Telefunken TKP2177ST Service Manual page 16

Bit 4
Bit 5
Bit 6
Bit 7
Menu 14(Remote key: "sleep)
Item
HAFC Bit 1 ~ 0
Bit 3 ~ 2
AGCC
NOIS
ONTM V-mute timing when power on (01H = 16ms)
NSHP Decreased level of sharpness when noise reduction is on
PVLVL X-ray protection start point (00H
PLMT (01H = 8ms)
Menu 15 (Remote key: "Calendar")
Item
RC-C R cut-off setting (for cool color temperature)
GC-C G cut-off setting (for cool color temperature)
BC-C B cut-off setting (for cool color temperature)
GD-C G drive setting (for cool color temperature)
BD-C B drive setting (for cool color temperature)
Menu 16 (Remote key: "System/INS" )
Item
RC-W R cut-off setting (for warm color temperature)
GC-W G cut-off setting (for warm color temperature)
BC-W B cut-off setting (for warm color temperature)
GD-W G drive setting (for warm color temperature)
BD-W B drive setting (for warm color temperature)
YUVGC YUV R cut-off
YUVBC YUV B cut-off
Menu 17 (Remote key: "FAV" )
Item
D-COL
Dynamic color
D-BRI
Dynamic brightess
D-CON Dynamic contrast
D-SHP Dynamic sharpness
Menu 18 (Remote key: "Return" )
Item
S-COL Standard color
S-BRI Standard brightess
S-CON
Standard contrast
S-SHP
Standard sharpness
Menu 19 (Remote key: "Picture" )
SLO f0 shift(test only)
Remark
AFC gain (TV mode) [1CH, bit 5 ~ 4]
AFC gain (AV mode) [1CH, bit 5 ~ 4]
Remark
Remark
Remark
Remark
0V & FFH 5V)
