Factory settings

D-mode:
Enter D-Mode by pressing D-Mode ON/OFF key, and then you can enter the D-mode.
S-mode:
Enter S-Mode by pressing VOLUME DOWN key on the unit until the
volume decrease to minimum level, then press the DISPLAY key on the remote
handset (don't release the volume key) and you can enter S- mode.
After enter D-mode or S-mode, press OK, then press program up/down to
select menu from menu 1 to menu 22, press OK to enter the menu, press program
up/down to select item, press volume up/down to adjust the setting. Press D-mode
again to quit factory mode.
You can also enter menu 1 to menu 19 directly by pressing digital button 1~9,
0, notebook, CAP, Display, Sleep, Calendar, System/INS, Favorite, Return, Picture.
Menu 1 (Remote key: "1")
Item
RC R cut-off setting
GC G cut-off setting
BC B cut-off setting
GD G drive setting
BD B drive setting
Menu 2 (Remote key: "2"))
Item
HIGH5 Height (50Hz)
VP50 Vertical position (50Hz)
VLIN5 Vertical linearity (50Hz)
VSC5 Vertical S correction (50Hz)
VBLK5 Vertical blanking start & stop [1C, bit 3 ~ 0]
VCEN5 Vertical center (50Hz)
Menu 2 (Remote key: "2")
Item
HIGH6 60Hz height
VP60 Vertical position
VLIN6 60Hz Vertical linearity
VSC6 Vertical S correction (60Hz)
VBLK6 Vertical blanking start & stop [1CH, bit 3 ~ 0]
VCEN6 Vertical center (60Hz)
Menu 3 (Remote key: "3")
Item
HPOS5 Horizontal position (50Hz)
Menu 3 (Remote key: "3" )
Item
HPOS6 Horizontal position (60Hz)
Remark
Remark
Remark
Remark
Remark
