;...
  • Page 906 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 30 is no longer in an over-temperature condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 907 SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-201fffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 31 is no longer in an over-temperature condition. Severity Info Serviceable...
  • Page 908 816f0a0c-2023ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 35 is no longer in an over-temperature condition. Severity Info Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 909 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2024ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 36 is no longer in an over-temperature condition.
  • Page 910 Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 911 • 816f0a0c-2028ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 40 is no longer in an over-temperature condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only;...
  • Page 912 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 44 is no longer in an over-temperature condition. Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 913 SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-202dffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM 45 is no longer in an over-temperature condition. Severity Info Serviceable...
  • Page 914 • 816f0a13-2401ffff : Bus [SensorElementName] has recovered from a Fatal Bus Error. The UEFI has detected that a system has recovered from a System Management Bus Fatal Severity Info Serviceable Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 915 Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0245 User Response Information only; no action is required. • 816f0a13-2582ffff : Bus [SensorElementName] has recovered from a Fatal Bus Error. IMM has detected that the system has recovered from a fatal bus error. (All PCI Error or One of PCI Error or PCIs) Severity Info...
  • Page 916 Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2002ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2003ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 917 Table 6. Events that automatically notify Support (continued) Automatically Event ID Message String Notify Support 806f010c-200401ff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2004ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2005ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 918 Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2015ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-201602ff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 919 Table 6. Events that automatically notify Support (continued) Automatically Event ID Message String Notify Support 806f010c-2016ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2017ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-201802ff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 920 Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-202702ff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2027ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 921 Table 6. Events that automatically notify Support (continued) Automatically Event ID Message String Notify Support 806f010c-202802ff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2028ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-202902ff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 922 806f020d-0400ffff Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. 806f020d-0401ffff Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. 806f020d-0402ffff Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 923 Table 6. Events that automatically notify Support (continued) Automatically Event ID Message String Notify Support 806f020d-0403ffff Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. 806f020d-0404ffff Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. 806f020d-0405ffff Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName]. 806f020d-0406ffff Failure Predicted on [StorageVolumeElementName] for array [ComputerSystemElementName].
  • Page 924 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-2013ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-2014ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 925 Table 6. Events that automatically notify Support (continued) Automatically Event ID Message String Notify Support 806f050c-201502ff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-2015ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-2016ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 926 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-2028ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-202902ff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 927 Table 6. Events that automatically notify Support (continued) Automatically Event ID Message String Notify Support 806f050c-2029ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-202affff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-202bffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].

