Page 1: Operating Instructions
TCD715NLM(E)-1Preparation1 01.9.17 8:06 PM Page 1 Digital Cordless Phone KX-TCD715NLM Model No. Operating Instructions Caller ID Compatible PLEASE READ BEFORE USE AND SAVE. Charge the batteries for about 15 hours before initial use. -
Page 2: Before Initial Use
Dear purchaser, You have acquired a KX-TCD715NLM, which is a product made in regard with the European Standards for Cordless Telephones (DECT). DECT technology is characterized by high-security protection against interceptions as well as high-quality digital transmission. -
Page 3: For Best Performance
TCD715NLM(E)-1Preparation1 01.9.17 8:06 PM For Best Performance Battery Charge Rechargeable Nickel-Metal Hydride (Ni-MH) batteries power the handset. Install the batteries and charge them for about 15 hours before initial use (p. 10). Base Unit Location Calls are transmitted between the base unit and the handset using wireless radio waves. For maximum distance and noise-free operation, the recommended base unit location is: Away from electrical appliances such as a TV, radio, personal... -
Page 4: Table Of Contents
TCD715NLM(E)-1Preparation1 01.9.17 8:06 PM Contents Chapter 1 Preparation Location of Controls ...6 Display ...8 Settings ...9 Connections ...9 Installing the Batteries in the Handset ...10 Battery Charge ...10 Turning the Power ON...11 Summary of Programmable Functions ...12 Programmable Settings ...16 Setting the Display Language ...16 Selecting the Auto Talk Feature ...16 Setting the Date and Time ...17... - Page 5 TCD715NLM(E)-1Preparation1 01.9.17 8:06 PM Setting the Key Tones ...54 Selecting the Display Backlight Color ...54 Setting the PIN ...55 Clearing the Settings in Memory...56 Chapter 4 Multi-Unit User Operations For Optional Multi-Unit Users...58 Operating More than One Handset...58 Operating More than One Base Unit ...58 Registering Optional Handset(s) in the Base Unit...59...
-
Page 6: Location Of Controls
TCD715NLM(E)-1Preparation1 01.9.17 8:07 PM Location of Controls Base unit Charge Contacts (p. 11) MIC (Microphone) (p. 22) (Mute) Button and Indicator (p. 22) (Redial/Pause) Button (p. 22, 41) (Cancel) Button (p. 22) (Digital Speakerphone) Button and Indicator (p. 22) Page 6 (Recall) Button (p. - Page 7 TCD715NLM(E)-1Preparation1 01.9.17 8:07 PM Handset Back side Speaker (p. 19) Display (p. 8) (Phonebook) Button (p. 31, 35) Headset Jack (p. 68) (Talk)button (p. 19) (Speakerphone) Button (p. 19) Navigator Key Charge Contact (p. 11) (Recall) Button (p. 43 Page 7 Receiver (p.
-
Page 8: Display
TCD715NLM(E)-1Preparation1 01.9.17 8:07 PM Display A B C D E F G H I a b c d e f g 1234567890123456 Icons The in-range icon indicates that the handset is in range of the base unit. It flashes when the handset is out of range. -
Page 9: Settings
01.9.17 8:07 PM Settings Connections USE ONLY WITH Panasonic AC ADAPTOR PQLV1CE. The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) If your unit is connected to a PBX which does not support Caller ID services, you cannot access those services. -
Page 10: Installing The Batteries In The Handset
TCD715NLM(E)-1Preparation1 01.9.17 8:07 PM Settings Installing the Batteries in the Handset Install the batteries as shown. Then install the handset cover. If the rechargeable batteries are not inserted correctly, the handset will not work. Battery Charge At the time of shipment, the batteries are not charged. To charge, place the handset on the base unit. -
Page 11: Turning The Power On
TCD715NLM(E)-1Preparation1 01.9.17 8:07 PM Battery information After your Panasonic batteries are fully charged: Operation Ni-MH battery operating time (included) While in use (Talk) Up to about 20 hours While not in use (Standby) Up to about 200 hours Battery Operating time may be shortened depending on usage conditions, such as: —... -
Page 12: Summary Of Programmable Functions
TCD715NLM(E)-2Preparation2 01.9.17 8:09 PM Summary of Programmable Functions You can program the following function items using the handset near the base unit. The display shows the instructions. After selecting “ (p. 13). See the corresponding pages for function details. Make sure that the power is ON (p. 11) and the unit is in the standby mode. <Standby mode>... - Page 13 TCD715NLM(E)-2Preparation2 01.9.17 8:09 PM Command menu @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ h ? @ @ h ?
-
Page 14: Handset Settings
TCD715NLM(E)-2Preparation2 01.9.17 8:09 PM Summary of Programmable Functions Handset settings You can program the following function items using the handset near the base unit. The display shows the instructions. After selecting “Setting Handset”, the main menu is displayed. Most items in the main menu have a sub-menu. The sub-menu is shown after selecting the item in the main menu. -
Page 15: Handset Settings Menu
TCD715NLM(E)-2Preparation2 01.9.17 8:09 PM Handset menu settings @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ h ? @ @ h ? -
Page 16: Programmable Settings
TCD715NLM(E)-2Preparation2 01.9.17 8:10 PM Programmable Settings Selecting the Display Language You can choose one of 18 display languages. The factory preset is French. Make sure that the power is ON (p. 11) and the unit is in the standby mode. Press Press until the arrow points to... -
Page 17: Setting The Date And Time
TCD715NLM(E)-2Preparation2 01.9.17 8:10 PM Setting the Date and Time After setting the date and time, the current date and time will be displayed on the handset in the standby mode. You can set 24-hour clock by programming. Make sure that the power is ON (p. 11) and the unit is in the standby mode. Setting time Press Press... -
Page 18: Selecting The Handset Ringer Volume
TCD715NLM(E)-2Preparation2 01.9.17 8:10 PM Programmable Settings Selecting the Handset Ringer Volume 6 levels are available. The lowest level is 1. The highest level is 6. The factory preset is 3. When set to OFF, the handset will not ring. Press to select “Setting Handset”... -
Page 19: Making Calls
TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM Making Calls With the Handset Make sure that the power is ON (p. 11). Press “ ” is displayed. Dial a phone number. The dialed number is displayed. 12345678 After a few seconds, the display will show the length of the call. - Page 20 TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM Making Calls To select the receiver volume (HIGH, MEDIUM or LOW) or speaker volume (6 levels) while talking To increase, press To decrease, press Ex. Receiver volume: HIGH Speaker volume: level 6 R e c e i v e r V o l u m e 1 2 3 4 5 6 HIGH Each time you press...
- Page 21 TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM To store a redial number in the phonebook While the desired number is displayed, press , then see “To store an entered number in the phonebook”, from step 3. To clear a number in the redial memory While the desired number is displayed, press...
-
Page 22: With The Base Unit (Digital Speakerphone)
TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM Making Calls With the Base Unit (Digital Speakerphone) Press The indicator lights. Dial a telephone number. If you misdial, press again. When the other party answers, talk into the MIC. To hang up, press The indicator light goes out. The base unit speaker phone cannot be used while a handset is in use. -
Page 23: Answering Calls
TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM Answering Calls If you subscribe to a Caller ID service, the calling party information will be displayed after the first ring (p. 24). Please wait until the second ring to answer a call in order to view the Caller ID information. You can also program the desired external ringer type (p. -
Page 24: Caller Id Service
TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM Caller ID Service This unit is compatible with a Caller ID service offered by your telephone company. After subscribing to a Caller ID service, the calling party information will be displayed after the first ring. The unit can record information of up to 50 different callers in the Caller List. Using this list, you can automatically call back a caller. -
Page 25: Using The Caller List
TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM Using the Caller List Viewing the Caller List Information of up to 50 different callers is sorted from the most recent to the oldest call in the Caller List. When the 51st call is received, the first caller’s information is deleted. Each caller’s phone number received is shown. -
Page 26: Calling Back From The Caller List
TCD715NLM(E)-3Basic1* 01.9.17 8:11 PM Using the Caller List Calling Back from the Caller List Make sure that the power is ON (p. 11) and the unit is in the standby mode. Press until the desired caller number is displayed. Press The displayed phone number is dialed automatically. -
Page 27: Storing The Caller List Information In The Phonebook
