Summary of Contents for N-Com bluetooth kit multi
- Page 1 SAFETY AND INSTRUCTIONS FOR USE...
- Page 2 FOR USA MARKET ONLY: SPECIAL WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 Long tests and thorough system development have resulted in the highest sound quality. Bluetooth Kit MULTI can be connected to your cell phone, to a GPS system or to an MP3 reader using Bluetooth wireless technology.
-
Page 4: Table Of Contents
Table of contents WARNINGS AND SAFETY ____ 5 BLUETOOTH RECEIVER (A2DP 1.1.Reference standards __________ 5 PROFILE) _______________ 23 1.2.Road safety _________________ 6 7.1.Affiliation with A2DP devices ___23 1.3.Switching on the system in safe 7.2.Operation with A2DP receiver __23 environments ____________________ 6 SATELLITE NAVIGATORS ___ 25 1.4.Interferences ________________ 7 CONNECTION TO OTHER... -
Page 5: Warnings And Safety
Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you will be using with the N-Com Bluetooth kit MULTI. Read the simple rules listed below. Failure to comply with these rules may lead to dangerous situations. -
Page 6: Road Safety
When using the N-Com system, comply with all limitations and instructions related to the use of cell phones. Do not turn on your cell phone or the N-Com system whenever their use is forbidden or when the devices can cause interference or dangerous situations. -
Page 7: Interferences
1.4. Interferences All phones and devices with wireless signal transmission are subject to interferences that may affect the performance of the device connected to them. These interferences are not ascribable to a defect of the N-Com system. 1.5. Appropriate use Use the device only in the normal position, as described in the product documentation. -
Page 8: Qualified Personnel
Warning: Listening to other equipment should not interfere with driving the vehicle, which must be the top priority at all times. Carry out all operations on the electronic equipment and on the N-Com system with the vehicle stopped, in compliance with Traffic Regulations. -
Page 9: Disposal
The helmet should never be left within the reach of unsupervised children in order to prevent damage to their health caused by access to the batteries. 1.8. Disposal Refer to this user manual and to manuals related to other parts of the N- Com system in order to disassemble the system from the helmet. -
Page 10: Content Of The Packaging
2. CONTENT OF THE PACKAGING The N-Com Bluetooth Kit MULTI package contains: e-box MULTI Wired support Pliers Adhesive plate Fixing screw Helmet support adhesive rubber Battery charger... -
Page 11: Installation
3. INSTALLATION The Bluetooth Kit MULTI can be installed on the helmet in two different ways, depending on the type of helmet used: using pliers with screw closing or by gluing the support to the helmet. 3.1. Fixing with screw pliers Fig. -
Page 12: Fixing With Adhesive Support
N.B.: Do not tighten the screw excessively in order to avoid damage to the system components. Caution: In case the polystyrene support is damaged during the operation, contact your local dealer for its replacement. 3.2. Fixing with adhesive support In case it is not possible to use the pliers to secure the system to the helmet, you can use the adhesive support instead. - Page 13 Thoroughly clean the outer surface of the shell to ensure that the Adhesive Plate sticks properly. Before gluing, make sure the shell is dry and free from oil or dirt. Before you glue the Adhesive Plate to the helmet, determine the right spot where e-box MULTI...
-
Page 14: Positioning The Speakers
3.3. Positioning the speakers Fig. 6 Fig. 7 Remove the adhesive film from the Velcro (fig. 6). Position the speaker so that it sticks perfectly to the cheek pad(fig. 7). Carry out this operation on both sides. N.B.: If possible, position the speakers underneath the comfort padding of the helmet. -
Page 15: Applying The E-Box Multi
3.4. Applying the e-box MULTI Fig 8 Fig 9 Insert the e-box on the support until you hear the slider click. Connect the wiring connector to the e-box (Fig 9). To remove the e-box: take out the connector, move the slider to the side to release the stop and remove the e-box by sliding it along the tracks. -
Page 16: Basic Functions
In a cell phone has both profiles, the system automatically chooses which one to use. In order for the Bluetooth Kit MULTI system to work with a cell phone, the latter has to be first affiliated with the N-Com system. -
Page 17: Affiliation With A Bluetooth Telephone (Or Other Bluetooth Devices)
The N-Com system is recognized by the cell phone as a Bluetooth earpiece. Please refer to your cell phone manual, the section on affiliation of Bluetooth devices, in order to verify the affiliation procedure as it changes depending on the specific model used. -
Page 18: Affiliation Reset Function
1. The affiliation procedure can be repeated multiple times without the risk of damaging the system. 8. Turn off both the cell phone and the Bluetooth Kit MULTI system, then turn them both on again in order to save the affiliation data. -
Page 19: Cell Phone Functions
To carry out operations involving a cell phone, the same cell phone has to be affiliated beforehand and connected to the Bluetooth Kit MULTI. When the telephone is connected to Bluetooth Kit MULTI, the connection is shown on the cell phone display (symbols vary depending on the phone used, for examples earphones, auto, Bluetooth logo, etc.). -
Page 20: Bluetooth Interphone
2 seconds 6. BLUETOOTH INTERPHONE To use the N-Com Bluetooth Kit MULTI as a wireless interphone, both helmets, the pilot’s and the passenger’s, need to be fitted with the Bluetooth kit. The Bluetooth Kit MULTI system allows pilot-passenger wireless communication with all the N-Com Bluetooth systems. -
Page 21: Affiliating Two Bluetooth Kits
6.1. Affiliating two Bluetooth Kits 1. Put both Bluetooth kit MULti systems in affiliation mode (starting with the system turned off, press the “on” button and keep it pressed until both LEDs start to flash quickly). -
Page 22: Interphone Functions Via Bluetooth
You may turn the interphone connection on and off at any time by pressing the “on” button briefly on any one of the two helmets. N.B.: It may take a few seconds for the Bluetooth kit MULTI to find the other system, depending on the connections that may be already active and the Bluetooth devices already present. -
Page 23: Bluetooth Receiver (A2Dp Profile)
4 seconds. (Mute function) 7. BLUETOOTH RECEIVER (A2DP PROFILE) You can listen to high-quality music by connecting the Bluetooth kit MULTI via Bluetooth to a receiver equipped with Bluetooth A2DP (Advanced Audio Distribution Profile) protocol. 7.1. Affiliation with A2DP devices In order to affiliate a device equipped with Bluetooth A2DP protocol, proceed as for the affiliation of a cell phone (Chapter 5.1). - Page 24 If the A2DP receiver is not equipped with the AVRCP protocol, it may not be possible to restart music reproduction from the Bluetooth kit MULTI (although it is possible to stop it). In this case reproduction must be restarted manually on the receiver.
-
Page 25: Satellite Navigators
Mono (Multimedia Wire) and Stereo (Multimedia Wire2) type. The Bluetooth Kit MULTI is pre-set for Stereo type cables. In order to use a Mono cable, you have to connect this cable prior to turning on the system. -
Page 26: Connection To Other Audio Peripherals
Press the “ ” button for 2 seconds (beep). Please refer to the list of Multimedia Wire and Multimedia Wire2 cables and the possible connections on the website www.n-com.it 10. CONNECTION TO OTHER AUDIO PERIPHERALS Connect the 3.5 mm 4-pole ... -
Page 27: Summary Diagram Of Commands
11. SUMMARY DIAGRAM OF COMMANDS Button Pressure Brief >2s Brief >2s Brief Brief Turning on Turning off Raising the Volume Lowering the Volume Answering a call Vocal call Hanging up/Rejecting a call Cell phone connection (HFP) Calling last... -
Page 28: Switching Off The
Button Pressure Brief >2s Brief >2s Brief Brief Connecting the receiver Play music (Play) Pause function (Pause) Next track (Forward) Disconnect the receiver Switching off the audio peripheral (via cable) Switching on the audio peripheral (via cable) -
Page 29: Battery
12.2. Charging the battery Before using the N-Com device for the first time, recharge the battery completely for at least 10 hours. To obtain best performances from the battery, it is recommended to completely recharge the battery the first few times. -
Page 30: Battery Discharged Signal
12.3. Battery discharged signal When turned on, the system signals when the battery is running down by switching to the “Reserve” mode. When the battery charging power falls below 1 hour of operation, the buttons “” and “” start to flash in order to indicate that the system is in “Reserve”... -
Page 31: Exclusions And Limitations Of The Coverage
Negligence and normal wear of internal and external parts. Any damage caused by an accident; Any change or modification made to the helmet or to the N-com system by the user or by third parties. Color changes or damages caused by exposure to harmful chemical products. -
Page 32: Validity Of This Limited Warranty
Nolan® shall not be held responsible in any case for incidental or consequential damages (including, without any limitation whatsoever, damages to one or more persons) resulting from non-fulfillment of the obligations arising from this warranty as it pertains to Nolan® products. 13.3. -
Page 33: Product Identification
Legislative Decree 2 February 2002 n. 24. 13.5. Product identification N-Com products are identified by means of a code that allows product traceability and identification. The identification code is found underneath the bar code printed on the product packaging. - Page 34 N-com™ by accidental impacts; c) damage caused by the application of stickers and/or adhesives;...
- Page 35 Serial number (located on the rear side of the box, on the white sticker Fig.1) Name of the authorized dealer. Date of purchase of the N-Com TM Name, address and telephone number of the purchaser Fig.1 PROCEDURE TO BE FOLLOWED TO MAKE POSSIBLE CLAIMS To proceed with any claim covered by this warranty, the purchaser must notify directly Nolan’s...
- Page 36 Any service provided under the warranty does not have the effect of extending the warranty period itself. If any device or any of its components are replaced a new warranty period does not begin to run on the product or on individual components supplied by the way of replacement; the date of purchase of the original device remains the deciding factor.
-
Page 39: Warranty Registration Form
14. WARRANTY REGISTRATION FORM Product name: Bluetooth kit MULTI Identification code Buyer’s Information Name Last name Address Phone e-mail Dealer’s stamp Date of purchase... - Page 40 Bluetooth Kit MULTI - 01/06/2016 16:40:00 Printed on recycled paper.
