Operating Instructions
Pan/Tilt Operation
Pan/tilt scan buttons automatically move the
lens horizontally from -50 ° to +50 ° and
vertically from -40 ° to +10 ° and return the
lens to the original position. Each pan/tilt
arrow moves the lens Up, Down, Right or Left,
and the home position button moves it to the
home position.
Pan/Tilt Range
Note
Do not apply pressure to the pan/tilt portion of the camera. Any forced
movement can damage the internal mechanism.
16
Pan: -50 ˚ to +50 ˚
Tilt: -40 ˚ to +10 ˚
Pan/Tilt
Scan
Pan/Tilt
