PART LIST—Model No. WEEVSY29530
Key No.
Qty.
Description
1
1
Stabiliser
2
1
Base
3
1
Base Support Plate
4
1
Front Upright
5
1
Rear Upright
6
1
Punching Bag Arm
7
1
Speed Bag Arm
8
2
Large Support Plate
9
2
Weight Guide
10
1
Top Frame
11
1
Left Arm
12
1
Right Arm
13
1
Press Frame
14
2
Press Arm
15
1
Seat Frame
16
1
Leg Lever
17
2
Pad Tube
18
4
Short Foam Pad
19
1
Seat Plate
20
1
Seat
21
1
Backrest
22
9
Weight
23
1
Weight Pin
24
1
Top Weight
25
1
Small "U"-bracket
26
1
Weight Tube
27
1
Weight Tube Bumper
28
2
Weight Bumper
29
1
Lock
30
1
Locking Bar
31
1
Speed Bag
32
1
Speed Bag Hook
33
1
Speed Bag Board
34
1
Lat Bar
35
4
Handgrip
36
1
Nylon Strap
37
1
Chain
38
5
Cable Clip
39
2
Base Cap
40
2
25mm x 22mm Plastic Bushing
41
1
Long Cable
42
1
Short Cable
43
3
Long Cable Trap
44
12
Pulley Cover
45
8
90mm Pulley
46
3
"V"-pulley
47
2
29mm x 32mm Plastic Bushing
48
4
25mm Retainer
49
2
25mm Round Cover Cap
50
1
Long "U"-bracket
51
1
Pulley Bracket
Note: "#" indicates a non-illustrated part. Specifications are subject to change without notice.
R1203A
Key No.
Qty.
Description
52
4
40mm x 50mm Inner Cap
53
1
25mm Square Inner Cap
54
4
19mm Round Inner Cap
55
3
50mm Square Inner Cap
56
6
45mm Square Inner Cap
57
2
38mm Square Inner Cap
58
4
M4 x 20mm Screw
59
2
Round Inner Cap
60
1
Seat Knob
61
2
25mm Round Inner Cap
62
2
Long Foam Pad
63
2
M10 x 99mm Bolt
64
2
M10 x 98mm Eyebolt
65
2
M8 x 63mm Carriage Bolt
66
1
M8 x 68mm Carriage Bolt
67
2
M6 x 16mm Screw
68
1
M6 x 50mm Carriage Bolt
69
4
M4 Washer
70
2
M10 x 89mm Bolt
71
2
M10 x 198mm Bolt
72
2
M6 x 63mm Screw
73
2
M8 x 68mm Bolt
74
1
Bungee Cord
75
1
M8 x 45mm Bolt
76
1
M6 x 50mm Screw
77
1
M8 x 59mm Bolt
78
1
M8 x 117mm Bolt
79
3
M10 x 58mm Bolt
80
4
M8 x 63mm Bolt
81
6
M6 Washer
82
5
M6 Nylon Locknut
83
16
M8 Nylon Locknut
84
25
M10 Nylon Locknut
85
2
M8 Washer
86
7
M10 Washer
87
2
M6 x 70mm Bolt
88
2
M6 x 30mm Bolt
89
4
M10 x 30mm Button Bolt
90
2
M10 x 150mm Bolt
91
1
M10 x 155mm Bolt
92
4
M10 x 75mm Bolt
93
2
Small Support Plate
94
3
M10 x 53mm Bolt
95
2
Plastic Cover
96
1
Punching Bag
97
2
M8 x 65mm Carriage Bolt
#
1
User's Manual
#
1
Exercise Guide
#
1
Grease Packet
#
1
6mm Hex Key
REMOVE THIS PART LIST/EXPLODED
DRAWING FROM THE MANUAL
SAVE THIS PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE
