- Page 1 Operators Manual Operators Manual Manuel De L'Opérateur Manual del Operador Рyкoвoдcтвo для oпepaтopa TILE SAWS - Spare Parts Book - Pièces détachées - Libro Despiece - Запасные части Книга 870/30006/3 06/14...
-
Page 2: Déclaration De Conformité
Lawaai Technische dossiers zijn in handen van Ray Neilson op de Belle groep hoofdkantoor adres, dat staat boven. Vi, Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB, erklærer hermed, at hvis det i dette certifikat beskrevne produkt er købt hos en autoriseret Belle Group forhandler i EU, er det i overensstemmelse med følgende EØF-direktiver: 2006/42/CE (Dette direktiv erstatter direktiv 98/37/EF), 2004/108/EØF (som ændret... - Page 3 ....( ........Ray Neilson ........Tegevdirektor - BELLE GROUP (SHEEN) UK poolt. Vado ais direktors BELLE GROU (S EEN) UK. BELLE GROU (S EEN) - Sheen, Nr. Buxton, Derbyshire, SK17 0EU, UK - 1999..............- Sheen, Nr. Buxton, Derbyshire, SK17 0EU, UK - 1999..............
-
Page 4: Table Of Contents
ALWAYS wear or use the proper safety items required for your personal protection. If you have ANY QUESTIONS about the safe use or maintenance of this unit, ASK YOUR SUPERVISOR OR CONTACT: BELLE GROUP (UK): 44 (0) 1298 84606 Contents How to use this manual ..................................... -
Page 5: Environment
Technical Data Model Minitile 180 Minitile 200 Minitile 230 Magiktile 180 Maxitile 260 Width (mm) Height (mm) 1240 Length (mm) 1150 Blade Diameter (mm) Blade Speed (rpm) 2800 2800 2800 2800 2800 Blade Centre Hole (mm) 25.4 25.4 25.4 25.4 25.4... -
Page 6: General Safety
General Safety When using electric tools, following safety precautions should always be followed to reduce the risk of re, electric shock and personal injuries. Read and follow all these instructions before attempting to WARNING operate this product. Keep your work area perfectly clean Cluttered areas invite injuries. -
Page 7: Pre-Start Checks
230V In 3 A Id 20 mA 115V In 6 A Id 20 mA TRANSFORMER 230V 50 Hz 650 W 115V 50 Hz 650 W MINITILE 200 RCCB 230V 5 A Id 20 mA 115V 6 A Id 20 mA TRANSFORMER... - Page 8 Adjusting The Blade Guard The machine is equipped with a continuous diamond rim blade. Even though this blade has been designed for operator safety if unintentionally touched, pay particular attention to avoid contact between your ngers CAUTION and the blade during operation of the machine. MINITILE &...
- Page 9 Operating Instructions MINITILE & MAGIKTILE ONLY!! Cutting at 90° Position the cutting guide and lock it by tightening the knobs fully. (See Figure 5a) The picture on the right shows how to position hands correctlyduring cutting at 90 . The forward movement of the piece must be proportional to the blade cutting capacity, to prevent hazardous fragments that would involve accidents or injuries from breaking off.
- Page 10 Maintenance Before performing any maintenance operation, ensure the machine is disconnected from the power CAUTION supply. MINITILE & MAGIKTILE ONLY!! DIAMOND BLADE DISASSEMBLY Remove the blade guard. Use the 4mm Allen Key to hold the motor shaft. Unscrew the blade ange block nut with the 19mm spanner.
- Page 11 Consult local dealer. Warranty Your new Belle Group Tile Saw is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The Belle Group warranty is against defects in design, materials an workmanship.
- Page 12 ALWAYS wear or use the proper safety items required for your personal protection. If you have ANY QUESTIONS about the safe use or maintenance of this unit, ASK YOUR SUPERVISOR OR CONTACT: BELLE GROUP (UK): 44 (0) 1298 84606 Contents How to use this manual ...................................
-
Page 13: Technical Data
Technical Data Model Minitile 180 Minitile 200 Minitile 230 Magiktile 180 Maxitile 260 Width (in) 18.8 18.1 23.0 15.5 17.3 Height (in) 10.6 10.2 13.1 48.8 Length (in) 19.6 13.0 22.0 15.5 45.3 Blade Diameter (in) Blade Speed (rpm) 2800... - Page 14 General Safety When using electric tools, following safety precautions should always be followed to reduce the risk of re, electric shock and personal injuries. Read and follow all these instructions before attempting to WARNING operate this product. Keep your work area perfectly clean Cluttered areas invite injuries.
-
Page 15: Health & Safety
230V In 3 A Id 20 mA 115V In 6 A Id 20 mA TRANSFORMER 230V 50 Hz 650 W 115V 50 Hz 650 W MINITILE 200 RCCB 230V 5 A Id 20 mA 115V 6 A Id 20 mA TRANSFORMER... -
Page 16: Adjusting The Blade Guard
Adjusting The Blade Guard The machine is equipped with a continuous diamond rim blade. Even though this blade has been designed for operator safety if unintentionally touched, pay particular attention to avoid contact between your ngers CAUTION and the blade during operation of the machine. MINITILE &... -
Page 17: Operating Instructions
Operating Instructions MINITILE & MAGIKTILE ONLY!! Cutting at 90° Position the cutting guide and lock it by tightening the knobs fully. (See Figure 5a) The picture on the right shows how to position hands correctlyduring cutting at 90°. The forward movement of the piece must be proportional to the blade cutting capacity, to prevent hazardous fragments that would involve accidents or injuries from breaking off. - Page 18 Maintenance Before performing any maintenance operation, ensure the machine is disconnected from the power CAUTION supply. MINITILE & MAGIKTILE ONLY!! DIAMOND BLADE DISASSEMBLY Remove the blade guard. Use the 4mm Allen Key to hold the motor shaft. Unscrew the blade ange block nut with the 19mm spanner.
-
Page 19: Troubleshooting Guide
Consult local dealer. Warranty Your new Belle Group Tile Saw is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The Belle Group warranty is against defects in design, materials an workmanship. -
Page 20: Comment Utiliser Ce Manuel
Il faut TOUJOURS porter ou utiliser les articles de protection appropriés pour assurer votre protection personnelle. Pour TOUTES QUESTIONS EVENTUELLES sur l’utilisation ou l’entretien en toute sécurité de cet appareil, CONSULTEZ VOTRE RESPONSABLE OU CONTACTEZ BELLE GROUP: 44 (0)1298 84606 Sommaire Comment Utiliser Ce Manuel ................................... -
Page 21: Caractéristiques Techniques
Caractéristiques Techniques Modèle Minitile 180 Minitile 200 Minitile 230 Magiktile 180 Maxitile 260 Largeur (mm) Hauteur (mm) 1240 Longeur (mm) 1150 Diamètre outil (mm) Vitesse de rotation (rpm) 2800 2800 2800 2800 2800 Alésage outil (mm) 25.4 25.4 25.4 25.4 25.4... -
Page 22: Consignes De Sécurité
Consignes De Sécurité A n de réduire le risque d’électrocution, de blessure ou d’incendie lors de l’utilisation d’outils AVERTISSEMENT électriques, observez toujours les mesures de sécurité suivantes. Lisez et observez ces instructions avant d’utiliser l’outil et conservez ces indications. Maintenez de l’ordre sur votre lieu de travail Le désordre dans le lieu de travail augmente le risque d’accident. -
Page 23: Santé Et Sécurité
230V In 3 A Id 20 mA 115V In 6 A Id 20 mA TRANSFORMATUER 230V 50 Hz 650 W 115V 50 Hz 650 W MINITILE 200 DIFF RENTIEL 230V 5 A Id 20 mA 115V 6 A Id 20 mA TRANSFORMATUER... -
Page 24: Réglage De La Protection Du Disque
Réglage de la Protection du Disque La machine est munie d’un disque diamant à couronne continue. Cet outil présente la caractéristique de ne pas blesser les doigts en cas de choc accidentel. Dans tous les cas, veuillez faire ATTENTION particulièrement attention lors de l’utilisation de la machine à tout contact entre les doigts et le disque diamant. -
Page 25: Fonctionnement De La Scie A Sol
Fonctionnement de la Scie a Sol MINITILE & MAGIKTILE SEULEMENT!! Faire une coupe à plat Placez le guide de coupe comme indiqué sur la gure et bloquez-le à l’aide des poignées de blocage. (Fig 5a) La Fig.5a montre comment placer correctement ses mains lors d’une coupe à plat. L’avance devra être proportionnelle à... -
Page 26: Entretien