  • Page 928: Uefi Diagnostic Codes

    Perform the steps listed in this section in the order shown until the problem is solved. After you perform all of the actions that are described in this field, if you cannot solve the problem, contact Lenovo Support. UEFI diagnostic code fields...
  • Page 929 Perform the steps listed in this section in the order shown until the problem is solved. After you perform all of the actions that are described in this field, if you cannot solve the problem, contact Lenovo Support. Finding the UEFI diagnostic code This topic provides information about finding the UEFI diagnostic code.
  • Page 930 • I.18007 [I.18007] : A power segment mismatch has been detected for one or more processor packages. Processors have mismatched Power Segments Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 931 User Response Complete the following steps: 1. If this is a newly installed option, ensure that matching Processors are installed in the correct Processor sockets according to the service information for this product. 2. If power requirements match, check IBM support site for an applicable service bulletin or firmware update that applies to this Processor error.
  • Page 932 2. Check IBM support site for an applicable service bulletin or firmware update that applies to this Processor error. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 933 3. (Trained Service technician only) Replace the Processor. Inspect Processor socket and replace the system board first if socket is damaged. • I.1800E [I.1800E] : A processor model mismatch has been detected for one or more processor packages. Processors have mismatched Model Number Severity Error User Response...
  • Page 934 2. Reflash Primary UEFI image. Refer to UEFI Recovery section of service information for this product. Related links – IBM Flex System and IBM PureFlex Firmware Updates Best Practices Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 935 • I.3808004 [I.3808004] : The IMM System Event log (SEL) is full. IPMI System Event Log is Full Severity Info User Response Complete the following steps: 1. Use IMM Web Interface to clear event log. 2. If IMM communication is unavailable, use F1 Setup to access System Event Logs Menu and Choose Clear IMM System Event Log and Restart Server.
  • Page 936 • I.580A5 [I.580A5] : Mirror Fail-over complete. DIMM number % has failed over to to the mirrored copy. DIMM Mirror Fail-over Detected Severity Info User Response Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 937 Complete the following steps: 1. Check the system-event log for uncorrected DIMM failures and replace those DIMMs. • I.580A6 [I.580A6] : Memory spare copy has completed successfully. Spare Copy Complete Severity Info User Response Complete the following steps: 1. Check system log for related DIMM failures and replace those DIMMs. •...
  • Page 938 Gen1 or Gen2 may be required. Gen1/Gen2 settings can be configured via F1 Setup -> System Settings -> Devices and I/O Ports -> PCIe Gen1/Gen2/Gen3 Speed Selection, or the ASU Utility. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 939 3. If problem persists, then remove Adapter Card. If system reboots successfully without the adapter, replace that card. 4. (Trained service technician only) Replace Processor associated with the PCIe slot. Inspect Processor socket for foreign debris or damage. If debris is found remove debris. If socket is damaged, replace the system board first.
  • Page 940 6. (Trained Service technician only) Replace the system board. • S.3060007 [S.3060007] : A firmware fault has been detected in the UEFI image. Internal UEFI Firmware Fault Detected, System halted Severity Error Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 941 User Response Complete the following steps: 1. Check IBM support site for an applicable service bulletin or firmware update that applies to this error. 2. Reflash UEFI image. 3. (Trained Service technician only) Replace the system board. • S.3070007 [S.3070007] : A firmware fault has been detected in the UEFI image. Internal UEFI Firmware Fault Detected, System halted Severity Error...
  • Page 942 DIMM population that could be related to this problem.) 2. Check IBM support site for an applicable service bulletin or firmware update that applies to this memory error. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 943 3. If no problem is observed on the DIMM connectors or the problem persists, replace the DIMM identified by LightPath and/or event log entry. If this is a flash DIMM, make sure it is still under warranty before replacing it. 4.
  • Page 944 Error Status register contains %. The Global Non-Fatal Error Status register contains %. Please check error logs for the presence of additional downstream device error data. Critical IOH-PCI Error Severity Error User Response Complete the following steps: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 945 1. Check IBM support site for an applicable service bulletin or firmware update for the system or adapter that applies to this error. 2. Check log for a separate error for an associated PCIe device and service that error. 3. (Trained service technician only) Replace Processor. Inspect Processor socket for foreign debris or damage.
  • Page 946 2. If problem persists, reflash the adapter firmware. • W.305800B [W.305800B] : DRIVER HEALTH PROTOCOL: Reports 'Reboot' Required Controller. Severity Warning User Response Complete the following steps: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 947 1. No action required – system will reboot at the end of POST. 2. If problem persists, reflash the adapter firmware. • W.305800C [W.305800C] : DRIVER HEALTH PROTOCOL: Reports 'System Shutdown' Required Controller. Severity Warning User Response Complete the following steps: 1.
  • Page 948 1. Continue booting system. If system does not reset, manually reset the system. 2. If the error is not reported on the subsequent boot, no additional recovery action is required. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 949 3. If the event persists, continue booting system and reflash UEFI image. Check whether there are any additional instructions to update to this level of UEFI. 4. (Trained Service technician only) Replace the system board. • W.381800D [W.381800D] : TPM physical presence is in asserted state Severity Warning User Response...
  • Page 950 If socket is damaged, replace the system board. 6. (Trained Service technician only) Replace affected processor. 7. (Trained Service technician only) Replace the system board. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 951 • W.58002 [W.58002] : Memory spare copy failed. Spare Copy Failed Severity Info User Response Complete the following steps: 1. Check system log for related DIMM failures and replace those DIMMs. • W.58007 [W.58007] : Invalid memory configuration (Unsupported DIMM Population) detected. Please verify memory configuration is valid.
  • Page 952 2. (Trained service technician only) Remove affected Processor and inspect Processor socket pins for damaged or mis-aligned pins. If damage is found, replace the system board. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 953 • W.580B1 [W.580B1] : Memory SMI Lane Redundancy Lost Severity Warning User Response Complete the following steps: 1. Ensure the Processor heatsink is fully screwed down 2. (Trained service technician only) Remove affected Processor and inspect Processor socket pins for damaged or mis-aligned pins. If damage is found, replace the system board. •...

  • Page 954: Troubleshooting By Symptom

    The CMM has reported that the I/O module has completed POST and that no errors have been reported in the logs. c. The SAN device is powered on and is functional. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 955 d. All cables between the I/O module and the SAN device are properly connected and secure, and that the activity LEDs are lit on the appropriate ports. 2. See the documentation for the I/O module for additional information about troubleshooting SAN connectivity or network connectivity issues.
  • Page 956 Remove the I/O module and install a working I/O module in the same I/O bay. e. If the problem is solved, replace the I/O module that you removed. Related Links: Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 957 • “Installing an I/O expansion adapter” on page 1011 • “Installing a compute node in a chassis” on page 976 • “Removing a compute node from a chassis” on page 975 • “Removing an I/O expansion adapter” on page 1011 •...
  • Page 958 4. Note: If the CMM recently lost connection to the DCHP server, you must to reset the IMM by using the CMM interface so that a new IP address can be acquired. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 959 5. In the CMM user interface, click Chassis Management > Component IP Configuration and make sure that the IP address that is listed is the same as the IP address that is displayed in the Setup utility. If it is not the same IP address, configure the IMM network settings correctly or reset the IMM to automatically acquire a new IP address.
  • Page 960 4. From the compute node operating system, verify that the network device is active. Check also the network settings, such as IP address, subnet mask (if you are using IPv4), DNS, DHCP settings, and Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 961 vLAN settings to make sure that the settings match the settings of the network device. See the documentation that comes with the operating system for information about viewing network devices and checking the network settings. 5. Check the IBM Support Portal for any firmware updates that might apply to this problem. You can view the release notes for a firmware update to determine the issues that are addressed by the update.
  • Page 962 If the I/O module is powered on and hung, reset the I/O module. Make sure that the correct ports are enabled for the node on the I/O module. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 963 3. Make sure that the management network port (eth1) is enabled in the management node. Make sure that the port configuration settings are correct for the data network. 4. Make sure that the configuration settings for each node are correct and that the data network ports are enabled.
  • Page 964 If you are unable to log in from the management network, attempt to log in from the data network. If the management node is powered on and hung, perform a virtual reseat of the management node from the Chassis Management Module (CMM). Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 965 2. Make sure that the Chassis Management Module (CMM) is powered on and is not hung by pinging the Chassis Management Module (CMM) from the management node: a. If the Chassis Management Module (CMM) is powered on and hung, reset the Chassis Management Module (CMM).
  • Page 966 Replace the management node. Related Links: • http://www.ibm.com/support • “Installing an I/O expansion adapter” on page 1011 • “Removing an I/O expansion adapter” on page 1011 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 967 Multiple nodes cannot ping the management node in the same chassis and different chassis Use the information in this section to troubleshoot multiple nodes that cannot ping the IBM Flex System Manager management node in the same chassis or a different chassis on the management network. 1.

  • Page 968: Hard Disk Drive Problems

    • “Removing the system-board components for base-assembly replacement” on page 1035 • http://www.ibm.com/support Hard disk drive problems Use this information to resolve hard disk drive problems. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 969 Compute node fails to recognize one drive Use this information to resolve hard disk drive problems. 1. Verify that the drive is supported for this compute node. See the IBM ServerProven website for a list of supported hard drives. 2. Make sure that the drive is seated in the drive bay properly and that there is no physical damage to the drive connectors.

  • Page 970: Intermittent Connectivity Problems

    1. Make sure that the correct device drivers are installed. See the manufacturer's website for documentation. 2. For a USB device: a. Make sure that the device is configured correctly (see Using the Setup utility). Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 971: Memory Problems

    b. Connect the device to another port. If using a USB hub, remove the hub and connect the device directly to the compute node. Make sure that the device is configured correctly for the port (see Using the Setup utility). c.

  • Page 972: Observable Problems

    4. If the problem remains, make sure that any new software has been installed and configured correctly. 5. Contact your place of purchase of the software or your software provider. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 973: Installation Problems

    Machine seems to be running hot On a single node Check the IBM Flex System Manager management software (if installed) or CMM log for rising temperature events. If there are no events, the compute node is running within normal operating temperatures. Note that you can expect some variation in temperature.

  • Page 974: Performance Problems

    1. Verify the cards in I/O connector 3 and 4 are not cards supported only in I/O expansion connectors 1 and 2. The following link to the Service Guide describes cards supported only in I/O expansion connector 1 and 2. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 975: Power-On Problems

    2. If the card is in the correctly supported connector, replace the card. Related Links: • “Installing an I/O expansion adapter” on page 1011 • “Removing an I/O expansion adapter” on page 1011 Poor or slow network performance Use this information to troubleshoot poor or slow network performance. 1.
  • Page 976 6. Replace the system-board assembly (see Removing the system-board assembly and Installing the system-board assembly). Related Links: • “Installing the system-board components for base-assembly replacement” on page 1036 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 977: Software

    • “Removing the system-board components for base-assembly replacement” on page 1035 Software Use this information to solve software problems Applications Use this information to solve software Application problems 1. To determine whether the problem is caused by the software, make sure that: 2.