TCD715NLM(E)-3Basic1* 01.9.17 8:12 PM Storing the Caller List Information in the Phonebook You can store phone numbers that are in the Caller List into the phonebook. You can also assign the caller information to one of 9 categories to use the private category feature (p. 34). Make sure that the power is ON (p. -
Page 28: Clearing The Caller List
TCD715NLM(E)-3Basic1* 01.9.17 8:12 PM Using the Caller List Clearing the Caller List You can clear some or all entries in the Caller List. Make sure that the power is ON (p. 11) and the unit is in the standby mode. To clear a specific entry from the Caller List Press... -
Page 29: Using The Phonebook
TCD715NLM(E)-4Basic2* 01.9.17 8:13 PM Using the Phonebook You can store up to 200 names and phone numbers in the phonebook. All phonebook items are sorted by the first word in alphabetical order. Using the phonebook, you can make a call by selecting a name on the display. -
Page 30: Storing Names And Numbers In The Phonebook
TCD715NLM(E)-4Basic2* 01.9.17 8:13 PM Using the Phonebook Storing Names and Numbers in the Phonebook After caller information is categorized in the phonebook, you can select the backlight color and ringer type for each private category (p. 34). Make sure that the power is ON (p. 11) and the unit is in the standby mode. Press Press until the arrow points... -
Page 31: If You Make A Mistake While Entering A Name
TCD715NLM(E)-4Basic2* 01.9.17 8:13 PM To enter names selecting characters The dialing buttons can be used to enter letters and character symbols. The letters are printed on the dialing buttons. Pressing each button selects a character as shown on page 32, 33. To change the character mode You can select one of 6 character modes by pressing The factory preset is “ABC”. -
Page 32: Character Mode Table
TCD715NLM(E)-4Basic2* 01.9.17 8:14 PM Using the Phonebook Character mode table ABC (Alphabet) Buttons # & ’ ( ) , – . / # & ’ ( ) , – . / A B C a b c D E F d e f G H I g h i... - Page 33 TCD715NLM(E)-4Basic2* 01.9.17 8:14 PM Character mode table Buttons SŚŠ (Extended 2) # & ’ ( ) , – . / # & ’ ( ) , – . / A Á Ä Ą B C Ć Č a á ä Ą b c Ć Č D Ď...
-
Page 34: Using The Private Category Feature
TCD715NLM(E)-4Basic2* 01.9.17 8:14 PM Using the Phonebook Using the Private Category Feature After subscribing to a Caller ID service, you can select the display backlight color and ringer type for each private category. When receiving a call, you can easily figure out who has called by setting backlight color and ringer type of each private category. -
Page 35: Finding Items In The Phonebook
TCD715NLM(E)-4Basic2* 01.9.17 8:14 PM Finding Items in the Phonebook Make sure that the power is ON (p. 11) and the unit is in the standby mode. Press to enter the phonebook. The first item is displayed. ANNE 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 Press until the desired name... -
Page 36: Editing An Item In The Phonebook
TCD715NLM(E)-4Basic2* 01.9.17 8:14 PM Using the Phonebook Editing an Item in the Phonebook Make sure that the power is ON (p. 11) and the unit is in the standby mode. Press to enter the phonebook. The first item is displayed. Press until the desired name is displayed, then press... -
Page 37: Hot Key Dial
TCD715NLM(E)-4Basic2* 01.9.17 8:14 PM Hot Key Dial The dialing buttons (1–9) function as one-touch dials. You can assign up to 9 phone numbers from the phonebook items into dialing buttons as hot key dials. Make sure that the power is ON (p. 11) and the unit is in the standby mode. Storing phonebook items as hot key dials Press... -
Page 38: Phonebook Copy
TCD715NLM(E)-4Basic2* 01.9.17 8:14 PM Using the Phonebook Phonebook Copy You can copy the information in the phonebook between the handsets registered in the same base unit. The phonebook copy must be operated in intercom mode (see page 39). Ex. Handset 2 is coping the phonebook to Handset 1 during an intercom call. To copy the specified item in the phonebook Handset 1 (Receiver):... -
Page 39: Intercom
TCD715NLM(E)-5Basic3* 01.9.17 8:15 PM Intercom A 2-way intercom is available between the handset and the base unit. Paging the base unit from the handset Handset: Press , then I N T “ ” is displayed and the base unit rings. To stop paging, press Base unit: Press... -
Page 40: Transferring A Call Using The Intercom
TCD715NLM(E)-5Basic3* 01.9.17 8:16 PM Intercom Trasferring a Call Using the Intercom The intercom can be used during a call. This feature enables you to transfer a call between the handset and the base unit. From the handset to the base unit Handset: During a call, press... -
Page 41: Special Features
TCD715NLM(E)-5Basic3* 01.9.17 8:16 PM Special Features How to Use the Pause Feature (For Analog PBX Line/Long Distance Service Users) We recommend you press distance service. Ex. Line access number (PBX) P h o n e n u m b e r Pressing creates a pause. -
Page 42: Setting The Key Lock
TCD715NLM(E)-5Basic3* 01.9.17 8:16 PM Special Features Setting the Key Lock You can lock the handset dialing buttons. Only incoming calls are accepted until the key lock is canceled. When the unit is in the standby mode, press and hold until a beep sounds. “... -
Page 43: Direct Call
TCD715NLM(E)-6Advance1 01.9.17 8:16 PM Direct Call You can easily make a call using a stored direct call number by pressing calls are accepted. To use this feature, store the direct call number and turn on the mode by programming. The factory preset is OFF. Setting the Direct Call Number and Mode After storing the direct call number, the unit will automatically switch to the direct call mode. -
Page 44: Call Prohibition
To turn OFF the call prohibition mode Press to select “OFF” in step 6. After returning to the standby mode, “ will go out. If you forget your handset PIN, please consult your nearest Panasonic Service Center. ” is displayed. ”... -
Page 45: Call Restriction
TCD715NLM(E)-6Advance1 01.9.17 8:16 PM Call Restriction You can restrict desired handset(s)/base unit from dialing selected phone numbers. Phone numbers beginning with the restricted digits cannot be dialed out. For example, if “00” is assigned as the call restriction number, international calls cannot be made. For selected handset(s)/base unit, you can assign up to 6 call restriction numbers (up to 8 digits). - Page 46 TCD715NLM(E)-6Advance1 01.9.17 8:16 PM When you dial a restricted number, the call is disconnected and the dialed number flashes. Ex. The restricted number is “00”. To cancel the call restricted handset(s) Follow steps 1 to 2 on page 45. Press Enter the 4-digit base unit PIN (p.
-
Page 47: Automatic Route Selection
TCD715NLM(E)-6Advance1 01.9.17 8:16 PM Automatic Route Selection Automatic Route Selection (ARS) is a feature which selects the least expensive carrier service when making long distance calls. Please contact your telephone company regarding the carrier telephone charges. After subscribing to a 2nd carrier service, store the 2nd carrier code. Then store the area codes (up to 25 codes) –... -
Page 48: Storing The Area Code(S)/ Carrier Code(S)
TCD715NLM(E)-6Advance1 01.9.17 8:16 PM Automatic Route Selection Storing the Carrier Code/Area Code(s) Make sure that the power is ON (p. 11) and the unit is in the standby mode. To store the carrier code Press Press until the arrow points to “Setting Base”, then press “Input Command”... -
Page 49: If You Use International Carrier Services
TCD715NLM(E)-6Advance1 01.9.17 8:16 PM If You Use International Carrier Services Automatic Route Selection (ARS) is also used for international calls. After subscribing to a second international carrier service, store the second international carrier code (see page 48). For certain countries, the second international carrier service costs more than the first carrier service. -
Page 50: Selecting The Talk Mode Display
TCD715NLM(E)-6Advance1 01.9.17 8:16 PM Selecting the Talk Mode Display You can choose whether to display the length of the call or the dialed telephone number while in the talk mode. The factory preset is the length of the call. Make sure that the power is ON (p. 11) and the unit is in the standby mode. Press Press until the arrow points... -
Page 51: Setting The Time Alarm
TCD715NLM(E)-6Advance1 01.9.17 8:17 PM Setting the Time Alarm The handset(s) will sound an alarm at a preset time for 30 seconds once or everday. You can also program the desired time alarm ringer type (p. 52). handset will sound longer (It depends on the ringer type). Confirm the current displayed time before setting time for alarm. -
Page 52: Other Programmable Settings
TCD715NLM(E)-7Advance2* 01.9.17 8:18 PM Other Programmable Settings Setting the Handset Ringer Type You can program the desired handset ringer type for external/internal calls and paging, time alarm. External ringer type (p. 23) You can select the external ringer type. 20 ringer types are available. The factory preset is type 1. Press to select “Setting Handset”... -
Page 53: Selecting The Base Unit Ringer Type
TCD715NLM(E)-7Advance2* 01.9.17 8:19 PM Selecting the Base Unit Ringer Type You can program the desired base unit rinter type (6 types). The factory preset is pattern 1. Press to select “Setting Base” then Ringer pattern (1–6) Setting the Call Waiting Tone If an incoming call has been received during an intercom between handsets, a call waiting tone sounds. -
Page 54: Setting The Key Tones
TCD715NLM(E)-7Advance2* 01.9.17 8:19 PM Other Programmable Settings Setting the Key Tones You can choose whether or not the handset keys will sound tones (key tone, confirmation tone, error tone). The factory preset is ON. On the handset Press to select “Setting Handset” then “Tone Option”... -
Page 55: Setting The Pin
Make sure that the power is ON (p. 11) and the unit is in the standby mode. Once you have programmed the PIN, you cannot confirm it. We recommend you write down the PIN. If you do forget it, please consult your nearest Panasonic Service Center. On the handset... -
Page 56: Clearing The Settings In Memory
TCD715NLM(E)-7Advance2* 01.9.17 8:19 PM Clearing the Settings in Memory On the handset This function enables the handset to clear the following settings at one time. They will return to their initial settings. Function Initial setting Time Alarm Clear Alarm ON/OFF Handset ringer volume MEDIUM External ringer type... -
Page 57: On The Base Unit
TCD715NLM(E)-7Advance2* 01.9.17 8:19 PM On the base unit This function enables the base unit to clear the following settings at one time. They will return to their initial settings. Function Initial setting Bell selection All handsets Bell interval (First ring) Flash timing 110 mic Pause timing... -
Page 58: For Optional Multi-Unit Users
The optional handset model number is KX-A115EX. The functions of the optional handset are the same as those of the KX-TCD715NLM handset. Operating More than One Base Unit You can register and operate your handset at up to 4 base units. -
Page 59: Registering Optional Handset(S) In The Base Unit
TCD715NLM(E)-8Multi 01.9.17 8:21 PM Registering Optional Handset(s) in the Base Unit You must register the handset in the base unit before use. Charge the optional handset batteries for about 15 hours before initial use. Make sure that the power is ON (p. 11) and the unit is in the standby mode. Register the handset number within 1 minute. -
Page 60: Selecting The Base Unit Access
TCD715NLM(E)-8Multi 01.9.17 8:21 PM For Optional Multi-Unit Users Selecting the Base Unit Access Automatic base unit access (Auto) The handset automatically selects a registered base unit. When the handset moves to another base unit radio area, it loses contact with the previous base unit and automatically accesses the new base unit. -
Page 61: Canceling A Handset
TCD715NLM(E)-8Multi 01.9.17 8:22 PM Canceling a Handset Each handset can cancel itself or another handset. Make sure that the power is ON (p. 11) and the unit is in the standby mode. Press Press until the arrow points to “Setting Base”, then press “Input Command”... -
Page 62: Bell Selection
TCD715NLM(E)-8Multi 01.9.17 8:22 PM For Optional Multi-Unit Users Bell Selection There are three choices for bell selection. When a call is being received: — all handsets ring. “All handsets” — the selected handset(s) ring(s). “Specified handset(s)” — the selected handset rings first, then if it does not answer, all other handsets will ring. “First handset”... -
Page 63: Selecting All Handsets
TCD715NLM(E)-8Multi 01.9.17 8:22 PM Selecting first handset One handset will ring first, then all other handsets will ring if the first handset is not answered. You can choose which handset will ring first and the ring count (1 to 6) until all of the handsets ring. -
Page 64: Selecting The Standby Mode Display
TCD715NLM(E)-8Multi 01.9.17 8:22 PM For Optional Multi-Unit Users Selecting the Standby Mode Display You can choose whether to display the currently connected base unit number, handset number or no display while in the standby mode. The factory preset is the base unit number. Make sure that the power is ON (p. -
Page 65: Paging/Intercom
TCD715NLM(E)-8Multi 01.9.17 8:22 PM Paging/Intercom Intercom between the Handset(s) and the Base Unit A 2-way intercom is available between one of the handsets and base unit when another handset is not having an outside call. The base unit user can page the handset users individually or at one time. Paging all the handsets from the base unit (All paging) The base unit user can talk with the handset... -
Page 66: Transferring A Call From The Base Unit To A Handset
TCD715NLM(E)-8Multi 01.9.17 8:22 PM Paging/Intercom Transferring a Call from the Base Unit to a Handset The intercom can be used during a call. This feature enables you to transfer a call between a handset and the base unit. Base unit: During a call, press the handset number you want to page, then press... -
Page 67: Transferring A Call From One Handset To Another
TCD715NLM(E)-8Multi 01.9.17 8:22 PM Transferring a Call from One Handset to Another The intercom can be used during a call, enabling you to transfer a call between handsets. Transferring a call using the intercom Ex. Handset 1 is transferring a call to Handset 2. -
Page 68: Conference
TCD715NLM(E)-8Multi 01.9.17 8:22 PM Paging/Intercom Conference During a call using the handset, you can make an intercom call to another handset and then combine the calls together to establish a conference call. Handset 1: During a call, press I N T the desired handset number. -
Page 69: Using A Belt Clip
Using an optional Headset Plugging an optional headset into the handset allows a hands-free phone conversation. Please use only the Panasonic KX-TCA89EX headset. Connecting the headset to the handset Open the headset jack cover, and connect the headset to the headset jack as shown. -
Page 70: Replacing The Batteries
If the rechargeable batteries are not inserted correctly, the handset will not work. Please return the rechargeable batteries to your sales shop at the end of their useful life. Nickel cadmium (Ni-Cd) rechargeable batteries (AA size) are available. Please use only Panasonic P6H batteries. - Page 71 TCD715NLM(E)-9Useful 01.9.17 8:43 PM Caution: To reduce the risk of fire or injury to persons, read and follow these instructions. 1. Use only the batteries specified. 2. Do not use non-rechargeable batteries. 3. Do not mix old and new batteries. 4.
-
Page 72: Wall Mounting
TCD715NLM(E)-9Useful 01.9.17 8:44 PM Wall Mounting This unit can be mounted on a wall. Connect the AC adaptor. Tuck the Telephone line cord inside the wall mounting adaptor, then push it in the direction of the arrow. The word “UP” should face upward. Install screws using the wall template below. -
Page 73: Option Covers
TCD715NLM(E)-9Useful 01.9.17 8:44 PM Option Covers You can change the look of your phone’s handset with option covers (KX-A109EX). 1. Turn the power OFF to prevent memory loss (p. 11). Remove the battery cover by sliding while pressing the arrow. Remove the batteries. 2. -
Page 74: Before Requesting Help
TCD715NLM(E)-9Useful 01.9.17 8:44 PM Before Requesting Help Problem The unit does not work. “ ” flashes and an alarm tone sounds when you press A busy tone sounds when you press You cannot dial. “ ” flashes during a conversation and the call is disconnected. - Page 75 TCD715NLM(E)-9Useful 01.9.17 8:44 PM Problem The handset does not ring. The base unit does not ring. You cannot program function items such as the setting the handset volume. You cannot store a name and phone number in the phonebook. While programming or searching, the unit starts to ring and stops the program/search.
- Page 76 TCD715NLM(E)-9Useful 01.9.17 8:44 PM Before Requesting Help Problem The paged handset does not answer. While using the intercom, two tones sound. The unit misdials when connected to a PBX. You cannot register the handset in the base unit. The battery strength is not displayed correctly.
-
Page 77: Safety Instructions
TCD715NLM(E)-9Useful 01.9.17 8:44 PM Safety Instructions Take special care to follow the safety suggestions listed below. Safety 1) The unit should be connected to a power supply only of the type described in the operating instructions or as marked on the unit. 2) When the unit is not used, turn the power off. -
Page 78: Term Definitions
TCD715NLM(E)-9Useful 01.9.17 8:44 PM Term Definitions DECT The abbreviation DECT means “Digital Enhanced Cordless Telecommunications”. Advantages of DECT Excellent voice quality: Through sampling of digital signals DECT units obtain nearly noiseless transmission. High grade taping security: Based on digital transmission, DECT conversations are well protected against unapproved monitoring. - Page 79 TCD715NLM(E)-9Useful 01.9.17 8:44 PM Page 79...
- Page 80 TCD715NLM(E)-9Useful 01.9.17 8:44 PM We, Kyushu Matsushita Electric Co., Ltd. of Matsushita Electric Industrial Co., Ltd./Panasonic Testing Centre (Europe) GmbH, declare that this equipment is in conpalisnce wiht the essantial requirements and other relevant provisions of Directive 1995/5/EC. If you want to get a copy of the original Declaration of Conformity of our products which relates to the R&TTE, please contact to our web address:...