Entreten Avant d’effectuer l’une quelconque des operations decrites dans ce chapitre, assurez-vous que la ATTENTION machine est bien debranchee. MINITILE & MAGIKTILE SEULEMENT!! DEMONTAGE DU DISQUE DIAMANTE Déposer la protection du disque. Maintenez bloqué l’arbre du moteur à l’aide de la clef Allen 4 mm. A l’aide de la clé de 19 mm, dévissez l’écrou de blocage de la bride de support du disque. -
Page 27: Recherches Des Pannes
Garantie La ‘Tile Saw’’ de Belle Group est garantie à l’acquéreur d’origine un an (12 mois) à partir de la date originale de l’achat. La garantie Belle Group s’applique à tous défauts de matériaux ou à un vice de conception ou de fabrication. -
Page 28: Uso De Este Manual
Uso De Este Manual Este manual ha sido compilado para ayudarle a operar y mantener con seguridad la sierra para pisos. Este manual está destinado para el uso de comerciantes y operadores de la sierra para pisos. Prólogo La sección dedicada al ‘Medioambiente’ comprende instrucciones sobre el reciclado de aparatos descartados, con el n de proteger el entorno. -
Page 29: Datos Técnicos
Datos Técnicos Modelo Minitile 180 Minitile 200 Minitile 230 Magiktile 180 Maxitile 260 Anchura (in) 18.8 18.1 23.0 15.5 17.3 Altura (in) 10.6 10.2 13.1 48.8 Longitud (in) 19.6 13.0 22.0 15.5 45.3 Diámetro herramienta (in) Velocidad de rotación (rpm) -
Page 30: Seguridad General
Seguridad General Cuando utilice aparatos eléctricos, observe las siguientes medidas de seguridad, a n de reducir el riesgo de descargas eléctricas, de lesiones y de incendio. Lea y observe todas estas instrucciones antes de utilizar AVISO el aparato y conserve bien estas instrucciones. Mantenga ordenado su lugar de trabajo El desorden en el área de trabajo aumenta el riesgo de accidentes. -
Page 31: Sanidad Y Seguridad
230V In 3 A Id 20 mA 115V In 6 A Id 20 mA TRANSFORMADOR 230V 50 Hz 650 W 115V 50 Hz 650 W MINITILE 200 DIFERENCIAL 230V 5 A Id 20 mA 115V 6 A Id 20 mA TRANSFORMADOR... -
Page 32: Regulacion De La Proteción Del Disco
Adjusting The Blade Guard La máquina está dotada de disco diamantado con corona continua. Este aparato tiene la característica de no herir ATENCIÓN los dedos si se la golpea accidentalmente. En todo caso, prestar particular atención, durante el uso de la máquina, al contacto de los dedos con el disco diamantado. -
Page 33: Operación
Operación MINITILE & MAGIKTILE SOLAMENTE!! Situar la guía de corte y bloquearla mediante las manillas de jación, (Figura 5a) En la gura 4 aparece indicada la posición correcta de las manos durante la ejecución del corte en super cie plana. El avance debe ser proporcional a la capacidad de corte del disco. -
Page 34: Mantenimiento
Mantenimiento Antes de iniciar cualquiera de las operaciones incluidas en el presente capítulo, asegurarse de que la ATENCIÓN máquina esté desconectada de la red eléctrica. MINITILE & MAGIKTILE ONLY!! DESMONTAJE DEL DISCO DIAMANTATO Retirar el cárter de protección del disco. Mediante la llave Allen de 4mm. -
Page 35: Localization De Averias
2. Las alteraciones, adiciones o reparaciones efectuadas por personas ajenas a Belle Group o a sus agentes reconocidos. 3. Los costos de transporte o embarque a y de Belle Group o sus agentes reconocidos, para la reparación o evaluación de una máquina al amparo de una reclamación contra la garantía. - Page 36 :BELLE GROUP : 44 (0) 1298 84606 ..............................36 ......................................36 ................................. 37 ....................................37 ................................38 ......................................39 ............................... 39 ..................................39 ..................................40 ........................................40 ....................................40 ................................. 41 ................................... 42 ............................43 ........................................43...