  • Page 978: Undetermined Problems

    If SMP card not functional, can not cluster the systems together into a multi-node 1. Insure SMP connector fully seated. 2. Contact IBM Support Undetermined problems Use this information to solve undetermined problems. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 979: Solving Undetermined Problems

    Lenovo Flex System chassis. • If all of the compute nodes have the same symptom, the problem is probably in the Lenovo Flex System chassis. For more information, see the documentation for your Lenovo Flex System chassis.

  • Page 980: Collecting Service Data

    “Recovering a UEFI image” on page 29. Check the LEDs on all the power supplies of the Lenovo Flex System chassis in which the compute node is installed. If the LEDs indicate that the power supplies are working correctly and reseating the compute node does not correct the problem, complete the following steps: 1.
  • Page 981 documentation at http://pic.dhe.ibm.com/infocenter/ flexsys/information/topic/ com.ibm.acc.8731.doc/ setting_up_electronic_service_agent.html. • The FFDA tool is integrated into the IMM2. For more information about accessing the IMM2, see Chapter 4 “Accessing the IMM2” on page 49. Chapter 6 Troubleshooting...
  • Page 982 Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 983: And Replacing Compute Node Components

    • Back up all important data before you make changes to hard disk drives. • Before you remove a compute node from the Lenovo Flex System chassis, you must shut down the operating system and turn off the compute node. You do not have to shut down the chassis itself.

  • Page 984: Handling Static-Sensitive Devices

    • Do not leave the device where others can handle and damage it. • While the device is still in its static-protective package, touch it to an unpainted metal part of the Lenovo Flex System chassis or any unpainted metal surface on any other grounded rack component in the rack in which you are installing the device for at least 2 seconds.

  • Page 985: Removing A Compute Node From A Chassis

    Handle Attention: • To maintain proper system cooling, do not operate the Lenovo Flex System chassis without a compute node or node bay filler installed in each node bay. • When you remove the compute node, note the node bay number. Reinstalling a compute node into a different node bay from the one it was removed from can have unintended consequences.

  • Page 986: Installing A Compute Node In A Chassis

    08/20/2012 or later. To determine whether your CMM firmware must be updated, log on to the IBM Chassis Management Module web interface. Click on the Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 987: Removing And Replacing Tier 1 Customer Replaceable Units (Crus)

    Removing and replacing Tier 1 customer replaceable units (CRUs) Use this information for removing and replacing Tier 1 CRUs. Replacement of Tier 1 CRUs is your responsibility. If Lenovo installs a Tier 1 CRU at your request, you will be charged for the installation.

  • Page 988: Removing The Adapter-Retention Assembly

    1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).

  • Page 989: Installing The Adapter-Retention Assembly

    1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).

  • Page 990: Removing The Bezel

    Before you install the bezel, read “Safety” on page v and “Installation guidelines” on page 973. To install the bezel, complete the following steps. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...

  • Page 991: Removing The Center Partition

    1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).

  • Page 992: Installing The Center Partition

    1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).

  • Page 993: Removing The Chassis Bulkhead

    1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).
  • Page 994 1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).

  • Page 995: Removing The Cmos Battery

    1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).

  • Page 996: Removing The Compute Node Cover

    3. Turn on the compute node, start the Setup utility, and reset the configuration (see “Using the Setup utility” on page 31 for instructions). Removing the compute node cover Use this information to remove the cover from a compute node. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
  • Page 997 1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).

  • Page 998: Installing The Compute Node Cover

    Before you install the compute node cover, read “Safety” on page v and “Installation guidelines” on page 973. You cannot insert the compute node into the Lenovo Flex System chassis until the cover is installed and closed. Do not attempt to override this protection.

  • Page 999: Removing A Dimm

    1. Read “Safety” on page v and “Installation guidelines” on page 973. 2. If the compute node is installed in a Lenovo Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 975 for instructions).
  • Page 1000 • Install the air baffles with the arrow indicating air flow direction pointing to the rear of the compute node. • To maintain proper system cooling, do not operate the compute node without air baffles installed over the DIMM connectors. Lenovo Flex System x280 X6, x480 X6, and x880 X6 Compute Node Installation and Service Guide...
