Telefunken TKP2177ST Service Manual page 17

Item
M-COL Mild color
M-BRI Mild brightess
M-CON Mild contrast
M-SHP Mild sharpness
Menu 20: no shortcut key
Item
SEG_POINT1 Highest frequency of VHFL
SEG_POINT2
Highest frequency of VHFH
DATA_VL
VHFL bandswitch（BB）
DATA_VH
VHFH bandswitch（BB）
DATA_UF UHF bandswitch（BB）
SPE_POS1 The channel number treated specially
Bandswitch in which the special channel （BB）
SPE_DATA1
SENSI_ON
SENSI_OFF
Menu 21: no shortcut key
Item
Theater
THEATER-BAS
Theater
THEATER-TRE
Concert
CONCERT-BAS
Concert
CONCERT-TRE
Brocast
BROCAST-BAS
Brocast
BROCAST-TRE
Menu 22: no shortcut key
Item
VOL_MAI Volume Loudspeaker
GATE Carrier-Mute
VOL-OUT AV output gain
AV GAIN AV input Gain
Note:
① Provided the production line is equipped with the self-adjusting equipment, The adjusted item
should be based on the result by such equipment.
②
There's difference between PAL geometric/OSD adjustment and NTSC geometric/OSD
adjustment. PAL adjustment must be done before NTSC adjustment.
Remark
Remark
Remark
bass
treble
bass
treble
bass
treble
Remark