- Page 37 1240 1150 2800 2800 2800 2800 2800 25,4 25,4 25,4 25,4 25,4 1200 (230 , 50 (115 , 50 (230 , 50 ( )) (110 , 50 ( ))
- Page 38 General Safety...
- Page 39 MINITILE 180 In = 3 A, Id = 20 In = 6 A, Id = 20 MINITILE 200 MINITILE 230 MAGIKTILE 180 230V In 6 A Id 20 mA 115V In 3 A Id 20 mA 230V 50 Hz 650 W...
- Page 40 . 3a). . 3b). . 3c). MAXITILE . 4). 45°,...
- Page 41 . 5a) 90°. . 5b, MAXITILE 0° . 6a). . 6b, 45° . 6b). . 6c 0 45°, . 6d). MAXITILE...
- Page 42 MAXITILE . 7d).
- Page 43 Belle Group .Belle Group Belle Group Belle Group. Belle Group Belle Group / Belle Group Belle Group Warranty Department, Sheen, Nr. Buston Derbyshire SK17 0EU England. Tel : 44 (0)1298 84606 Fax : 44 (0)1298 84722 Email : warranty@belle-group.co.uk...
- Page 44 Minitile 180...
- Page 45 Minitile 180 ITEM PART NUMBER NUMBER DESCRIPTION 156.0.303 Water Tank 156.0.288 External Body 156.0.305 Fastener Kit 156.0.255 Handle 156.0.375 Switch (230v - 50Hz) 156.0.376 Switch (115v - 50Hz) 156.0.293 Electrical Cable & Rear Cover (230v - 50Hz) 156.0.291 Electrical Cable & Rear Cover (115v - 50Hz) 156.0.292 Electrical Cable &...
- Page 46 Minitile 200...
- Page 47 Minitile 200 ITEM PART NUMBER NUMBER DESCRIPTION 156.0.356 Steel Body 156.0.313 Drain Plug 156.0.368 Plug & Cable (230v - 50Hz) 156.0.369 Plug & Cable (115v - 50Hz) 156.0.359 Fastener Kit 156.0.255 Handle 156.0.375 Switch (230v - 50Hz) 156.0.376 Switch (115v - 50Hz) 156.0.349...
- Page 48 Minitile 230...
- Page 49 Minitile 230 ITEM PART NUMBER NUMBER DESCRIPTION 156.0.365 Steel Body 156.0.313 Drain Plug 156.0.369 Plug & Cable (230v - 50Hz) 156.0.368 Plug & Cable (115v - 50Hz) 156.0.261 Fastener Kit 156.0.255 Handle 156.0.375 Switch (230v - 50Hz) 156.0.376 Switch (115v - 50Hz) 156.0.349 Tool Kit 156.0.366...
- Page 50 Magiktile 180...
- Page 51 Magiktile 180 ITEM PART NUMBER NUMBER DESCRIPTION 156.0.301 Outer Cover 156.0.305 Screw Kit 156.0.296 Plastic Flange Kit c/w Nut 156.0.280 Motor Cover 156.0.290 Tipping Bracket 156.0.282 Electrical Cable (230v - 50Hz) 156.0.283 Electrical Cable (115v - 50Hz) 156.0.358 Diagonal Fence 156.0.284 Cutting Line 156.0.311...
- Page 52 Maxitile 260...
- Page 53 Maxitile 260 ITEM PART NUMBER NUMBER DESCRIPTION 156.0.339 Bung 156.0.353 Fastener Kit 156.0.350 Water Spray Protection Kit 156.0.339 Legs 156.0.255 Handles 156.0.322 Brackets 156.0.321 Steel Body 156.0.333 Scale Measurement 156.0.354 Plug & Cable (115v - 50Hz) 156.0.370 Plug & Cable (230v - 50Hz) 156.0.371 Plug &...
- Page 54 ALTRAD Belle Head Office Sheen, Nr. Buxton Derbyshire. SK17 OEU England Tel: +44 (0)1298 84606 Fax: +44 (0)1298 84722 email: sales@belle-group.co.uk www.ALTRAD-Belle.com www.Belle247.com No.1 for Light Construction Equipment, Scaffolding, Wheelbarrows www.ALTRAD-Belle.com Belle... ALTRAD... BarOmix... FORT... Limex... Richard Fraisse... Plettac COMPACTING... MIXING...
