Repeatedly press button 1 until
desired heating stage 2 ap-
pears on the display.
z
The handlebar grips have two-
stage heating.
50% heating power
100% heating power
Stage 2 is for heating the grips
quickly: it is advisable to switch
back to stage 1 as soon as the
grips are warm.
The selected heating stage will
be saved if you allow a certain
length of time to pass without
making further changes.
In order to switch off the
heated handlebar grips,
repeatedly press button 1 until
the heated handlebar grip
symbol 2 is no longer shown
on the display.
Mirrors
Adjusting mirrors
Turn the mirror to the correct
position.
Adjusting mirror arm
Push protective cap 1 up over
the threaded fastener on the
mirror arm.
Slacken nut 2.
Turn the mirror arm to the ap-
propriate position.
Tighten the nut to the spe-
cified tightening torque, while
holding the mirror arm to en-
sure that it does not move out
of position.
Mirror (lock nut) to ad-
apter
22 Nm
